Class to contain the payload of MVA weightfiles needed for charged particle identification. More...

#include <ChargedPidMVAWeights.h>

Inheritance diagram for ChargedPidMVAWeights:

Collaboration diagram for ChargedPidMVAWeights:

[legend]

Public Types
enum	ChargedPidMVATrainingMode : unsigned int { c_Classification = 0, c_Multiclass = 1, c_ECL_Classification = 2, c_ECL_Multiclass = 3, c_PSD_Classification = 4, c_PSD_Multiclass = 5, c_ECL_PSD_Classification = 6, c_ECL_PSD_Multiclass = 7 }
	A (strongly-typed) enumerator identifier for each valid MVA training mode. More...

Public Member Functions
	ChargedPidMVAWeights ()
	Default constructor, necessary for ROOT to stream the object.

	~ChargedPidMVAWeights ()
	Destructor.

void	setEnergyUnit (const double &unit)
	Set the energy unit to ensure consistency w/ the one used to define the bins grid.

void	setAngularUnit (const double &unit)
	Set the angular unit to ensure consistency w/ the one used to define the bins grid.

void	setWeightCategories (TH2F *h)
	Set the 2D (clusterTheta, p) grid representing the categories for which weightfiles are defined. More...

void	storeMVAWeights (const int pdg, const std::vector< std::string > &filepaths, const std::vector< std::pair< float, float >> &categoryBinCentres)
	Given a particle mass hypothesis' pdgId, store the list of MVA weight files (one for each category) into the payload. More...

void	storeMVAWeightsMultiClass (const std::vector< std::string > &filepaths, const std::vector< std::pair< float, float >> &categoryBinCentres)
	For the multi-class mode, store the list of MVA weight files (one for each category) into the payload. More...

void	storeCuts (const int pdg, const std::vector< std::string > &cutfiles, const std::vector< std::pair< float, float >> &categoryBinCentres)
	Given a particle mass hypothesis' pdgId, store the list of selection cuts (one for each category) into the payload. More...

void	storeCutsMultiClass (const std::vector< std::string > &cutfiles, const std::vector< std::pair< float, float >> &categoryBinCentres)
	For the multi-class mode, store the list of selection cuts (one for each category) into the payload. More...

const std::vector< std::string > *	getMVAWeights (const int pdg) const
	Given a particle mass hypothesis' pdgId, get the list of (serialized) MVA weightfiles stored in the payload, one for each (clusterTheta, p) category. More...

const std::vector< std::string > *	getMVAWeightsMulticlass () const
	For the multi-class mode, get the list of (serialized) MVA weightfiles stored in the payload, one for each (clusterTheta, p) category.

const std::vector< std::string > *	getCuts (const int pdg) const
	Given a particle mass hypothesis' pdgId, get the list of selection cuts stored in the payload, one for each (clusterTheta, p) category. More...

const std::vector< std::string > *	getCutsMulticlass () const
	For the multi-class mode, get the list of selection cuts stored in the payload, one for each (clusterTheta, p) category.

unsigned int	getMVAWeightIdx (const double &theta, const double &p, int &jth, int &ip) const
	Get the index of the XML weight file, for a given reconstructed pair (clusterTheta, p). More...

unsigned int	getMVAWeightIdx (const double &theta, const double &p) const
	Overloaded method, to be used if not interested in knowing the 2D (clusterTheta, p) bin coordinates.

void	dumpPayload (const double &theta, const double &p, const int pdg, bool dump_all=false) const
	Read and dump the payload content from the internal 'matrioska' maps into an XML weightfile for the given set of inputs. More...

void	dumpPayloadMulticlass (const double &theta, const double &p) const
	Special version for multi-class mode.

bool	isValidPdg (const int pdg) const
	Check if the input pdgId is that of a valid charged particle. More...

Private Types
typedef std::unordered_map< int, std::vector< std::string > >	WeightfilesByParticle
	Typedef.

Private Member Functions
int	findBin (const TH2F *h, const double &x, const double &y) const
	Find global bin index of a 2D histogram for the given (x, y) values. More...

	ClassDef (ChargedPidMVAWeights, 5)
	2: add energy/angular units. More...

Private Attributes
TParameter< double >	m_energy_unit
	The energy unit used for defining the bins grid.

TParameter< double >	m_ang_unit
	The angular unit used for defining the bins grid.

TH2F *	m_categories = nullptr
	A 2D (clusterTheta, p) histogram whose bins represent the categories for which XML weight files are defined. More...

WeightfilesByParticle	m_weightfiles
	For each charged particle mass hypothesis' pdgId, this map contains a list of (serialized) Weightfile objects to be stored in the payload. More...

WeightfilesByParticle	m_cuts
	For each charged particle mass hypothesis' pdgId, this map contains a list of selection cuts to be stored in the payload. More...

Detailed Description

Class to contain the payload of MVA weightfiles needed for charged particle identification.

Definition at line 48 of file ChargedPidMVAWeights.h.

Member Enumeration Documentation

◆ ChargedPidMVATrainingMode

enum ChargedPidMVATrainingMode : unsigned int

strong

A (strongly-typed) enumerator identifier for each valid MVA training mode.

Enumerator
c_Classification	Binary classification.
c_Multiclass	Multi-class classification.
c_ECL_Classification	Binary classification, ECL only.
c_ECL_Multiclass	Multi-class classification, ECL only.
c_PSD_Classification	Binary classification, including PSD.
c_PSD_Multiclass	Multi-class classification, including PSD.
c_ECL_PSD_Classification	Binary classification, ECL only, including PSD.
c_ECL_PSD_Multiclass	Multi-class classification, ECL only, including PSD.

Definition at line 71 of file ChargedPidMVAWeights.h.

                                            { m_energy_unit.SetVal(unit); }



Member Function Documentation

◆ ClassDef()

ClassDef	(	ChargedPidMVAWeights	,
		5
	)

private

2: add energy/angular units.

remove 2D grid dependence on pdgId, add multi-class support, define enum for valid training modes4. add cuts map.3. add overloaded getMVAWeightIdx. 1: first class implementation.

◆ dumpPayload()

void dumpPayload	(	const double &	theta,
		const double &	p,
		const int	pdg,
		bool	dump_all = `false`
	)		const

inline

Read and dump the payload content from the internal 'matrioska' maps into an XML weightfile for the given set of inputs.

Useful for debugging.

Parameters

theta	the particle polar angle (from the ECL cluster) in [rad].
p	the particle momentum (from the track) in [GeV/c].
pdg	the particle mass hypothesis' pdgId.
dump_all	dump all information

Definition at line 333 of file ChargedPidMVAWeights.h.

◆ findBin()

int findBin	(	const TH2F *	h,
		const double &	x,
		const double &	y
	)		const

inlineprivate

Find global bin index of a 2D histogram for the given (x, y) values.

This method had to be re-implemented b/c ROOT has no const version of TH1::FindBin() :(

Parameters

h	2D histogram
x	value along the x axis.
y	value along the y axis.

Returns: the global linearised bin index.

Definition at line 409 of file ChargedPidMVAWeights.h.

◆ getCuts()

const std::vector<std::string>* getCuts ( const int pdg ) const

inline

Given a particle mass hypothesis' pdgId, get the list of selection cuts stored in the payload, one for each (clusterTheta, p) category.

Parameters

pdg	the particle mass hypothesis' pdgId.
pdg	the particle mass hypothesis' pdgId.

Definition at line 267 of file ChargedPidMVAWeights.h.

◆ getMVAWeightIdx()

unsigned int getMVAWeightIdx	(	const double &	theta,
		const double &	p,
		int &	jth,
		int &	ip
	)		const

inline

Get the index of the XML weight file, for a given reconstructed pair (clusterTheta, p).

The index is obtained by linearising the 2D m_categories histogram. The same index can be used to look up the correct MVAExpert, Dataset and Cut in the application module, hence we believe it's more useful to return the index rather than a pointer to the weightfile itself. The function also retrieves the (clusterTheta, p) bin coordinates.

Parameters

	theta	the particle polar angle (from the ECL cluster) in [rad].
	p	the particle momentum (from the track) in [GeV/c].
[out]	jth	the index of the (theta, p) bin along the theta (X) axis.
[out]	ip	the index of the (theta, p) bin along the p (Y) axis.

Returns: the index of the weightfile of interest from the array of weightfiles.

Definition at line 295 of file ChargedPidMVAWeights.h.

◆ getMVAWeights()

const std::vector<std::string>* getMVAWeights ( const int pdg ) const

inline

Given a particle mass hypothesis' pdgId, get the list of (serialized) MVA weightfiles stored in the payload, one for each (clusterTheta, p) category.

Parameters

pdg	the particle mass hypothesis' pdgId.

Definition at line 245 of file ChargedPidMVAWeights.h.

◆ isValidPdg()

bool isValidPdg ( const int pdg ) const

inline

Check if the input pdgId is that of a valid charged particle.

An input value of pdg=0 is considered valid, since it's reserved for multi-class mode.

Definition at line 391 of file ChargedPidMVAWeights.h.

◆ setWeightCategories()

void setWeightCategories ( TH2F * h )

inline

Set the 2D (clusterTheta, p) grid representing the categories for which weightfiles are defined.

Parameters

h	the 2D histogram.

Definition at line 107 of file ChargedPidMVAWeights.h.

◆ storeCuts()

void storeCuts	(	const int	pdg,
		const std::vector< std::string > &	cutfiles,
		const std::vector< std::pair< float, float >> &	categoryBinCentres
	)

inline

Given a particle mass hypothesis' pdgId, store the list of selection cuts (one for each category) into the payload.

Parameters

pdg	the particle mass hypothesis' pdgId.
cutfiles	a list of text files w/ cut strings, for each (clusterTheta, p) category. The format of the cut must comply with the `GeneralCut` syntax.
categoryBinCentres	a list of pair<float, float> representing the (clusterTheta,p) bin centres. Used to check consistency of the xml vector indexing w/ the linearised TH2 category map.

Definition at line 188 of file ChargedPidMVAWeights.h.

◆ storeCutsMultiClass()

void storeCutsMultiClass	(	const std::vector< std::string > &	cutfiles,
		const std::vector< std::pair< float, float >> &	categoryBinCentres
	)

inline

For the multi-class mode, store the list of selection cuts (one for each category) into the payload.

Parameters

cutfiles	a list of text files w/ cut strings, for each (clusterTheta, p) category. The format of the cut must comply with the `GeneralCut` syntax.
categoryBinCentres	a list of pair<float, float> representing the (clusterTheta,p) bin centres. Used to check consistency of the xml vector indexing w/ the linearised TH2 category map.

Definition at line 234 of file ChargedPidMVAWeights.h.

◆ storeMVAWeights()

void storeMVAWeights	(	const int	pdg,
		const std::vector< std::string > &	filepaths,
		const std::vector< std::pair< float, float >> &	categoryBinCentres
	)

inline

Given a particle mass hypothesis' pdgId, store the list of MVA weight files (one for each category) into the payload.

Parameters

pdg	the particle mass hypothesis' pdgId.
filepaths	a list of xml (root) file paths for several (clusterTheta,p) categories.
categoryBinCentres	a list of pair<float, float> representing the (clusterTheta,p) bin centres. Used to check consistency of the xml vector indexing w/ the linearised TH2 category map.

Definition at line 121 of file ChargedPidMVAWeights.h.

◆ storeMVAWeightsMultiClass()

void storeMVAWeightsMultiClass	(	const std::vector< std::string > &	filepaths,
		const std::vector< std::pair< float, float >> &	categoryBinCentres
	)

inline

For the multi-class mode, store the list of MVA weight files (one for each category) into the payload.

Parameters

filepaths	a list of xml (root) file paths for several (clusterTheta,p) categories.
categoryBinCentres	a list of pair<float, float> representing the (clusterTheta,p) bin centres. Used to check consistency of the xml vector indexing w/ the linearised TH2 category map.

Definition at line 171 of file ChargedPidMVAWeights.h.

Member Data Documentation

◆ m_categories

TH2F* m_categories = nullptr

private

A 2D (clusterTheta, p) histogram whose bins represent the categories for which XML weight files are defined.

It is used to lookup the correct file in the payload, given a reconstructed pair (clusterTheta, p).

Definition at line 444 of file ChargedPidMVAWeights.h.

◆ m_cuts

WeightfilesByParticle m_cuts

private

Initial value:

= {
      { 0, std::vector<std::string>() },
      { Const::electron.getPDGCode(), std::vector<std::string>() },
      { Const::muon.getPDGCode(), std::vector<std::string>() },
      { Const::pion.getPDGCode(), std::vector<std::string>() },
      { Const::kaon.getPDGCode(), std::vector<std::string>() },
      { Const::proton.getPDGCode(), std::vector<std::string>() },
      { Const::deuteron.getPDGCode(), std::vector<std::string>() }
    }

For each charged particle mass hypothesis' pdgId, this map contains a list of selection cuts to be stored in the payload.

To each Weightfile (i.e., category) corresponds a cut. The indexing in each vector must reflect the one of the corresponding 'linearised' TH2F histogram contained in the m_grids map.

The dummy pdgId=0 key is reserved for multi-class, where a unique signal hypothesis is not defined.

Definition at line 474 of file ChargedPidMVAWeights.h.

◆ m_weightfiles

WeightfilesByParticle m_weightfiles

private

Initial value:

= {
      { 0, std::vector<std::string>() },
      { Const::electron.getPDGCode(), std::vector<std::string>() },
      { Const::muon.getPDGCode(), std::vector<std::string>() },
      { Const::pion.getPDGCode(), std::vector<std::string>() },
      { Const::kaon.getPDGCode(), std::vector<std::string>() },
      { Const::proton.getPDGCode(), std::vector<std::string>() },
      { Const::deuteron.getPDGCode(), std::vector<std::string>() }
    }

For each charged particle mass hypothesis' pdgId, this map contains a list of (serialized) Weightfile objects to be stored in the payload.

Each weightfile in the list corresponds to a (clusterTheta, p) category. The indexing in each vector must reflect the one of the corresponding 'linearised' TH2F histogram contained in the m_grids map.

The dummy pdgId=0 key is reserved for multi-class, where a unique signal hypothesis is not defined.

Definition at line 455 of file ChargedPidMVAWeights.h.

The documentation for this class was generated from the following file:

analysis/dbobjects/include/ChargedPidMVAWeights.h

Public Types

Public Member Functions

Private Types

Private Member Functions

Private Attributes

Detailed Description

Member Enumeration Documentation

◆ ChargedPidMVATrainingMode

Member Function Documentation

◆ ClassDef()

◆ dumpPayload()

◆ findBin()

◆ getCuts()

◆ getMVAWeightIdx()

◆ getMVAWeights()

◆ isValidPdg()

◆ setWeightCategories()

◆ storeCuts()

◆ storeCutsMultiClass()

◆ storeMVAWeights()

◆ storeMVAWeightsMultiClass()

Member Data Documentation

◆ m_categories

◆ m_cuts

◆ m_weightfiles
