Database object containing cut values to filter CDCWireHits. More...

#include <CDCWireHitRequirements.h>

Inheritance diagram for CDCWireHitRequirements:

Collaboration diagram for CDCWireHitRequirements:

Public Member Functions
	CDCWireHitRequirements ()=default
	Default constructor.

	CDCWireHitRequirements (boost::property_tree::ptree tree)
	Constructor using a boost::property_tree.

	~CDCWireHitRequirements ()=default
	Destructor.

const intRange_t &	getADCRangeFirstSuperLayer () const
	Get allowed ADC range (first super layer of CDC). An upper value of -1 stands for unbounded.

void	setADCRangeFirstSuperLayer (const intRange_t &ADCRangeFirstSuperLayer)
	Set allowed ADC range (first super layer of CDC). An upper value of -1 stands for unbounded.

const intRange_t &	getADCRangeOuterSuperLayers () const
	Get allowed ADC range (outer super layers of CDC). An upper value of -1 stands for unbounded.

void	setADCRangeOuterSuperLayers (const intRange_t &ADCRangeOuterSuperLayers)
	Set allowed ADC range (outer super layers of CDC). An upper value of -1 stands for unbounded.

const intRange_t &	getTOTRangeFirstSuperLayer () const
	Get allowed TOT range (first super layer of CDC). An upper value of -1 stands for unbounded.

void	setTOTRangeFirstSuperLayer (const intRange_t &TOTRangeFirstSuperLayer)
	Set allowed TOT range (first super layer of CDC). An upper value of -1 stands for unbounded.

const intRange_t &	getTOTRangeOuterSuperLayers () const
	Get allowed TOT range (outer super layers of CDC). An upper value of -1 stands for unbounded.

void	setTOTRangeOuterSuperLayers (const intRange_t &TOTRangeOuterSuperLayers)
	Set allowed TOT range (outer super layers of CDC). An upper value of -1 stands for unbounded.

const floatRange_t &	getADCOverTOTRangeFirstSuperLayer () const
	Get allowed ADC/TOT range (first super layer of CDC). An upper value of -1 stands for unbounded.

void	setADCOverTOTRangeFirstSuperLayer (const floatRange_t &ADCOverTOTRangeFirstSuperLayer)
	Set allowed ADC/TOT range (first super layer of CDC). An upper value of -1 stands for unbounded.

const floatRange_t &	getADCOverTOTRangeOuterSuperLayers () const
	Get allowed ADC/TOT range (outer super layers of CDC). An upper value of -1 stands for unbounded.

void	setADCOverTOTRangeOuterSuperLayers (const floatRange_t &ADCOverTOTRangeOuterSuperLayers)
	Set allowed ADC/TOT range (outer super layers of CDC). An upper value of -1 stands for unbounded.

const std::map< short, short >	getMaxADCGivenTOTFirstSuperLayer () const
	Get map of maximum allowed ADC given TOT (first super layer of CDC). An upper value of -1 stands for unbounded.

short	getMaxADCGivenTOTFirstSuperLayer (short tot) const
	Get maximum allowed ADC given TOT (first super layer of CDC). An upper value of -1 stands for unbounded.

void	setMaxADCGivenTOTFirstSuperLayer (const std::map< short, short > &MaxADCGivenTOTFirstSuperLayer)
	Set map of maximum allowed ADC given TOT (first super layer of CDC). An upper value of -1 stands for unbounded.

const std::map< short, short >	getMaxADCGivenTOTOuterSuperLayers () const
	Get map of maximum allowed ADC given TOT (outer super layers of CDC). An upper value of -1 stands for unbounded.

short	getMaxADCGivenTOTOuterSuperLayers (short tot) const
	Get maximum allowed ADC given TOT (outer super layers of CDC). An upper value of -1 stands for unbounded.

void	setMaxADCGivenTOTOuterSuperLayers (const std::map< short, short > &MaxADCGivenTOTOuterSuperLayers)
	Set map of maximum allowed ADC given TOT (outer super layers of CDC). An upper value of -1 stands for unbounded.

void	dump () const
	Print content.

Private Types
typedef std::pair< short, short >	intRange_t
	Integer range. More...

typedef std::pair< float, float >	floatRange_t
	Float range. More...

Private Member Functions
	ClassDef (CDCWireHitRequirements, 2)
	ROOT ClassDef.

Private Attributes
intRange_t	m_ADCRangeFirstSuperLayer = {1, -1}
	Allowed ADC range (first super layer of CDC). More...

intRange_t	m_ADCRangeOuterSuperLayers = {1, -1}
	Allowed ADC range (outer super layers of CDC). More...

intRange_t	m_TOTRangeFirstSuperLayer = {1, -1}
	Allowed TOT range (first super layer of CDC). More...

intRange_t	m_TOTRangeOuterSuperLayers = {1, -1}
	Allowed TOT range (outer super layers of CDC). More...

floatRange_t	m_ADCOverTOTRangeFirstSuperLayer = {0.0, -1.0}
	Allowed ADC/TOT range (first super layer of CDC). More...

floatRange_t	m_ADCOverTOTRangeOuterSuperLayers = {0.0, -1.0}
	Allowed ADC/TOT range (outer super layers of CDC). More...

std::map< short, short >	m_MaxADCGivenTOTFirstSuperLayer = {}
	Map of conditions of the type: if TOT==x, then ADC<=y (first super layer of CDC). More...

std::map< short, short >	m_MaxADCGivenTOTOuterSuperLayers = {}
	Map of conditions of the type: if TOT==x, then ADC<=y (outer super layers of CDC). More...

Detailed Description

Database object containing cut values to filter CDCWireHits.

The set of conditions is: {minADC<=ADC<=maxADC, minTOT<=TOT<=maxTOT, minADCOverTOT<=ADC/TOT<=maxACDOverTOT, if TOT==x, then ADC<=y (std::map)}. The first super layer of the CDC can have specific requirements. The other super layers of the CDC (outer super layers) share a single set of conditions. In the allowed range for ADC, TOT, ..., an upper value of -1 stands for unbounded. For example, the ADC range {5,-1} accepts all the hits with ADC>=5.

Definition at line 44 of file CDCWireHitRequirements.h.

Member Typedef Documentation

◆ floatRange_t

typedef std::pair<float, float> floatRange_t

private

Float range.

The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range. An upper value of -1 stands for unbounded.

Definition at line 57 of file CDCWireHitRequirements.h.

◆ intRange_t

typedef std::pair<short, short> intRange_t

private

Integer range.

The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range. An upper value of -1 stands for unbounded.

Definition at line 51 of file CDCWireHitRequirements.h.

Member Data Documentation

◆ m_ADCOverTOTRangeFirstSuperLayer

floatRange_t m_ADCOverTOTRangeFirstSuperLayer = {0.0, -1.0}

private

Allowed ADC/TOT range (first super layer of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 292 of file CDCWireHitRequirements.h.

◆ m_ADCOverTOTRangeOuterSuperLayers

floatRange_t m_ADCOverTOTRangeOuterSuperLayers = {0.0, -1.0}

private

Allowed ADC/TOT range (outer super layers of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 296 of file CDCWireHitRequirements.h.

◆ m_ADCRangeFirstSuperLayer

intRange_t m_ADCRangeFirstSuperLayer = {1, -1}

private

Allowed ADC range (first super layer of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 274 of file CDCWireHitRequirements.h.

◆ m_ADCRangeOuterSuperLayers

intRange_t m_ADCRangeOuterSuperLayers = {1, -1}

private

Allowed ADC range (outer super layers of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 278 of file CDCWireHitRequirements.h.

◆ m_MaxADCGivenTOTFirstSuperLayer

std::map<short, short> m_MaxADCGivenTOTFirstSuperLayer = {}

private

Map of conditions of the type: if TOT==x, then ADC<=y (first super layer of CDC).

An upper value of -1 stands for unbounded. The first value is the given TOT, the second value is the maximum ADC. The upper bound is included in the allowed range.

Definition at line 301 of file CDCWireHitRequirements.h.

◆ m_MaxADCGivenTOTOuterSuperLayers

std::map<short, short> m_MaxADCGivenTOTOuterSuperLayers = {}

private

Map of conditions of the type: if TOT==x, then ADC<=y (outer super layers of CDC).

An upper value of -1 stands for unbounded. The first value is the given TOT, the second value is the maximum ADC. The upper bound is included in the allowed range.

Definition at line 305 of file CDCWireHitRequirements.h.

◆ m_TOTRangeFirstSuperLayer

intRange_t m_TOTRangeFirstSuperLayer = {1, -1}

private

Allowed TOT range (first super layer of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 283 of file CDCWireHitRequirements.h.

◆ m_TOTRangeOuterSuperLayers

intRange_t m_TOTRangeOuterSuperLayers = {1, -1}

private

Allowed TOT range (outer super layers of CDC).

An upper value of -1 stands for unbounded. The first value is the lower bound, the second value is the upper bound. The two bounds are included in the allowed range.

Definition at line 287 of file CDCWireHitRequirements.h.

The documentation for this class was generated from the following file:

cdc/dbobjects/include/CDCWireHitRequirements.h
