ParticleGun Class Reference

Class to generate tracks in the particle gun and store them in a MCParticle graph. More...

#include <ParticleGun.h>

Collaboration diagram for ParticleGun:

Classes

struct  Parameters
 Struct to keep all necessary parameters for the particle gun. More...


Public Types

enum  EDistribution {
  c_fixedValue,
  c_uniformDistribution,
  c_uniformPtDistribution,
  c_uniformCosDistribution,
  c_uniformLogDistribution,
  c_uniformLogPtDistribution,
  c_normalDistribution,
  c_normalPtDistribution,
  c_normalCosDistribution,
  c_discreteSpectrum,
  c_discretePtSpectrum,
  c_inversePtDistribution,
  c_polylineDistribution,
  c_polylinePtDistribution,
  c_polylineCosDistribution
}
 enum containing all known distributions available for generation of values More...


Public Member Functions

 ParticleGun ()
 Default constructor.

 ~ParticleGun ()
 Default destructor.

bool generateEvent (MCParticleGraph &graph)
 Generate the next event and store the result in the given MCParticle graph. More...

bool setParameters (const Parameters &parameters)
 Set the parameters for generating the Particles.


Protected Member Functions

double generateValue (EDistribution dist, const std::vector< double > &params)
 Generate a value according to the given distribution with the given parameters.


Protected Attributes

Parameters m_params
 All relevant parameters.


Detailed Description

Class to generate tracks in the particle gun and store them in a MCParticle graph.

The class supports multiple tracks per event, different PDGcodes and the range for track momenta, track angle and track origin is configurable.

Definition at line 36 of file ParticleGun.h.

Member Enumeration Documentation

◆ EDistribution

enum containing all known distributions available for generation of values

Enumerator
c_fixedValue

Fixed value, no random generation at all, 1 parameter.

c_uniformDistribution

Uniform distribution, parameters are min and max value.

c_uniformPtDistribution

Uniform distribution of Pt, parameters are min and max value.

c_uniformCosDistribution

Uniform distribution of the cosine of the values, parameters are min and max value.

c_uniformLogDistribution

Uniform distribution of the logarithm of the values, parameters are min and max value.

c_uniformLogPtDistribution

Uniform distribution of the logarithm of the Pt, parameters are min and max value.

c_normalDistribution

Normal distribution, parameters are mean and sigma.

c_normalPtDistribution

Normal distribution of Pt, parameters are mean and sigma.

c_normalCosDistribution

Normal distribution of the cosinge, parameters are mean and sigma.

c_discreteSpectrum

Discrete spectrum, parameters are first the values and then the weights (non-negative) for each value.

c_discretePtSpectrum

Discrete pt spectrum, parameters are first the values and then the weights (non-negative) for each value.

c_inversePtDistribution

Distribution uniform in the inverse pt distribution, that is uniform in track curvature.

c_polylineDistribution

Distribution given as list of (x,y) points.

The Distribution will follow the line connection all points. Parameters are first the x coordinates (sorted) and then the y coordinates (non-negative)

c_polylinePtDistribution

Same as polylineDistribution but for the transverse momentum.

c_polylineCosDistribution

Same as polylineDistribution but for the cosine of the angle.

Definition at line 39 of file ParticleGun.h.

67  {
69  EDistribution momentumDist = c_fixedValue;
71  EDistribution phiDist = c_fixedValue;

Member Function Documentation

◆ generateEvent()

bool generateEvent ( MCParticleGraph graph)

Generate the next event and store the result in the given MCParticle graph.

Returns
true if the event was generated.

Definition at line 121 of file ParticleGun.cc.

122 {
123  //generate the event vertex (possible the same for all particles in event)
127
128  // Time offset
129  double timeOffset = generateValue(m_params.timeDist, m_params.timeParams);
130
131  //Determine number of tracks
132  int nTracks = static_cast<int>(m_params.nTracks);
133  if (m_params.nTracks <= 0) {
134  nTracks = m_params.pdgCodes.size();
135  } else if (m_params.varyNumberOfTracks) {
136  nTracks = gRandom->Poisson(m_params.nTracks);
137  }
138
139  //Make list of particles
140  double firstMomentum;
141  for (int i = 0; i < nTracks; ++i) {
143  p.setStatus(MCParticle::c_PrimaryParticle);
144  if (m_params.pdgCodes.size() == 1) {
145  //only one PDGcode available, always take this one
146  p.setPDG(m_params.pdgCodes[0]);
147  } else if (m_params.nTracks <= 0) {
148  //0 or negative nTracks, take the ids sequentially
149  p.setPDG(m_params.pdgCodes[i]);
150  } else {
151  //else choose randomly one of the available codes
152  int index = static_cast<int>(gRandom->Uniform(m_params.pdgCodes.size()));
153  p.setPDG(m_params.pdgCodes[index]);
154  }
155  p.setMassFromPDG();
156  p.setFirstDaughter(0);
157  p.setLastDaughter(0);
158
159  //lets generate the momentum vector:
161  // if the fixed momentum option enabled, either store the generated momentum for the first
162  // particle or reuse for all others
164  i == 0 ? firstMomentum = momentum : momentum = firstMomentum;
165  }
168
169  double pt = momentum * sin(theta);
173  //this means we are actually generating the Pt and not the P, so exchange values
174  pt = momentum;
175  momentum = (sin(theta) > 0) ? (pt / sin(theta)) : numeric_limits<double>::max();
176  }
177
178  double pz = momentum * cos(theta);
179  double px = pt * cos(phi);
180  double py = pt * sin(phi);
181  double m = p.getMass();
182  double e = sqrt(momentum * momentum + m * m);
183
184  p.setMomentum(px, py, pz);
185  p.setEnergy(e);
186  p.setProductionVertex(vx, vy, vz);
187  p.addStatus(MCParticle::c_StableInGenerator);
188  //Particle is stable in generator. We could use MCParticleGraph options to
189  //do this automatically but setting it here makes the particle correct
190  //independent of the options
191  p.setDecayTime(numeric_limits<double>::infinity());
192
193  // set time offset to check fit bias in e.g. the ECL waveform fits
194  p.setProductionTime(timeOffset);
195
197  //If we have independent vertices, generate new vertex for next particle
201  }
202  }// end loop over particles in event
203
204  return true;
205 }

The documentation for this class was generated from the following files:
