The PXD DAQ DHE Status class. More...

#include <PXDDAQDHEStatus.h>

Collaboration diagram for PXDDAQDHEStatus:

[legend]

Public Member Functions
	PXDDAQDHEStatus ()
	Default constructor for the ROOT IO.

	PXDDAQDHEStatus (VxdID id, int dheid, PXDErrorFlags mask, unsigned short tg, unsigned short fn)
	constructor setting the error mask, dheid, raw and reduced data counters, ... More...

bool	isUsable () const
	Return Usability of data. More...

void	markUnusable ()
	Mark Data in DHE as Unusable.

void	setErrorMask (PXDErrorFlags m)
	Set Error bit mask. More...

PXDErrorFlags	getErrorMask (void) const
	Return Error bit mask. More...

void	setCritErrorMask (PXDErrorFlags m)
	Set Critical Error bit mask. More...

PXDErrorFlags	getCritErrorMask (void) const
	Return Critical Error bit mask. More...

void	Decide (void)
	Calculate the usability decision If any of the critical bits is set in the error mask the PXD data from this DHE is not usable for analysis TODO Maybe this decision needs improvement.

void	setDHEID (VxdID id, int dheid)
	Set VxdID and DHE ID of sensor.

unsigned short	getDHEID (void) const
	Get DHE ID of sensor.

VxdID	getSensorID (void) const
	Get VxdID of sensor.

void	setCounters (uint32_t raw, uint32_t red)
	Set Data counters for reduction calculation.

void	getCounters (uint32_t &raw, uint32_t &red) const
	Get Data counters for reduction calculation.

uint32_t	getRawCnt (void) const
	Set Raw Data counter for reduction calculation.

uint32_t	getRedCnt (void) const
	Set Reduced Data counter for reduction calculation.

void	setTriggerGate (unsigned int tg)
	set Trigger Gate

unsigned short	getTriggerGate (void) const
	get Trigger Gate

unsigned short	getStartRow (void) const
	get Trigger Start Row

void	setFrameNr (unsigned int fn)
	set Readout Frame number

unsigned short	getFrameNr (void) const
	get Readout Frame number

unsigned short	getDHPFoundMask (void)
	get Mask for found DHPs with valid data

void	setDHPFoundMask (unsigned short dhpmask)
	set Mask for found DHPs with valid data

void	setEndErrorInfo (uint32_t e)
	set erroinfo from the DHE END

uint32_t	getEndErrorInfo (void) const
	get erroinfo from the DHE END

void	addDHP (PXDDAQDHPStatus &daqdhp)
	Add DHP information. More...

template<class ... Args>
PXDDAQDHPStatus &	newDHP (Args &&... params)
	New DHP information. More...

std::vector< PXDDAQDHPStatus >::iterator	begin ()
	iterator-based iteration for DHPs

std::vector< PXDDAQDHPStatus >::iterator	end ()
	iterator-based iteration for DHPs

std::vector< PXDDAQDHPStatus >::const_iterator	cbegin () const
	const iterator-based iteration for DHPs

std::vector< PXDDAQDHPStatus >::const_iterator	cend () const
	const iterator-based iteration for DHPs

PXDDAQDHPStatus &	dhp_back ()
	Returns PXDDAQDHPStatus for the last DHP.

size_t	dhp_size () const
	Returns number of DHPs.

auto	addCM (PXDDAQDHPComMode &daqcm)
	Add Common Mode information. More...

std::vector< PXDDAQDHPComMode >::iterator	cm_begin ()
	iterator-based iteration for Common Mode

std::vector< PXDDAQDHPComMode >::iterator	cm_end ()
	iterator-based iteration for Common Mode

PXDDAQDHPComMode &	cm_back ()
	Returns last Common Mode for this event.

size_t	cm_size () const
	Returns number of Common Mode blocks in this event.

int	get_cm_dhp (int i) const
	Returns CM DHP ID at position i.

int	get_cm_row (int i) const
	Returns CM row at position i.

int	get_cm_value (int i) const
	Returns CM value at position i.

Private Member Functions
	ClassDef (PXDDAQDHEStatus, 7)
	necessary for ROOT

Private Attributes
PXDErrorFlags	m_errorMask
	errors found in this DHE/sensor

PXDErrorFlags	m_critErrorMask
	critical error mask

bool	m_usable
	data is useable.

unsigned short	m_sensorID
	Sensor ID.

unsigned short	m_dheID
	DHE ID as delivered by DAQ.

unsigned short	m_triggerGate
	Trigger Gate ("Startrow") from DHE header.

unsigned short	m_frameNr
	Frame number (low bits) from DHE header.

unsigned short	m_dhp_found_mask
	Mask for DHP with valid data.

uint32_t	m_rawCount
	raw byte count for monitoring

uint32_t	m_redCount
	reduced byte count for monitoring

uint32_t	m_errorinfo
	erroinfo from the DHE END

std::vector< PXDDAQDHPStatus >	m_pxdDHP
	Vector of DHP informations belonging to this event.

std::vector< PXDDAQDHPComMode >	m_commode
	Vector of Common Mode informations belonging to this event.

Detailed Description

The PXD DAQ DHE Status class.

This is a small class that records information about PXD DAQ DHE status It will record if the data of this sensor (readout by this DHE) is useable.

Definition at line 46 of file PXDDAQDHEStatus.h.

Constructor & Destructor Documentation

◆ PXDDAQDHEStatus()

PXDDAQDHEStatus	(	VxdID	id,
		int	dheid,
		PXDErrorFlags	mask,
		unsigned short	tg,
		unsigned short	fn
	)

inline

constructor setting the error mask, dheid, raw and reduced data counters, ...

Parameters

id	VxdID of sensor
dheid	DHEID of sensor
mask	Error mask
tg	Trigger Gate (Start Row, Trigger Offset)
fn	(absolute) Readout Frame Number, lower bits only

Definition at line 61 of file PXDDAQDHEStatus.h.

64 { m_usable = false; m_errorMask |= EPXDErrMask::c_UNUSABLE_DATA;}

Member Function Documentation

◆ addCM()

auto addCM ( PXDDAQDHPComMode & daqcm )

inline

Add Common Mode information.

Parameters

daqcm DHP Common Mode object

Definition at line 171 of file PXDDAQDHEStatus.h.

◆ addDHP()

void addDHP ( PXDDAQDHPStatus & daqdhp )

inline

Add DHP information.

Parameters

daqdhp DHP Status Object

Definition at line 142 of file PXDDAQDHEStatus.h.

◆ getCritErrorMask()

PXDErrorFlags getCritErrorMask ( void ) const

inline

Return Critical Error bit mask.

Returns: bit mask

Definition at line 93 of file PXDDAQDHEStatus.h.

◆ getErrorMask()

PXDErrorFlags getErrorMask ( void ) const

inline

Return Error bit mask.

Returns: bit mask

Definition at line 83 of file PXDDAQDHEStatus.h.

◆ isUsable()

bool isUsable ( ) const

inline

Return Usability of data.

Returns: conclusion if data is useable

Definition at line 69 of file PXDDAQDHEStatus.h.

◆ newDHP()

PXDDAQDHPStatus& newDHP ( Args &&... params )

inline

New DHP information.

Parameters

params constructor parameter

Returns: new DHP Status Object

Definition at line 148 of file PXDDAQDHEStatus.h.

◆ setCritErrorMask()

void setCritErrorMask ( PXDErrorFlags m )

inline

Set Critical Error bit mask.

Parameters

m	Bit Mask to set

Definition at line 88 of file PXDDAQDHEStatus.h.

◆ setErrorMask()

void setErrorMask ( PXDErrorFlags m )

inline

Set Error bit mask.

Parameters

m	Bit Mask to set

Definition at line 78 of file PXDDAQDHEStatus.h.

The documentation for this class was generated from the following file:

pxd/dataobjects/include/PXDDAQDHEStatus.h
