Belle II Software  release-05-01-25
QualityEstimatorTripletFit Class Referencefinal

does a tripletFit of the given hits The filter is based on the paper 'A New Three-Dimensional Track Fit with Multiple Scattering' by Andre Schoening et al. More...

#include <QualityEstimatorTripletFit.h>

Inheritance diagram for QualityEstimatorTripletFit:
Collaboration diagram for QualityEstimatorTripletFit:

Public Member Functions

virtual double estimateQuality (std::vector< SpacePoint const * > const &measurements) final
 Calculating the quality estimate using a triplet fit. More...

virtual QualityEstimationResults estimateQualityAndProperties (std::vector< SpacePoint const * > const &measurements) final
 perform quality estimation and extract additional information from the fit More...

void setMagneticFieldStrength (double magneticFieldZ=1.5)
 Setter for z component of magnetic field. More...


Protected Member Functions

double calcPt (double const radius) const
 Returns a value for the transverse momentum in GeV calculated from a provided radius. More...


Protected Attributes

std::vector< double > m_alphas
 angle alpha

std::vector< double > m_thetas
 angle theta

std::vector< double > m_R3Ds
 3D radius

std::vector< double > m_sigmaR3DSquareds
 squared error of 3D radius

double m_averageR3D = 0
 average 3D radius

double m_materialBudgetFactor = 1.45
 Triplet Fit hyper parameters. More...

double m_maxPt = 0.01
 Cut off value for 3D Radius calculated in Triplet Fit. More...

double m_magneticFieldZ = 1.5
 Member storing the z component of the magnetic field.

QualityEstimationResults m_results
 Result of the quality estimation This is stored as a member variable, because some values may be calculated by 'estimateQuality' anyways. More...


Detailed Description

does a tripletFit of the given hits The filter is based on the paper 'A New Three-Dimensional Track Fit with Multiple Scattering' by Andre Schoening et al.

https://arxiv.org/abs/1606.04990

Definition at line 31 of file QualityEstimatorTripletFit.h.

Member Function Documentation

◆ calcPt()

double calcPt ( double const  radius) const
inlineprotectedinherited

Returns a value for the transverse momentum in GeV calculated from a provided radius.

Utilizing m_magneticFieldZ and hard coded speed of light

Definition at line 91 of file QualityEstimatorBase.h.

◆ estimateQuality()

double estimateQuality ( std::vector< SpacePoint const * > const &  measurements)
finalvirtual

Calculating the quality estimate using a triplet fit.

Parameters
measurements: vector of SPs of the track candidate
Returns
quality indicator value

Using average material budged of SVD sensors for approximation of radiation length Belle II TDR page 156 states a value of 0.57% X_0. This approximation is a first approach to the problem and must be checked.

Implements QualityEstimatorBase.

Definition at line 24 of file QualityEstimatorTripletFit.cc.

25 {
26  const int nTriplets = measurements.size() - 2;
27
28  if (nTriplets < 1) return 0;
29
30  double combinedChi2 = 0.;
31
32  // values required for pt calculation
33  m_R3Ds.clear();
34  m_R3Ds.reserve(nTriplets);
35  m_sigmaR3DSquareds.clear();
36  m_sigmaR3DSquareds.reserve(nTriplets);
37  m_alphas.clear();
38  m_alphas.reserve(nTriplets);
39  m_thetas.clear();
40  m_thetas.reserve(nTriplets);
41
42  // looping over all triplets
43  for (int i = 0; i < nTriplets; i++) {
44
45  // Three hits relevant for curent triplet
46  const TVector3 hit0 = measurements.at(i)->getPosition();
47  const TVector3 hit1 = measurements.at(i + 1)->getPosition();
48  const TVector3 hit2 = measurements.at(i + 2)->getPosition();
49
50  const double d01sq = pow(hit1.X() - hit0.X(), 2) + pow(hit1.Y() - hit0.Y(), 2);
51  const double d12sq = pow(hit2.X() - hit1.X(), 2) + pow(hit2.Y() - hit1.Y(), 2);
52  const double d02sq = pow(hit2.X() - hit0.X(), 2) + pow(hit2.Y() - hit0.Y(), 2);
53
54  const double d01 = sqrt(d01sq);
55  const double d12 = sqrt(d12sq);
56  const double d02 = sqrt(d02sq);
57
58  const double z01 = hit1.Z() - hit0.Z();
59  const double z12 = hit2.Z() - hit1.Z();
60
61  const double R_C = (d01 * d12 * d02) / sqrt(-d01sq * d01sq - d12sq * d12sq - d02sq * d02sq + 2 * d01sq * d12sq + 2 * d12sq * d02sq +
62  2 *
63  d02sq * d01sq);
64
65  const double Phi1C = 2. * asin(d01 / (2. * R_C));
66  const double Phi2C = 2. * asin(d12 / (2. * R_C));
67  // TODO Phi1C and Phi2C have 2 solutions (<Pi and >Pi), each, of which the correct one must be chosen!
68
69  const double R3D1C = sqrt(R_C * R_C + (z01 * z01) / (Phi1C * Phi1C));
70  const double R3D2C = sqrt(R_C * R_C + (z12 * z12) / (Phi2C * Phi2C));
71
72  const double theta1C = acos(z01 / (Phi1C * R3D1C));
73  const double theta2C = acos(z12 / (Phi2C * R3D2C));
74  const double theta = (theta1C + theta2C) / 2.;
75
76  double alpha1 = R_C * R_C * Phi1C * Phi1C + z01 * z01;
77  alpha1 *= 1. / (0.5 * R_C * R_C * Phi1C * Phi1C * Phi1C / tan(Phi1C / 2.) + z01 * z01);
78  double alpha2 = R_C * R_C * Phi2C * Phi2C + z12 * z12;
79  alpha2 *= 1. / (0.5 * R_C * R_C * Phi2C * Phi2C * Phi2C / tan(Phi2C / 2.) + z12 * z12);
80
81  const double PhiTilde = - 0.5 * (Phi1C * alpha1 + Phi2C * alpha2);
82  const double eta = 0.5 * Phi1C * alpha1 / R3D1C + 0.5 * Phi2C * alpha2 / R3D2C;
83  const double ThetaTilde = theta2C - theta1C - (1 - alpha2) / tan(theta2C) + (1 - alpha1) / tan(theta1C);
84  const double beta = (1 - alpha2) / (R3D2C * tan(theta2C)) - (1 - alpha1) / (R3D1C * tan(theta1C));
85
86  // Calculation of sigmaMS
87  // First get the orientation of the sensor plate for material budged calculation
88  double entranceAngle = theta;
89  VxdID::baseType sensorID = measurements.at(i + 1)->getVxdID();
90  int detID = measurements.at(i + 1)->getType();
91  if (sensorID != 0 and detID == VXD::SensorInfoBase::SVD) {
92  const SVD::SensorInfo& sensor = dynamic_cast<const SVD::SensorInfo&>(VXD::GeoCache::get(sensorID));
93  TVector3 sensorOrigin = sensor.pointToGlobal(TVector3(0, 0, 0), true);
94  TVector3 sensoru = sensor.pointToGlobal(TVector3(1, 0, 0), true);
95  TVector3 sensorv = sensor.pointToGlobal(TVector3(0, 1, 0), true);
96
97  TVector3 globalu = sensoru - sensorOrigin;
98  TVector3 globalv = sensorv - sensorOrigin;
99  TVector3 normal = globalu.Cross(globalv);
100
101  // Calculate the angle of incidence for the middle hit
102  if (sensorOrigin.Angle(normal) > M_PI * 0.5) { normal *= -1.; }
103  entranceAngle = (hit1 - hit0).Angle(normal);
104  }
105
110  const double XoverX0 = m_materialBudgetFactor * 0.0057 / cos(entranceAngle);
111
112  double R3D = - (eta * PhiTilde * sin(theta) * sin(theta) + beta * ThetaTilde);
113  R3D *= 1. / (eta * eta * sin(theta) * sin(theta) + beta * beta);
114  const double b = 4.5 / m_magneticFieldZ * sqrt(XoverX0);
115
116  // Calculation of maximal 3D radius from a maximal p_t cut off value
117  // (which is a hyper parameter of the Triplet Fit QE) via conversion
118  // using the magnetic field at the origin and the speed of light in the
119  // default units cm/ns times 1e-4 due to the units of the magnetic field.
120  double R3DmaxCut = m_maxPt / (m_magneticFieldZ * 1e-4 * Const::speedOfLight);
121  double R3D_truncated = R3D > R3DmaxCut ? R3DmaxCut : R3D;
122  const double sigmaMS = b / R3D_truncated;
123
124  double sigmaR3DSquared = pow(sigmaMS, 2) / (pow(eta * sin(theta), 2) + pow(beta, 2));
125
126  double Chi2min = pow(beta * PhiTilde - eta * ThetaTilde, 2);
127  Chi2min *= 1. / (sigmaMS * sigmaMS * (eta * eta + beta * beta / pow(sin(theta), 2)));
128
129  // bias correction as proposed in section 2.4 of the paper describing this fit. (see above)
130  double delta = (beta * PhiTilde - eta * ThetaTilde) / (eta * PhiTilde * sin(theta) * sin(theta) + beta * ThetaTilde);
131  if (8 * delta * delta * sin(theta) * sin(theta) <= 1) {
132  R3D *= (0.75 + sqrt(1 - 8 * delta * delta * sin(theta) * sin(theta)) / 4.);
133  }
134
135  // required for optional pt calculation
136  m_thetas.push_back(theta);
137  m_alphas.push_back((alpha1 + alpha2) / 2.);
138
139  // store values for combination
140  m_R3Ds.push_back(R3D);
141  m_sigmaR3DSquareds.push_back(sigmaR3DSquared);
142
143  combinedChi2 += Chi2min;
144  }
145
146  // Calculate average R3D
147  double numerator = 0;
148  double denominator = 0;
149  for (short i = 0; i < nTriplets; ++i) {
150  numerator += pow(m_R3Ds.at(i), 3) / m_sigmaR3DSquareds.at(i);
151  denominator += pow(m_R3Ds.at(i), 2) / m_sigmaR3DSquareds.at(i);
152  }
153  m_averageR3D = numerator / denominator;
154
155  // Compare individual R3Ds with average R3D to improve chi2 as presented at:
156  // Connecting the Dots, Vienna, Feb 2016 by A. Schoening
157  double globalCompatibilityOfR3Ds = 0;
158  for (short i = 0; i < nTriplets; ++i) {
159  globalCompatibilityOfR3Ds += pow(m_R3Ds.at(i) - m_averageR3D, 2) / m_sigmaR3DSquareds.at(i);
160  }
161
162  double const finalChi2 = combinedChi2 + globalCompatibilityOfR3Ds;
163
164  m_results.chiSquared = finalChi2;
165
166  return TMath::Prob(finalChi2, 2 * measurements.size() - 5);
167 }

◆ estimateQualityAndProperties()

QualityEstimationResults estimateQualityAndProperties ( std::vector< SpacePoint const * > const &  measurements)
finalvirtual

perform quality estimation and extract additional information from the fit

Parameters
measurements: vector of SPs of the track candidate
Returns
: QualityEstimationResults struct

Reimplemented from QualityEstimatorBase.

Definition at line 170 of file QualityEstimatorTripletFit.cc.

◆ setMagneticFieldStrength()

void setMagneticFieldStrength ( double  magneticFieldZ = 1.5)
inlineinherited

Setter for z component of magnetic field.

Parameters
magneticFieldZ: value to set it to

Definition at line 64 of file QualityEstimatorBase.h.

Member Data Documentation

◆ m_materialBudgetFactor

double m_materialBudgetFactor = 1.45
protected

Triplet Fit hyper parameters.

Scaling factor for material budget which is applied to the radiation length value X/X_0 = 0.57% which is taken from the Belle II TDR page 156. This scaling factor is optimized to achieve the best performance on MC.

Definition at line 62 of file QualityEstimatorTripletFit.h.

◆ m_maxPt

double m_maxPt = 0.01
protected

Cut off value for 3D Radius calculated in Triplet Fit.

This value is a hyper parameter of the Triplet Fit which is tuned on MC.

Definition at line 67 of file QualityEstimatorTripletFit.h.

◆ m_results

QualityEstimationResults m_results
protectedinherited

Result of the quality estimation This is stored as a member variable, because some values may be calculated by 'estimateQuality' anyways.

Therefore they don't need to be calculated explicitly in 'estimateQualityAndProperties'.

Definition at line 101 of file QualityEstimatorBase.h.


The documentation for this class was generated from the following files:
Belle2::QualityEstimatorTripletFit::m_thetas
std::vector< double > m_thetas
angle theta
Definition: QualityEstimatorTripletFit.h:50
prepareAsicCrosstalkSimDB.e
e
aux.
Definition: prepareAsicCrosstalkSimDB.py:53
Belle2::QualityEstimationResults::chiSquared
boost::optional< double > chiSquared
chi squared value obtained by the fit of the QE
Definition: QualityEstimatorBase.h:38
Belle2::VXD::GeoCache::get
static const SensorInfoBase & get(Belle2::VxdID id)
Return a reference to the SensorInfo of a given SensorID.
Definition: GeoCache.h:141
Belle2::QualityEstimatorTripletFit::m_alphas
std::vector< double > m_alphas
angle alpha
Definition: QualityEstimatorTripletFit.h:49
Belle2::SVD::SensorInfo
Specific implementation of SensorInfo for SVD Sensors which provides additional sensor specific infor...
Definition: SensorInfo.h:35
Belle2::QualityEstimatorTripletFit::m_materialBudgetFactor
double m_materialBudgetFactor
Triplet Fit hyper parameters.
Definition: QualityEstimatorTripletFit.h:62
Belle2::Const::speedOfLight
static const double speedOfLight
[cm/ns]
Definition: Const.h:568
Belle2::VxdID::baseType
unsigned short baseType
The base integer type for VxdID.
Definition: VxdID.h:46
Belle2::QualityEstimatorBase::m_magneticFieldZ
double m_magneticFieldZ
Member storing the z component of the magnetic field.
Definition: QualityEstimatorBase.h:95
Belle2::VXD::SensorInfoBase::SVD
@ SVD
SVD Sensor.
Definition: SensorInfoBase.h:45
Belle2::QualityEstimatorTripletFit::m_sigmaR3DSquareds
std::vector< double > m_sigmaR3DSquareds
squared error of 3D radius
Definition: QualityEstimatorTripletFit.h:52
Belle2::QualityEstimatorTripletFit::m_R3Ds
std::vector< double > m_R3Ds
3D radius
Definition: QualityEstimatorTripletFit.h:51
Belle2::QualityEstimatorTripletFit::m_averageR3D
double m_averageR3D
average 3D radius
Definition: QualityEstimatorTripletFit.h:54
Belle2::QualityEstimatorTripletFit::m_maxPt
double m_maxPt
Cut off value for 3D Radius calculated in Triplet Fit.
Definition: QualityEstimatorTripletFit.h:67
Belle2::QualityEstimatorBase::m_results
QualityEstimationResults m_results
Result of the quality estimation This is stored as a member variable, because some values may be calc...
Definition: QualityEstimatorBase.h:101
