Base class for StoreObjPtr and StoreArray for easier common treatment. More...

#include <StoreAccessorBase.h>

Inheritance diagram for StoreAccessorBase:

[legend]

Collaboration diagram for StoreAccessorBase:

Public Member Functions
	StoreAccessorBase (const std::string &name, DataStore::EDurability durability, TClass *objClass, bool isArray)
	Constructor to access an object or array in the DataStore. More...

virtual	~StoreAccessorBase ()
	Destructor. More...

bool	registerInDataStore (DataStore::EStoreFlags storeFlags=DataStore::c_WriteOut)
	Register the object/array in the DataStore. More...

bool	registerInDataStore (const std::string &name, DataStore::EStoreFlags storeFlags=DataStore::c_WriteOut)
	Register the object/array in the DataStore. More...

bool	isRequired (const std::string &name="")
	Ensure this array/object has been registered previously. More...

bool	isOptional (const std::string &name="")
	Tell the DataStore about an optional input. More...

bool	create (bool replace=false)
	Create a default object in the data store. More...

bool	assign (TObject *object, bool replace=false)
	Assign 'object' to this accessor. More...

virtual void	clear ()
	Clear contents of this object.

const std::string &	getName () const
	Return name under which the object is saved in the DataStore.

DataStore::EDurability	getDurability () const
	Return durability with which the object is saved in the DataStore.

AccessorParams	getAccessorParams () const
	Return pair of name and durability under which stored object is saved. More...

virtual bool	operator== (const StoreAccessorBase &other) const
	Check if two store accessors point to the same object/array.

virtual bool	operator!= (const StoreAccessorBase &other) const
	Check if two store accessors point to a different object/array.

TClass *	getClass () const
	The underlying object's type.

bool	isArray () const
	Is this an accessor for an array?

bool	notWrittenOut () const
	Returns true if this object/array should not be saved by output modules. More...

std::string	readableName () const
	Convert this acessor into a readable string (for messages). More...

Protected Attributes
std::string	m_name
	Store name under which this object/array is saved.

DataStore::EDurability	m_durability
	Store durability under which the object/array is saved.

TClass *	m_class
	The underlying object's type.

bool	m_isArray
	Is this an accessor for an array?

Detailed Description

Base class for StoreObjPtr and StoreArray for easier common treatment.

Definition at line 27 of file StoreAccessorBase.h.

Constructor & Destructor Documentation

◆ StoreAccessorBase()

StoreAccessorBase	(	const std::string &	name,
		DataStore::EDurability	durability,
		TClass *	objClass,
		bool	isArray
	)

inline

Constructor to access an object or array in the DataStore.

Parameters

name	Name under which the object is stored in the DataStore.
durability	Decides durability map used for getting the accessed object.
objClass	Type of the object
isArray	true if the entry in the DataStore is an array

Definition at line 37 of file StoreAccessorBase.h.

◆ ~StoreAccessorBase()

virtual ~StoreAccessorBase ( )

inlinevirtual

Destructor.

Virtual because this is a base class.

Definition at line 44 of file StoreAccessorBase.h.

Member Function Documentation

◆ assign()

bool assign	(	TObject *	object,
		bool	replace = `false`
	)

Assign 'object' to this accessor.

(takes ownership).

Parameters

object	The object that should be put in the DataStore, should be of same type as the one used by this accessor.
replace	Should an existing object be replaced? (if existing and supplied object are equal, this has no effect)

Returns: True if the assignment succeeded. If false, assign() will delete 'object', do not use it afterwards.

Definition at line 33 of file StoreAccessorBase.cc.

◆ create()

bool create ( bool replace = false )

inline

Create a default object in the data store.

This only works after registerInDataStore() has been called by this or another module.

Parameters

replace Should an existing object be replaced?

Returns: True if the creation succeeded.

Definition at line 107 of file StoreAccessorBase.h.

◆ getAccessorParams()

AccessorParams getAccessorParams ( ) const

inline

Return pair of name and durability under which stored object is saved.

Definition at line 134 of file StoreAccessorBase.h.

◆ isOptional()

bool isOptional ( const std::string & name = "" )

inline

Tell the DataStore about an optional input.

Mainly useful for creating diagrams of module inputs and outputs.

Parameters

name	If not empty, set non-default name for this object/array. This is permanent, so that e.g. after using registerInDataStore("myName") in initialize(), this object will continue refer to 'myName' in event().

Returns: True if the object/array exists.

Definition at line 93 of file StoreAccessorBase.h.

◆ isRequired()

bool isRequired ( const std::string & name = "" )

inline

Ensure this array/object has been registered previously.

Will cause an ERROR if it does not exist. This must be called in the initialization phase.

Parameters

name	If not empty, set non-default name for this object/array. This is permanent, so that e.g. after using registerInDataStore("myName") in initialize(), this object will continue refer to 'myName' in event().

Returns: True if the object/array exists.

Definition at line 78 of file StoreAccessorBase.h.

◆ notWrittenOut()

bool notWrittenOut ( ) const

Returns true if this object/array should not be saved by output modules.

See DataStore::c_DontWriteOut. Can be changed by re-registering it with/without the flag.

Definition at line 53 of file StoreAccessorBase.cc.

◆ readableName()

std::string readableName ( ) const

Convert this acessor into a readable string (for messages).

e.g. "object EventMetaData (durability: event)"

Definition at line 18 of file StoreAccessorBase.cc.

◆ registerInDataStore() [1/2]

bool registerInDataStore	(	const std::string &	name,
		DataStore::EStoreFlags	storeFlags = `DataStore::c_WriteOut`
	)

inline

Register the object/array in the DataStore.

This must be called in the initialization phase.

Parameters

name	If not empty, set non-default name for this object/array. This is permanent, so that e.g. after using registerInDataStore("myName") in initialize(), this object will continue refer to 'myName' in event().
storeFlags	ORed combination of DataStore::EStoreFlags.

Returns: True if the registration succeeded.

Definition at line 64 of file StoreAccessorBase.h.

◆ registerInDataStore() [2/2]

bool registerInDataStore ( DataStore::EStoreFlags storeFlags = DataStore::c_WriteOut )

inline

Register the object/array in the DataStore.

This must be called in the initialization phase.

Parameters

storeFlags ORed combination of DataStore::EStoreFlags.

Returns: True if the registration succeeded.

Definition at line 52 of file StoreAccessorBase.h.

The documentation for this class was generated from the following files:

framework/datastore/include/StoreAccessorBase.h
framework/datastore/src/StoreAccessorBase.cc
