SensitiveDetector Class Reference

Sensitive Detector implementation of the MICROTPC detector. More...

#include <SensitiveDetector.h>

Inheritance diagram for SensitiveDetector:

Collaboration diagram for SensitiveDetector:

Public Member Functions
	SensitiveDetector ()
	Constructor.
int	saveG4TrackInfo (int trackID, int PDG, float Mass, float Energy, float vtx[3], float mom[3])
	Save saveG4TrackInfo into datastore.

Static Public Member Functions
static const std::map< std::string, RelationArray::EConsolidationAction > &	getMCParticleRelations ()
	Return a list of all registered Relations with MCParticles.
static void	setActive (bool activeStatus)
	Enable/Disable all Sensitive Detectors. More...
static void	registerMCParticleRelation (const std::string &name, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Register an relation involving MCParticles. More...
static void	registerMCParticleRelation (const RelationArray &relation, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Overload to make it easer to register MCParticle relations. More...

Protected Member Functions
bool	step (G4Step *step, G4TouchableHistory *) override
	Step processing method. More...

Protected Attributes
int	m_trackID

Private Member Functions
virtual bool	ProcessHits (G4Step *aStep, G4TouchableHistory *aROhist)
	Check if recording hits is enabled and if so call step() and set the correct MCParticle flag. More...

Private Attributes
Const::EDetector	m_subdetector
	Subdetector the class belongs to.

Static Private Attributes
static std::map< std::string, RelationArray::EConsolidationAction >	s_mcRelations
	Static set holding all relations which have to be updated at the end of the Event.
static bool	s_active
	Static bool which indicates wether recording of hits is enabled.

Detailed Description

Sensitive Detector implementation of the MICROTPC detector.

Definition at line 32 of file SensitiveDetector.h.

Member Function Documentation

ProcessHits()

bool ProcessHits ( G4Step *  aStep, G4TouchableHistory *  aROhist  )

inlineprivatevirtualinherited

Check if recording hits is enabled and if so call step() and set the correct MCParticle flag.

Called by Geant4 for each step inside the sensitive volumes attached

Definition at line 98 of file SensitiveDetectorBase.h.

registerMCParticleRelation() [1/2]

static void registerMCParticleRelation ( const RelationArray &  relation, RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight  )

inlinestaticinherited

Overload to make it easer to register MCParticle relations.

Parameters

relation	RelationArray to register
ignoreAction

Definition at line 70 of file SensitiveDetectorBase.h.

registerMCParticleRelation() [2/2]

void registerMCParticleRelation ( const std::string &  name, RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight  )

staticinherited

Register an relation involving MCParticles.

All Relations which point from an MCParticle to something have to be registered with addMCParticleRelation() because the index of the MCParticles might change at the end of the event. During simulation, the TrackID should be used as index of the MCParticle

Parameters

name	Name of the relation to register
ignoreAction

Definition at line 24 of file SensitiveDetectorBase.cc.

setActive()

static void setActive ( bool  activeStatus )

inlinestaticinherited

Enable/Disable all Sensitive Detectors.

By default, all sensitive detectors won't create hits to make it possible to use the Geant4 Navigator for non-simulation purposes. Only during simulation the sensitive detectors will be enabled to record hits

Parameters

activeStatus

bool to indicate wether hits should be recorded

Definition at line 54 of file SensitiveDetectorBase.h.

step()

bool step ( G4Step *  step, G4TouchableHistory *    )

overrideprotectedvirtual

Step processing method.

Parameters

step	the G4Step with the current step information

Returns

true if a Hit has been created, false if the hit was ignored

Implements SensitiveDetectorBase.

Definition at line 60 of file SensitiveDetector.cc.

                                           {
        //TrackID changed, store track informations
        m_trackID = track.GetTrackID();
      }

      //Save Hit if track leaves volume or is killed
      if (track.GetNextVolume() != track.GetVolume() || track.GetTrackStatus() >= fStopAndKill) {
        auto& mcparticle = Simulation::TrackInfo::getInfo(track);
        int PDG = mcparticle.getPDG();
        float Mass = mcparticle.getMass();
        float Energy = mcparticle.getEnergy();
        float vtx[3];
        vtx[0] = mcparticle.getProductionVertex().X();
        vtx[1] = mcparticle.getProductionVertex().Y();
        vtx[2] = mcparticle.getProductionVertex().Z();
        float mom[3];
        mom[0] = mcparticle.getMomentum().X();
        mom[1] = mcparticle.getMomentum().Y();
        mom[2] = mcparticle.getMomentum().Z();
        saveG4TrackInfo(m_trackID, PDG, Mass, Energy, vtx, mom);
        //Reset TrackID
        m_trackID = 0;
      }

      StoreArray<MicrotpcSimHit> MicrotpcHits;
      MicrotpcSimHit* hit = MicrotpcHits.appendNew(
                              trackID,
                              depEnergy,
                              nielEnergy,
                              tkPDG,
                              tkKEnergy,
                              detNb,
                              GlTime,
                              tkPos,
                              tkMom,
                              tkMomDir
                            );

      //Add Relation between SimHit and MCParticle with a weight of 1. Since
      //the MCParticle index is not yet defined we use the trackID from Geant4
      relMCSimHit.add(trackID, hit->getArrayIndex(), 1.0);

      return true;
    }

    int SensitiveDetector::saveG4TrackInfo
    (
      int trackID,
      int PDG,
      float Mass,
      float Energy,
      float vtx[3],

---

The documentation for this class was generated from the following files:

• beast/microtpc/simulation/include/SensitiveDetector.h
• beast/microtpc/simulation/src/SensitiveDetector.cc
