provides the core event processing loop. More...

#include <EventProcessor.h>

Inheritance diagram for EventProcessor:

[legend]

Collaboration diagram for EventProcessor:

[legend]

Classes
class	StoppedBySignalException
	Exception thrown when execution is stopped by a signal. More...

Public Member Functions
	EventProcessor ()
	Constructor.

virtual	~EventProcessor ()
	Destructor.

void	process (const PathPtr &startPath, long maxEvent=0)
	Processes the full module chain, starting with the first module in the given path. More...

void	setProfileModuleName (const std::string &name)
	Set the name of the module we want to profile. More...

Static Public Member Functions
static void	writeToStdErr (const char msg[])
	async-safe method to write something to STDERR.

static void	installSignalHandler (int sig, void(*fn)(int))
	Install a signal handler 'fn' for given signal.

static void	installMainSignalHandlers (void(*fn)(int)=nullptr)
	Install signal handler for INT, TERM and QUIT signals. More...

Protected Member Functions
void	processInitialize (const ModulePtrList &modulePathList, bool setEventInfo=true)
	Initializes the modules. More...

void	processCore (const PathPtr &startPath, const ModulePtrList &modulePathList, long maxEvent=0, bool isInputProcess=true)
	Processes the full module chain consisting of an arbitrary number of connected paths, starting with the first module in the specified path. More...

bool	processEvent (PathIterator moduleIter, bool skipMasterModule)
	Calls event() functions on all modules for the current event. More...

void	callEvent (Module *module)
	Calls event() on one single module, setting up logging and statistics as needed. More...

void	processTerminate (const ModulePtrList &modulePathList)
	Terminates the modules. More...

void	processBeginRun (bool skipDB=false)
	Calls the begin run methods of all modules. More...

void	processEndRun ()
	Calls the end run methods of all modules. More...

long	getMaximumEventNumber (long maxEvent) const
	Calculate the maximum event number out of the argument from command line and the environment.

Protected Attributes
const Module *	m_master
	The master module that determines the experiment/run/event number.

ModulePtrList	m_moduleList
	List of all modules in order initialized.

std::string	m_profileModuleName
	Name of the module which should be profiled, empty if no profiling is requested.

Module *	m_profileModule = nullptr
	Adress of the module which we want to profile, nullptr if no profiling is requested.

StoreObjPtr< EventMetaData >	m_eventMetaDataPtr
	EventMetaData is used by processEvent()/processCore().

EventMetaData	m_previousEventMetaData
	Stores state of EventMetaData before it was last changed. More...

StoreObjPtr< ProcessStatistics >	m_processStatisticsPtr
	Also used in a number of places.

bool	m_inRun
	Are we currently in a run? If yes, processEndRun() needs to do something.

double	m_lastMetadataUpdate
	Time in seconds of last call for metadata update in event loop.

double	m_metadataUpdateInterval
	Minimal time difference in seconds for metadata updates in event loop.

bool	m_steerRootInputModuleOn = false
	True if the SteerRootInputModule is in charge for event processing.

Detailed Description

provides the core event processing loop.

Definition at line 29 of file EventProcessor.h.

Member Function Documentation

◆ callEvent()

void callEvent ( Module * module )

protected

Calls event() on one single module, setting up logging and statistics as needed.

Parameters

module Module to call the event() function

Definition at line 226 of file EventProcessor.cc.

 {
   LogSystem& logSystem = LogSystem::Instance();
   const bool collectStats = !Environment::Instance().getNoStats();
   // set up logging
   logSystem.updateModule(&(module->getLogConfig()), module->getName());
   // set up statistics is requested
   if (collectStats) m_processStatisticsPtr->startModule();
   // call module
   CALL_MODULE(module, event);
   // stop timing
   if (collectStats) m_processStatisticsPtr->stopModule(module, ModuleStatistics::c_Event);
   // reset logging
   logSystem.updateModule(nullptr);
 };

◆ installMainSignalHandlers()

void installMainSignalHandlers ( void(*)(int) fn = nullptr )

static

Install signal handler for INT, TERM and QUIT signals.

If argument is NULL, EventProcessor's own signal handler will be installed.

Definition at line 312 of file EventProcessor.cc.

◆ process()

void process	(	const PathPtr &	startPath,
		long	maxEvent = `0`
	)

Processes the full module chain, starting with the first module in the given path.

Processes all events for the given run number and for events from 0 to maxEvent. If maxEvent is smaller or equal 0 the maximum number check is disabled and all events are processed. If runNumber is smaller than 0, the run number has to be set externally by a module and not the given number is used.

Parameters

startPath	The processing starts with the first module of this path.
maxEvent	Optional: The maximum number of events that will be processed. If the number is smaller or equal 0, all events will be processed.

Definition at line 123 of file EventProcessor.cc.

◆ processBeginRun()

void processBeginRun ( bool skipDB = false )

protected

Calls the begin run methods of all modules.

Loops over all module instances specified in a list and calls their beginRun() method. Please note: the beginRun() method of the module which triggered the beginRun() loop will also be called.

Definition at line 467 of file EventProcessor.cc.

◆ processCore()

void processCore	(	const PathPtr &	startPath,
		const ModulePtrList &	modulePathList,
		long	maxEvent = `0`,
		bool	isInputProcess = `true`
	)

protected

Processes the full module chain consisting of an arbitrary number of connected paths, starting with the first module in the specified path.

Parameters

startPath	The processing starts with the first module of this path.
modulePathList	A list of all modules which could be executed during the data processing (used for calling the beginRun() and endRun() method).
maxEvent	The maximum number of events that will be processed. If the number is smaller or equal 0, all events are processed.
isInputProcess	true when this is either the only or the input process

Definition at line 406 of file EventProcessor.cc.

◆ processEndRun()

void processEndRun ( )

protected

Calls the end run methods of all modules.

Loops over all module instances specified in a list and calls their endRun() method. Please note: the endRun() method of the module which triggered the endRun() loop will also be called.

Definition at line 501 of file EventProcessor.cc.

◆ processEvent()

bool processEvent	(	PathIterator	moduleIter,
		bool	skipMasterModule
	)

protected

Calls event() functions on all modules for the current event.

Used by processCore.

Parameters

moduleIter	iterator of the path containing all the modules
skipMasterModule	skip the execution of the master module, presumably because this is the first event and it's already been done in initialize()

Returns: true if execution should stop.

Definition at line 321 of file EventProcessor.cc.

◆ processInitialize()

void processInitialize	(	const ModulePtrList &	modulePathList,
		bool	setEventInfo = `true`
	)

protected

Initializes the modules.

Loops over all module instances specified in a list and calls their initialize() method.

Parameters

modulePathList	A list of all modules which could be executed during the data processing.
setEventInfo	if true the first event call of the master module will be called immidiately to load the event info right away so that it's available for subsequent modules

Definition at line 242 of file EventProcessor.cc.

◆ processTerminate()

void processTerminate ( const ModulePtrList & modulePathList )

protected

Terminates the modules.

Loops over all module instances in reverse order specified in a list and calls their terminate() method.

Parameters

modulePathList A list of all modules which could be executed during the data processing.

Definition at line 440 of file EventProcessor.cc.

◆ setProfileModuleName()

void setProfileModuleName ( const std::string & name )

inline

Set the name of the module we want to profile.

Parameters

name	Name of the module as returned by getName()

Definition at line 57 of file EventProcessor.h.

57 { m_profileModuleName = name; }

Belle2::EventProcessor::m_profileModuleName

std::string m_profileModuleName

Name of the module which should be profiled, empty if no profiling is requested.

Definition: EventProcessor.h:157

Member Data Documentation

◆ m_previousEventMetaData

EventMetaData m_previousEventMetaData

protected

Stores state of EventMetaData before it was last changed.

Useful since processEndRun() needs info about which run it needs to end.

Definition at line 166 of file EventProcessor.h.

The documentation for this class was generated from the following files:

framework/core/include/EventProcessor.h
framework/core/src/EventProcessor.cc
