RecoPhoton Class Reference

representation of the photon constraint More...

#include <RecoPhoton.h>

Inheritance diagram for RecoPhoton:
Collaboration diagram for RecoPhoton:

Public Types

enum  TFParticleType {
  kInteractionPoint,
  kOrigin,
  kRecoComposite,
  kRecoResonance,
  kInternalParticle,
  kRecoTrack,
  kResonance,
  kRecoPhoton,
  kRecoKlong,
  kMissingParticle,
  kFeedthroughParticle,
  kInternalTrack
}
 particle types


typedef std::vector< Constraintconstraintlist
 alias

typedef std::vector< std::pair< const ParticleBase *, int > > indexmap
 alias


Public Member Functions

 RecoPhoton (Belle2::Particle *bc, const ParticleBase *mother)
 constructor

virtual ~RecoPhoton ()
 destructor

virtual ErrCode initParticleWithMother (FitParams &fitparams) override
 init particle with mother

virtual ErrCode initMotherlessParticle (FitParams &fitparams) override
 init particle without mother

ErrCode initCovariance (FitParams &fitparams) const override
 init covariance

ErrCode initParams ()
 update or init params

ErrCode projectRecoConstraint (const FitParams &fitparams, Projection &p) const override
 project photon constraint More...

virtual int dimM () const override
 sets the size of the corresponding residual projection

virtual bool hasEnergy () const override
 how should the energy be calculated ? from momentum or from E ?


virtual int dim () const override
 set the size of the particle in the statevector

virtual int type () const override
 type

virtual void addToConstraintList (constraintlist &alist, int depth) const override
 add to list

virtual std::string parname (int index) const override
 name

virtual int momIndex () const override
 get momentum index

virtual ErrCode projectConstraint (Constraint::Type, const FitParams &, Projection &) const override
 abstract abstract projection

virtual void updateIndex (int &offset)
 this sets the index for momentum, position, etc. More...

const ParticleBaselocate (Belle2::Particle *particle) const
 get particle base from basf2 particle

Belle2::Particleparticle () const
 get basf2 particle


int index () const
 get index


const ParticleBasemother () const
 getMother() / hasMother()

const std::string & name () const
 get name of the particle

virtual ErrCode projectGeoConstraint (const FitParams &, Projection &) const
 project geometrical constraint More...

virtual ErrCode projectMassConstraintParticle (const FitParams &, Projection &) const
 project mass constraint using the particles parameters More...

virtual ErrCode projectMassConstraintDaughters (const FitParams &, Projection &) const
 project mass constraint using the parameters of the daughters More...

virtual ErrCode projectMassConstraint (const FitParams &, Projection &) const
 project mass constraint abstract

virtual void forceP4Sum (FitParams &) const
 force p4 sum conservation all allong the tree

virtual int posIndex () const
 get vertex index (in statevector!)

virtual int tauIndex () const
 get tau index

virtual bool hasPosition () const
 get false


int eneIndex () const
 get energy index


virtual double chiSquare (const FitParams &) const
 get chi2

double pdgMass () const
 get pdg mass


double pdgWidth () const
 get pdg width

double pdgLifeTime () const
 get pdg lifetime

double pdgTime () const
 get Tau

int charge () const
 get charge

virtual ParticleBaseaddDaughter (Belle2::Particle *, const ConstraintConfiguration &config, bool forceFitAll=false)
 add daughter


virtual void removeDaughter (const ParticleBase *pb)
 remove daughter

virtual void retrieveIndexMap (indexmap &anindexmap) const
 get index map


void setMother (const ParticleBase *m)
 set mother


void collectVertexDaughters (std::vector< ParticleBase * > &particles, int posindex)
 get vertex daughters

virtual int nFinalChargedCandidates () const
 number of charged candidates

void setParticle (Belle2::Particle *particle)
 set the relation to basf2 particle type


Static Public Member Functions

static bool useEnergy (const Belle2::Particle &cand)
 has energy in fit params?

static ParticleBasecreateParticle (Belle2::Particle *particle, const ParticleBase *mother, const ConstraintConfiguration &config, bool forceFitAll=false)
 create the according treeFitter particle obj for a basf2 particle type


static ParticleBasecreateOrigin (Belle2::Particle *daughter, const ConstraintConfiguration &config, bool forceFitAll)
 create a custom origin particle or a beamspot


Protected Types

typedef std::vector< ParticleBase * > ParticleContainer
 just an alias


Protected Member Functions

ErrCode initTau (FitParams &par) const
 initialises tau as a length


void setIndex (int i)
 set Index (in statevector)


Static Protected Member Functions

static double pdgLifeTime (Belle2::Particle *particle)
 get pdg lifetime

static bool isAResonance (Belle2::Particle *particle)
 controls if a particle is treated as a resonance(lifetime=0) or a particle that has a finite lifetime. More...

static double bFieldOverC ()
 Bz/c



Protected Attributes

Belle2::Particlem_particle
 pointer to framework type


const ParticleBasem_mother
 motherparticle

std::vector< ParticleBase * > m_daughters
 daughter container


bool m_isStronglyDecayingResonance
 decay length less than 1 micron


const ConstraintConfigurationm_config
 has all the constraint config


Private Attributes

const int m_dim
 dimension of residuals and 'width' of H

bool m_init
 was initialized*

bool m_useEnergy
 has energy ins statevector

Eigen::Matrix< double, 1, 4 > m_clusterPars
 constrains measured params (x_c, y_c, z_c, E_c)

Eigen::Matrix< double, 4, 4 > m_covariance
 covariance (x_c,y_c,z_c,E_c) of measured pars

int m_i1
 index with the highest momentum. More...

int m_i2
 random other index

int m_i3
 another random index

int m_index
 index

const double m_pdgMass
 pdg mass


double m_pdgWidth
 particle width

const double m_pdgLifeTime
 lifetime in cm


int m_charge
 charge


std::string m_name
 name



Detailed Description

representation of the photon constraint

Definition at line 25 of file RecoPhoton.h.

Member Function Documentation

◆ isAResonance()

bool isAResonance ( Belle2::Particle particle)
staticprotectedinherited

controls if a particle is treated as a resonance(lifetime=0) or a particle that has a finite lifetime.

A finite life time means it will register a geo constraint for this particle

Definition at line 235 of file ParticleBase.cc.

◆ projectGeoConstraint()

ErrCode projectGeoConstraint ( const FitParams fitparams,
Projection p
) const
virtualinherited

project geometrical constraint

the direction of the momentum is very well known from the kinematic constraints that is why we do not extract the distance as a vector here

Definition at line 359 of file ParticleBase.cc.

◆ projectMassConstraintDaughters()

ErrCode projectMassConstraintDaughters ( const FitParams fitparams,
Projection p
) const
virtualinherited

project mass constraint using the parameters of the daughters

be aware that the signs here are important E-|p|-m extracts a negative mass and messes with the momentum !

Definition at line 435 of file ParticleBase.cc.

◆ projectMassConstraintParticle()

ErrCode projectMassConstraintParticle ( const FitParams fitparams,
Projection p
) const
virtualinherited

project mass constraint using the particles parameters

be aware that the signs here are important E-|p|-m extracts a negative mass and messes with the momentum !

Definition at line 496 of file ParticleBase.cc.

◆ projectRecoConstraint()

ErrCode projectRecoConstraint ( const FitParams fitparams,
Projection p
) const
overridevirtual

project photon constraint

m : decay vertex mother p : momentum photon c : position cluster so: m + p = c thus (tau converts p to the correct units): 0 = c - m - tau * p we have 3 geometric equations and eliminate tau using the dimension with the highest momentum (because we have to divide by that momentum) only downside is we have to figure out which dimension this is the 4th equation is the energy which we keep as: 0 = E - |p| just to be sure, essentially this is always zero because p is build from E

Implements RecoParticle.

Definition at line 171 of file RecoPhoton.cc.

171  :
172  * m + p = c
173  * thus (tau converts p to the correct units):
174  * 0 = c - m - tau * p
175  * we have 3 geometric equations and eliminate tau using the dimension with the highest momentum
176  * (because we have to divide by that momentum)
177  * only downside is we have to figure out which dimension this is
178  * the 4th equation is the energy which we keep as:
179  * 0 = E - |p|
180  * just to be sure, essentially this is always zero because p is build from E
181  * */
182
183  const Eigen::Matrix<double, 1, 3> x_vertex = fitparams.getStateVector().segment(posindex, 3);
184  const Eigen::Matrix<double, 1, 3> p_vec = fitparams.getStateVector().segment(momindex, 3);
185
186  if (0 == p_vec[m_i1]) { return ErrCode(ErrCode::photondimerror); }
187
188  // p_vec[m_i1] must not be 0
189  const double elim = (m_clusterPars[m_i1] - x_vertex[m_i1]) / p_vec[m_i1];
190  const double mom = p_vec.norm();
191
192  // r'
193  Eigen::Matrix<double, 3, 1> residual3 = Eigen::Matrix<double, 3, 1>::Zero(3, 1);
194  residual3(0) = m_clusterPars[m_i2] - x_vertex[m_i2] - p_vec[m_i2] * elim;
195  residual3(1) = m_clusterPars[m_i3] - x_vertex[m_i3] - p_vec[m_i3] * elim;
196  residual3(2) = m_clusterPars[3] - mom;
197
198  // dr'/dm | m:={xc,yc,zc,Ec} the measured quantities
199  Eigen::Matrix<double, 3, 4> P = Eigen::Matrix<double, 3, 4>::Zero(3, 4);
200  // deriving by the cluster pars
201  P(0, m_i2) = 1;
202  P(0, m_i1) = - p_vec[m_i2] / p_vec[m_i1];
203
204  P(1, m_i3) = 1;
205  P(1, m_i1) = - p_vec[m_i3] / p_vec[m_i1];
206  P(2, 3) = 1; // dE/dEc
207
208  p.getResiduals().segment(0, 3) = residual3;
209
210  p.getV() = P * m_covariance.selfadjointView<Eigen::Lower>() * P.transpose();
211
212  // dr'/dm | m:={x,y,z,px,py,pz,E}
213  // x := x_vertex (decay vertex of mother)
214  p.getH()(0, posindex + m_i1) = p_vec[m_i2] / p_vec[m_i1];
215  p.getH()(0, posindex + m_i2) = -1.0;
216  p.getH()(0, posindex + m_i3) = 0;
217
218  p.getH()(1, posindex + m_i1) = p_vec[m_i3] / p_vec[m_i1];
219  p.getH()(1, posindex + m_i2) = 0;
220  p.getH()(1, posindex + m_i3) = -1.0;
221
222  // elim already devided by p_vec[m_i1]
223  p.getH()(0, momindex + m_i1) = p_vec[m_i2] * elim / p_vec[m_i1];
224  p.getH()(0, momindex + m_i2) = -1. * elim;
225  p.getH()(0, momindex + m_i3) = 0;
226
227  p.getH()(1, momindex + m_i1) = p_vec[m_i3] * elim / p_vec[m_i1];
228  p.getH()(1, momindex + m_i2) = 0;
229  p.getH()(1, momindex + m_i3) = -1. * elim;
230
231  p.getH()(2, momindex + m_i1) = -1. * p_vec[m_i1] / mom;
232  p.getH()(2, momindex + m_i2) = -1. * p_vec[m_i2] / mom;
233  p.getH()(2, momindex + m_i3) = -1. * p_vec[m_i3] / mom;
234  // the photon does not store an energy in the state vector
235  // so no p.getH()(2, momindex + 3) here
236
237  return ErrCode(ErrCode::Status::success);
238  }
239
240 }
241
242

◆ updateIndex()

void updateIndex ( int &  offset)
virtualinherited

this sets the index for momentum, position, etc.

in the statevector

Definition at line 138 of file ParticleBase.cc.

Member Data Documentation

◆ m_i1

int m_i1
private

index with the highest momentum.

We have to make sure this does not change during the fit.

Definition at line 96 of file RecoPhoton.h.
