constainer More...

Collaboration diagram for ConstraintConfiguration:

[legend]

Public Member Functions
	ConstraintConfiguration ()
	constructor

	ConstraintConfiguration (const bool &massConstraintType, const std::vector< int > &massConstraintListPDG, const std::vector< int > &fixedToMotherVertexListPDG, const std::vector< int > &geoConstraintListPDG, const std::vector< std::string > &removeConstraintList, const bool &automatic_vertex_constraining, const bool &ipConstraint, const bool &customOrigin, const std::vector< double > &customOriginVertex, const std::vector< double > &customOriginCovariance, const int &originDimension, const int &beamConstraintPDG, const Eigen::Matrix< double, 4, 1 > &beamMomE, const Eigen::Matrix< double, 4, 4 > &beamCovariance, const int &inflationFactorCovZ=1)
	constructor

Public Attributes
const bool	m_massConstraintType
	const flag for the type of the mass constraint

const std::vector< int >	m_massConstraintListPDG
	list of pdg codes to mass constrain

const std::vector< int >	m_fixedToMotherVertexListPDG
	list of pdg codes to mass constrain

const std::vector< int >	m_geoConstraintListPDG
	list of pdg codes to mass constrain

const std::vector< std::string >	m_removeConstraintList
	list of constraints not to apply in tree fit

const bool	m_automatic_vertex_constraining
	automatically determining if it is worth extracting a vertex for this particle or if it should be joined with the mother

const bool	m_ipConstraint
	is IP constraint

const bool	m_customOrigin
	is custom origin

const std::vector< double >	m_customOriginVertex
	x,y,z of custom origin as vector len 3

const std::vector< double >	m_customOriginCovariance
	covariance matrix of origin as row major vector len = 9

const int	m_originDimension
	dimension of the origin constraint and ALL geometric gcosntraints

int	m_headOfTreePDG
	PDG code of the head particle.

const int	m_beamConstraintPDG
	PDG code to beam constraint.

Eigen::Matrix< double, 4, 1 >	m_beamMomE
	Beam four-momentum.

Eigen::Matrix< double, 4, 4 >	m_beamCovariance
	Beam Covariance.

const int	m_inflationFactorCovZ
	inflate covariance of z by this number -> iptube

Detailed Description

constainer

Definition at line 16 of file ConstraintConfiguration.h.

The documentation for this class was generated from the following file:
