Geometry parameters of a module (optical components + positioning) More...

#include <TOPGeoModule.h>

Inheritance diagram for TOPGeoModule:

Collaboration diagram for TOPGeoModule:

[legend]

Public Member Functions
	TOPGeoModule ()
	Default constructor.

	TOPGeoModule (int moduleID, double radius, double phi, double backwardZ, const std::string &name="TOPModule")
	Useful constructor. More...

	TOPGeoModule (const TOPGeoModule &module)
	Copy constructor.

TOPGeoModule &	operator= (const TOPGeoModule &module)
	Assignment operator.

	~TOPGeoModule ()
	Destructor.

void	setModuleCNumber (unsigned moduleCNumber)
	Sets module construction number (0 = ideal module = default) More...

void	setBarSegment1 (const TOPGeoBarSegment &bar)
	Sets bar segment No.1 (forward bar) More...

void	setBarSegment2 (const TOPGeoBarSegment &bar)
	Sets bar segment No.2 (backward bar) More...

void	setMirrorSegment (const TOPGeoMirrorSegment &mirror)
	Sets mirror segment. More...

void	setPrism (const TOPGeoPrism &prism)
	Sets prism. More...

void	setPMTArray (const TOPGeoPMTArray &array)
	Sets PMT array. More...

void	setDecoupledPMT (unsigned pmtID)
	Sets PMT as optically decoupled. More...

void	generateDecoupledPMTs (double fraction)
	Generate randomly a fraction of PMT's to be optically decoupled. More...

void	setBrokenGlue (int glueID, double fraction, double angle, const std::string &material)
	Sets glue to be broken (delaminated) More...

void	setPeelOffRegions (double thickness, const std::string &material)
	Sets parameters of the peel-off cookie volumes. More...

void	appendPeelOffRegion (unsigned ID, double fraction, double angle)
	Appends peel-off cookie region. More...

void	setPMTArrayDisplacement (const TOPGeoPMTArrayDisplacement &displ)
	Sets PMT array displacement. More...

void	setModuleDisplacement (const TOPGeoModuleDisplacement &displ)
	Sets module displacement. More...

int	getModuleID () const
	Returns module ID. More...

double	getRadius () const
	Returns radius of the bar central plane in Belle II frame. More...

double	getPhi () const
	Returns module azimuthal angle in Belle II frame. More...

double	getBackwardZ () const
	Returns the z position of prism-bar joint in Belle II frame. More...

unsigned	getModuleCNumber () const
	Returns module construction number (0 = ideal module) More...

const TOPGeoBarSegment &	getBarSegment1 () const
	Returns bar segment No.1 (forward bar) More...

const TOPGeoBarSegment &	getBarSegment2 () const
	Returns bar segment No.2 (backward bar) More...

const TOPGeoMirrorSegment &	getMirrorSegment () const
	Returns mirror segment. More...

const TOPGeoPrism &	getPrism () const
	Returns prism. More...

const TOPGeoPMTArray &	getPMTArray () const
	Returns PMT array. More...

const TOPGeoPMTArrayDisplacement &	getPMTArrayDisplacement () const
	Returns PMT array displacement. More...

const TOPGeoModuleDisplacement &	getModuleDisplacement () const
	Returns module displacement. More...

double	getBarLength () const
	Returns bar length (w/o prism) including glue joints. More...

double	getFullLength () const
	Returns full length (including prism, wavelenght filter and glue joints) More...

double	getForwardZ () const
	Returns the z position of the bar forward end in Belle II frame. More...

double	getBarThickness () const
	Returns average bar thickness (weigthed by segment lengths) More...

double	getBarWidth () const
	Returns average bar width (weigthed by segment lengths) More...

double	getSurfaceReflectivity (double energy) const
	Returns average surface reflectivity at given photon energy (weigthed by segment lengths) More...

double	getZc () const
	Returns z of bar center (w/o prism) in Belle II frame. More...

double	getInnerRadius () const
	Returns inner surface radius in Belle II frame. More...

TVector3	pointToLocal (const TVector3 &point) const
	Transforms 3D point from Belle II to module internal frame. More...

TVector3	momentumToLocal (const TVector3 &momentum) const
	Transforms momentum vector from Belle II to module internal frame. More...

TVector3	pointToGlobal (const TVector3 &point) const
	Transforms 3D point from module internal frame to Belle II frame. More...

TVector3	momentumToGlobal (const TVector3 &momentum) const
	Transforms momentum vector from module internal frame to Belle II frame. More...

bool	isConsistent () const override
	Check for consistency of data members. More...

void	print (const std::string &title="Module geometry parameters") const override
	Print the content of the class. More...

void	setName (const std::string &name)
	Sets object name. More...

const std::string &	getName () const
	Returns object name. More...

virtual void	printSurface (const GeoOpticalSurface &surface) const
	Print the content of optical surface. More...

double	getReflectivity (const GeoOpticalSurface &surface, double energy) const
	Returns reflectivity of optical surface at given photon energy. More...

Protected Member Functions
void	printUnderlined (const std::string &title) const
	Print the content of the class. More...

	ClassDef (TOPGeoBase, 1)
	ClassDef.

Protected Attributes
std::string	m_name
	geometry object name

Static Protected Attributes
static double	s_unit = Unit::cm
	conversion unit for length

static std::string	s_unitName
	conversion unit name

Private Member Functions
void	setTransformation () const
	Sets transformation cache.

	ClassDefOverride (TOPGeoModule, 3)
	ClassDef.

Private Attributes
int	m_moduleID = 0
	module ID

float	m_radius = 0
	radius of bar central plane in Belle II frame

float	m_phi = 0
	azimuthal angle in Belle II frame

float	m_backwardZ = 0
	z position of prism-bar joint in Belle II frame

unsigned	m_moduleCNumber = 0
	module construction number, 0 = ideal module

TOPGeoBarSegment	m_bar1
	bar segment 1 (forward bar)

TOPGeoBarSegment	m_bar2
	bar segment 2 (backward bar)

TOPGeoMirrorSegment	m_mirror
	mirror segment

TOPGeoPrism	m_prism
	prism

TOPGeoPMTArray	m_pmtArray
	geometry parameters of PMT array

TOPGeoPMTArrayDisplacement	m_arrayDisplacement
	PMT array displacement.

TOPGeoModuleDisplacement	m_moduleDisplacement
	module displacement

TRotation *	m_rotation = 0
	cache for rotation matrix (from internal to Belle II frame)

TRotation *	m_rotationInverse = 0
	cache for inverse rotation matrix

TVector3 *	m_translation = 0
	cache for translation vector (from internal to Belle II frame)

Detailed Description

Geometry parameters of a module (optical components + positioning)

Definition at line 40 of file TOPGeoModule.h.

Constructor & Destructor Documentation

◆ TOPGeoModule()

TOPGeoModule	(	int	moduleID,
		double	radius,
		double	phi,
		double	backwardZ,
		const std::string &	name = `"TOPModule"`
	)

inline

Useful constructor.

Parameters

moduleID	module ID
radius	radius of the bar central plane in Belle II frame
phi	azimuthal angle in Belle II frame
backwardZ	z position of prism-bar joint in Belle II frame
name	object name

Definition at line 57 of file TOPGeoModule.h.

                                             : TOPGeoBase(module.getName())
     {
       *this = module;
       m_rotation = 0;

Member Function Documentation

◆ appendPeelOffRegion()

void appendPeelOffRegion	(	unsigned	ID,
		double	fraction,
		double	angle
	)

inline

Appends peel-off cookie region.

Parameters

ID	region ID (1-based)
fraction	fraction of the area
angle	angle of the area

Definition at line 186 of file TOPGeoModule.h.

◆ generateDecoupledPMTs()

void generateDecoupledPMTs ( double fraction )

inline

Generate randomly a fraction of PMT's to be optically decoupled.

Parameters

fraction decoupled fraction

Definition at line 158 of file TOPGeoModule.h.

◆ getBackwardZ()

double getBackwardZ ( ) const

inline

Returns the z position of prism-bar joint in Belle II frame.

Returns: z position

Definition at line 232 of file TOPGeoModule.h.

◆ getBarLength()

double getBarLength ( ) const

inline

Returns bar length (w/o prism) including glue joints.

Returns: length

Definition at line 292 of file TOPGeoModule.h.

◆ getBarSegment1()

const TOPGeoBarSegment& getBarSegment1 ( ) const

inline

Returns bar segment No.1 (forward bar)

Returns: bar segment geometry parameters

Definition at line 244 of file TOPGeoModule.h.

◆ getBarSegment2()

const TOPGeoBarSegment& getBarSegment2 ( ) const

inline

Returns bar segment No.2 (backward bar)

Returns: bar segment geometry parameters

Definition at line 250 of file TOPGeoModule.h.

◆ getBarThickness()

double getBarThickness ( ) const

inline

Returns average bar thickness (weigthed by segment lengths)

Returns: average bar thickness

Definition at line 313 of file TOPGeoModule.h.

◆ getBarWidth()

double getBarWidth ( ) const

inline

Returns average bar width (weigthed by segment lengths)

Returns: average bar width

Definition at line 324 of file TOPGeoModule.h.

◆ getForwardZ()

double getForwardZ ( ) const

inline

Returns the z position of the bar forward end in Belle II frame.

Returns: z position

Definition at line 307 of file TOPGeoModule.h.

◆ getFullLength()

double getFullLength ( ) const

inline

Returns full length (including prism, wavelenght filter and glue joints)

Returns: length

Definition at line 301 of file TOPGeoModule.h.

◆ getInnerRadius()

double getInnerRadius ( ) const

inline

Returns inner surface radius in Belle II frame.

Returns: radius

Definition at line 353 of file TOPGeoModule.h.

◆ getMirrorSegment()

const TOPGeoMirrorSegment& getMirrorSegment ( ) const

inline

Returns mirror segment.

Returns: mirror segment geometry parameters

Definition at line 256 of file TOPGeoModule.h.

◆ getModuleCNumber()

unsigned getModuleCNumber ( ) const

inline

Returns module construction number (0 = ideal module)

Returns: construction number

Definition at line 238 of file TOPGeoModule.h.

◆ getModuleDisplacement()

const TOPGeoModuleDisplacement& getModuleDisplacement ( ) const

inline

Returns module displacement.

Returns: module displacement parameters

Definition at line 283 of file TOPGeoModule.h.

◆ getModuleID()

int getModuleID ( ) const

inline

Returns module ID.

Returns: module ID

Definition at line 214 of file TOPGeoModule.h.

◆ getName()

const std::string& getName ( ) const

inlineinherited

Returns object name.

Returns: object name

Definition at line 61 of file TOPGeoBase.h.

◆ getPhi()

double getPhi ( ) const

inline

Returns module azimuthal angle in Belle II frame.

Returns: azimuthal angle

Definition at line 226 of file TOPGeoModule.h.

◆ getPMTArray()

const TOPGeoPMTArray& getPMTArray ( ) const

inline

Returns PMT array.

Returns: PMT array geometry parameters

Definition at line 268 of file TOPGeoModule.h.

◆ getPMTArrayDisplacement()

const TOPGeoPMTArrayDisplacement& getPMTArrayDisplacement ( ) const

inline

Returns PMT array displacement.

Returns: PMT array displacement parameters

Definition at line 274 of file TOPGeoModule.h.

◆ getPrism()

const TOPGeoPrism& getPrism ( ) const

inline

Returns prism.

Returns: prism geometry parameters

Definition at line 262 of file TOPGeoModule.h.

◆ getRadius()

double getRadius ( ) const

inline

Returns radius of the bar central plane in Belle II frame.

Returns: radius

Definition at line 220 of file TOPGeoModule.h.

◆ getSurfaceReflectivity()

double getSurfaceReflectivity ( double energy ) const

inline

Returns average surface reflectivity at given photon energy (weigthed by segment lengths)

Parameters

energy photon energy in [eV]

Returns: average reflectivity

Definition at line 336 of file TOPGeoModule.h.

◆ getZc()

double getZc ( ) const

inline

Returns z of bar center (w/o prism) in Belle II frame.

Returns: z coordinate if bar center

Definition at line 347 of file TOPGeoModule.h.

◆ setBarSegment1()

void setBarSegment1 ( const TOPGeoBarSegment & bar )

inline

Sets bar segment No.1 (forward bar)

Parameters

bar	segment No.1 geometry parameters

Definition at line 122 of file TOPGeoModule.h.

◆ setBarSegment2()

void setBarSegment2 ( const TOPGeoBarSegment & bar )

inline

Sets bar segment No.2 (backward bar)

Parameters

bar	segment No.2 geometry parameters

Definition at line 128 of file TOPGeoModule.h.

◆ setDecoupledPMT()

void setDecoupledPMT ( unsigned pmtID )

inline

Sets PMT as optically decoupled.

Parameters

pmtID ID of PMT to be set as decoupled (1-based)

Definition at line 152 of file TOPGeoModule.h.

◆ setMirrorSegment()

void setMirrorSegment ( const TOPGeoMirrorSegment & mirror )

inline

Sets mirror segment.

Parameters

mirror mirror segment geometry parameters

Definition at line 134 of file TOPGeoModule.h.

◆ setModuleCNumber()

void setModuleCNumber ( unsigned moduleCNumber )

inline

Sets module construction number (0 = ideal module = default)

Parameters

moduleCNumber construction number

Definition at line 116 of file TOPGeoModule.h.

◆ setModuleDisplacement()

void setModuleDisplacement ( const TOPGeoModuleDisplacement & displ )

inline

Sets module displacement.

Parameters

displ module displacement parameters

Definition at line 205 of file TOPGeoModule.h.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Sets object name.

Parameters

name	object name

Definition at line 55 of file TOPGeoBase.h.

◆ setPMTArray()

void setPMTArray ( const TOPGeoPMTArray & array )

inline

Sets PMT array.

Parameters

array PMT array geometry parameters

Definition at line 146 of file TOPGeoModule.h.

◆ setPMTArrayDisplacement()

void setPMTArrayDisplacement ( const TOPGeoPMTArrayDisplacement & displ )

inline

Sets PMT array displacement.

Parameters

displ PMT array displacement parameters

Definition at line 196 of file TOPGeoModule.h.

◆ setPrism()

void setPrism ( const TOPGeoPrism & prism )

inline

Sets prism.

Parameters

prism prism geometry parameters

Definition at line 140 of file TOPGeoModule.h.

The documentation for this class was generated from the following files:

top/dbobjects/include/TOPGeoModule.h
top/dbobjects/src/TOPGeoModule.cc

Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Private Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ TOPGeoModule()

Member Function Documentation

◆ appendPeelOffRegion()

◆ generateDecoupledPMTs()

◆ getBackwardZ()

◆ getBarLength()

◆ getBarSegment1()

◆ getBarSegment2()

◆ getBarThickness()

◆ getBarWidth()

◆ getForwardZ()

◆ getFullLength()

◆ getInnerRadius()

◆ getMirrorSegment()

◆ getModuleCNumber()

◆ getModuleDisplacement()

◆ getModuleID()

◆ getName()

◆ getPhi()

◆ getPMTArray()

◆ getPMTArrayDisplacement()

◆ getPrism()

◆ getRadius()

◆ getSurfaceReflectivity()

◆ getZc()

◆ setBarSegment1()

◆ setBarSegment2()

◆ setDecoupledPMT()

◆ setMirrorSegment()

◆ setModuleCNumber()

◆ setModuleDisplacement()

◆ setName()

◆ setPMTArray()

◆ setPMTArrayDisplacement()

◆ setPrism()
