AlignableCDCRecoHit Class Reference

This class is used to transfer CDC information to the track fit and Millepede. More...

#include <AlignableCDCRecoHit.h>

Inheritance diagram for AlignableCDCRecoHit:
Collaboration diagram for AlignableCDCRecoHit:

Public Member Functions

 ~AlignableCDCRecoHit ()
 Destructor.

AlignableCDCRecoHitclone () const override
 Creating a copy of this hit.

virtual std::pair< std::vector< int >, TMatrixD > globalDerivatives (const genfit::StateOnPlane *sop) override
 Labels and derivatives of residuals (local measurement coordinates) w.r.t. More...

virtual TMatrixD localDerivatives (const genfit::StateOnPlane *sop) override
 Derivatives for (local) fit parameters. More...

 CDCRecoHit ()
 Inherit constructors.

 CDCRecoHit (const CDCHit *cdcHit, const genfit::TrackCandHit *trackCandHit)
 Inherit constructors.

WireID getWireID () const
 Getter for WireID object.

genfit::SharedPlanePtr constructPlane (const genfit::StateOnPlane &state) const override
 Methods that actually interface to Genfit.

std::vector< genfit::MeasurementOnPlane * > constructMeasurementsOnPlane (const genfit::StateOnPlane &state) const override
 build MeasurementsOnPlane

virtual const genfit::HMatrixUconstructHMatrix (const genfit::AbsTrackRep *) const override
 construct error matrix

std::vector< double > timeDerivativesMeasurementsOnPlane (const genfit::StateOnPlane &state) const
 Get the time derivative of the MesuredStateOnPlane (derived from the track fit). More...

bool getFlyByDistanceVector (B2Vector3D &pointingVector, B2Vector3D &trackDir, const genfit::AbsTrackRep *rep=NULL, bool usePlaneFromFit=false)
 Get the vector pointing from the wire to the fitted trajectory as well as the direction of the track in the fitted point. More...

void setLeftRightResolution (int lr)
 select how to resolve the left/right ambiguity: -1: negative (left) side on vector (wire direction) x (track direction) 0: mirrors enter with same weight, DAF will decide. More...

bool isLeftRightMeasurement () const override
 CDC RecoHits always have left-right ambiguity.

int getLeftRightResolution () const override
 Getter for left/right passage flag.

const CDCHitgetCDCHit () const
 get the pointer to the CDCHit object that was used to create this CDCRecoHit object. More...

TrackPoint * getTrackPoint () const

void setTrackPoint (TrackPoint *tp)

const TVectorD & getRawHitCoords () const

TVectorD & getRawHitCoords ()

const TMatrixDSym & getRawHitCov () const

TMatrixDSym & getRawHitCov ()

int getDetId () const

int getHitId () const

unsigned int getDim () const

void setRawHitCoords (const TVectorD &coords)

void setRawHitCov (const TMatrixDSym &cov)

void setDetId (int detId)

void setHitId (int hitId)

virtual void Print (const Option_t *="") const

virtual std::vector< int > labels ()
 Vector of integer labels for calibration/alignment parameters available (must match #columns of derivatives(...)) More...

virtual TMatrixD derivatives (const genfit::StateOnPlane *)
 Derivatives of residuals (local measurement coordinates) w.r.t. More...

virtual std::vector< int > localLabels ()
 Vector of integer labels for local calibration parameters available (must match #columns of localDerivatives(...)) More...


Static Public Member Functions

static void setTranslators (CDC::ADCCountTranslatorBase *const adcCountTranslator, CDC::CDCGeometryTranslatorBase *const cdcGeometryTranslator, CDC::TDCCountTranslatorBase *const tdcCountTranslator, bool useTrackTime=false, bool cosmics=false)
 Setter for the Translators.


Static Public Attributes

static bool s_enableTrackT0LocalDerivative = true
 Static enabling(true) or disabling(false) addition of local derivative for track T0.

static bool s_enableWireSaggingGlobalDerivative = false
 Static enabling(true) or disabling(false) addition of global derivative for wire sagging coefficient (per wire)

static bool s_enableWireByWireAlignmentGlobalDerivatives = false
 Static enabling(true) or disabling(false) addition of global derivatives for wire-by-wire alignment.


Protected Member Functions

 ClassDefOverride (CDCRecoHit, 10)
 ROOT Macro.


Protected Attributes

unsigned short m_tdcCount
 TDC Count as out of CDCHit.

unsigned short m_adcCount
 ADC Count as out of CDCHit.

WireID m_wireID
 Wire Identifier.

const CDCHitm_cdcHit
 Pointer to the CDCHit used to created this CDCRecoHit.

signed char m_leftRight
 Flag showing left/right passage.

TVectorD rawHitCoords_

TMatrixDSym rawHitCov_

int detId_

int hitId_

TrackPoint * trackPoint_
 Pointer to TrackPoint where the measurement belongs to.


Static Protected Attributes

static std::unique_ptr< CDC::ADCCountTranslatorBases_adcCountTranslator = 0
 Object for ADC Count translation.

static std::unique_ptr< CDC::CDCGeometryTranslatorBases_cdcGeometryTranslator = 0
 Object for geometry translation.

static std::unique_ptr< CDC::TDCCountTranslatorBases_tdcCountTranslator = 0
 Object for getting drift-length and -resolution.

static bool s_useTrackTime = false
 Whether to use the track time or not when building the measurementOnPlane. More...

static bool s_cosmics = false
 Switch to use cosmic events, or physics events from IP. More...


Private Member Functions

 ClassDefOverride (AlignableCDCRecoHit, 1)
 ROOT Macro.


Detailed Description

This class is used to transfer CDC information to the track fit and Millepede.

Definition at line 32 of file AlignableCDCRecoHit.h.

Member Function Documentation

◆ derivatives()

virtual TMatrixD derivatives ( const genfit::StateOnPlane )
inlinevirtualinherited

Derivatives of residuals (local measurement coordinates) w.r.t.

alignment/calibration parameters Matrix "G" of derivatives valid for given prediction of track state:

G(i, j) = d_residual_i/d_parameter_j

For 2D measurement (u,v):

G = ( du/da du/db du/dc ... ) ( dv/da dv/db dv/dc ... )

for calibration parameters a, b, c.

For 1D measurement both forms are allowed:

G = ( 0 0 0 ... ) ( dv/da dv/db dv/dc ... ) for V-strip,

G = ( du/da du/db du/dc ... ) ( 0 0 0 ... ) for U-strip,

or :

G = ( d_sensitive/da d_sensitive/db d_sensitive/dc ... ) as matrix with one row.

A possible algorithm using these derivatives should be able to resolve this based on the measurement HMatrix. Measurements with more dimesions (slopes, curvature) should provide full 4-5Dx(n params) matrix (state as (q/p, u', v', u, v) or (u', v', u, v))

Parameters
sopPredicted state of the track as linearization point around which derivatives of alignment/calibration parameters shall be computed
Returns
TMatrixD Matrix with #rows = dimension of residual, #columns = number of parameters. #columns must match labels().size().

Definition at line 129 of file ICalibrationParametersDerivatives.h.

◆ getCDCHit()

const CDCHit* getCDCHit ( ) const
inlineinherited

get the pointer to the CDCHit object that was used to create this CDCRecoHit object.

Can be NULL if CDCRecoHit was not created with the CDCRecoHit(const CDCHit* cdcHit) constructor

Definition at line 123 of file CDCRecoHit.h.

◆ getFlyByDistanceVector()

bool getFlyByDistanceVector ( B2Vector3D pointingVector,
B2Vector3D trackDir,
const genfit::AbsTrackRep rep = NULL,
bool  usePlaneFromFit = false
)
inherited

Get the vector pointing from the wire to the fitted trajectory as well as the direction of the track in the fitted point.

Uses the cardinal TrackRep if rep == NULL. Returns false if the track is not fitted in this point for the requested TrackRep. If the hit does not belong to a track, an error is issued and false returned. If usePlaneFromFit is used, constructPlane is not called to evaluate the closest point on the wire to the track. Instead the origin of the plane of the fitted state is used (which will be the same point if the wire is not bent).

Definition at line 370 of file CDCRecoHit.cc.

374 {
375  const genfit::TrackPoint* tp = this->getTrackPoint();
376  if (!tp) {
377  B2ERROR("No genfit::TrackPoint for CDCRecoHit.");
378  return false;
379  }
380  const genfit::AbsFitterInfo* fi = tp->getFitterInfo(rep);
381  if (!fi) {
382  B2DEBUG(200, "No genfit::AbsFitterInfo for this CDCRecoHit.");
383  return false;
384  }
385
386  const genfit::MeasuredStateOnPlane& mop = fi->getFittedState();
387  B2Vector3D fittedPoca = mop.getPos();
388  // constructPlane places the coordinate center in the POCA to the
389  // wire. Using this is the default behavior. If this should be too
390  // slow, as it has to re-evaluate the POCA, alternatively the user
391  // can set usePlaneFromFit which uses the plane determined by the
392  // track fit.
393  B2Vector3D pocaOnWire = (usePlaneFromFit
394  ? mop.getPlane()->getO()
395  : this->constructPlane(mop)->getO());
396
397  // The vector from the wire to the track.
398  pointingVector = fittedPoca - pocaOnWire;
399
400  trackDir = mop.getMom();
401  trackDir.SetMag(1.);
402  return true;
403 }

◆ globalDerivatives()

std::pair< std::vector< int >, TMatrixD > globalDerivatives ( const genfit::StateOnPlane sop)
overridevirtual

Labels and derivatives of residuals (local measurement coordinates) w.r.t.

alignment/calibration parameters Matrix "G" of derivatives valid for given prediction of track state:

G(i, j) = d_residual_i/d_parameter_j

For 2D measurement (u,v):

G = ( du/da du/db du/dc ... ) ( dv/da dv/db dv/dc ... )

for calibration parameters a, b, c.

For 1D measurement:

G = ( 0 0 0 ... ) ( dv/da dv/db dv/dc ... ) for V-strip,

G = ( du/da du/db du/dc ... ) ( 0 0 0 ... ) for U-strip,

Measurements with more dimesions (slopes, curvature) should provide full 4-5Dx(n params) matrix (state as (q/p, u', v', u, v) or (u', v', u, v))

Parameters
sopPredicted state of the track as linearization point around which derivatives of alignment/calibration parameters shall be computed
Returns
pair<vector<int>, TMatrixD> With matrix with #rows = dimension of residual, #columns = number of parameters. #columns must match vector<int>.size().

Reimplemented from ICalibrationParametersDerivatives.

Definition at line 29 of file AlignableCDCRecoHit.cc.
