DependencyMap Class Reference

Collect information about the dependencies between modules. More...

#include <DependencyMap.h>

Collaboration diagram for DependencyMap:

Classes
struct	ModuleInfo
	Stores information on inputs/outputs of a module, as obtained by requireInput()/optionalInput()/registerEntry();. More...

Public Types
enum	EEntryType {   c_Input ,   c_OptionalInput ,   c_Output ,   c_NEntryTypes }
	Possible types of entries/relations for a module. More...

Public Member Functions
bool	isUsedAs (const std::string &branchName, EEntryType type) const
	Is the object/array/relation with given name used as specified input/output type (in any module)? More...
void	setModule (const Module &mod)
	Set the current module (for getCurrentModuleInfo())
ModuleInfo &	getCurrentModuleInfo ()
	Get info for current module.
const std::map< std::string, ModuleInfo > &	getModuleInfoMap () const
	return information on inputs/outputs of each module, as obtained by requireInput()/optionalInput()/registerEntry();
void	clear ()
	Reset all collected data.

Static Public Member Functions
static std::string	getModuleID (const Module &mod)
	Return unique ID for given module.

Private Attributes
std::map< std::string, ModuleInfo >	m_moduleInfo
	Stores information on inputs/outputs of each module, as obtained by requireInput()/optionalInput()/registerEntry();.
std::string	m_currentModule
	Stores the current module, used to fill m_moduleInfo.

Detailed Description

Collect information about the dependencies between modules.

Filled inside DataStore during register/require/optional, and used by the –visualize-dataflow and –module-io arguments to basf2 to create graphs of data dependencies.

See also

DataFlowVisualization

Definition at line 29 of file DependencyMap.h.

Member Enumeration Documentation

EEntryType

enum EEntryType

Possible types of entries/relations for a module.

Enumerator
c_Input	required input.
c_OptionalInput	optional input.
c_Output	registered output.
c_NEntryTypes	size of this enum.

Definition at line 32 of file DependencyMap.h.

                    {
      c_Input,
      c_OptionalInput,
      c_Output,
      c_NEntryTypes
    };

Member Function Documentation

isUsedAs()

bool isUsedAs	(	const std::string &	branchName,
		EEntryType	type
	)		const

Is the object/array/relation with given name used as specified input/output type (in any module)?

E.g. is('EventMetaData', c_Output) asks if EventMetaData was registered, is('EventMetaData', c_Input) asks if any module has it as required input.

Definition at line 29 of file DependencyMap.cc.

{
  return any_of(m_moduleInfo.begin(), m_moduleInfo.end(),
  [branchName, type](const pair<string, ModuleInfo>& info) {
    if (info.second.entries[type].count(branchName))
      return true;
    return (bool)info.second.relations[type].count(branchName);
  });
}

---

The documentation for this class was generated from the following files:

• framework/datastore/include/DependencyMap.h
• framework/datastore/src/DependencyMap.cc
