SVDGlobalConfigParameters Class Reference

This class defines the payload which stores to the central DB the SVD global configuring parameters, and the methods to import and retrieve these parameters. More...

#include <SVDGlobalConfigParameters.h>

Inheritance diagram for SVDGlobalConfigParameters:

Collaboration diagram for SVDGlobalConfigParameters:

Public Member Functions
	SVDGlobalConfigParameters (const TString &uniqueID="")
	Default constructor.
float	getZeroSuppression (void) const
	Returns the zero suppression threshold for global data taking in ZS acquisition mode. More...
int	getLatency (void) const
	Returns the latency set for global data taking. More...
int	getMaskFilter (void) const
	Returns the masking bitmap used to mask the strips at FADC level (only for CM-section) More...
float	getAPVClockInRFCUnits (void) const
	Returns the APV clock. More...
float	getHV (void) const
	Returns the HV = Vbias/2. More...
int	getRelativeTimeShift (void) const
	Returns the relative time shift between the 3-sample and 6-sample acquired events in units of APV clock/4. More...
int	getNrFrames (void) const
	Returns the number of frames 3 -> 3-sample only DAQ mode 6 -> 6-sample only DAQ mode 9 -> 3-mixed-6 sample DAQ mode.
void	setZeroSuppression (float zeroSuppression)
	Set the zero suppression Input: More...
void	setLatency (float latency)
	Set the latency Input: More...
void	setMaskFilter (int maskFilter)
	Set the masking bitmap Input: More...
void	setAPVClockInRFCUnits (const std::string &APVClockUnits)
	Set the APV Clock units Input: More...
void	setHV (float hv)
	Set the HV (in V) Input: More...
void	setRelativeTimeShift (float relativeTimeShift)
	Set the Relative time shift between 3- and 6- sample acquired events in units of APV clock / 4 Input: More...
void	setNrFrames (int nrFrames)
	Set the number of frames 3 -> 3-sample only DAQ mode 6 -> 6-sample only DAQ mode 9 -> 3-mixed-6 sample DAQ mode.
TString	get_uniqueID () const
	Get the unique ID of the calibration.

Private Member Functions
	ClassDef (SVDGlobalConfigParameters, 3)
	needed by root

Private Attributes
TString	m_uniqueID
	Add a string as unique identifier for a given local run configuration)
float	m_zeroSuppression
	zero suppression value which defines the S/N threshold of data mode acquisition during global run in ZS mode More...
int	m_latency
	integer number of buffer cells to go back in the buffer ring to correctly sampling the signal pulse when the trigger is received.
int	m_maskFilter
	masking bitmap
float	m_hv = 0
	HV = Vbias/2 in V.
float	m_relativeTimeShift = 0
	relative time shift between the 3-sample and 6-sample acquired events in units of APV clock/4 [0,15]
float	m_nrFrames = 0
	number of frames 3 -> 3-sample only DAQ mode 6 -> 6-sample only DAQ mode 9 -> 3-mixed-6 sample DAQ mode
std::string	m_APVClockInRFCUnits
	APVclock.

Detailed Description

This class defines the payload which stores to the central DB the SVD global configuring parameters, and the methods to import and retrieve these parameters.

Definition at line 40 of file SVDGlobalConfigParameters.h.

Member Function Documentation

getAPVClockInRFCUnits()

float getAPVClockInRFCUnits ( void  ) const

inline

Returns the APV clock.

Parameters

none

Returns

float corresponding to the APV clock units in [ns]

Definition at line 83 of file SVDGlobalConfigParameters.h.

                             { return m_hv; };


getHV()

float getHV ( void  ) const

inline

Returns the HV = Vbias/2.

Parameters

none

Returns

float corresponding to the HV = Vbias/2

Definition at line 101 of file SVDGlobalConfigParameters.h.

getLatency()

int getLatency ( void  ) const

inline

Returns the latency set for global data taking.

Parameters

none

Returns

int corresponding to the latency set for global data taking

Definition at line 69 of file SVDGlobalConfigParameters.h.

getMaskFilter()

int getMaskFilter ( void  ) const

inline

Returns the masking bitmap used to mask the strips at FADC level (only for CM-section)

Parameters

none

Returns

int corresponding to the mask filter applied at FADC level

Definition at line 76 of file SVDGlobalConfigParameters.h.

getRelativeTimeShift()

int getRelativeTimeShift ( void  ) const

inline

Returns the relative time shift between the 3-sample and 6-sample acquired events in units of APV clock/4.

Parameters

none

Returns

int [0,15] corresponding to relative time shift between the 3-sample and 6-sample acquired events in units of APV clock/4

Definition at line 108 of file SVDGlobalConfigParameters.h.

getZeroSuppression()

float getZeroSuppression ( void  ) const

inline

Returns the zero suppression threshold for global data taking in ZS acquisition mode.

Parameters

none

Returns

float corresponding to zero suppression cut applied during data taking

Definition at line 61 of file SVDGlobalConfigParameters.h.

setAPVClockInRFCUnits()

void setAPVClockInRFCUnits ( const std::string &  APVClockUnits )

inline

Set the APV Clock units Input:

Parameters

std::string

coeff + units [RFC]

Definition at line 159 of file SVDGlobalConfigParameters.h.

setHV()

void setHV ( float  hv )

inline

Set the HV (in V) Input:

Parameters

float

hv

Definition at line 170 of file SVDGlobalConfigParameters.h.

setLatency()

void setLatency ( float  latency )

inline

Set the latency Input:

Parameters

int

Definition at line 136 of file SVDGlobalConfigParameters.h.

setMaskFilter()

void setMaskFilter ( int  maskFilter )

inline

Set the masking bitmap Input:

Parameters

int

Definition at line 148 of file SVDGlobalConfigParameters.h.

setRelativeTimeShift()

void setRelativeTimeShift ( float  relativeTimeShift )

inline

Set the Relative time shift between 3- and 6- sample acquired events in units of APV clock / 4 Input:

Parameters

int	relative time shift

Definition at line 181 of file SVDGlobalConfigParameters.h.

setZeroSuppression()

void setZeroSuppression ( float  zeroSuppression )

inline

Set the zero suppression Input:

Parameters

float

Definition at line 125 of file SVDGlobalConfigParameters.h.

Member Data Documentation

m_zeroSuppression

float m_zeroSuppression

private

zero suppression value which defines the S/N threshold of data mode acquisition during global run in ZS mode

Definition at line 209 of file SVDGlobalConfigParameters.h.

---

The documentation for this class was generated from the following file:

• svd/dbobjects/include/SVDGlobalConfigParameters.h
