Module to read TTree data from file into the data store. More...

#include <RootInputModule.h>

Inheritance diagram for RootInputModule:

Collaboration diagram for RootInputModule:

[legend]

Classes
struct	ReadStats
	for collecting statistics over multiple files. More...

Public Types
enum	EModulePropFlags { c_Input = 1 , c_Output = 2 , c_ParallelProcessingCertified = 4 , c_HistogramManager = 8 , c_InternalSerializer = 16 , c_TerminateInAllProcesses = 32 , c_DontCollectStatistics = 64 }
	Each module can be tagged with property flags, which indicate certain features of the module. More...

typedef ModuleCondition::EAfterConditionPath	EAfterConditionPath
	Forward the EAfterConditionPath definition from the ModuleCondition.

Public Member Functions
	RootInputModule ()
	Constructor.

virtual	~RootInputModule ()
	Destructor.

virtual void	initialize () override
	Initialize the Module.

virtual void	event () override
	Running over all events.

virtual void	terminate () override
	Is called at the end of your Module.

virtual std::vector< std::string >	getFileNames (bool outputFiles=false) override
	Get list of input files, taking -i command line overrides into account.

virtual void	beginRun ()
	Called when entering a new run. More...

virtual void	endRun ()
	This method is called if the current run ends. More...

const std::string &	getName () const
	Returns the name of the module. More...

const std::string &	getType () const
	Returns the type of the module (i.e. More...

const std::string &	getPackage () const
	Returns the package this module is in.

const std::string &	getDescription () const
	Returns the description of the module.

void	setName (const std::string &name)
	Set the name of the module. More...

void	setPropertyFlags (unsigned int propertyFlags)
	Sets the flags for the module properties. More...

LogConfig &	getLogConfig ()
	Returns the log system configuration.

void	setLogConfig (const LogConfig &logConfig)
	Set the log system configuration.

void	setLogLevel (int logLevel)
	Configure the log level.

void	setDebugLevel (int debugLevel)
	Configure the debug messaging level.

void	setAbortLevel (int abortLevel)
	Configure the abort log level.

void	setLogInfo (int logLevel, unsigned int logInfo)
	Configure the printed log information for the given level. More...

void	if_value (const std::string &expression, const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	Add a condition to the module. More...

void	if_false (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	A simplified version to add a condition to the module. More...

void	if_true (const std::shared_ptr< Path > &path, EAfterConditionPath afterConditionPath=EAfterConditionPath::c_End)
	A simplified version to set the condition of the module. More...

bool	hasCondition () const
	Returns true if at least one condition was set for the module.

const ModuleCondition *	getCondition () const
	Return a pointer to the first condition (or nullptr, if none was set)

const std::vector< ModuleCondition > &	getAllConditions () const
	Return all set conditions for this module.

bool	evalCondition () const
	If at least one condition was set, it is evaluated and true returned if at least one condition returns true. More...

std::shared_ptr< Path >	getConditionPath () const
	Returns the path of the last true condition (if there is at least one, else reaturn a null pointer). More...

Module::EAfterConditionPath	getAfterConditionPath () const
	What to do after the conditional path is finished. More...

std::vector< std::shared_ptr< Path > >	getAllConditionPaths () const
	Return all condition paths currently set (no matter if the condition is true or not).

bool	hasProperties (unsigned int propertyFlags) const
	Returns true if all specified property flags are available in this module. More...

bool	hasUnsetForcedParams () const
	Returns true and prints error message if the module has unset parameters which the user has to set in the steering file.

const ModuleParamList &	getParamList () const
	Return module param list.

template<typename T >
ModuleParam< T > &	getParam (const std::string &name) const
	Returns a reference to a parameter. More...

bool	hasReturnValue () const
	Return true if this module has a valid return value set.

int	getReturnValue () const
	Return the return value set by this module. More...

std::shared_ptr< PathElement >	clone () const override
	Create an independent copy of this module. More...

std::shared_ptr< boost::python::list >	getParamInfoListPython () const
	Returns a python list of all parameters. More...

Static Public Member Functions
static void	exposePythonAPI ()
	Exposes methods of the Module class to Python.

Protected Member Functions
virtual void	def_initialize ()
	Wrappers to make the methods without "def_" prefix callable from Python. More...

virtual void	def_beginRun ()
	Wrapper method for the virtual function beginRun() that has the implementation to be used in a call from Python.

virtual void	def_event ()
	Wrapper method for the virtual function event() that has the implementation to be used in a call from Python.

virtual void	def_endRun ()
	This method can receive that the current run ends as a call from the Python side. More...

virtual void	def_terminate ()
	Wrapper method for the virtual function terminate() that has the implementation to be used in a call from Python.

void	setDescription (const std::string &description)
	Sets the description of the module. More...

void	setType (const std::string &type)
	Set the module type. More...

template<typename T >
void	addParam (const std::string &name, T &paramVariable, const std::string &description, const T &defaultValue)
	Adds a new parameter to the module. More...

template<typename T >
void	addParam (const std::string &name, T &paramVariable, const std::string &description)
	Adds a new enforced parameter to the module. More...

void	setReturnValue (int value)
	Sets the return value for this module as integer. More...

void	setReturnValue (bool value)
	Sets the return value for this module as bool. More...

void	setParamList (const ModuleParamList &params)
	Replace existing parameter list.

Private Types
typedef std::vector< DataStore::StoreEntry * >	StoreEntries
	Vector of entries in the data store.

Private Member Functions
void	readTree ()
	Actually performs the reading from the tree.

bool	connectBranches (TTree tree, DataStore::EDurability durability, StoreEntries storeEntries)
	Connect branches of the given tree to the data store. More...

bool	createParentStoreEntries ()
	Connect the parent trees and fill m_parentStoreEntries.

bool	readParentTrees ()
	Read data of the current event from the parents.

void	readPersistentEntry (long fileEntry)
	Loads given entry from persistent tree.

void	entryNotFound (const std::string &entryOrigin, const std::string &name, bool fileChanged=true)
	Check if we warn the user or abort after an entry was missing after changing files.

void	addEventListForIndexFile (const std::string &parentLfn)
	For index files, this creates TEventList/TEntryListArray to enable better cache use.

void	realDataWorkaround (FileMetaData &metaData)
	Correct isMC flag for raw data recorded before experiment 8 run 2364.

std::list< ModulePtr >	getModules () const override
	no submodules, return empty list

std::string	getPathString () const override
	return the module name.

void	setParamPython (const std::string &name, const boost::python::object &pyObj)
	Implements a method for setting boost::python objects. More...

void	setParamPythonDict (const boost::python::dict &dictionary)
	Implements a method for reading the parameter values from a boost::python dictionary. More...

Private Attributes
std::string	m_inputFileName
	File to read from. More...

std::vector< std::string >	m_inputFileNames
	Files to read from.

std::vector< std::string >	m_entrySequences
	The number sequences (e.g. More...

bool	m_ignoreCommandLineOverride
	Ignore filename override from command line.

std::vector< std::string >	m_branchNames [DataStore::c_NDurabilityTypes]
	Array for names of branches, that shall be written out. More...

std::vector< std::string >	m_excludeBranchNames [DataStore::c_NDurabilityTypes]
	Array for names of branches that should NOT be written out. More...

unsigned int	m_skipNEvents
	Can be set from steering file to skip the first N events.

int	m_parentLevel
	Level of parent files to be read.

bool	m_collectStatistics
	Collect statistics on amount of data read and print statistics (seperate for input & parent files) after processing.

std::vector< int >	m_skipToEvent
	experiment, run, event number of first event to load

long	m_nextEntry
	Next entry to be read in event tree. More...

long	m_lastPersistentEntry
	last entry to be in persistent tree. More...

std::string	m_lastParentFileLFN
	last parent file LFN seen. More...

TChain *	m_tree
	TTree for event input.

TChain *	m_persistent
	TTree for persistent input.

std::set< std::string >	m_connectedBranches [DataStore::c_NDurabilityTypes]
	Already connected branches.

StoreEntries	m_storeEntries
	Vector of DataStore entries of event durability that we are supposed to read in.

StoreEntries	m_persistentStoreEntries
	Vector of DataStore entries of persistent durability that we are supposed to read in.

std::vector< StoreEntries >	m_parentStoreEntries
	The parent DataStore entries per level.

std::map< std::string, TTree * >	m_parentTrees
	Map of file LFNs to trees.

ReadStats	m_readStats
	some statistics for all files read so far.

int	m_cacheSize {0}
	Input ROOT File Cache size in MB, <0 means default.

bool	m_discardErrorEvents {true}
	Discard events that have an error flag != 0.

unsigned int	m_discardErrorMask {EventMetaData::c_HLTDiscard}
	Don't issue a warning when discarding events if the error flag consists exclusively of flags in this mask.

bool	m_processingAllEvents {true}
	Set to true if we process the input files completely: No skip events or sequences or -n parameters.

bool	m_isSecondaryInput {false}
	When using a second RootInputModule in an independent path [usually if you are using add_independent_merge_path(...)] this has to be set to true.

std::string	m_name
	The name of the module, saved as a string (user-modifiable)

std::string	m_type
	The type of the module, saved as a string.

std::string	m_package
	Package this module is found in (may be empty).

std::string	m_description
	The description of the module.

unsigned int	m_propertyFlags
	The properties of the module as bitwise or (with \|) of EModulePropFlags.

LogConfig	m_logConfig
	The log system configuration of the module.

ModuleParamList	m_moduleParamList
	List storing and managing all parameter of the module.

bool	m_hasReturnValue
	True, if the return value is set.

int	m_returnValue
	The return value.

std::vector< ModuleCondition >	m_conditions
	Module condition, only non-null if set.

Detailed Description

Module to read TTree data from file into the data store.

For more information consult the basf2 Software Portal confluence page. You can specify different TTrees for different durabilities, and specify if only specific branches should be read (branchNames), or if some should be excluded (excludeBranchNames).

The module supports reading from multiple files using TChain, entries will be read in the order the files are specified.

See also: DataStore::EDurability

Definition at line 42 of file RootInputModule.h.

Member Enumeration Documentation

◆ EModulePropFlags

enum EModulePropFlags

inherited

Each module can be tagged with property flags, which indicate certain features of the module.

Enumerator
c_Input	This module is an input module (reads data).
c_Output	This module is an output module (writes data).
c_ParallelProcessingCertified	This module can be run in parallel processing mode safely (All I/O must be done through the data store, in particular, the module must not write any files.)
c_HistogramManager	This module is used to manage histograms accumulated by other modules.
c_InternalSerializer	This module is an internal serializer/deserializer for parallel processing.
c_TerminateInAllProcesses	When using parallel processing, call this module's terminate() function in all processes(). This will also ensure that there is exactly one process (single-core if no parallel modules found) or at least one input, one main and one output process.
c_DontCollectStatistics	No statistics is collected for this module.

Definition at line 77 of file Module.h.

Member Function Documentation

◆ beginRun()

virtual void beginRun ( )

inlinevirtualinherited

Called when entering a new run.

Called at the beginning of each run, the method gives you the chance to change run dependent constants like alignment parameters, etc.

This method can be implemented by subclasses.

Reimplemented in PyModule, AWESOMEBasicModule, MVAPrototypeModule, MVAMultipleExpertsModule, MVAExpertModule, ExportGeometryModule, CreateFieldMapModule, TxModule, RxModule, SeqRootOutputModule, SeqRootInputModule, StatisticsSummaryModule, HistoManagerModule, GearboxModule, RandomBarrierModule, ProgressModule, IoVDependentConditionModule, EventLimiterModule, EventInfoPrinterModule, SwitchDataStoreModule, SubEventModule, HistoModule, BelleMCOutputModule, B2BIIMdstInputModule, B2BIIFixMdstModule, B2BIIConvertMdstModule, B2BIIConvertBeamParamsModule, B2BIIMCParticlesMonitorModule, TreeFitterModule, TagVertexModule, PhotonEfficiencySystematicsModule, ParticleVertexFitterModule, LowEnergyPi0VetoExpertModule, LowEnergyPi0IdentificationExpertModule, CurlTaggerModule, ChargedPidMVAMulticlassModule, ChargedPidMVAModule, and EnergyBiasCorrectionModule.

Definition at line 147 of file Module.h.

◆ clone()

std::shared_ptr< PathElement > clone ( ) const

overridevirtualinherited

Create an independent copy of this module.

Note that parameters are shared, so changing them on a cloned module will also affect the original module.

Implements PathElement.

Definition at line 179 of file Module.cc.

◆ connectBranches()

bool connectBranches	(	TTree *	tree,
		DataStore::EDurability	durability,
		StoreEntries *	storeEntries
	)

private

Connect branches of the given tree to the data store.

Parameters

tree	The tree to be connected.
durability	The data store durability level.
storeEntries	The store entries to which the branches are connected will be added to this vector.

Returns: True if the branches could be connected successfully.

Definition at line 518 of file RootInputModule.cc.

 {
   B2DEBUG(30, "File changed, loading persistent data.");
   DataStore::StoreEntryMap& map = DataStore::Instance().getStoreEntryMap(durability);
   //Go over the branchlist and connect the branches with DataStore entries
   const TObjArray* branchesObjArray = tree->GetListOfBranches();
   if (!branchesObjArray) {
     B2FATAL("Tree '" << tree->GetName() << "' doesn't contain any branches!");
   }
   std::vector<TBranch*> branches;
   set<string> branchList;
   for (int jj = 0; jj < branchesObjArray->GetEntriesFast(); jj++) {
     auto* branch = static_cast<TBranch*>(branchesObjArray->At(jj));
     if (!branch) continue;
     branchList.insert(branch->GetName());
     branches.emplace_back(branch);
     // start with all branches disabled and only enable what we read
     setBranchStatus(branch, false);
   }
   //skip branches the user doesn't want
   branchList = filterBranches(branchList, m_branchNames[durability], m_excludeBranchNames[durability], durability, true);
   for (TBranch* branch : branches) {
     const std::string branchName = branch->GetName();
     //skip already connected branches
     if (m_connectedBranches[durability].find(branchName) != m_connectedBranches[durability].end())
       continue;

     if ((branchList.count(branchName) == 0) and
         ((branchName != "FileMetaData") || (tree != m_persistent)) and
         ((branchName != "EventMetaData") || (tree != m_tree))) {
       continue;
     }
     auto found = setBranchStatus(branch, true);
     B2DEBUG(32, "Enabling branch" << LogVar("branchName", branchName)
             << LogVar("children found", found));

     //Get information about the object in the branch
     TObject* objectPtr = nullptr;
     branch->SetAddress(&objectPtr);
     branch->GetEntry();
     bool array = (string(branch->GetClassName()) == "TClonesArray");
     TClass* objClass = nullptr;
     if (array)
       objClass = (static_cast<TClonesArray*>(objectPtr))->GetClass();
     else
       objClass = objectPtr->IsA();
     delete objectPtr;

     //Create a DataStore entry and connect the branch address to it
     if (!DataStore::Instance().registerEntry(branchName, durability, objClass, array, DataStore::c_WriteOut)) {
       B2FATAL("Cannot connect branch to datastore" << LogVar("branchName", branchName));
       continue;
     }
     DataStore::StoreEntry& entry = (map.find(branchName))->second;
     tree->SetBranchAddress(branch->GetName(), &(entry.object));
     if (storeEntries) storeEntries->push_back(&entry);

     //Keep track of already connected branches
     m_connectedBranches[durability].insert(branchName);
   }

   return true;
 }

◆ def_endRun()

virtual void def_endRun ( )

inlineprotectedvirtualinherited

This method can receive that the current run ends as a call from the Python side.

For regular C++-Modules that forwards the call to the regular endRun() method.

Reimplemented in PyModule.

Definition at line 439 of file Module.h.

◆ def_initialize()

virtual void def_initialize ( )

inlineprotectedvirtualinherited

Wrappers to make the methods without "def_" prefix callable from Python.

Overridden in PyModule. Wrapper method for the virtual function initialize() that has the implementation to be used in a call from Python.

Reimplemented in PyModule.

Definition at line 420 of file Module.h.

◆ endRun()

virtual void endRun ( )

inlinevirtualinherited

This method is called if the current run ends.

Use this method to store information, which should be aggregated over one run.

This method can be implemented by subclasses.

Reimplemented in PyModule, AWESOMEBasicModule, ZMQTxWorkerModule, ZMQTxInputModule, TxModule, RxModule, SeqRootOutputModule, SeqRootInputModule, StatisticsSummaryModule, HistoManagerModule, RandomBarrierModule, EventInfoPrinterModule, SwitchDataStoreModule, SubEventModule, HistoModule, BelleMCOutputModule, B2BIIMdstInputModule, B2BIIConvertMdstModule, B2BIIMCParticlesMonitorModule, LowEnergyPi0VetoExpertModule, LowEnergyPi0IdentificationExpertModule, and CurlTaggerModule.

Definition at line 166 of file Module.h.

◆ evalCondition()

bool evalCondition ( ) const

inherited

If at least one condition was set, it is evaluated and true returned if at least one condition returns true.

If no condition or result value was defined, the method returns false. Otherwise, the condition is evaluated and true returned, if at least one condition returns true. To speed up the evaluation, the condition strings were already parsed in the method if_value().

Returns: True if at least one condition and return value exists and at least one condition expression was evaluated to true.

Definition at line 96 of file Module.cc.

◆ getAfterConditionPath()

Module::EAfterConditionPath getAfterConditionPath ( ) const

inherited

What to do after the conditional path is finished.

(defaults to c_End if no condition is set)

Definition at line 133 of file Module.cc.

◆ getConditionPath()

std::shared_ptr< Path > getConditionPath ( ) const

inherited

Returns the path of the last true condition (if there is at least one, else reaturn a null pointer).

Definition at line 113 of file Module.cc.

◆ getName()

const std::string& getName ( ) const

inlineinherited

Returns the name of the module.

This can be changed via e.g. set_name() in the steering file to give more useful names if there is more than one module of the same type.

For identifying the type of a module, using getType() (or type() in Python) is recommended.

Definition at line 187 of file Module.h.

◆ getParamInfoListPython()

std::shared_ptr< boost::python::list > getParamInfoListPython ( ) const

inherited

Returns a python list of all parameters.

Each item in the list consists of the name of the parameter, a string describing its type, a python list of all default values and the description of the parameter.

Returns: A python list containing the parameters of this parameter list.

Definition at line 279 of file Module.cc.

◆ getReturnValue()

int getReturnValue ( ) const

inlineinherited

Return the return value set by this module.

This value is only meaningful if hasReturnValue() is true

Definition at line 381 of file Module.h.

◆ getType()

const std::string & getType ( ) const

inherited

Returns the type of the module (i.e.

class name minus 'Module')

Definition at line 41 of file Module.cc.

◆ hasProperties()

bool hasProperties ( unsigned int propertyFlags ) const

inherited

Returns true if all specified property flags are available in this module.

Parameters

propertyFlags Ored EModulePropFlags which should be compared with the module flags.

Definition at line 160 of file Module.cc.

◆ if_false()

void if_false	(	const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

A simplified version to add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression "<1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters

path	Shared pointer to the Path which will be executed if the return value is false.
afterConditionPath	What to do after executing 'path'.

Definition at line 85 of file Module.cc.

◆ if_true()

void if_true	(	const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

A simplified version to set the condition of the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

It is equivalent to the if_value() method, using the expression ">=1". This method is meant to be used together with the setReturnValue(bool value) method.

Parameters

path	Shared pointer to the Path which will be executed if the return value is true.
afterConditionPath	What to do after executing 'path'.

Definition at line 90 of file Module.cc.

◆ if_value()

void if_value	(	const std::string &	expression,
		const std::shared_ptr< Path > &	path,
		EAfterConditionPath	afterConditionPath = `EAfterConditionPath::c_End`
	)

inherited

Add a condition to the module.

Please note that successive calls of this function will add more than one condition to the module. If more than one condition results in true, only the last of them will be used.

See https://confluence.desy.de/display/BI/Software+ModCondTut or ModuleCondition for a description of the syntax.

Please be careful: Avoid creating cyclic paths, e.g. by linking a condition to a path which is processed before the path where this module is located in.

Parameters

expression	The expression of the condition.
path	Shared pointer to the Path which will be executed if the condition is evaluated to true.
afterConditionPath	What to do after executing 'path'.

Definition at line 79 of file Module.cc.

◆ setDescription()

void setDescription ( const std::string & description )

protectedinherited

Sets the description of the module.

Parameters

description A description of the module.

Definition at line 214 of file Module.cc.

◆ setLogInfo()

void setLogInfo	(	int	logLevel,
		unsigned int	logInfo
	)

inherited

Configure the printed log information for the given level.

Parameters

logLevel	The log level (one of LogConfig::ELogLevel)
logInfo	What kind of info should be printed? ORed combination of LogConfig::ELogInfo flags.

Definition at line 73 of file Module.cc.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Set the name of the module.

Note: The module name is set when using the REG_MODULE macro, but the module can be renamed before calling process() using the set_name() function in your steering file.

Parameters

name	The name of the module

Definition at line 214 of file Module.h.

◆ setParamPython()

void setParamPython	(	const std::string &	name,
		const boost::python::object &	pyObj
	)

privateinherited

Implements a method for setting boost::python objects.

The method supports the following types: list, dict, int, double, string, bool The conversion of the python object to the C++ type and the final storage of the parameter value is done in the ModuleParam class.

Parameters

name	The unique name of the parameter.
pyObj	The object which should be converted and stored as the parameter value.

Definition at line 234 of file Module.cc.

◆ setParamPythonDict()

void setParamPythonDict ( const boost::python::dict & dictionary )

privateinherited

Implements a method for reading the parameter values from a boost::python dictionary.

The key of the dictionary has to be the name of the parameter and the value has to be of one of the supported parameter types.

Parameters

dictionary The python dictionary from which the parameter values are read.

Definition at line 249 of file Module.cc.

◆ setPropertyFlags()

void setPropertyFlags ( unsigned int propertyFlags )

inherited

Sets the flags for the module properties.

Parameters

propertyFlags bitwise OR of EModulePropFlags

Definition at line 208 of file Module.cc.

◆ setReturnValue() [1/2]

void setReturnValue ( bool value )

protectedinherited

Sets the return value for this module as bool.

The bool value is saved as an integer with the convention 1 meaning true and 0 meaning false. The value can be used in the steering file to divide the analysis chain into several paths.

Parameters

value The value of the return value.

Definition at line 227 of file Module.cc.

◆ setReturnValue() [2/2]

void setReturnValue ( int value )

protectedinherited

Sets the return value for this module as integer.

The value can be used in the steering file to divide the analysis chain into several paths.

Parameters

value The value of the return value.

Definition at line 220 of file Module.cc.

◆ setType()

void setType ( const std::string & type )

protectedinherited

Set the module type.

Only for use by internal modules (which don't use the normal REG_MODULE mechanism).

Definition at line 48 of file Module.cc.

Member Data Documentation

◆ m_branchNames

std::vector<std::string> m_branchNames[DataStore::c_NDurabilityTypes]

private

Array for names of branches, that shall be written out.

Empty vector results in all branches being read. These vectors can be configured in the steering file.

Definition at line 133 of file RootInputModule.h.

◆ m_entrySequences

std::vector<std::string> m_entrySequences

private

The number sequences (e.g.

23:42,101) defining the entries which are processed for each inputFileName.

Definition at line 122 of file RootInputModule.h.

◆ m_excludeBranchNames

std::vector<std::string> m_excludeBranchNames[DataStore::c_NDurabilityTypes]

private

Array for names of branches that should NOT be written out.

This takes precedence over m_branchNames, so if a branch is in both m_branchNames[d] and m_excludeBranchNames[d], it is not saved.

Definition at line 140 of file RootInputModule.h.

◆ m_inputFileName

std::string m_inputFileName

private

File to read from.

Cannot be used together with m_inputFileNames.

Definition at line 114 of file RootInputModule.h.

◆ m_lastParentFileLFN

std::string m_lastParentFileLFN

private

last parent file LFN seen.

(used by addEventListForIndexFile())

Definition at line 164 of file RootInputModule.h.

◆ m_lastPersistentEntry

long m_lastPersistentEntry

private

last entry to be in persistent tree.

Definition at line 161 of file RootInputModule.h.

◆ m_nextEntry

long m_nextEntry

private

Next entry to be read in event tree.

Definition at line 158 of file RootInputModule.h.

The documentation for this class was generated from the following files:

framework/modules/rootio/include/RootInputModule.h
framework/modules/rootio/src/RootInputModule.cc

Classes

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Types

Private Member Functions

Private Attributes

Detailed Description

Member Enumeration Documentation

◆ EModulePropFlags

Member Function Documentation

◆ beginRun()

◆ clone()

◆ connectBranches()

◆ def_endRun()

◆ def_initialize()

◆ endRun()

◆ evalCondition()

◆ getAfterConditionPath()

◆ getConditionPath()

◆ getName()

◆ getParamInfoListPython()

◆ getReturnValue()

◆ getType()

◆ hasProperties()

◆ if_false()

◆ if_true()

◆ if_value()

◆ setDescription()

◆ setLogInfo()

◆ setName()

◆ setParamPython()

◆ setParamPythonDict()

◆ setPropertyFlags()

◆ setReturnValue() [1/2]

◆ setReturnValue() [2/2]

◆ setType()

Member Data Documentation

◆ m_branchNames

◆ m_entrySequences

◆ m_excludeBranchNames

◆ m_inputFileName

◆ m_lastParentFileLFN

◆ m_lastPersistentEntry

◆ m_nextEntry
