This class defines the dbobject and the methods to access the calibration of the cluster reconstruction. More...

#include <SVDClusterCalibrations.h>

Collaboration diagram for SVDClusterCalibrations:

[legend]

Public Types
typedef SVDCalibrationsBase< SVDCalibrationsScalar< SVDClusterCuts > >	t_payload
	typedef for the of SVDClusterCuts payload of all SVD sensors

typedef SVDCalibrationsBase< SVDCalibrationsScalar< SVDHitTimeSelectionFunction > >	t_time_payload
	typedef for the of SVDHitTimeSelectionFunction payload of all SVD sensors

Public Member Functions
	SVDClusterCalibrations ()
	Constructor, no input argument is required.

double	getCorrectedClusterPositionError (const Belle2::VxdID &sensorID, const bool &isU, const int &size, const double &raw_error) const
	Return the corrected cluster position error. More...

double	getMinSeedSNR (const Belle2::VxdID &sensorID, const bool &isU) const
	Return the minimum SNR for the seed. More...

double	getMinAdjSNR (const Belle2::VxdID &sensorID, const bool &isU) const
	Return the minimum SNR for the adjacent. More...

double	getMinClusterSNR (const Belle2::VxdID &sensorID, const bool &isU) const
	Return the minimum SNR for the cluster. More...

bool	isClusterInTime (const Belle2::VxdID &sensorID, const bool &isU, const double &svdTime, const double &svdTimeError=0, const double &t0=0, const double &t0Error=0) const
	Return whether the cluster is estimated to be in time with the event or off-time. More...

bool	areClusterTimesCompatible (const Belle2::VxdID &sensorID, const double &uTime, const double &vTime=0) const
	Return whether the cluster is estimated to be in time with the event or off-time. More...

int	getTimeSelectionFunction (const Belle2::VxdID &sensorID, const bool &isU) const
	Return the version of the function used to determine whether the cluster time is acceptable at the SP creation. More...

float	getMinClusterTime (const Belle2::VxdID &sensorID, const bool &isU) const
	Return the min value of the cluster time to use it for reconstruction. More...

TString	getUniqueID ()
	returns the unique ID of the payload

bool	isValid ()
	returns true if the m_aDBObtPtr is valid in the requested IoV

Static Public Attributes
static std::string	name = std::string("SVDClusterCut")
	name of SVDClusterCuts payload

static std::string	time_name = std::string("SVDHitTimeSelectionFunction")
	name of SVDHitTimeSelectionFunction payload

Private Attributes
DBObjPtr< t_payload >	m_aDBObjPtr
	SVDClusterCuts payload.

DBObjPtr< t_time_payload >	m_time_aDBObjPtr
	SVDHitTimeSelectionFunction paylaod.

Detailed Description

This class defines the dbobject and the methods to access the calibration of the cluster reconstruction.

Definition at line 40 of file SVDClusterCalibrations.h.

Member Function Documentation

◆ areClusterTimesCompatible()

bool areClusterTimesCompatible	(	const Belle2::VxdID &	sensorID,
		const double &	uTime,
		const double &	vTime = `0`
	)		const

inline

Return whether the cluster is estimated to be in time with the event or off-time.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
uTime	U-Side cluster time
vTime	V-Side cluster time

Output: bool true if the U and V cluster times are compatible

Definition at line 201 of file SVDClusterCalibrations.h.

◆ getCorrectedClusterPositionError()

double getCorrectedClusterPositionError	(	const Belle2::VxdID &	sensorID,
		const bool &	isU,
		const int &	size,
		const double &	raw_error
	)		const

inline

Return the corrected cluster position error.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED
size	cluster size
raw_error	: error provided by the algorithm in the SVDSimpleClusterizer

Output: double corresponding to the corrected cluster position error [cm]

Definition at line 75 of file SVDClusterCalibrations.h.

◆ getMinAdjSNR()

double getMinAdjSNR	(	const Belle2::VxdID &	sensorID,
		const bool &	isU
	)		const

inline

Return the minimum SNR for the adjacent.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED

Output: double corresponding to the minimum SNR for the adjacent

Definition at line 122 of file SVDClusterCalibrations.h.

◆ getMinClusterSNR()

double getMinClusterSNR	(	const Belle2::VxdID &	sensorID,
		const bool &	isU
	)		const

inline

Return the minimum SNR for the cluster.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED

Output: double corresponding to the minimum SNR for the cluster

Definition at line 146 of file SVDClusterCalibrations.h.

◆ getMinClusterTime()

float getMinClusterTime	(	const Belle2::VxdID &	sensorID,
		const bool &	isU
	)		const

inline

Return the min value of the cluster time to use it for reconstruction.

this function is used in the calibration monitoring

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED

Output:

Definition at line 251 of file SVDClusterCalibrations.h.

◆ getMinSeedSNR()

double getMinSeedSNR	(	const Belle2::VxdID &	sensorID,
		const bool &	isU
	)		const

inline

Return the minimum SNR for the seed.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED

Output: double corresponding to the minimum SNR for the seed

Definition at line 99 of file SVDClusterCalibrations.h.

◆ getTimeSelectionFunction()

int getTimeSelectionFunction	(	const Belle2::VxdID &	sensorID,
		const bool &	isU
	)		const

inline

Return the version of the function used to determine whether the cluster time is acceptable at the SP creation.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED

Output:

Definition at line 226 of file SVDClusterCalibrations.h.

◆ isClusterInTime()

bool isClusterInTime	(	const Belle2::VxdID &	sensorID,
		const bool &	isU,
		const double &	svdTime,
		const double &	svdTimeError = `0`,
		const double &	t0 = `0`,
		const double &	t0Error = `0`
	)		const

inline

Return whether the cluster is estimated to be in time with the event or off-time.

Input:

Parameters

sensor	ID: identity of the sensor for which the calibration is required
isU	sensor side, true for p side, false for n side
strip	NOT USED
svdTime	cluster time
svdTimeError	cluster time error
t0	event t0
t0Error	event t0 error

Output: bool true if the svd hit time is compatible with t0

Definition at line 175 of file SVDClusterCalibrations.h.

The documentation for this class was generated from the following files:

svd/calibration/include/SVDClusterCalibrations.h
svd/calibration/src/SVDClusterCalibrations.cc
