Module for generation of KLM displacement or alignment data. More...

#include <KLMDisplacementGenerator.h>

Collaboration diagram for KLMDisplacementGenerator:

[legend]

Public Member Functions
	KLMDisplacementGenerator ()
	Constructor.

	~KLMDisplacementGenerator ()
	Destructor.

void	fillZeroDisplacements (EKLMAlignment alignment, EKLMSegmentAlignment segmentAlignment)
	Fill EKLMAlignment with zero displacements. More...

void	generateFixedModuleDisplacement (double deltaU, double deltaV, double deltaGamma)
	Generation of fixed module displacements. More...

void	generateRandomDisplacement (EKLMAlignment alignment, EKLMSegmentAlignment segmentAlignment, bool displaceModule, bool displaceSegment, bool moduleSameDisplacement=false, bool moduleZeroDeltaU=false, bool moduleZeroDeltaV=false, bool moduleZeroDeltaGamma=false)
	Generation of random displacements. More...

void	readDisplacementFromROOTFile (EKLMAlignment alignment, EKLMSegmentAlignment segmentAlignment, const char *inputFile)
	Read displacement from ROOT file. More...

void	studyModuleAlignmentLimits (TFile *f)
	Generate random module displacements and check if they are correct (no overlaps). More...

void	studySegmentAlignmentLimits (TFile *f)
	Generate random segment displacements and check if they are correct (no overlaps). More...

void	studyAlignmentLimits (const char *outputFile)
	Generate random displacements and check if they are correct (no overlaps). More...

void	saveDisplacement (EKLMAlignment alignment, EKLMSegmentAlignment segmentAlignment, const char *outputFile)
	Save displacements to a ROOT file. More...

Private Attributes
const EKLM::GeometryData *	m_GeoDat
	Geometry data.

const KLMElementNumbers *	m_ElementNumbers
	Element numbers.

const EKLMElementNumbers *	m_eklmElementNumbers
	EKLM element numbers.

Detailed Description

Module for generation of KLM displacement or alignment data.

Definition at line 40 of file KLMDisplacementGenerator.h.

Member Function Documentation

◆ fillZeroDisplacements()

void fillZeroDisplacements	(	EKLMAlignment *	alignment,
		EKLMSegmentAlignment *	segmentAlignment
	)

Fill EKLMAlignment with zero displacements.

Parameters

[out]	alignment	Displacements.
[out]	segmentAlignment	Segment displacements.

Definition at line 39 of file KLMDisplacementGenerator.cc.

 {
   KLMAlignmentData alignmentData(0, 0, 0, 0, 0, 0);
   int iSection, iLayer, iSector, iPlane, iSegment, segment;
   for (iSection = 1; iSection <= m_GeoDat->getNSections(); iSection++) {
     for (iLayer = 1; iLayer <= m_GeoDat->getNDetectorLayers(iSection);
          iLayer++) {
       for (iSector = 1; iSector <= m_GeoDat->getNSectors(); iSector++) {
         int module = m_ElementNumbers->moduleNumberEKLM(iSection, iSector, iLayer);
         alignment->setModuleAlignment(module, &alignmentData);
         for (iPlane = 1; iPlane <= m_GeoDat->getNPlanes(); iPlane++) {
           for (iSegment = 1; iSegment <= m_GeoDat->getNSegments(); iSegment++) {
             segment = m_eklmElementNumbers->segmentNumber(
                         iSection, iLayer, iSector, iPlane, iSegment);
             segmentAlignment->setSegmentAlignment(segment, &alignmentData);
           }
         }
       }
     }
   }
 }

◆ generateFixedModuleDisplacement()

void generateFixedModuleDisplacement	(	double	deltaU,
		double	deltaV,
		double	deltaGamma
	)

Generation of fixed module displacements.

Parameters

[in]	deltaU	Shift in U.
[in]	deltaV	Shift in V.
[in]	deltaGamma	Rotation in Gamma.

Definition at line 62 of file KLMDisplacementGenerator.cc.

◆ generateRandomDisplacement()

void generateRandomDisplacement	(	EKLMAlignment *	alignment,
		EKLMSegmentAlignment *	segmentAlignment,
		bool	displaceModule,
		bool	displaceSegment,
		bool	moduleSameDisplacement = `false`,
		bool	moduleZeroDeltaU = `false`,
		bool	moduleZeroDeltaV = `false`,
		bool	moduleZeroDeltaGamma = `false`
	)

Generation of random displacements.

Parameters

[out]	alignment	Displacements.
[out]	segmentAlignment	Segment displacements.
[in]	displaceModule	Whether modules should be displaced.
[in]	displaceSegment	Whether segments should be displaced.
[in]	moduleSameDisplacement	If the displacement should be the same for all modules.
[in]	moduleZeroDeltaU	Fix module deltaU at 0.
[in]	moduleZeroDeltaV	Fix module deltaV at 0.
[in]	moduleZeroDeltaGamma	Fix module deltaGamma at 0.
