Class to collect log likelihoods from TOP, ARICH, dEdx, ECL and KLM aimed for output to mdst includes functions to return combined likelihood probability. More...

#include <PIDLikelihood.h>

Inheritance diagram for PIDLikelihood:

[legend]

Collaboration diagram for PIDLikelihood:

[legend]

Public Member Functions
	PIDLikelihood ()
	Default constructor: log likelihoods and flags set to 0.

void	setLogLikelihood (Const::EDetector det, const Const::ChargedStable &part, float logl)
	Set log likelihood for a given detector and particle. More...

bool	isAvailable (Const::PIDDetectorSet set) const
	Check whether PID information from a given set of detectors is available. More...

float	getLogL (const Const::ChargedStable &part, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return log likelihood for a given detector set and particle. More...

float	getDeltaLogL (const Const::ChargedStable &p1, const Const::ChargedStable &p2, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return log likelihood difference for a given detector set and particles. More...

double	getProbability (const Const::ChargedStable &p1, const Const::ChargedStable &p2, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return combined likelihood probability for a particle being p1 and not p2, assuming equal prior probabilities. More...

double	getProbability (const Const::ChargedStable &p1, const Const::ChargedStable &p2, double ratio, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return combined likelihood probability for a particle being p1 and not p2. More...

double	getProbability (const Const::ChargedStable &part, const double *fractions=0, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return combined likelihood probability for a particle according to chargedStableSet; if prior fractions not given equal prior probabilities assumed. More...

Const::ChargedStable	getMostLikely (const double *fractions=0, Const::PIDDetectorSet set=Const::PIDDetectorSet::set()) const
	Return most likely particle among chargedStableSet; if prior fractions not given equal prior probabilities assumed. More...

void	printArray () const
	Prints the content of a private array of log likelihoods.

std::string	getInfoHTML () const
	Return HTML Info of PID Likelihoods.

void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...

void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...

void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...

template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...

template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...

template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...

virtual std::string	getName () const
	Return a short name that describes this object, e.g. More...

std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...

std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.

int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Protected Member Functions
TClonesArray *	getArrayPointer () const
	Returns the pointer to the raw DataStore array holding this object (protected since these arrays are easy to misuse).

Private Member Functions
void	probability (double probabilities[], const double *fractions, Const::PIDDetectorSet detSet) const
	Calculate likelihood probabilities. More...

	ClassDef (PIDLikelihood, 3)
	Collect log likelihoods from TOP, ARICH, dEdx, ECL and KLM.

Private Attributes
Const::DetectorSet	m_detectors
	set of detectors with PID information

float	m_logl [Const::PIDDetectors::c_size][Const::ChargedStable::c_SetSize]
	log likelihoods

DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.

int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Detailed Description

Class to collect log likelihoods from TOP, ARICH, dEdx, ECL and KLM aimed for output to mdst includes functions to return combined likelihood probability.

Definition at line 37 of file PIDLikelihood.h.

Member Function Documentation

◆ addRelationTo() [1/2]

void addRelationTo	(	const RelationsInterface< BASE > *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo	(	const TObject *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > * sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ getDeltaLogL()

float getDeltaLogL	(	const Const::ChargedStable &	p1,
		const Const::ChargedStable &	p2,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

inline

Return log likelihood difference for a given detector set and particles.

Parameters

p1	charged stable particle
p2	charged stable particle
set	a set of PID detectors to use

Returns: log likelihood difference logL_p1 - logL_p2

Definition at line 79 of file PIDLikelihood.h.

◆ getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note: : You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getLogL()

float getLogL	(	const Const::ChargedStable &	part,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

Return log likelihood for a given detector set and particle.

Parameters

part	charged stable particle
set	a set of PID detectors to use

Returns: log likelihood

Definition at line 56 of file PIDLikelihood.cc.

 {
   float result = 0;
   for (unsigned int index = 0; index < Const::PIDDetectorSet::set().size(); ++index) {
     if (set.contains(Const::PIDDetectorSet::set()[index]))
       result += m_logl[index][part.getIndex()];
   }
   return result;
 }

◆ getMostLikely()

Const::ChargedStable getMostLikely	(	const double *	fractions = `0`,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

Return most likely particle among chargedStableSet; if prior fractions not given equal prior probabilities assumed.

Parameters

fractions	array of prior probabilities in the order defined in Const::ChargedStable
set	a set of PID detectors to use

Returns: particle type

Definition at line 108 of file PIDLikelihood.cc.

◆ getName()

virtual std::string getName ( ) const

inlinevirtualinherited

Return a short name that describes this object, e.g.

pi+ for an MCParticle.

Reimplemented in SpacePoint, Particle, and MCParticle.

Definition at line 346 of file RelationsObject.h.

◆ getProbability() [1/3]

double getProbability	(	const Const::ChargedStable &	p1,
		const Const::ChargedStable &	p2,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

inline

Return combined likelihood probability for a particle being p1 and not p2, assuming equal prior probabilities.

Parameters

p1	charged stable particle
p2	charged stable particle
set	a set of PID detectors to use

Returns: likelihood probability

Definition at line 94 of file PIDLikelihood.h.

◆ getProbability() [2/3]

double getProbability	(	const Const::ChargedStable &	p1,
		const Const::ChargedStable &	p2,
		double	ratio,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

Return combined likelihood probability for a particle being p1 and not p2.

Parameters

p1	charged stable particle
p2	charged stable particle
ratio	ratio of prior probabilities (p1/p2)
set	a set of PID detectors to use

Returns: likelihood probability

Definition at line 68 of file PIDLikelihood.cc.

◆ getProbability() [3/3]

double getProbability	(	const Const::ChargedStable &	part,
		const double *	fractions = `0`,
		Const::PIDDetectorSet	set = `Const::PIDDetectorSet::set()`
	)		const

Return combined likelihood probability for a particle according to chargedStableSet; if prior fractions not given equal prior probabilities assumed.

Parameters

part	charged stable particle
fractions	array of prior probabilities in the order defined in Const::ChargedStable
set	a set of PID detectors to use

Returns: likelihood probability (a value btw. 0 and 1)

Definition at line 94 of file PIDLikelihood.cc.

◆ getRelated()

T* getRelated	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ isAvailable()

bool isAvailable ( Const::PIDDetectorSet set ) const

inline

Check whether PID information from a given set of detectors is available.

Parameters

set	a set of PID detectors

Returns: true if the given set of detectors contributed to the PID information

Definition at line 61 of file PIDLikelihood.h.

◆ probability()

void probability	(	double	probabilities[],
		const double *	fractions,
		Const::PIDDetectorSet	detSet
	)		const

private

Calculate likelihood probabilities.

Parameters

fractions	array of prior fractions (not needed to be normalized)
probabilities	array of resulting probabilities
detSet	a set of PID detectors to use

Definition at line 125 of file PIDLikelihood.cc.

◆ setLogLikelihood()

void setLogLikelihood	(	Const::EDetector	det,
		const Const::ChargedStable &	part,
		float	logl
	)

Set log likelihood for a given detector and particle.

Parameters

det	detector enumerator
part	charged stable particle
logl	log likelihood

Definition at line 35 of file PIDLikelihood.cc.

The documentation for this class was generated from the following files:

mdst/dataobjects/include/PIDLikelihood.h
mdst/dataobjects/src/PIDLikelihood.cc

Public Member Functions

Protected Member Functions

Private Member Functions

Private Attributes

Detailed Description

Member Function Documentation

◆ addRelationTo() [1/2]

◆ addRelationTo() [2/2]

◆ copyRelations()

◆ getDeltaLogL()

◆ getInfo()

◆ getLogL()

◆ getMostLikely()

◆ getName()

◆ getProbability() [1/3]

◆ getProbability() [2/3]

◆ getProbability() [3/3]

◆ getRelated()

◆ getRelatedFrom()

◆ getRelatedFromWithWeight()

◆ getRelatedTo()

◆ getRelatedToWithWeight()

◆ getRelatedWithWeight()

◆ getRelationsFrom()

◆ getRelationsTo()

◆ getRelationsWith()

◆ isAvailable()

◆ probability()

◆ setLogLikelihood()
