SensitiveAero Class Reference

This is optional (temporary) class that provides information on track parameters on aerogel plane, until tracking is not prepared. More...

#include <SensitiveAero.h>

Inheritance diagram for SensitiveAero:

Collaboration diagram for SensitiveAero:

Public Member Functions
	SensitiveAero ()
	Constructor. More...
bool	step (G4Step *aStep, G4TouchableHistory *) override
	Process each step and calculate variables defined in PXDSimHit. More...

Static Public Member Functions
static const std::map< std::string, RelationArray::EConsolidationAction > &	getMCParticleRelations ()
	Return a list of all registered Relations with MCParticles.
static void	setActive (bool activeStatus)
	Enable/Disable all Sensitive Detectors. More...
static void	registerMCParticleRelation (const std::string &name, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Register an relation involving MCParticles. More...
static void	registerMCParticleRelation (const RelationArray &relation, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Overload to make it easer to register MCParticle relations. More...

Private Member Functions
virtual bool	ProcessHits (G4Step *aStep, G4TouchableHistory *aROhist)
	Check if recording hits is enabled and if so call step() and set the correct MCParticle flag. More...

Private Attributes
Const::EDetector	m_subdetector
	Subdetector the class belongs to.

Static Private Attributes
static std::map< std::string, RelationArray::EConsolidationAction >	s_mcRelations
	Static set holding all relations which have to be updated at the end of the Event.
static bool	s_active
	Static bool which indicates wether recording of hits is enabled.

Detailed Description

This is optional (temporary) class that provides information on track parameters on aerogel plane, until tracking is not prepared.

Definition at line 32 of file SensitiveAero.h.

Constructor & Destructor Documentation

SensitiveAero()

SensitiveAero

(

)

Constructor.

Parameters

name	Name of the sensitive detector. Do we still need that?

Definition at line 32 of file SensitiveAero.cc.

                                :
      Simulation::SensitiveDetectorBase("ARICH", Const::ARICH)
    {

      // registration of store arrays and relations

      StoreArray<MCParticle> mcParticles;
      StoreArray<ARICHAeroHit> aeroHits;
      aeroHits.registerInDataStore();
      mcParticles.registerRelationTo(aeroHits);

      // additional registration of MCParticle relation (required for correct relations)

      RelationArray relation(mcParticles, aeroHits);
      registerMCParticleRelation(relation, RelationArray::c_deleteElement);

    }

Member Function Documentation

ProcessHits()

bool ProcessHits ( G4Step *  aStep, G4TouchableHistory *  aROhist  )

inlineprivatevirtualinherited

Check if recording hits is enabled and if so call step() and set the correct MCParticle flag.

Called by Geant4 for each step inside the sensitive volumes attached

Definition at line 98 of file SensitiveDetectorBase.h.

registerMCParticleRelation() [1/2]

static void registerMCParticleRelation ( const RelationArray &  relation, RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight  )

inlinestaticinherited

Overload to make it easer to register MCParticle relations.

Parameters

relation	RelationArray to register
ignoreAction

Definition at line 70 of file SensitiveDetectorBase.h.

registerMCParticleRelation() [2/2]

void registerMCParticleRelation ( const std::string &  name, RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight  )

staticinherited

Register an relation involving MCParticles.

All Relations which point from an MCParticle to something have to be registered with addMCParticleRelation() because the index of the MCParticles might change at the end of the event. During simulation, the TrackID should be used as index of the MCParticle

Parameters

name	Name of the relation to register
ignoreAction

Definition at line 24 of file SensitiveDetectorBase.cc.

setActive()

static void setActive ( bool  activeStatus )

inlinestaticinherited

Enable/Disable all Sensitive Detectors.

By default, all sensitive detectors won't create hits to make it possible to use the Geant4 Navigator for non-simulation purposes. Only during simulation the sensitive detectors will be enabled to record hits

Parameters

activeStatus

bool to indicate wether hits should be recorded

Definition at line 54 of file SensitiveDetectorBase.h.

step()

bool step ( G4Step *  aStep, G4TouchableHistory *    )

overridevirtual

Process each step and calculate variables defined in PXDSimHit.

Parameters

aStep

Current Geant4 step in the sensitive medium.

Returns

true if a hit was stored, o.w. false.

Implements SensitiveDetectorBase.

Definition at line 50 of file SensitiveAero.cc.

---

The documentation for this class was generated from the following files:

• arich/simulation/include/SensitiveAero.h
• arich/simulation/src/SensitiveAero.cc
