TOPWavelengthFilter Class Reference

Bulk transmittance of wavelength filter. More...

#include <TOPWavelengthFilter.h>

Inheritance diagram for TOPWavelengthFilter:

Collaboration diagram for TOPWavelengthFilter:

Public Member Functions
	TOPWavelengthFilter ()
	Default constructor.
	TOPWavelengthFilter (float lambdaFirst, float lambdaStep, const std::vector< float > &trEffi, const std::string &name="TOPWavelengthFilter")
	Full constructor. More...
const std::vector< float > &	getBulkTransmittances () const
	Returns bulk transmittance data points. More...
float	getBulkTransmittance (double lambda) const
	Returns bulk transmittance at given wavelength using linear interpolation. More...
float	getLambdaFirst () const
	Returns wavelength of the first data point. More...
float	getLambdaStep () const
	Returns wavelength step. More...
bool	isConsistent () const override
	Check for consistency of data members. More...
void	print (const std::string &title="Wavelength filter bulk transmittance") const override
	Print the content of the class. More...
void	setName (const std::string &name)
	Sets object name. More...
const std::string &	getName () const
	Returns object name. More...
virtual void	printSurface (const GeoOpticalSurface &surface) const
	Print the content of optical surface. More...
double	getReflectivity (const GeoOpticalSurface &surface, double energy) const
	Returns reflectivity of optical surface at given photon energy. More...

Protected Member Functions
void	printUnderlined (const std::string &title) const
	Print the content of the class. More...
	ClassDef (TOPGeoBase, 1)
	ClassDef.

Protected Attributes
std::string	m_name
	geometry object name

Static Protected Attributes
static double	s_unit = Unit::cm
	conversion unit for length
static std::string	s_unitName
	conversion unit name

Private Member Functions
	ClassDefOverride (TOPWavelengthFilter, 1)
	ClassDef.

Private Attributes
float	m_lambdaFirst = 0
	wavelength of the first data point [nm]
float	m_lambdaStep = 0
	wavelength step [nm]
std::vector< float >	m_transmittances
	bulk transmittance data points

Detailed Description

Bulk transmittance of wavelength filter.

Definition at line 33 of file TOPWavelengthFilter.h.

Constructor & Destructor Documentation

TOPWavelengthFilter()

TOPWavelengthFilter ( float  lambdaFirst, float  lambdaStep, const std::vector< float > &  trEffi, const std::string &  name = "TOPWavelengthFilter"  )

inline

Full constructor.

Parameters

lambdaFirst	wavelength of the first data point [nm]
lambdaStep	wavelength step [nm]
trEffi	bulk transmittance data points
name	object name

Definition at line 49 of file TOPWavelengthFilter.h.

                                                          {return m_transmittances;}


Member Function Documentation

getBulkTransmittances()

const std::vector<float>& getBulkTransmittances ( ) const

inline

Returns bulk transmittance data points.

Returns

bulk transmittance data points

Definition at line 59 of file TOPWavelengthFilter.h.

getLambdaFirst()

float getLambdaFirst ( ) const

inline

Returns wavelength of the first data point.

Returns

wavelength in [nm]

Definition at line 72 of file TOPWavelengthFilter.h.

getLambdaStep()

float getLambdaStep ( ) const

inline

Returns wavelength step.

Returns

wavelength step in [nm]

Definition at line 78 of file TOPWavelengthFilter.h.

getName()

const std::string& getName ( ) const

inlineinherited

Returns object name.

Returns

object name

Definition at line 61 of file TOPGeoBase.h.

setName()

void setName ( const std::string &  name )

inlineinherited

Sets object name.

Parameters

name	object name

Definition at line 55 of file TOPGeoBase.h.

---

The documentation for this class was generated from the following files:

• top/dbobjects/include/TOPWavelengthFilter.h
• top/dbobjects/src/TOPWavelengthFilter.cc
