ZMQConnection Class Reference

Base class for every connection with virtual functions to be implemented: More...

#include <ZMQConnection.h>

Inheritance diagram for ZMQConnection:

Collaboration diagram for ZMQConnection:

Public Types
using	ReactorFunction = std::function< void(void)>
	Typedef of a function which will be called if a connection has a message.

Public Member Functions
virtual	~ZMQConnection ()=default
	Virtual default destructor.
virtual bool	isReady () const
	Return true of this connection is able to send messages right now. Can be overloaded in derived classes.
virtual std::vector< zmq::socket_t * >	getSockets () const =0
	Return the list of sockets which should be polled on to check for incoming messages. Can be empty. Must be overloaded in derived classes.
virtual std::string	getMonitoringJSON () const
	Convert the stored monitoring values to a JSON string ready for sending out via a message.
template<class AClass >
void	log (const std::string &key, const AClass &value)
	Store a value under a certain key. Different types of values can be stored, namely long, double or string. Mixtures are not allowed for a given key.
void	increment (const std::string &key)
	Increment the value with the given key (only numerical values). If not present, set to 1.
void	decrement (const std::string &key)
	Decrement the value with the given key (only numerical values). If not present, set to -1.
template<size_t MAX_SIZE = 100>
void	average (const std::string &key, double value)
	Instead of storeing the double value directly under the given key, store the average of the last MAX_SIZE values.
template<size_t AVERAGE_SIZE = 2000>
void	timeit (const std::string &key)
	Measure the rate of calls with the same key every AVERAGE_SIZE calls (and also display the last time AVERAGE_SIZE was reached under <key>_last_measurement)
void	logTime (const std::string &key)
	Store the current time as a string under the given key.

Static Public Member Functions
static bool	poll (const std::map< const ZMQConnection *, ReactorFunction > &connectionList, int timeout)
	Poll on the given connections and call the attached function if a messages comes in. More...
static bool	hasMessage (const ZMQConnection *connection)
	Check if the given connection as an incoming message (right now, no waiting).

Private Attributes
std::map< std::string, std::variant< long, double, std::string > >	m_monitoring
	Internal storage of all stored values.
std::unordered_map< std::string, std::tuple< std::vector< double >, size_t > >	m_averages
	Internal storage of the previous values when calculating averages.
std::unordered_map< std::string, std::tuple< unsigned long, std::chrono::system_clock::time_point > >	m_timeCounters
	Internal storage how often the timeit function for a given key was called and when it has last reached MAX_SIZE.

Detailed Description

Base class for every connection with virtual functions to be implemented:

• isReady(): return True if this connection can send events
• getSockets(): return the list of sockets to be used while polling for incoming messages (can be empty)

Additionally, it has static functions for polling on a list of connections or checking if a specific connection has messages.

Definition at line 30 of file ZMQConnection.h.

Member Function Documentation

poll()

bool poll ( const std::map< const ZMQConnection *, ReactorFunction > &  connectionList, int  timeout  )

static

Poll on the given connections and call the attached function if a messages comes in.

If after timeout milliseconds still no message is received, return anyways. If timeout is 0, do not wait. If timeout is -1, wait infinitely.

Returns true if a message was received on any socket, false otherwise. Attention: in case of an interrupted system call (e.g. because a signal was received) the function might return anyways with a negative result even before the timeout!

Definition at line 27 of file ZMQConnection.cc.

---

The documentation for this class was generated from the following files:

• framework/pcore/zmq/connections/include/ZMQConnection.h
• framework/pcore/zmq/connections/src/ZMQConnection.cc
