Class to store reconstructed particles. More...

#include <Particle.h>

Inheritance diagram for Particle:

Collaboration diagram for Particle:

[legend]

Public Types
enum	EParticleSourceObject { c_Undefined = 0, c_Track = 1, c_ECLCluster = 2, c_KLMCluster = 3, c_V0 = 4, c_MCParticle = 5, c_Composite = 6 }
	particle source enumerators

enum	EFlavorType { c_Unflavored = 0, c_Flavored = 1 }
	describes flavor type, see getFlavorType(). More...

enum	{ c_DimPosition = 3, c_DimMomentum = 4, c_DimMatrix = 7, c_SizeMatrix = c_DimMatrix * (c_DimMatrix + 1) / 2 }
	error matrix dimensions and size of 1D representation

enum	{ c_Px, c_Py, c_Pz, c_E, c_X, c_Y, c_Z }
	enumerator used for error matrix handling, shows also in which order the rows (columns) are defined

enum	PropertyFlags { c_Ordinary = 0, c_IsUnspecified = 1, c_IsIgnoreRadiatedPhotons = 2, c_IsIgnoreIntermediate = 4, c_IsIgnoreMassive = 8, c_IsIgnoreNeutrino = 16, c_IsIgnoreGamma = 32, c_IsIgnoreBrems = 64, c_IsIgnoreMisID = 128, c_IsIgnoreDecayInFlight = 256 }
	Flags that describe the particle property, which are used in the MC matching. More...

Public Member Functions
	Particle ()
	Default constructor. More...

	Particle (const TLorentzVector &momentum, const int pdgCode)
	Constructor from a Lorentz vector and PDG code. More...

	Particle (const TLorentzVector &momentum, const int pdgCode, EFlavorType flavorType, const EParticleSourceObject particleType, const unsigned mdstIndex)
	Constructor for final state particles. More...

	Particle (const TLorentzVector &momentum, const int pdgCode, EFlavorType flavorType, const std::vector< int > &daughterIndices, TClonesArray *arrayPointer=nullptr)
	Constructor for composite particles. More...

	Particle (const TLorentzVector &momentum, const int pdgCode, EFlavorType flavorType, const std::vector< int > &daughterIndices, int properties, TClonesArray *arrayPointer=nullptr)
	Constructor for composite particles. More...

	Particle (const TLorentzVector &momentum, const int pdgCode, EFlavorType flavorType, const std::vector< int > &daughterIndices, int properties, const std::vector< int > &daughterProperties, TClonesArray *arrayPointer=nullptr)
	Constructor for composite particles. More...

	Particle (const Track *track, const Const::ChargedStable &chargedStable)
	Constructor from a reconstructed track (mdst object Track);. More...

	Particle (const int trackArrayIndex, const TrackFitResult *trackFit, const Const::ChargedStable &chargedStable, const Const::ChargedStable &chargedStableUsedForFit)
	Constructor from a reconstructed Track given as TrackFitResult. More...

	Particle (int trackArrayIndex, const TrackFitResult *trackFit, const Const::ChargedStable &chargedStable)
	Constructor from a reconstructed Track given as TrackFitResult. More...

	Particle (const ECLCluster *eclCluster, const Const::ParticleType &type=Const::photon)
	Constructor of a photon from a reconstructed ECL cluster that is not matched to any charged track. More...

	Particle (const KLMCluster *klmCluster, const int pdgCode=Const::Klong.getPDGCode())
	Constructor from a reconstructed KLM cluster. More...

	Particle (const MCParticle *MCparticle)
	Constructor from MC particle (mdst object MCParticle) More...

	~Particle ()
	Destructor.

void	set4Vector (const TLorentzVector &p4)
	Sets Lorentz vector. More...

void	setVertex (const TVector3 &vertex)
	Sets position (decay vertex) More...

void	setMomentumVertexErrorMatrix (const TMatrixFSym &errMatrix)
	Sets 7x7 error matrix. More...

void	setPValue (float pValue)
	Sets chi^2 probability of fit. More...

void	setProperty (const int properties)
	sets m_properties

void	updateMomentum (const TLorentzVector &p4, const TVector3 &vertex, const TMatrixFSym &errMatrix, float pValue)
	Sets Lorentz vector, position, 7x7 error matrix and p-value. More...

void	updateMass (const int pdgCode)
	Updates particle mass with the mass of the particle corresponding to the given PDG. More...

void	appendDaughter (const Particle *daughter, const bool updateType=true)
	Appends index of daughter to daughters index array. More...

void	appendDaughter (int particleIndex, const bool updateType=true)
	Appends index of daughter to daughters index array. More...

void	removeDaughter (const Particle *daughter, const bool updateType=true)
	Removes index of daughter from daughters index array. More...

int	getPDGCode (void) const
	Returns PDG code. More...

float	getCharge (void) const
	Returns particle charge. More...

EFlavorType	getFlavorType () const
	Returns flavor type of the decay (for FS particles: flavor type of particle) More...

EParticleSourceObject	getParticleSource () const
	Returns particle source as defined with enum EParticleSourceObject. More...

unsigned	getMdstArrayIndex (void) const
	Returns 0-based index of MDST store array object (0 for composite particles) More...

int	getProperty () const
	Returns particle property as a bit pattern The values are defined in the PropertyFlags enum and described in detail there. More...

float	getMass () const
	Returns invariant mass (= nominal for FS particles) More...

float	getPDGMass (void) const
	Returns uncertaint on the invariant mass (requiers valid momentum error matrix) More...

float	getEnergy () const
	Returns total energy. More...

TLorentzVector	get4Vector () const
	Returns Lorentz vector. More...

TVector3	getMomentum () const
	Returns momentum vector. More...

float	getMomentumMagnitude () const
	Returns momentum magnitude. More...

float	getP () const
	Returns momentum magnitude (same as getMomentumMagnitude but with shorter name) More...

float	getPx () const
	Returns x component of momentum. More...

float	getPy () const
	Returns y component of momentum. More...

float	getPz () const
	Returns z component of momentum. More...

TVector3	getVertex () const
	Returns vertex position (POCA for charged, IP for neutral FS particles) More...

float	getX () const
	Returns x component of vertex position. More...

float	getY () const
	Returns y component of vertex position. More...

float	getZ () const
	Returns z component of vertex position. More...

float	getPValue () const
	Returns chi^2 probability of fit if done or -1. More...

TMatrixFSym	getMomentumVertexErrorMatrix () const
	Returns 7x7 error matrix. More...

TMatrixFSym	getMomentumErrorMatrix () const
	Returns the 4x4 momentum error matrix. More...

TMatrixFSym	getVertexErrorMatrix () const
	Returns the 3x3 position error sub-matrix. More...

float	getCosHelicity (const Particle *mother=nullptr) const
	Returns cosine of the helicity angle The helicity angle is defined in the rest frame of the particle as the angle between the negative momentum of the mother and. More...

float	getCosHelicityDaughter (unsigned iDaughter, unsigned iGrandDaughter=0) const
	Returns cosine of the helicity angle of the given daughter defined by given grand daughter. More...

float	getAcoplanarity () const
	Returns acoplanarity angle defined as the angle between the decay planes of the grand daughters in the particle's rest frame This assumes that the particle and its daughters have two daughters each. More...

int	getMdstSource () const
	Returns unique identifier of final state particle (needed in particle combiner) More...

unsigned	getNDaughters (void) const
	Returns number of daughter particles. More...

const std::vector< int > &	getDaughterIndices () const
	Returns a vector of store array indices of daughter particles. More...

const std::vector< int > &	getDaughterProperties () const
	Returns a vector of properties of daughter particles. More...

const Particle *	getDaughter (unsigned i) const
	Returns a pointer to the i-th daughter particle. More...

bool	forEachDaughter (const std::function< bool(const Particle *)> &function, bool recursive=true, bool includeSelf=true) const
	Apply a function to all daughters of this particle. More...

std::vector< Belle2::Particle * >	getDaughters () const
	Returns a vector of pointers to daughter particles. More...

std::vector< const Belle2::Particle * >	getFinalStateDaughters () const
	Returns a vector of pointers to Final State daughter particles. More...

std::vector< int >	getMdstArrayIndices (EParticleSourceObject type) const
	Returns a vector of StoreArray indices of given MDST dataobjects. More...

bool	overlapsWith (const Particle *oParticle) const
	Returns true if final state ancessors of oParticle overlap. More...

bool	isCopyOf (const Particle *oParticle, bool doDetailedComparison=false) const
	Returns true if this Particle and oParticle are copies of each other. More...

const Track *	getTrack () const
	Returns the pointer to the Track object that was used to create this Particle (ParticleType == c_Track). More...

const TrackFitResult *	getTrackFitResult () const
	Returns the pointer to the TrackFitResult that was used to create this Particle (ParticleType == c_Track). More...

const V0 *	getV0 () const
	Returns the pointer to the V0 object that was used to create this Particle (if ParticleType == c_V0). More...

const PIDLikelihood *	getPIDLikelihood () const
	Returns the pointer to the PIDLikelihood object that is related to the Track, which was used to create this Particle (ParticleType == c_Track). More...

const ECLCluster *	getECLCluster () const
	Returns the pointer to the ECLCluster object that was used to create this Particle (if ParticleType == c_ECLCluster). More...

double	getECLClusterEnergy () const
	Returns the energy of the ECLCluster for the particle. More...

const KLMCluster *	getKLMCluster () const
	Returns the pointer to the KLMCluster object that was used to create this Particle (ParticleType == c_KLMCluster). More...

const MCParticle *	getMCParticle () const
	Returns the pointer to the MCParticle object that was used to create this Particle (ParticleType == c_MCParticle). More...

virtual std::string	getName () const
	Return name of this particle.

virtual std::string	getInfoHTML () const
	Return a short summary of this object's contents in HTML format.

void	print () const
	Prints the contents of a Particle object to standard output.

std::vector< std::string >	getExtraInfoNames () const
	get a list of the extra info names

void	removeExtraInfo ()
	Remove all stored extra info fields.

float	getExtraInfo (const std::string &name) const
	Return given value if set. More...

bool	hasExtraInfo (const std::string &name) const
	Return wether the extra info with the given name is set.

int	getExtraInfoMap () const
	Return the id of the associated ParticleExtraInfoMap or -1 if no map is set.

unsigned int	getExtraInfoSize () const
	Return the size of the extra info array.

void	writeExtraInfo (const std::string &name, const float value)
	Sets the user defined extraInfo. More...

void	setExtraInfo (const std::string &name, float value)
	Sets the user-defined data of given name to the given value. More...

void	addExtraInfo (const std::string &name, float value)
	Sets the user-defined data of given name to the given value. More...

TClonesArray *	getArrayPointer () const
	Returns the pointer to the store array which holds the daughter particles. More...

int	getPDGCodeUsedForFit ()
	Return the always positive PDG code which was used for the track fit (if there was a track fit) of this particle. More...

bool	wasExactFitHypothesisUsed () const
	Returns true if the type represented by this Particle object was used use as a mass hypothesis during the track of this Particle's parameters.

ECLCluster::EHypothesisBit	getECLClusterEHypothesisBit () const
	Returns the ECLCluster EHypothesisBit for this Particle.

const Particle *	getParticleFromGeneralizedIndexString (const std::string &generalizedIndex) const
	Explores the decay tree of the particle and returns the (grand^n)daughter identified by a generalized index. More...

void	addRelationTo (const RelationsInterface< BASE > *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (with caching). More...

void	addRelationTo (const TObject *object, float weight=1.0, const std::string &namedRelation="") const
	Add a relation from this object to another object (no caching, can be quite slow). More...

void	copyRelations (const RelationsInterface< BASE > *sourceObj)
	Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights). More...

template<class TO >
RelationVector< TO >	getRelationsTo (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from this object to another store array. More...

template<class FROM >
RelationVector< FROM >	getRelationsFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the relations that point from another store array to this object. More...

template<class T >
RelationVector< T >	getRelationsWith (const std::string &name="", const std::string &namedRelation="") const
	Get the relations between this object and another store array. More...

template<class TO >
TO *	getRelatedTo (const std::string &name="", const std::string &namedRelation="") const
	Get the object to which this object has a relation. More...

template<class FROM >
FROM *	getRelatedFrom (const std::string &name="", const std::string &namedRelation="") const
	Get the object from which this object has a relation. More...

template<class T >
T *	getRelated (const std::string &name="", const std::string &namedRelation="") const
	Get the object to or from which this object has a relation. More...

template<class TO >
std::pair< TO *, float >	getRelatedToWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing to an array. More...

template<class FROM >
std::pair< FROM *, float >	getRelatedFromWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from an array. More...

template<class T >
std::pair< T *, float >	getRelatedWithWeight (const std::string &name="", const std::string &namedRelation="") const
	Get first related object & weight of relation pointing from/to an array. More...

std::string	getInfo () const
	Return a short summary of this object's contents in raw text format. More...

std::string	getArrayName () const
	Get name of array this object is stored in, or "" if not found.

int	getArrayIndex () const
	Returns this object's array index (in StoreArray), or -1 if not found.

Private Member Functions
void	setMomentumPositionErrorMatrix (const TrackFitResult *trackFit)
	Sets the momentum, position and error matrix for this particle (created from charged Track)

void	resetErrorMatrix ()
	Resets 7x7 error matrix All elements are set to 0.0.

void	storeErrorMatrix (const TMatrixFSym &errMatrix)
	Stores 7x7 error matrix into private member m_errMatrix. More...

void	fillFSPDaughters (std::vector< const Belle2::Particle * > &fspDaughters) const
	Fill final state particle daughters into a vector. More...

void	fillDecayChain (std::vector< int > &decayChain) const
	Fill vector with (PDGCode, MdstSource) pairs for the entire decay chain. More...

void	setFlavorType ()
	sets m_flavorType using m_pdgCode

void	setMdstArrayIndex (const int arrayIndex)
	set mdst array index

int	generatePDGCodeFromCharge (const int chargedSign, const Const::ChargedStable &chargedStable)
	Generate the PDG code with correct sign, using the charge. More...

	ClassDef (Particle, 12)
	Class to store reconstructed particles.

Private Attributes
int	m_pdgCode
	PDG code.

int	m_pdgCodeUsedForFit = 0
	PDG code used for the track fit.

float	m_mass
	particle (invariant) mass

float	m_px
	momentum component x

float	m_py
	momentum component y

float	m_pz
	momentum component z

float	m_x
	position component x

float	m_y
	position component y

float	m_z
	position component z

float	m_errMatrix [c_SizeMatrix] = {}
	error matrix (1D representation)

float	m_pValue
	chi^2 probability of the fit. More...

std::vector< int >	m_daughterIndices
	daughter particle indices

EFlavorType	m_flavorType
	flavor type.

EParticleSourceObject	m_particleSource
	(mdst) source of particle

unsigned	m_mdstIndex
	0-based index of MDST store array object

int	m_properties
	particle property

std::vector< int >	m_daughterProperties
	daughter particle properties

int	m_identifier = -1
	Identifier that can be used to identify whether the particle is unique or is a copy or representation of another. More...

std::vector< float >	m_extraInfo
	Stores associated user defined values. More...

TClonesArray *	m_arrayPointer
	Internal pointer to DataStore array containing the daughters of this particle. More...

DataStore::StoreEntry *	m_cacheDataStoreEntry
	Cache of the data store entry to which this object belongs.

int	m_cacheArrayIndex
	Cache of the index in the TClonesArray to which this object belongs.

Friends
class	ParticleSubset

Detailed Description

Class to store reconstructed particles.

This class is a common representation of all particle types, e.g.:

final state particles (FS particles):
- charged kaons/pions/electrons/muons/protons reconstructed as Track
- photons reconstructed as ECLCluster (without associated Track)
- long lived neutral kaons reconstructed in KLM (as KLMCluster without associated Track)
composite particles:
- pre-reconstructed V0 particles: Kshort, Lambda baryon, converted photon, ...
- reconstructed in decays (via combinations)

Private members are limited to those which completely define the particle and that are common to all particle types. These are:

particle mass
- nominal for FS particles
- invariant for composite particles
momentum vector (px, py, pz)
position (x, y, z)
- POCA for charged FS particles
- IP for photons, Klong and pi0
- decay vertex for composite particles
7x7 error matrix (order is: px, py, pz, E, x, y, z)
chi^2 probability of the fit (track fit, pi0 mass-constr. fit or vertex fit)
PDG code
vector of StoreArray<Particle> indices of daughter particles

Additional private members are needed in order to make composite particles (via combinations):

mdst index of an object from which the FS particle is created
source of the object from which the particle is created (see EParticleSourceObject)
flavor type (unflavored/flavored) of a decay or flavor type of FS particle

Finally, it is possible to store user-defined floating-point values using addExtraInfo() and getExtraInfo(), identified by a string key. These are general purpose functions for collecting additional information about reconstructed particles that can not be included into any existing data object. Different Particle objects can store different sets of values, and there are no hard-coded limitations on the number of values stored.

Definition at line 77 of file Particle.h.

Member Enumeration Documentation

◆ EFlavorType

enum EFlavorType

describes flavor type, see getFlavorType().

Enumerator
c_Unflavored	Is its own antiparticle or we don't know whether it is a particle/antiparticle.
c_Flavored	Is either particle or antiparticle.

Definition at line 95 of file Particle.h.

                      {
       c_Unflavored = 0,
       c_Flavored = 1,
     };

◆ PropertyFlags

enum PropertyFlags

Flags that describe the particle property, which are used in the MC matching.

Enumerator
c_IsUnspecified	Ordinary particles. Is the particle unspecified by marking @ ?
c_IsIgnoreRadiatedPhotons	Is the particle MC matched with the ignore radiated photon flag set?
c_IsIgnoreIntermediate	Is the particle MC matched with the ignore intermediate resonances flag set?
c_IsIgnoreMassive	Is the particle MC matched with the ignore missing massive particle flag set?
c_IsIgnoreNeutrino	Is the particle MC matched with the ignore missing neutrino flag set?
c_IsIgnoreGamma	Is the particle MC matched with the ignore missing gamma flag set?
c_IsIgnoreBrems	Is the particle MC matched with the ignore added Brems gamma flag set?
c_IsIgnoreMisID	Is the particle MC matched with the ignore MisID flag set?
c_IsIgnoreDecayInFlight	Is the particle MC matched with the ignore DecayInFlight flag set?

Definition at line 117 of file Particle.h.

Constructor & Destructor Documentation

◆ Particle() [1/12]

Particle ( )

Default constructor.

All private members are set to 0. Particle type is set to c_Undefined.

Definition at line 47 of file Particle.cc.

                    :
   m_pdgCode(0), m_mass(0), m_px(0), m_py(0), m_pz(0), m_x(0), m_y(0), m_z(0),
   m_pValue(nan("")), m_flavorType(c_Unflavored), m_particleSource(c_Undefined), m_mdstIndex(0), m_properties(0),
   m_arrayPointer(nullptr)
 {
   resetErrorMatrix();
 }

◆ Particle() [2/12]

Particle	(	const TLorentzVector &	momentum,
		const int	pdgCode
	)

Constructor from a Lorentz vector and PDG code.

All other private members are set to their default values (0).

Parameters

momentum	Lorentz vector
pdgCode	PDG code

Definition at line 56 of file Particle.cc.

◆ Particle() [3/12]

Particle	(	const TLorentzVector &	momentum,
		const int	pdgCode,
		EFlavorType	flavorType,
		const EParticleSourceObject	particleType,
		const unsigned	mdstIndex
	)

Constructor for final state particles.

All other private members are set to their default values (0).

Parameters

momentum	Lorentz vector
pdgCode	PDG code
flavorType	flavor type
particleType	particle source
mdstIndex	mdst index

Definition at line 66 of file Particle.cc.

◆ Particle() [4/12]

Particle	(	const TLorentzVector &	momentum,
		const int	pdgCode,
		EFlavorType	flavorType,
		const std::vector< int > &	daughterIndices,
		TClonesArray *	arrayPointer = `nullptr`
	)

Constructor for composite particles.

All other private members are set to their default values (0).

Parameters

momentum	Lorentz vector
pdgCode	PDG code
flavorType	decay flavor type
daughterIndices	indices of daughters in StoreArray<Particle>
arrayPointer	pointer to store array which stores the daughters, if the particle itself is stored in the same array the pointer can be automatically determined

Definition at line 83 of file Particle.cc.

◆ Particle() [5/12]

Particle	(	const TLorentzVector &	momentum,
		const int	pdgCode,
		EFlavorType	flavorType,
		const std::vector< int > &	daughterIndices,
		int	properties,
		TClonesArray *	arrayPointer = `nullptr`
	)

Constructor for composite particles.

All other private members are set to their default values (0).

Parameters

momentum	Lorentz vector
pdgCode	PDG code
flavorType	decay flavor type
daughterIndices	indices of daughters in StoreArray<Particle>
properties	particle property
arrayPointer	pointer to store array which stores the daughters, if the particle itself is stored in the same array the pointer can be automatically determined

Definition at line 112 of file Particle.cc.

◆ Particle() [6/12]

Particle	(	const TLorentzVector &	momentum,
		const int	pdgCode,
		EFlavorType	flavorType,
		const std::vector< int > &	daughterIndices,
		int	properties,
		const std::vector< int > &	daughterProperties,
		TClonesArray *	arrayPointer = `nullptr`
	)

Constructor for composite particles.

All other private members are set to their default values (0).

Parameters

momentum	Lorentz vector
pdgCode	PDG code
flavorType	decay flavor type
daughterIndices	indices of daughters in StoreArray<Particle>
particle	property
daughter	particle properties
arrayPointer	pointer to store array which stores the daughters, if the particle itself is stored in the same array the pointer can be automatically determined

Definition at line 144 of file Particle.cc.

◆ Particle() [7/12]

Particle	(	const Track *	track,
		const Const::ChargedStable &	chargedStable
	)

Constructor from a reconstructed track (mdst object Track);.

Parameters

track	pointer to Track object
chargedStable	Type of charged particle

Definition at line 175 of file Particle.cc.

◆ Particle() [8/12]

Particle	(	const int	trackArrayIndex,
		const TrackFitResult *	trackFit,
		const Const::ChargedStable &	chargedStable,
		const Const::ChargedStable &	chargedStableUsedForFit
	)

Constructor from a reconstructed Track given as TrackFitResult.

To be used to create Particle objects from V0 daughters.

Parameters

trackArrayIndex	track StoreArray index
trackFit	pointer to TrackFitResult object
chargedStable	Type of charged particle
chargedStableUsedForFit	Type of particle which has been used in the track fit. This can be different as chargedStable as we don't fit all tracks with all hypothesis.

Definition at line 208 of file Particle.cc.

◆ Particle() [9/12]

Particle	(	int	trackArrayIndex,
		const TrackFitResult *	trackFit,
		const Const::ChargedStable &	chargedStable
	)

Constructor from a reconstructed Track given as TrackFitResult.

To be used to create Particle objects from tracks with full control over the hypothesis (e.g. V0 daughters).

Parameters

trackArrayIndex	track StoreArray index
trackFit	pointer to TrackFitResult object
chargedStable	Type of charged particle

Definition at line 182 of file Particle.cc.

◆ Particle() [10/12]

Particle	(	const ECLCluster *	eclCluster,
		const Const::ParticleType &	type = `Const::photon`
	)

explicit

Constructor of a photon from a reconstructed ECL cluster that is not matched to any charged track.

Parameters

eclCluster	pointer to ECLCluster object
type	the kind of ParticleType we want (photon by default)

Definition at line 235 of file Particle.cc.

◆ Particle() [11/12]

Particle	(	const KLMCluster *	klmCluster,
		const int	pdgCode = `Const::Klong.getPDGCode()`
	)

explicit

Constructor from a reconstructed KLM cluster.

Parameters

klmCluster	pointer to KLMCluster object
pdgCode	PDG code (Klong by default)

Definition at line 271 of file Particle.cc.

◆ Particle() [12/12]

Particle ( const MCParticle * MCparticle )

explicit

Constructor from MC particle (mdst object MCParticle)

Parameters

MCparticle pointer to MCParticle object

Definition at line 297 of file Particle.cc.

Member Function Documentation

◆ addExtraInfo()

void addExtraInfo	(	const std::string &	name,
		float	value
	)

Sets the user-defined data of given name to the given value.

throws std::runtime_error if variable is already set.

Definition at line 1224 of file Particle.cc.

◆ addRelationTo() [1/2]

void addRelationTo	(	const RelationsInterface< BASE > *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (with caching).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 144 of file RelationsObject.h.

◆ addRelationTo() [2/2]

void addRelationTo	(	const TObject *	object,
		float	weight = `1.0`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Add a relation from this object to another object (no caching, can be quite slow).

Parameters

object	The object to which the relation should point.
weight	The weight of the relation.
namedRelation	Additional name for the relation, or "" for the default naming

Definition at line 157 of file RelationsObject.h.

◆ appendDaughter() [1/2]

void appendDaughter	(	const Particle *	daughter,
		const bool	updateType = `true`
	)

Appends index of daughter to daughters index array.

Parameters

daughter	pointer to the daughter particle
updateType	bool to set whether particle type should be updated

Definition at line 633 of file Particle.cc.

◆ appendDaughter() [2/2]

void appendDaughter	(	int	particleIndex,
		const bool	updateType = `true`
	)

inline

Appends index of daughter to daughters index array.

Parameters

particleIndex	index of daughter in StoreArray<Particle>
updateType	bool to set whether particle type should be updated

Definition at line 357 of file Particle.h.

◆ copyRelations()

void copyRelations ( const RelationsInterface< BASE > * sourceObj )

inlineinherited

Copies all relations of sourceObj (pointing from or to sourceObj) to this object (including weights).

Useful if you want to make a complete copy of a StoreArray object to make modifications to it, but retain all information on linked objects.

Note: this only works if sourceObj inherits from the same base (e.g. RelationsObject), and only for related objects that also inherit from the same base.

Definition at line 172 of file RelationsObject.h.

◆ fillDecayChain()

void fillDecayChain ( std::vector< int > & decayChain ) const

private

Fill vector with (PDGCode, MdstSource) pairs for the entire decay chain.

Used to determine if two Particles are copies or not.

Function is called recursively

Parameters

decayChain vector of (PDGCode, MdstSource) pairs for each particle in the decay chain of this particle

Definition at line 1034 of file Particle.cc.

◆ fillFSPDaughters()

void fillFSPDaughters ( std::vector< const Belle2::Particle * > & fspDaughters ) const

private

Fill final state particle daughters into a vector.

Function is called recursively

Parameters

fspDaughters vector of daughter particles

Definition at line 1021 of file Particle.cc.

◆ forEachDaughter()

bool forEachDaughter	(	const std::function< bool(const Particle *)> &	function,
		bool	recursive = `true`,
		bool	includeSelf = `true`
	)		const

Apply a function to all daughters of this particle.

Parameters

function	function object to run on each daughter. If this function returns true the processing will be stopped immeddiately.
recursive	if true go through all daughters of daughters as well
includeSelf	if true also apply the function to this particle

Returns: true if the function returned true for any of the particles it was applied to

Definition at line 1246 of file Particle.cc.

◆ generatePDGCodeFromCharge()

int generatePDGCodeFromCharge	(	const int	chargedSign,
		const Const::ChargedStable &	chargedStable
	)

private

Generate the PDG code with correct sign, using the charge.

Parameters

chargedSign	charge of the particle
chargedStable	Type of charged particle

Definition at line 1270 of file Particle.cc.

◆ get4Vector()

TLorentzVector get4Vector ( ) const

inline

Returns Lorentz vector.

Returns: Lorentz vector

Definition at line 464 of file Particle.h.

◆ getAcoplanarity()

float getAcoplanarity ( ) const

Returns acoplanarity angle defined as the angle between the decay planes of the grand daughters in the particle's rest frame This assumes that the particle and its daughters have two daughters each.

Returns: acoplanarity angle

Definition at line 502 of file Particle.cc.

◆ getArrayPointer()

TClonesArray* getArrayPointer ( ) const

inline

Returns the pointer to the store array which holds the daughter particles.

Warning: TClonesArray is dangerously easy to misuse, please avoid.

Definition at line 844 of file Particle.h.

◆ getCharge()

float getCharge ( void ) const

Returns particle charge.

Returns: particle charge in units of elementary charge

Definition at line 586 of file Particle.cc.

◆ getCosHelicity()

float getCosHelicity ( const Particle * mother = nullptr ) const

Returns cosine of the helicity angle The helicity angle is defined in the rest frame of the particle as the angle between the negative momentum of the mother and.

the momentum of the first daughter for two body decays
the momentum of the photon for pi0 Dalitz decays
the direction perpendicular to the daughter momenta for three body decays
Parameters

mother mother particle, if not given the center of mass system is taken as mother frame

Returns
cosine of the helicity angle

Definition at line 425 of file Particle.cc.

◆ getCosHelicityDaughter()

float getCosHelicityDaughter	(	unsigned	iDaughter,
		unsigned	iGrandDaughter = `0`
	)		const

Returns cosine of the helicity angle of the given daughter defined by given grand daughter.

Parameters

iDaughter	0-based index of daughter particle
iGrandDaughter	0-based index of grand daughter particle

Returns: cosine of the helicity angle

Definition at line 469 of file Particle.cc.

◆ getDaughter()

const Particle * getDaughter ( unsigned i ) const

Returns a pointer to the i-th daughter particle.

Parameters

i	0-based index of daughter particle

Returns: Pointer to i-th daughter particles

Definition at line 595 of file Particle.cc.

◆ getDaughterIndices()

const std::vector<int>& getDaughterIndices ( ) const

inline

Returns a vector of store array indices of daughter particles.

Returns: vector of store array indices of daughter particle

Definition at line 634 of file Particle.h.

◆ getDaughterProperties()

const std::vector<int>& getDaughterProperties ( ) const

inline

Returns a vector of properties of daughter particles.

Returns: vector of daughter properties

Definition at line 643 of file Particle.h.

◆ getDaughters()

std::vector< Belle2::Particle * > getDaughters ( ) const

Returns a vector of pointers to daughter particles.

Returns: vector of pointers to daughter particles

Definition at line 601 of file Particle.cc.

◆ getECLCluster()

const ECLCluster * getECLCluster ( ) const

Returns the pointer to the ECLCluster object that was used to create this Particle (if ParticleType == c_ECLCluster).

Returns the pointer to the most energetic ECLCluster matched to the track (if ParticleType == c_Track). NULL pointer is returned, if the Particle has no relation to an ECLCluster (either the particle is a different type or there was no track match).

Returns: const pointer to the ECLCluster

Definition at line 816 of file Particle.cc.

◆ getECLClusterEnergy()

double getECLClusterEnergy ( ) const

Returns the energy of the ECLCluster for the particle.

The return value depends on the ECLCluster hypothesis.

Returns: energy of the ECLCluster

Definition at line 844 of file Particle.cc.

◆ getEnergy()

float getEnergy ( ) const

inline

Returns total energy.

Returns: total energy

Definition at line 455 of file Particle.h.

◆ getExtraInfo()

float getExtraInfo ( const std::string & name ) const

Return given value if set.

throws std::runtime_error if variable is not set.

Definition at line 1177 of file Particle.cc.

◆ getFinalStateDaughters()

std::vector< const Belle2::Particle * > getFinalStateDaughters ( ) const

Returns a vector of pointers to Final State daughter particles.

Returns: vector of pointers to final state daughter particles

Definition at line 613 of file Particle.cc.

◆ getFlavorType()

EFlavorType getFlavorType ( ) const

inline

Returns flavor type of the decay (for FS particles: flavor type of particle)

Returns: flavor type (0=unflavored, 1=flavored)

Definition at line 395 of file Particle.h.

◆ getInfo()

std::string getInfo ( ) const

inlineinherited

Return a short summary of this object's contents in raw text format.

Returns the contents of getInfoHTML() while translating line-breaks etc.

Note: : You don't need to implement this function (it's not virtual), getInfoHTML() is enough.

Definition at line 372 of file RelationsObject.h.

◆ getKLMCluster()

const KLMCluster * getKLMCluster ( ) const

Returns the pointer to the KLMCluster object that was used to create this Particle (ParticleType == c_KLMCluster).

Returns the pointer to the KLMCluster object associated to this Particle if ParticleType == c_Track. NULL pointer is returned, if the Particle has no relation to the KLMCluster.

Returns: const pointer to the KLMCluster

Definition at line 850 of file Particle.cc.

◆ getMass()

float getMass ( ) const

inline

Returns invariant mass (= nominal for FS particles)

Returns: invariant mass

Definition at line 433 of file Particle.h.

◆ getMCParticle()

const MCParticle * getMCParticle ( ) const

Returns the pointer to the MCParticle object that was used to create this Particle (ParticleType == c_MCParticle).

Returns the best MC match for this particle (if ParticleType == c_Track or c_ECLCluster or c_KLMCluster) NULL pointer is returned, if the Particle was not made from MCParticle or not matched.

Returns: const pointer to the MCParticle

Definition at line 866 of file Particle.cc.

◆ getMdstArrayIndex()

unsigned getMdstArrayIndex ( void ) const

inline

Returns 0-based index of MDST store array object (0 for composite particles)

Returns: index of MDST store array object

Definition at line 413 of file Particle.h.

◆ getMdstArrayIndices()

std::vector< int > getMdstArrayIndices ( EParticleSourceObject type ) const

Returns a vector of StoreArray indices of given MDST dataobjects.

Parameters

type	EParticleSourceObject corresponding to a given MDST dataobject

Returns: vector of StoreArray indices of a given MDST dataobjects

Definition at line 621 of file Particle.cc.

◆ getMdstSource()

int getMdstSource ( ) const

Returns unique identifier of final state particle (needed in particle combiner)

Returns: unique identifier of final state particle

Definition at line 347 of file Particle.cc.

◆ getMomentum()

TVector3 getMomentum ( ) const

inline

Returns momentum vector.

Returns: momentum vector

Definition at line 475 of file Particle.h.

◆ getMomentumErrorMatrix()

TMatrixFSym getMomentumErrorMatrix ( ) const

Returns the 4x4 momentum error matrix.

Returns: The 4x4 momentum error matrix (order: px,py,pz,E)

Definition at line 401 of file Particle.cc.

◆ getMomentumMagnitude()

float getMomentumMagnitude ( ) const

inline

Returns momentum magnitude.

Returns: momentum magnitude

Definition at line 484 of file Particle.h.

◆ getMomentumVertexErrorMatrix()

TMatrixFSym getMomentumVertexErrorMatrix ( ) const

Returns 7x7 error matrix.

Returns: 7x7 error matrix (order: px,py,pz,E,x,y,z)

Definition at line 386 of file Particle.cc.

◆ getNDaughters()

unsigned getNDaughters ( void ) const

inline

Returns number of daughter particles.

Returns: number of daughter particles

Definition at line 625 of file Particle.h.

◆ getP()

float getP ( ) const

inline

Returns momentum magnitude (same as getMomentumMagnitude but with shorter name)

Returns: momentum magnitude

Definition at line 493 of file Particle.h.

◆ getParticleFromGeneralizedIndexString()

const Particle * getParticleFromGeneralizedIndexString ( const std::string & generalizedIndex ) const

Explores the decay tree of the particle and returns the (grand^n)daughter identified by a generalized index.

The generalized index consists of a colon-separated list of daughter indexes, starting from the root particle: 0:1:3 identifies the fourth daughter (3) of the second daughter (1) of the first daughter (0) of the mother particle.

Parameters

generalizedIndex the generalized index of the particle to be returned

Returns: a particle in the decay tree of the root particle.

Definition at line 880 of file Particle.cc.

◆ getParticleSource()

EParticleSourceObject getParticleSource ( ) const

inline

Returns particle source as defined with enum EParticleSourceObject.

Returns: particle type

Definition at line 404 of file Particle.h.

◆ getPDGCode()

int getPDGCode ( void ) const

inline

Returns PDG code.

Returns: PDG code

Definition at line 380 of file Particle.h.

◆ getPDGCodeUsedForFit()

int getPDGCodeUsedForFit ( )

inline

Return the always positive PDG code which was used for the track fit (if there was a track fit) of this particle.

This can be different than the Particle's PDG id as not all mass hypothesis are fitted during the reconstruction.

Definition at line 856 of file Particle.h.

◆ getPDGMass()

float getPDGMass ( void ) const

Returns uncertaint on the invariant mass (requiers valid momentum error matrix)

Returns: mass error Returns particle nominal mass; nominal mass

Definition at line 577 of file Particle.cc.

◆ getPIDLikelihood()

const PIDLikelihood * getPIDLikelihood ( ) const

Returns the pointer to the PIDLikelihood object that is related to the Track, which was used to create this Particle (ParticleType == c_Track).

NULL pointer is returned, if the Particle was not made from Track or if the Track has no relation to the PIDLikelihood

Returns: const pointer to the Track

Definition at line 796 of file Particle.cc.

◆ getProperty()

int getProperty ( ) const

inline

Returns particle property as a bit pattern The values are defined in the PropertyFlags enum and described in detail there.

Returns: Combination of Properties describing the particle property

Definition at line 424 of file Particle.h.

◆ getPValue()

float getPValue ( ) const

inline

Returns chi^2 probability of fit if done or -1.

Returns: p-value of fit (nan means no fit done)

Definition at line 565 of file Particle.h.

◆ getPx()

float getPx ( ) const

inline

Returns x component of momentum.

Returns: x component of momentum

Definition at line 502 of file Particle.h.

◆ getPy()

float getPy ( ) const

inline

Returns y component of momentum.

Returns: y component of momentum

Definition at line 511 of file Particle.h.

◆ getPz()

float getPz ( ) const

inline

Returns z component of momentum.

Returns: z component of momentum

Definition at line 520 of file Particle.h.

◆ getRelated()

T* getRelated	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to or from which this object has a relation.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 280 of file RelationsObject.h.

◆ getRelatedFrom()

FROM* getRelatedFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object from which this object has a relation.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 265 of file RelationsObject.h.

◆ getRelatedFromWithWeight()

std::pair<FROM*, float> getRelatedFromWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from an array.

Template Parameters

FROM	The class of objects from which the relation points.

Parameters

name	The name of the store array from which the relation points. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 316 of file RelationsObject.h.

◆ getRelatedTo()

TO* getRelatedTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the object to which this object has a relation.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: The first related object or a null pointer.

Definition at line 250 of file RelationsObject.h.

◆ getRelatedToWithWeight()

std::pair<TO*, float> getRelatedToWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing to an array.

Template Parameters

TO	The class of objects to which the relation points.

Parameters

name	The name of the store array to which the relation points. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 299 of file RelationsObject.h.

◆ getRelatedWithWeight()

std::pair<T*, float> getRelatedWithWeight	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get first related object & weight of relation pointing from/to an array.

Template Parameters

T	The class of objects to or from which the relation points.

Parameters

name	The name of the store array to or from which the relation points. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: Pair of first related object and the relation weight, or (NULL, 1.0) if none found.

Definition at line 333 of file RelationsObject.h.

◆ getRelationsFrom()

RelationVector<FROM> getRelationsFrom	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from another store array to this object.

Template Parameters

FROM	The class of objects from which the relations point.

Parameters

name	The name of the store array from which the relations point. If empty the default store array name for class FROM will be used. If the special name "ALL" is given all store arrays containing objects of type FROM are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 214 of file RelationsObject.h.

◆ getRelationsTo()

RelationVector<TO> getRelationsTo	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations that point from this object to another store array.

Template Parameters

TO	The class of objects to which the relations point.

Parameters

name	The name of the store array to which the relations point. If empty the default store array name for class TO will be used. If the special name "ALL" is given all store arrays containing objects of type TO are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 199 of file RelationsObject.h.

◆ getRelationsWith()

RelationVector<T> getRelationsWith	(	const std::string &	name = `""`,
		const std::string &	namedRelation = `""`
	)		const

inlineinherited

Get the relations between this object and another store array.

Relations in both directions are returned.

Template Parameters

T	The class of objects to or from which the relations point.

Parameters

name	The name of the store array to or from which the relations point. If empty the default store array name for class T will be used. If the special name "ALL" is given all store arrays containing objects of type T are considered.
namedRelation	Additional name for the relation, or "" for the default naming

Returns: A vector of relations.

Definition at line 232 of file RelationsObject.h.

◆ getTrack()

const Track * getTrack ( ) const

Returns the pointer to the Track object that was used to create this Particle (ParticleType == c_Track).

NULL pointer is returned, if the Particle was not made from Track.

Returns: const pointer to the Track

Definition at line 770 of file Particle.cc.

◆ getTrackFitResult()

const TrackFitResult * getTrackFitResult ( ) const

Returns the pointer to the TrackFitResult that was used to create this Particle (ParticleType == c_Track).

NULL pointer is returned, if the Particle was not made from Track.

Returns: const pointer to the TrackFitResult

Definition at line 779 of file Particle.cc.

◆ getV0()

const V0 * getV0 ( ) const

Returns the pointer to the V0 object that was used to create this Particle (if ParticleType == c_V0).

NULL pointer is returned if the Particle was not made from a V0.

Returns: const pointer to the V0

Definition at line 805 of file Particle.cc.

◆ getVertex()

TVector3 getVertex ( ) const

inline

Returns vertex position (POCA for charged, IP for neutral FS particles)

Returns: vertex position

Definition at line 529 of file Particle.h.

◆ getVertexErrorMatrix()

TMatrixFSym getVertexErrorMatrix ( ) const

Returns the 3x3 position error sub-matrix.

Returns: The 3x3 position error matrix (order: x,y,z)

Definition at line 413 of file Particle.cc.

◆ getX()

float getX ( ) const

inline

Returns x component of vertex position.

Returns: x component of vertex position

Definition at line 538 of file Particle.h.

◆ getY()

float getY ( ) const

inline

Returns y component of vertex position.

Returns: y component of vertex position

Definition at line 547 of file Particle.h.

◆ getZ()

float getZ ( ) const

inline

Returns z component of vertex position.

Returns: z component of vertex position

Definition at line 556 of file Particle.h.

◆ isCopyOf()

bool isCopyOf	(	const Particle *	oParticle,
		bool	doDetailedComparison = `false`
	)		const

Returns true if this Particle and oParticle are copies of each other.

Copies are defined as: o) The decay chain of both Particles is exactly the same o) Both Particles are constructed from exactly the same final state particles

Examples: M1 -> (C1 -> F1 F2) (C2 -> F3 F4) M2 -> (C1 -> F1 F2) (C2 -> F3 F5) M3 -> (C1 -> F1 F2) F3 F4 M4 -> (C1 -> F1 F2) (C2 -> F3 F4) and M4 is kinematically fitted (its momentum updated)

M1 and M2 are not copies since condition 2 is not fulfilled. M1 and M3 are not copies since condition 1 is not fulfilled. M1 and M4 are copies since both conditions are fulfilled.

Parameters

oParticle	pointer to other particle
doDetailedComparison	if true, this means that particles of different PDG codes, but created from the same track or cluster will be indicated as copies. Returns B2FATAL in case of comparison of c_MCParticle type to a non c_MCParticle.

Returns: true if particles are copies of each-other, otherwise false

Definition at line 677 of file Particle.cc.

◆ overlapsWith()

bool overlapsWith ( const Particle * oParticle ) const

Returns true if final state ancessors of oParticle overlap.

Parameters

oParticle pointer to particle

Returns: true if overlap, otherwise false

Definition at line 662 of file Particle.cc.

◆ removeDaughter()

void removeDaughter	(	const Particle *	daughter,
		const bool	updateType = `true`
	)

Removes index of daughter from daughters index array.

Parameters

daughter	pointer to the daughter particle
updateType	bool whether particle type should be updated if last daughter was removed

Definition at line 645 of file Particle.cc.

◆ set4Vector()

void set4Vector ( const TLorentzVector & p4 )

inline

Sets Lorentz vector.

Parameters

p4	Lorentz vector

Definition at line 279 of file Particle.h.

◆ setExtraInfo()

void setExtraInfo	(	const std::string &	name,
		float	value
	)

Sets the user-defined data of given name to the given value.

throws std::runtime_error if variable isn't set.

Definition at line 1205 of file Particle.cc.

◆ setMomentumVertexErrorMatrix()

void setMomentumVertexErrorMatrix ( const TMatrixFSym & errMatrix )

Sets 7x7 error matrix.

Parameters

errMatrix 7x7 momentum and vertex error matrix (order: px,py,pz,E,x,y,z)

Definition at line 373 of file Particle.cc.

◆ setPValue()

void setPValue ( float pValue )

inline

Sets chi^2 probability of fit.

Parameters

pValue p-value of fit

Definition at line 308 of file Particle.h.

◆ setVertex()

void setVertex ( const TVector3 & vertex )

inline

Sets position (decay vertex)

Parameters

vertex position

Definition at line 291 of file Particle.h.

◆ storeErrorMatrix()

void storeErrorMatrix ( const TMatrixFSym & errMatrix )

private

Stores 7x7 error matrix into private member m_errMatrix.

Parameters

errMatrix 7x7 error matrix

Definition at line 1009 of file Particle.cc.

◆ updateMass()

void updateMass ( const int pdgCode )

Updates particle mass with the mass of the particle corresponding to the given PDG.

Parameters

pdgCode PDG code of the particle with the desired mass

Definition at line 570 of file Particle.cc.

◆ updateMomentum()

void updateMomentum	(	const TLorentzVector &	p4,
		const TVector3 &	vertex,
		const TMatrixFSym &	errMatrix,
		float	pValue
	)

inline

Sets Lorentz vector, position, 7x7 error matrix and p-value.

Parameters

p4	Lorentz vector
vertex	point (position or vertex)
errMatrix	7x7 momentum and vertex error matrix (order: px,py,pz,E,x,y,z)
pValue	chi^2 probability of the fit

Definition at line 328 of file Particle.h.

◆ writeExtraInfo()

void writeExtraInfo	(	const std::string &	name,
		const float	value
	)

Sets the user defined extraInfo.

Adds it if necessary, overwrites existing ones if they share the same name.

Definition at line 1196 of file Particle.cc.

Member Data Documentation

◆ m_arrayPointer

TClonesArray* m_arrayPointer

mutableprivate

Internal pointer to DataStore array containing the daughters of this particle.

This is a transient member and will not be written to file. The pointer is set by getArrayPointer() when first called.

Definition at line 947 of file Particle.h.

◆ m_extraInfo

std::vector<float> m_extraInfo

private

Stores associated user defined values.

Order is given by string -> index mapping in ParticleExtraInfoMap. entry 0 is reserved specifies which map to use.

Definition at line 938 of file Particle.h.

◆ m_identifier

int m_identifier = -1

private

Identifier that can be used to identify whether the particle is unique or is a copy or representation of another.

For example a kaon and pion particles constructed from the same Track are representations of the same physical object in the detector and cannot be used in the reconstruction of the same decay chain

Definition at line 931 of file Particle.h.

◆ m_pValue

float m_pValue

private

chi^2 probability of the fit.

Default is nan

Definition at line 916 of file Particle.h.

The documentation for this class was generated from the following files:

analysis/dataobjects/include/Particle.h
analysis/dataobjects/src/Particle.cc

Public Types

Public Member Functions

Private Member Functions

Private Attributes

Friends

Detailed Description

Member Enumeration Documentation

◆ EFlavorType

◆ PropertyFlags

Constructor & Destructor Documentation

◆ Particle() [1/12]

◆ Particle() [2/12]

◆ Particle() [3/12]

◆ Particle() [4/12]

◆ Particle() [5/12]

◆ Particle() [6/12]

◆ Particle() [7/12]

◆ Particle() [8/12]

◆ Particle() [9/12]

◆ Particle() [10/12]

◆ Particle() [11/12]

◆ Particle() [12/12]

Member Function Documentation

◆ addExtraInfo()

◆ addRelationTo() [1/2]

◆ addRelationTo() [2/2]

◆ appendDaughter() [1/2]

◆ appendDaughter() [2/2]

◆ copyRelations()

◆ fillDecayChain()

◆ fillFSPDaughters()

◆ forEachDaughter()

◆ generatePDGCodeFromCharge()

◆ get4Vector()

◆ getAcoplanarity()

◆ getArrayPointer()

◆ getCharge()

◆ getCosHelicity()

◆ getCosHelicityDaughter()

◆ getDaughter()

◆ getDaughterIndices()

◆ getDaughterProperties()

◆ getDaughters()

◆ getECLCluster()

◆ getECLClusterEnergy()

◆ getEnergy()

◆ getExtraInfo()

◆ getFinalStateDaughters()

◆ getFlavorType()

◆ getInfo()

◆ getKLMCluster()

◆ getMass()

◆ getMCParticle()

◆ getMdstArrayIndex()

◆ getMdstArrayIndices()

◆ getMdstSource()

◆ getMomentum()

◆ getMomentumErrorMatrix()

◆ getMomentumMagnitude()

◆ getMomentumVertexErrorMatrix()

◆ getNDaughters()

◆ getP()

◆ getParticleFromGeneralizedIndexString()

◆ getParticleSource()

◆ getPDGCode()

◆ getPDGCodeUsedForFit()

◆ getPDGMass()

◆ getPIDLikelihood()

◆ getProperty()

◆ getPValue()

◆ getPx()

◆ getPy()

◆ getPz()

◆ getRelated()

◆ getRelatedFrom()

◆ getRelatedFromWithWeight()

◆ getRelatedTo()

◆ getRelatedToWithWeight()

◆ getRelatedWithWeight()

◆ getRelationsFrom()
