RelationElement Class Reference

Class to store a single element of a relation. More...

#include <RelationElement.h>

Inheritance diagram for RelationElement:

Collaboration diagram for RelationElement:

Public Types
typedef unsigned int	index_type
	type used for indices.
typedef float	weight_type
	type used for weights.

Public Member Functions
	RelationElement ()
	Empty constructor for ROOT.
	RelationElement (index_type from, index_type to, weight_type weight=1.0)
	Constructor for a 1:1 relation. More...
	RelationElement (index_type from, const std::vector< index_type > &to, const std::vector< weight_type > &weights)
	Constructor for a 1:n relation. More...
template<class InputIterator >
	RelationElement (index_type from, const InputIterator &begin, const InputIterator &end)
	Constructor for a 1:n relation. More...
index_type	getFromIndex () const
	Get index we point from.
size_t	getSize () const
	Get number of indices we points to.
std::pair< index_type, weight_type >	getTo (size_t n=0) const
	Get nth pair of index,weight we point to.
index_type	getToIndex (size_t n=0) const
	Get nth index we point to.
weight_type	getWeight (size_t n=0) const
	Get nth weight we point to.
const std::vector< index_type > &	getToIndices () const
	Get vector of indices we point to.
const std::vector< weight_type > &	getWeights () const
	Get vector of weights we point to.
void	setFromIndex (index_type from)
	Set index we point from.
void	setToIndex (index_type to, weight_type weight=1.0)
	Set index we point to, converts relation to 1:1 and discards all existing to-indices.
template<class InputIterator >
void	setToIndices (InputIterator begin, const InputIterator &end)
	Set new indices and weights we point to. More...

Protected Member Functions
	ClassDef (RelationElement, 1)
	Class to store a single element of a relation.

Protected Attributes
index_type	m_from
	index we point from.
std::vector< index_type >	m_to
	indices we point to.
std::vector< weight_type >	m_weights
	weights for to-indices.

Detailed Description

Class to store a single element of a relation.

Supports 1:n relations with individual weights.

Definition at line 33 of file RelationElement.h.

Constructor & Destructor Documentation

RelationElement() [1/3]

RelationElement ( index_type  from, index_type  to, weight_type  weight = 1.0  )

inline

Constructor for a 1:1 relation.

Parameters

from	index to point from
to	index to point to
weight	weight of the relation

Definition at line 52 of file RelationElement.h.

RelationElement() [2/3]

RelationElement	(	index_type	from,
		const std::vector< index_type > &	to,
		const std::vector< weight_type > &	weights
	)

Constructor for a 1:n relation.

Parameters

from	index to point from
to	indices to point to
weights	weights of the relation

Definition at line 20 of file RelationElement.cc.

                                                                                                                       :
  TObject(),
  m_from(from),
  m_to(to.begin(), to.end()),
  m_weights(weights.begin(), weights.end())
{
  if (to.size() != weights.size()) {
    B2FATAL("Index and weight vector sizes differ!");
  }
}

RelationElement() [3/3]

RelationElement ( index_type  from, const InputIterator &  begin, const InputIterator &  end  )

inline

Constructor for a 1:n relation.

Parameters

from	index to point from
begin	iterator pointing to the begin of a sequence of std::pair<index_type,weight_type> or compatible
end	iterator pointing to the end of a sequence of std::pair<index_type,weight_type> or compatible

Definition at line 71 of file RelationElement.h.

Member Function Documentation

setToIndices()

void setToIndices ( InputIterator  begin, const InputIterator &  end  )

inline

Set new indices and weights we point to.

Parameters

begin	iterator pointing to the begin of a sequence of std::pair<index_type,weight_type> or compatible
end	iterator pointing to the end of a sequence of std::pair<index_type,weight_type> or compatible

Definition at line 115 of file RelationElement.h.

---

The documentation for this class was generated from the following files:

• framework/dataobjects/include/RelationElement.h
• framework/dataobjects/src/RelationElement.cc
