The Class for ARICH Geometry Parameters. More...

#include <ARICHGeometryConfig.h>

Inheritance diagram for ARICHGeometryConfig:

Collaboration diagram for ARICHGeometryConfig:

[legend]

Public Member Functions
	ARICHGeometryConfig ()
	Default constructor.

	ARICHGeometryConfig (const GearDir &)
	Contructor.

void	clear (void)
	Clears.

void	print (const std::string &title="ARICH geometry parameters") const
	Print some debug information.

void	read (const GearDir &content)
	gets geometry parameters from gearbox.

double	getDetectorZPosition () const
	get z position of detector plane (starting z of HAPDs)

int	doBeamBackgroundStudy () const
	returns 1 if beam background study (to add additional sensitive modules, detect neutrons, ...), 0 else

TVector2	getChannelPosition (unsigned moduleID, unsigned xChn, unsigned yChn) const
	Get position of HAPD (x,y) channel in local ARICH coordinates. More...

const ARICHGeoDetectorPlane &	getDetectorPlane () const
	Get geometry configuration of HAPD plane. More...

const ARICHGeoAerogelPlane &	getAerogelPlane () const
	Get geometry configuration of aerogel plane. More...

const ARICHGeoMirrors &	getMirrors () const
	Get mirrors geometry configuration. More...

const ARICHGeoMasterVolume &	getMasterVolume () const
	Get ARICH master volume geometry configuration. More...

const ARICHGeoSupport &	getSupportStructure () const
	Get ARICH support structure geometry configuration. More...

const ARICHGeoHAPD &	getHAPDGeometry () const
	Get HAPD geometry parameters. More...

const ARICHGeoMerger &	getMergerGeometry () const
	Get Merger PCB geometry parameters. More...

const ARICHGeoCablesEnvelope &	getCablesEnvelope () const
	Get ARICH cables envelop geometry parameters. More...

const ARICHGeoCooling &	getCoolingGeometry () const
	Get ARICH cooling system geometry parameters. More...

const ARICHGeoFEBCooling &	getFEBCoolingGeometry () const
	Get ARICH FEB cooling system (v2) geometry parameters. More...

const ARICHGeoGlobalDisplacement &	getGlobalDisplacement () const
	Get global displacement parameters. More...

const ARICHGeoMirrorDisplacement &	getMirrorDisplacement () const
	Get mirror displacement parameters. More...

void	setAerogelPlane (const ARICHGeoAerogelPlane &aerogelPlane)
	Set geometry configuration of aerogel plane. More...

void	setDetectorPlane (const ARICHGeoDetectorPlane &detectorPlane)
	Set geometry configuration of HAPD plane. More...

void	setMirrors (const ARICHGeoMirrors &mirrors)
	Set mirrors geometry configuration. More...

void	setMasterVolume (const ARICHGeoMasterVolume &masterVolume)
	Set master volume geometry configuration. More...

void	setSupportStructure (const ARICHGeoSupport &supportStructure)
	Set support structure geometry configuration. More...

void	setGlobalDisplacement (const ARICHGeoGlobalDisplacement &displ)
	Set global displacement parameters. More...

void	setMirrorDisplacement (const ARICHGeoMirrorDisplacement &displ)
	Set mirror displacement parameters. More...

void	setUseGlobalDisplacement (bool use)

void	setUseMirrorDisplacement (bool use)

bool	useGlobalDisplacement () const

bool	useMirrorDisplacement () const

void	setName (const std::string &name)
	Sets object name. More...

const std::string &	getName () const
	Returns object name. More...

virtual bool	isConsistent () const
	Check for consistency of data members. More...

virtual void	printSurface (const GeoOpticalSurface &surface) const
	Print the content of optical surface. More...

virtual void	printPlacement (double x, double y, double z, double rx, double ry, double rz) const
	Print volume positioning parameters. More...

Static Public Member Functions
static void	useBasf2Units ()
	Use basf2 units when returning geometry parameters.

static void	useGeantUnits ()
	Use Geant4 units when returning geometry parameters.

Protected Member Functions
	ClassDef (ARICHGeoBase, 2)
	ClassDef.

Protected Attributes
std::string	m_name
	geometry object name

Static Protected Attributes
static double	s_unit = Unit::cm
	conversion unit for length

static std::string	s_unitName
	conversion unit name

Private Member Functions
void	modulesPosition (const GearDir &content)
	initializes the positions of HAPD modules, with the parameters from xml.

	ClassDef (ARICHGeometryConfig, 5)
	ClassDef, must be the last term before the closing {}.

Private Attributes
ARICHGeoDetectorPlane	m_detectorPlane
	detector plane geometry configuration

ARICHGeoAerogelPlane	m_aerogelPlane
	aerogel plane geometry configuration

ARICHGeoMirrors	m_mirrors
	mirrors geometry configuration

ARICHGeoMasterVolume	m_masterVolume
	master volume geometry configuration

ARICHGeoSupport	m_supportStructure
	support structure geometry configuration

ARICHGeoHAPD	m_hapd
	HAPD geometry configuration.

ARICHGeoMerger	m_merger
	Merger PCB geometry configuration.

ARICHGeoCablesEnvelope	m_cablesenvelope
	ARICH cables envelop geometry configuration.

ARICHGeoCooling	m_cooling
	ARICH cooling system geometry configuration.

ARICHGeoFEBCooling	m_coolingv2
	ARICH cooling system (v2) geometry configuration.

ARICHGeoGlobalDisplacement	m_globalDispl
	global displacement parameters

ARICHGeoMirrorDisplacement	m_mirrorDispl
	mirror displacement parameters

bool	m_displaceMirrors = 0
	use mirror displacement parameters

bool	m_displaceGlobal = 0
	use global displacement parameters

int	m_bbstudy = 0
	is beam background study

Detailed Description

The Class for ARICH Geometry Parameters.

This class provides ARICH gemetry paramters for simulation, reconstruction and so on. These parameters are gotten from gearbox.

Definition at line 42 of file ARICHGeometryConfig.h.

Member Function Documentation

◆ getAerogelPlane()

const ARICHGeoAerogelPlane& getAerogelPlane ( ) const

inline

Get geometry configuration of aerogel plane.

Returns: aerogel plane geometry parameters

Definition at line 98 of file ARICHGeometryConfig.h.

98 {return m_aerogelPlane;}

◆ getCablesEnvelope()

const ARICHGeoCablesEnvelope& getCablesEnvelope ( ) const

inline

Get ARICH cables envelop geometry parameters.

Returns: ARICH cables envelop geometry parameters

Definition at line 134 of file ARICHGeometryConfig.h.

◆ getChannelPosition()

TVector2 getChannelPosition	(	unsigned	moduleID,
		unsigned	xChn,
		unsigned	yChn
	)		const

Get position of HAPD (x,y) channel in local ARICH coordinates.

Parameters

moduleID	module ID
xChn	HAPD x channel
yChn	HAPD y channel

Returns: channel position

Definition at line 380 of file ARICHGeometryConfig.cc.

 {
   TVector2 origin;
   origin.SetMagPhi(m_detectorPlane.getSlotR(moduleID), m_detectorPlane.getSlotPhi(moduleID));
   double x, y;
   m_hapd.getXYChannelPos(chX, chY, x, y);
   TVector2 locPos(x, y);
   return origin + locPos.Rotate(m_detectorPlane.getSlotPhi(moduleID));
 }

◆ getCoolingGeometry()

const ARICHGeoCooling& getCoolingGeometry ( ) const

inline

Get ARICH cooling system geometry parameters.

Returns: ARICH cooling system geometry parameters

Definition at line 140 of file ARICHGeometryConfig.h.

◆ getDetectorPlane()

const ARICHGeoDetectorPlane& getDetectorPlane ( ) const

inline

Get geometry configuration of HAPD plane.

Returns: detector plane geometry parameters

Definition at line 92 of file ARICHGeometryConfig.h.

◆ getFEBCoolingGeometry()

const ARICHGeoFEBCooling& getFEBCoolingGeometry ( ) const

inline

Get ARICH FEB cooling system (v2) geometry parameters.

Returns: ARICH FEB cooling system (v2) geometry parameters

Definition at line 146 of file ARICHGeometryConfig.h.

◆ getGlobalDisplacement()

const ARICHGeoGlobalDisplacement& getGlobalDisplacement ( ) const

inline

Get global displacement parameters.

Returns: global displacement parameters

Definition at line 152 of file ARICHGeometryConfig.h.

◆ getHAPDGeometry()

const ARICHGeoHAPD& getHAPDGeometry ( ) const

inline

Get HAPD geometry parameters.

Returns: HAPD geometry parameters

Definition at line 122 of file ARICHGeometryConfig.h.

◆ getMasterVolume()

const ARICHGeoMasterVolume& getMasterVolume ( ) const

inline

Get ARICH master volume geometry configuration.

Returns: master volume geometry parameters

Definition at line 110 of file ARICHGeometryConfig.h.

◆ getMergerGeometry()

const ARICHGeoMerger& getMergerGeometry ( ) const

inline

Get Merger PCB geometry parameters.

Returns: Merger PCB geometry parameters

Definition at line 128 of file ARICHGeometryConfig.h.

◆ getMirrorDisplacement()

const ARICHGeoMirrorDisplacement& getMirrorDisplacement ( ) const

inline

Get mirror displacement parameters.

Returns: mirror displacement parameters

Definition at line 158 of file ARICHGeometryConfig.h.

◆ getMirrors()

const ARICHGeoMirrors& getMirrors ( ) const

inline

Get mirrors geometry configuration.

Returns: mirrors geometry parameters

Definition at line 104 of file ARICHGeometryConfig.h.

◆ getName()

const std::string& getName ( ) const

inlineinherited

Returns object name.

Returns: object name

Definition at line 59 of file ARICHGeoBase.h.

◆ getSupportStructure()

const ARICHGeoSupport& getSupportStructure ( ) const

inline

Get ARICH support structure geometry configuration.

Returns: support structure geometry parameters

Definition at line 116 of file ARICHGeometryConfig.h.

◆ isConsistent()

virtual bool isConsistent ( ) const

inlinevirtualinherited

Check for consistency of data members.

Returns: true if values consistent (valid)

Reimplemented in ARICHGeoHAPD, ARICHPositionElement, ARICHGeoSupport, ARICHGeoAerogelPlane, ARICHGeoMasterVolume, ARICHGeoMirrors, and ARICHGeoDetectorPlane.

Definition at line 65 of file ARICHGeoBase.h.

◆ printPlacement()

void printPlacement	(	double	x,
		double	y,
		double	z,
		double	rx,
		double	ry,
		double	rz
	)		const

virtualinherited

Print volume positioning parameters.

Parameters

x	x position
y	y position
z	z position
rx	rotation around x-axis
ry	rotation around y-axis
rz	rotation around z-axis

Definition at line 27 of file ARICHGeoBase.cc.

◆ printSurface()

void printSurface ( const GeoOpticalSurface & surface ) const

virtualinherited

Print the content of optical surface.

Parameters

surface optical surface parameters

Definition at line 34 of file ARICHGeoBase.cc.

◆ setAerogelPlane()

void setAerogelPlane ( const ARICHGeoAerogelPlane & aerogelPlane )

inline

Set geometry configuration of aerogel plane.

Parameters

aerogelPlane aerogel plane geometry parameters

Definition at line 165 of file ARICHGeometryConfig.h.

◆ setDetectorPlane()

void setDetectorPlane ( const ARICHGeoDetectorPlane & detectorPlane )

inline

Set geometry configuration of HAPD plane.

Parameters

detectorPlane detector plane geometry parameters

Definition at line 174 of file ARICHGeometryConfig.h.

◆ setGlobalDisplacement()

void setGlobalDisplacement ( const ARICHGeoGlobalDisplacement & displ )

inline

Set global displacement parameters.

Parameters

displ global displacement parameters

Definition at line 210 of file ARICHGeometryConfig.h.

◆ setMasterVolume()

void setMasterVolume ( const ARICHGeoMasterVolume & masterVolume )

inline

Set master volume geometry configuration.

Parameters

masterVolume master volume geometry parameters

Definition at line 192 of file ARICHGeometryConfig.h.

◆ setMirrorDisplacement()

void setMirrorDisplacement ( const ARICHGeoMirrorDisplacement & displ )

inline

Set mirror displacement parameters.

Parameters

displ mirror displacement parameters

Definition at line 219 of file ARICHGeometryConfig.h.

◆ setMirrors()

void setMirrors ( const ARICHGeoMirrors & mirrors )

inline

Set mirrors geometry configuration.

Parameters

mirrors mirrors geometry parameters

Definition at line 183 of file ARICHGeometryConfig.h.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Sets object name.

Parameters

name	object name

Definition at line 53 of file ARICHGeoBase.h.

◆ setSupportStructure()

void setSupportStructure ( const ARICHGeoSupport & supportStructure )

inline

Set support structure geometry configuration.

Parameters

supportStructure support structure geometry parameters

Definition at line 201 of file ARICHGeometryConfig.h.

The documentation for this class was generated from the following files:

arich/dbobjects/include/ARICHGeometryConfig.h
arich/dbobjects/src/ARICHGeometryConfig.cc

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Private Member Functions

Private Attributes

Detailed Description

Member Function Documentation

◆ getAerogelPlane()

◆ getCablesEnvelope()

◆ getChannelPosition()

◆ getCoolingGeometry()

◆ getDetectorPlane()

◆ getFEBCoolingGeometry()

◆ getGlobalDisplacement()

◆ getHAPDGeometry()

◆ getMasterVolume()

◆ getMergerGeometry()

◆ getMirrorDisplacement()

◆ getMirrors()

◆ getName()

◆ getSupportStructure()

◆ isConsistent()

◆ printPlacement()

◆ printSurface()

◆ setAerogelPlane()

◆ setDetectorPlane()

◆ setGlobalDisplacement()

◆ setMasterVolume()

◆ setMirrorDisplacement()

◆ setMirrors()

◆ setName()

◆ setSupportStructure()
