Belle II Software  release-05-01-25
FeedthroughParticle Class Reference

mediates 1->1 transition, that actually is the same particle More...

#include <FeedthroughParticle.h>

Inheritance diagram for FeedthroughParticle:
Collaboration diagram for FeedthroughParticle:

Public Types

enum  TFParticleType {
  kInteractionPoint,
  kOrigin,
  kRecoComposite,
  kRecoResonance,
  kInternalParticle,
  kRecoTrack,
  kResonance,
  kRecoPhoton,
  kRecoKlong,
  kMissingParticle,
  kFeedthroughParticle,
  kInternalTrack
}
 particle types


typedef std::vector< Constraintconstraintlist
 alias

typedef std::vector< std::pair< const ParticleBase *, int > > indexmap
 alias


Public Member Functions

 FeedthroughParticle (Belle2::Particle *particle, const ParticleBase *mother, const ConstraintConfiguration &config, bool forceFitAll)
 Constructor.

 ~FeedthroughParticle ()
 Destructor.

virtual ErrCode initMotherlessParticle (FitParams &) override
 init particle that does not need a mother vertex


virtual ErrCode initParticleWithMother (FitParams &) override
 init particle that does need a mother vertex


virtual ErrCode initCovariance (FitParams &) const override
 init covariance matrix, do nothing, since the particle is just a feedthrough

virtual int dim () const override
 get dimension of constraint

virtual void addToConstraintList (constraintlist &alist, int depth) const override
 add to constraint list


int type () const override
 get particle type

int posIndex () const override
 take posIndex from daughter

int momIndex () const override
 take momIndex from daughter

virtual void updateIndex (int &offset)
 this sets the index for momentum, position, etc. More...

virtual std::string parname (int index) const
 get name of parameter i

const ParticleBaselocate (Belle2::Particle *particle) const
 get particle base from basf2 particle

Belle2::Particleparticle () const
 get basf2 particle


int index () const
 get index


const ParticleBasemother () const
 getMother() / hasMother()

const std::string & name () const
 get name of the particle

virtual ErrCode projectGeoConstraint (const FitParams &, Projection &) const
 project geometrical constraint More...

virtual ErrCode projectMassConstraintParticle (const FitParams &, Projection &) const
 project mass constraint using the particles parameters More...

virtual ErrCode projectMassConstraintDaughters (const FitParams &, Projection &) const
 project mass constraint using the parameters of the daughters More...

virtual ErrCode projectMassConstraint (const FitParams &, Projection &) const
 project mass constraint abstract

virtual ErrCode projectConstraint (Constraint::Type, const FitParams &, Projection &) const
 project constraint. More...

virtual void forceP4Sum (FitParams &) const
 force p4 sum conservation all allong the tree

virtual int tauIndex () const
 get tau index

virtual bool hasEnergy () const
 get momentum dimension

virtual bool hasPosition () const
 get false


int eneIndex () const
 get energy index


virtual double chiSquare (const FitParams &) const
 get chi2

double pdgMass () const
 get pdg mass


double pdgWidth () const
 get pdg width

double pdgLifeTime () const
 get pdg lifetime

double pdgTime () const
 get Tau

int charge () const
 get charge

virtual ParticleBaseaddDaughter (Belle2::Particle *, const ConstraintConfiguration &config, bool forceFitAll=false)
 add daughter


virtual void removeDaughter (const ParticleBase *pb)
 remove daughter

virtual void retrieveIndexMap (indexmap &anindexmap) const
 get index map


void setMother (const ParticleBase *m)
 set mother


void collectVertexDaughters (std::vector< ParticleBase * > &particles, int posindex)
 get vertex daughters

virtual int nFinalChargedCandidates () const
 number of charged candidates

void setParticle (Belle2::Particle *particle)
 set the relation to basf2 particle type


Static Public Member Functions

static ParticleBasecreateParticle (Belle2::Particle *particle, const ParticleBase *mother, const ConstraintConfiguration &config, bool forceFitAll=false)
 create the according treeFitter particle obj for a basf2 particle type


static ParticleBasecreateOrigin (Belle2::Particle *daughter, const ConstraintConfiguration &config, bool forceFitAll)
 create a custom origin particle or a beamspot


Protected Types

typedef std::vector< ParticleBase * > ParticleContainer
 just an alias


Protected Member Functions

ErrCode initTau (FitParams &par) const
 initialises tau as a length


void setIndex (int i)
 set Index (in statevector)


Static Protected Member Functions

static double pdgLifeTime (Belle2::Particle *particle)
 get pdg lifetime

static bool isAResonance (Belle2::Particle *particle)
 controls if a particle is treated as a resonance(lifetime=0) or a particle that has a finite lifetime. More...

static double bFieldOverC ()
 Bz/c



Protected Attributes

Belle2::Particlem_particle
 pointer to framework type


const ParticleBasem_mother
 motherparticle

std::vector< ParticleBase * > m_daughters
 daughter container


bool m_isStronglyDecayingResonance
 decay length less than 1 micron


const ConstraintConfigurationm_config
 has all the constraint config


Private Attributes

int m_index
 index

const double m_pdgMass
 pdg mass


double m_pdgWidth
 particle width

const double m_pdgLifeTime
 lifetime in cm


int m_charge
 charge


std::string m_name
 name



Detailed Description

mediates 1->1 transition, that actually is the same particle

Definition at line 24 of file FeedthroughParticle.h.

Member Function Documentation

◆ isAResonance()

bool isAResonance ( Belle2::Particle particle)
staticprotectedinherited

controls if a particle is treated as a resonance(lifetime=0) or a particle that has a finite lifetime.

A finite life time means it will register a geo constraint for this particle

Definition at line 235 of file ParticleBase.cc.

238  : //bremsstrahlung
239  case 11:
240  rc = true ;
241  break ;
242  default: //everything with boosted flight length less than 1 micrometer
243  rc = (pdgcode && pdgLifeTime(particle) < 1e-5);
244  }
245  }
246  return rc ;
247  }
248
249  void ParticleBase::collectVertexDaughters(std::vector<ParticleBase*>& particles, int posindex)
250  {
251  if (mother() && mother()->posIndex() == posindex) {
252  particles.push_back(this);
253  }
254
255  for (auto* daughter : m_daughters) {

◆ projectConstraint()

ErrCode projectConstraint ( Constraint::Type  type,
const FitParams fitparams,
Projection p
) const
virtualinherited

project constraint.


Reimplemented in Origin, RecoParticle, RecoComposite, RecoResonance, InternalParticle, and InternalTrack.

Definition at line 537 of file ParticleBase.cc.

◆ projectGeoConstraint()

ErrCode projectGeoConstraint ( const FitParams fitparams,
Projection p
) const
virtualinherited

project geometrical constraint

the direction of the momentum is very well known from the kinematic constraints that is why we do not extract the distance as a vector here

Definition at line 359 of file ParticleBase.cc.

◆ projectMassConstraintDaughters()

ErrCode projectMassConstraintDaughters ( const FitParams fitparams,
Projection p
) const
virtualinherited

project mass constraint using the parameters of the daughters

be aware that the signs here are important E-|p|-m extracts a negative mass and messes with the momentum !

Definition at line 435 of file ParticleBase.cc.

◆ projectMassConstraintParticle()

ErrCode projectMassConstraintParticle ( const FitParams fitparams,
Projection p
) const
virtualinherited

project mass constraint using the particles parameters

be aware that the signs here are important E-|p|-m extracts a negative mass and messes with the momentum !

Definition at line 496 of file ParticleBase.cc.

◆ updateIndex()

void updateIndex ( int &  offset)
virtualinherited

this sets the index for momentum, position, etc.

in the statevector

Definition at line 138 of file ParticleBase.cc.
