BFieldComponent3d Class Reference

The BFieldComponent3d class. More...

#include <BFieldComponent3d.h>

Inheritance diagram for BFieldComponent3d:
Collaboration diagram for BFieldComponent3d:

Public Member Functions

 BFieldComponent3d ()=default
 The BFieldComponent3d constructor.

virtual ~BFieldComponent3d ()=default
 The BFieldComponent3d destructor.

virtual void initialize () override
 Initializes the magnetic field component. More...

virtual B2Vector3D calculate (const B2Vector3D &point) const override
 Calculates the magnetic field vector at the specified space point. More...

virtual void terminate () override
 Terminates the magnetic field component. More...

void setMapFilename (const std::string &filename)
 Sets the filename of the magnetic field map. More...

void setMapSize (int sizeR, int sizePhi, int sizeZ)
 Sets the size of the magnetic field map. More...

void setMapRegionZ (double minZ, double maxZ, double offset)
 Sets the size of the magnetic field map. More...

void setMapRegionR (double minR, double maxR)
 Sets the size of the magnetic field map. More...

void setGridPitch (double pitchR, double pitchPhi, double pitchZ)
 Sets the grid pitch of the magnetic field map. More...

void setExcludeRegionZ (double minZ, double maxZ)
 Sets the size of the magnetic field map to exclude. More...

void setExcludeRegionR (double minR, double maxR)
 Sets the size of the magnetic field map to exclude. More...

void setErrorRegionR (double minR=-1., double maxR=-1., double errBr=0.0, double errBphi=0.0, double errBz=0.0)
 Sets the size of the magnetic field map to apply error on B. More...

void mirrorPhi (bool mirrorPhi=0.)

void doInterpolation (bool interpolate=true)

void enableCoordinate (const std::string &mapEnable="rphiz")
 Optino to reduce 3D to 2D map (in coordinates, NOT Br, Bphi, Bz components) More...


Private Member Functions

B2Vector3D interpolate (unsigned int ir, unsigned int iphi, unsigned int iz, double wr, double wphi, double wz) const
 Interpolate the value of B-field between (ir, iphi, iz) and (ir+1, iphi+1, iz+1) using weights (wr, wphi, wz)


Private Attributes

std::string m_mapFilename {""}
 The filename of the magnetic field map.

std::vector< B2Vector3Fm_bmap
 The memory buffer for the magnetic field map.

std::string m_mapEnable {"rphiz"}
 Enable different dimension, "rphiz", "rphi", "phiz" or "rz" >

bool m_interpolate {true}
 Flag to switch on/off interpolation >

int m_mapSize [3]
 The size of the map in r, phi and z.

double m_mapRegionZ [2] {0}
 The min and max boundaries of the map region in z.

double m_mapOffset {0}
 Offset required because the accelerator group defines the Belle center as zero.

double m_mapRegionR [2] {0}
 The min and max boundaries of the map region in r.

double m_gridPitch [3] {0}
 The grid pitch in r,phi,z.

double m_igridPitch [3] {0}
 The inverted grid pitch in r,phi,z.

double m_exRegionZ [2] {0}
 The min and max boundaries of the excluded region in z.

double m_exRegionR [2] {0}
 The min and max boundaries of the excluded region in r.

bool m_exRegion {true}
 Flag to indicate whether there is a region to exclude. More...

bool m_mirrorPhi {true}
 Flag to indicate whether there is a region to exclude. More...

double m_errRegionR [2] {0}
 The min and max boundaries of the region in r to apply error.

double m_errB [3] {0}
 The error Br, Bphi, Bz as a scale factor (B_new = m_errB * B_old).


Detailed Description

The BFieldComponent3d class.

This class represents a 3d magnetic field map. The magnetic field map is stored as a grid in cylindrical coordinates. It is defined by a minimum radius and a maximum radius, a minimum z and a maximum z value (phi is assumed to be in 360 degrees range, option to mirror about the x-y plane exist), a pitch size in both, r, z and phi and the number of grid points. The ZOffset is used to account for the fact that the acceleration group defines 0 to be in the center of the detector, while the detector group defines the IP to be the center. The filename points to the zip file containing the magnetic field map.

Definition at line 44 of file BFieldComponent3d.h.

Member Function Documentation

◆ calculate()

B2Vector3D calculate ( const B2Vector3D point) const
overridevirtual

Calculates the magnetic field vector at the specified space point.

Parameters
pointThe space point in [cm] at which the magnetic field vector should be calculated.
Returns
The magnetic field vector at the given space point in [T]. Returns a zero vector TVector(0,0,0) if the space point lies outside the region described by the component.

Implements BFieldComponentAbs.

Definition at line 186 of file BFieldComponent3d.cc.

187 {
188  auto getPhiIndexWeight = [this](double y, double x, double & wphi) -> unsigned int {
189  double phi = fast_atan2_minimax<4>(y, x);
190  wphi = phi * m_igridPitch[1];
191  auto iphi = static_cast<unsigned int>(wphi);
192  iphi = min(iphi, static_cast<unsigned int>(m_mapSize[1] - 2));
193  wphi -= iphi;
194  return iphi;
195  };
196
197  B2Vector3D B(0, 0, 0);
198
199  // If both '3d' and 'Beamline' components are defined in xml file,
200  // '3d' component returns zero field where 'Beamline' component is defined.
201  // If no 'Beamline' component is defined in xml file, the following function will never be called.
202  if (BFieldComponentBeamline::Instance().isInRange(point)) {
203  return B;
204  }
205
206  double z = point.z();
207  // Check if the point lies inside the magnetic field boundaries
208  if (z < m_mapRegionZ[0] || z > m_mapRegionZ[1]) return B;
209
210  double r2 = point.Perp2();
211  // Check if the point lies inside the magnetic field boundaries
212  if (r2 < m_mapRegionR[0]*m_mapRegionR[0] || r2 >= m_mapRegionR[1]*m_mapRegionR[1]) return B;
213  // Check if the point lies in the exclude region
214  if (m_exRegion && (z >= m_exRegionZ[0]) && (z < m_exRegionZ[1]) &&
215  (r2 >= m_exRegionR[0]*m_exRegionR[0]) && (r2 < m_exRegionR[1]*m_exRegionR[1])) return B;
216
217  // Calculate the lower index of the point in the Z grid
218  // Note that z coordinate is inverted to match ANSYS frame
219  double wz = (m_mapRegionZ[1] - z) * m_igridPitch[2];
220  unsigned int iz = static_cast<int>(wz);
221  iz = min(iz, static_cast<unsigned int>(m_mapSize[2] - 2));
222  wz -= iz;
223
224  if (r2 > 0) {
225  double r = sqrt(r2);
226
227  // Calculate the lower index of the point in the R grid
228  double wr = (r - m_mapRegionR[0]) * m_igridPitch[0];
229  auto ir = static_cast<unsigned int>(wr);
230  ir = min(ir, static_cast<unsigned int>(m_mapSize[0] - 2));
231  wr -= ir;
232
233  // Calculate the lower index of the point in the Phi grid
234  double ay = std::abs(point.y());
235  double wphi;
236  unsigned int iphi = getPhiIndexWeight(ay, point.x(), wphi);
237
238  // Get B-field values from map
239  B2Vector3D b = interpolate(ir, iphi, iz, wr, wphi, wz); // in cylindrical system
240  double norm = 1 / r;
241  double s = ay * norm, c = point.x() * norm;
242  // Flip sign of By if y<0
243  const double sgny = (point.y() >= 0) - (point.y() < 0);
244  // in cartesian system
245  B.SetXYZ(-(b.x() * c - b.y() * s), -sgny * (b.x() * s + b.y() * c), b.z());
246  } else {
247  // Get B-field values from map in cartesian system assuming phi=0, so Bx = Br and By = Bphi
248  B = interpolate(0, 0, iz, 0, 0, wz);
249  }
250
251  return B;
252 }

◆ doInterpolation()

void doInterpolation ( bool  interpolate = true)
inline
Parameters
mapEnableFlag to switch on/off interpolation

Definition at line 145 of file BFieldComponent3d.h.

145 :
146

◆ enableCoordinate()

void enableCoordinate ( const std::string &  mapEnable = "rphiz")
inline

Optino to reduce 3D to 2D map (in coordinates, NOT Br, Bphi, Bz components)

Parameters
mapEnableList of dimensions to enable: "rphiz", "rphi", "phiz" or "rz"

Definition at line 151 of file BFieldComponent3d.h.

◆ initialize()

void initialize ( )
overridevirtual

Initializes the magnetic field component.

This method opens the magnetic field map file.

Reimplemented from BFieldComponentAbs.

Definition at line 26 of file BFieldComponent3d.cc.

◆ mirrorPhi()

void mirrorPhi ( bool  mirrorPhi = 0.)
inline
Parameters
mirrorPhiFlag to enable mirroring in phi about x-z plane

Definition at line 140 of file BFieldComponent3d.h.

◆ setErrorRegionR()

void setErrorRegionR ( double  minR = -1.,
double  maxR = -1.,
double  errBr = 0.0,
double  errBphi = 0.0,
double  errBz = 0.0
)
inline

Sets the size of the magnetic field map to apply error on B.

Parameters
minRThe left (min) border of the magnetic field map region in r [m] -> [cm].
maxRThe right (max) border of the magnetic field map region in r [m] -> [cm].
errBrThe size of the error on Br, Br_new = errBr*Br [fraction].
errBPhiThe size of the error on Bphi, Bphi_new = errBphi*Bphi [fraction].
errBzThe size of the error on Bz, Bz_new = errBz*Bz [fraction].

Definition at line 134 of file BFieldComponent3d.h.

◆ setExcludeRegionR()

void setExcludeRegionR ( double  minR,
double  maxR
)
inline

Sets the size of the magnetic field map to exclude.

Parameters
minRThe left (min) border of the magnetic field map region in r [m] -> [cm].
maxRThe right (max) border of the magnetic field map region in r [m] -> [cm].

Definition at line 124 of file BFieldComponent3d.h.

◆ setExcludeRegionZ()

void setExcludeRegionZ ( double  minZ,
double  maxZ
)
inline

Sets the size of the magnetic field map to exclude.

Parameters
minZThe left (min) border of the magnetic field map region in z [m] -> [cm].
maxZThe right (max) border of the magnetic field map region in z [m] -> [cm].

Definition at line 117 of file BFieldComponent3d.h.

◆ setGridPitch()

void setGridPitch ( double  pitchR,
double  pitchPhi,
double  pitchZ
)
inline

Sets the grid pitch of the magnetic field map.

Parameters
pitchRThe pitch of the grid in r [m] -> [cm].
pitchPhiThe pitch of the grid in phi [degrees] -> [rad] converted back to degrees in the code.
pitchZThe pitch of the grid in z [m] -> [cm].

Definition at line 110 of file BFieldComponent3d.h.

◆ setMapFilename()

void setMapFilename ( const std::string &  filename)
inline

Sets the filename of the magnetic field map.

Parameters
filenameThe filname of the magnetic field map.

Definition at line 79 of file BFieldComponent3d.h.

◆ setMapRegionR()

void setMapRegionR ( double  minR,
double  maxR
)
inline

Sets the size of the magnetic field map.

Parameters
minRThe left (min) border of the magnetic field map region in r [m] -> [cm].
maxRThe right (max) border of the magnetic field map region in r [m] -> [cm].

Definition at line 102 of file BFieldComponent3d.h.

◆ setMapRegionZ()

void setMapRegionZ ( double  minZ,
double  maxZ,
double  offset
)
inline

Sets the size of the magnetic field map.

Parameters
minZThe left (min) border of the magnetic field map region in z [m] -> [cm].
maxZThe right (max) border of the magnetic field map region in z [m] -> [cm].
offsetThe offset in z [m] -> [cm] which is required because the accelerator group defines the Belle center as zero.

Definition at line 95 of file BFieldComponent3d.h.

◆ setMapSize()

void setMapSize ( int  sizeR,
int  sizePhi,
int  sizeZ
)
inline

Sets the size of the magnetic field map.

Parameters
sizeRThe number of points in the r direction.
sizePhiThe number of points in the phi direction.
sizeZThe number of points in the z direction.

Definition at line 87 of file BFieldComponent3d.h.

◆ terminate()

void terminate ( )
overridevirtual

Terminates the magnetic field component.

This method closes the magnetic field map file.

Reimplemented from BFieldComponentAbs.

Definition at line 254 of file BFieldComponent3d.cc.

Member Data Documentation

◆ m_exRegion

bool m_exRegion {true}
private

Flag to indicate whether there is a region to exclude.

>

Definition at line 186 of file BFieldComponent3d.h.

◆ m_mirrorPhi

bool m_mirrorPhi {true}
private

Flag to indicate whether there is a region to exclude.

>

Definition at line 188 of file BFieldComponent3d.h.


The documentation for this class was generated from the following files:
Belle2::BFieldComponent3d::m_mapRegionR
double m_mapRegionR[2]
The min and max boundaries of the map region in r.
Definition: BFieldComponent3d.h:176
Belle2::BFieldComponent3d::m_exRegion
bool m_exRegion
Flag to indicate whether there is a region to exclude.
Definition: BFieldComponent3d.h:186
Belle2::BFieldComponent3d::m_exRegionR
double m_exRegionR[2]
The min and max boundaries of the excluded region in r.
Definition: BFieldComponent3d.h:184
Belle2::BFieldComponent3d::m_igridPitch
double m_igridPitch[3]
The inverted grid pitch in r,phi,z.
Definition: BFieldComponent3d.h:180
Belle2::B2Vector3::x
DataType x() const
access variable X (= .at(0) without boundary check)
Definition: B2Vector3.h:424
Belle2::BFieldComponent3d::m_mapRegionZ
double m_mapRegionZ[2]
The min and max boundaries of the map region in z.
Definition: BFieldComponent3d.h:172
Belle2::BFieldComponent3d::m_exRegionZ
double m_exRegionZ[2]
The min and max boundaries of the excluded region in z.
Definition: BFieldComponent3d.h:182
Belle2::B2Vector3< double >
Belle2::BFieldComponent3d::m_mapSize
int m_mapSize[3]
The size of the map in r, phi and z.
Definition: BFieldComponent3d.h:170
Belle2::BFieldComponentBeamline::Instance
static BFieldComponentBeamline & Instance()
BFieldComponentBeamline instance.
Definition: BFieldComponentBeamline.cc:699
Belle2::B2Vector3::y
DataType y() const
access variable Y (= .at(1) without boundary check)
Definition: B2Vector3.h:426
Belle2::B2Vector3::Perp2
DataType Perp2() const
The transverse component squared (R^2 in cylindrical coordinate system).
Definition: B2Vector3.h:195
Belle2::B2Vector3::z
DataType z() const
access variable Z (= .at(2) without boundary check)
Definition: B2Vector3.h:428
Belle2::BFieldComponent3d::interpolate
B2Vector3D interpolate(unsigned int ir, unsigned int iphi, unsigned int iz, double wr, double wphi, double wz) const
Interpolate the value of B-field between (ir, iphi, iz) and (ir+1, iphi+1, iz+1) using weights (wr,...
Definition: BFieldComponent3d.cc:258
