FilterCalculator Class Reference

Implementation of a calculator used in the SoftwareTriggerModule to fill a SoftwareTriggerObject for doing HLT cuts. More...

#include <FilterCalculator.h>

Inheritance diagram for FilterCalculator:

Collaboration diagram for FilterCalculator:

Public Member Functions
	FilterCalculator ()
	Set the default names for the store object particle lists.
void	requireStoreArrays () override
	Require the particle list. We do not need more here.
void	doCalculation (SoftwareTriggerObject &calculationResult) override
	Actually write out the variables into the map. More...
void	writeDebugOutput (const std::unique_ptr< TTree > &debugOutputTTree)
	Function to write out debug output into the given TTree. More...
void	addDebugOutput (const StoreObjPtr< SoftwareTriggerVariables > &storeObject, const std::string &prefix)
	Function to write out debug output into the given StoreObject. More...
const SoftwareTriggerObject &	fillInCalculations ()
	Main function of this class: calculate the needed variables using the overwritten doCalculation function and write out the values into the results object (with their names). More...

Private Attributes
StoreArray< Track >	m_tracks
	Store Array of the tracks to be used.
StoreArray< ECLCluster >	m_eclClusters
	Store Array of the ecl clusters to be used.
StoreObjPtr< TRGSummary >	m_l1Trigger
	Store Object with the trigger result.
StoreArray< CDCTriggerUnpacker::NNBitStream >	m_bitsNN
	Store Object with the trigger NN bits.
double	m_looseTrkZ0 = 10 * Unit::cm
	which Z0 defines a loose track
double	m_tightTrkZ0 = 2 * Unit::cm
	which Z0 defines a tight track
double	m_E2min = 0.2
	which CMS energy defines nElow
double	m_E0min = 0.3
	which CMS energy defines nEmedium
double	m_Ehigh = 2
	which CMS energy defines nEhigh
double	m_EminLab = 0.18
	which lab energy defines nE180Lab
double	m_EminLab4Cluster = 0.3
	which lab energy defines nE300Lab
double	m_EminLab3Cluster = 0.5
	which lab energy defines nE500Lab
double	m_EsinglePhoton = 1
	which CMS energy defines nEsingleClust
double	m_reducedEsinglePhoton = 0.5
	which CMS energy defines nReducedEsingle clusters
double	m_cosmicMinPt = 0.5 * Unit::GeV
	which LAB pt defines a cosmic
double	m_cosmicMaxClusterEnergy = 1.0 * Unit::GeV
	which LAB cluster energy vetoes a cosmic candidate
double	m_goodMagneticRegionZ0 = 57.
	maximum z0 for well understood magnetic field (cm)
double	m_goodMagneticRegionD0 = 26.5
	minimum d0 for well understood magnetic field, if z0 is large (cm)
SoftwareTriggerObject	m_calculationResult
	Internal storage of the result of the calculation.
bool	m_debugPrepared = false
	Flag to not add the branches twice to the TTree.

Detailed Description

Implementation of a calculator used in the SoftwareTriggerModule to fill a SoftwareTriggerObject for doing HLT cuts.

This calculator exports variables needed for the trigger HLT part of the path ( = filtering out events)

This class implements the two main functions requireStoreArrays and doCalculation of the SoftwareTriggerCalculation class.

Definition at line 40 of file FilterCalculator.h.

Member Function Documentation

addDebugOutput()

void addDebugOutput ( const StoreObjPtr< SoftwareTriggerVariables > &  storeObject, const std::string &  prefix  )

inherited

Function to write out debug output into the given StoreObject.

Needs an already prefilled calculationResult for this (probably using the fillInCalculations function). All added variables are prefixed with the given prefix string.

Definition at line 44 of file SoftwareTriggerCalculation.cc.

    {
      const unsigned int sizeBeforeCheck = m_calculationResult.size();
      doCalculation(m_calculationResult);

      if (m_calculationResult.size() != sizeBeforeCheck and sizeBeforeCheck > 0) {
        B2WARNING("Calculator added more variables (" << m_calculationResult.size() <<

doCalculation()

void doCalculation ( SoftwareTriggerObject &  calculationResult )

overridevirtual

Actually write out the variables into the map.

< number of loose tracks

< number of tight tracks

< Bhabha, 2 tracks with accompanying ECL info

< number of clusters with E*>m_Emedium (higher threshold)

< number of clusters with E*>m_Elow (lower threshold)

< number of clusters with E*>m_Ehigh (2 GeV)

< number of clusters with Elab > m_EminLab outside of high background endcap region

< number of clusters with Elab > m_EminLab4Cluster outside of high background endcap region

< number of clusters with Elab > m_EminLab3Cluster outside of high background endcap region

< number of clusters with Ecms > m_Ehigh outside of high background endcap region

< number of clusters with E*>4 GeV

< neutral clusters with Elab>250 MeV (anywhere)

< Neutral, zmva>0.5, in [17,150], max 2 energy clusters

< dphi* between 2 max E clusters

< net charge of loose tracks

< maximum p* of loose tracks (GeV/c)

< Bhabha, 2 tracks, at least 1 of which has ECL info

< number of clusters with E*>m_Ehigh, low angles

< clusters with E*> m_EsinglePhoton (1 GeV)

< neutral clusters with E*> 1 GeV in [45,115]

< neutral clusters with E*> 1 GeV in [32,130]

< neutral clusters with E*> 1 GeV, not barrel or low

< charged clusters with E*> 1 GeV in [45,115]

< charged clusters with E*> 1 GeV in [32,130]

< charged clusters with E*> 0.5 GeV in [44,98]

< clusters with E>m_Emedium and |t|/dt99 < 10

< charged clusters with E*>2 GeV

< neutral clusters with E*>0.45 GeV in [17,150]

< neutral clusters with E*>0.45 GeV in [30,130]

< track + ECL info consistent with Bhabha

< Bhabha, 2 ECL clusters, one of which is charged

< Bhabha, 1 track has high energy cluster, other is electron

< Bhabha, 2 ECL clusters

< gg veto, 2 ECL clusters

Implements SoftwareTriggerCalculation.

Definition at line 78 of file FilterCalculator.cc.

{
  calculationResult["nTrkLoose"] = 0;
  calculationResult["nTrkTight"] = 0;
  calculationResult["ee2leg"] = 0;
  calculationResult["nEmedium"] = 0;
  calculationResult["nElow"] = 0;
  calculationResult["nEhigh"] = 0;
  calculationResult["nE180Lab"] = 0;
  calculationResult["nE300Lab"] = 0;
  calculationResult["nE500Lab"] = 0;
  calculationResult["nE2000CMS"] = 0;
  calculationResult["nE4000CMS"] = 0;
  calculationResult["nE250Lab"] = 0;
  calculationResult["nMaxEPhotonAcc"] = 0;
  calculationResult["dphiCmsClust"] = NAN;
  calculationResult["netChargeLoose"] = 0;
  calculationResult["maximumPCMS"] = NAN;
  calculationResult["eexx"] = 0;
  calculationResult["ee1leg1trk"] = 0;
  calculationResult["nEhighLowAng"] = 0;
  calculationResult["nEsingleClust"] = 0;
  calculationResult["nEsinglePhotonBarrel"] = 0;
  calculationResult["nEsinglePhotonExtendedBarrel"] = 0;
  calculationResult["nEsinglePhotonEndcap"] = 0;
  calculationResult["nEsingleElectronBarrel"] = 0;
  calculationResult["nEsingleElectronExtendedBarrel"] = 0;
  calculationResult["nReducedEsinglePhotonReducedBarrel"] = 0;
  calculationResult["nVetoClust"] = 0;
  calculationResult["chrgClust2GeV"] = 0;
  calculationResult["neutClust045GeVAcc"] = 0;
  calculationResult["neutClust045GeVBarrel"] = 0;
  calculationResult["singleTagLowMass"] = 0;
  calculationResult["singleTagHighMass"] = 0;
  calculationResult["n2GeVNeutBarrel"] = 0;
  calculationResult["n2GeVNeutEndcap"] = 0;
  calculationResult["n2GeVChrg"] = 0;
  calculationResult["n2GeVPhotonBarrel"] = 0;
  calculationResult["n2GeVPhotonEndcap"] = 0;
  calculationResult["ee1leg"] = 0;
  calculationResult["ee1leg1clst"] = 0;
  calculationResult["ee1leg1e"] = 0;
  calculationResult["ee2clst"] = 0;
  calculationResult["gg2clst"] = 0;
  calculationResult["eeee"] = 0;
  calculationResult["eemm"] = 0;
  calculationResult["eexxSelect"] = 0;
  calculationResult["radBhabha"] = 0;
  calculationResult["eeBrem"] = 0;
  calculationResult["isrRadBhabha"] = 0;
  calculationResult["muonPairECL"] = 0;
  calculationResult["selectee1leg1trk"] = 0;
  calculationResult["selectee1leg1clst"] = 0;
  calculationResult["selectee"] = 0;
  calculationResult["ggBarrelVL"] = 0;
  calculationResult["ggBarrelLoose"] = 0;
  calculationResult["ggBarrelTight"] = 0;
  calculationResult["ggEndcapVL"] = 0;
  calculationResult["ggEndcapLoose"] = 0;
  calculationResult["ggEndcapTight"] = 0;
  calculationResult["muonPairV"] = 0;
  calculationResult["selectmumu"] = 0;
  calculationResult["singleMuon"] = 0;
  calculationResult["cosmic"] = 0;
  calculationResult["eeFlat0"] = 0;
  calculationResult["eeFlat1"] = 0;
  calculationResult["eeFlat2"] = 0;
  calculationResult["eeFlat3"] = 0;
  calculationResult["eeFlat4"] = 0;
  calculationResult["eeFlat5"] = 0;
  calculationResult["eeFlat6"] = 0;
  calculationResult["eeFlat7"] = 0;
  calculationResult["eeFlat8"] = 0;
  calculationResult["eeOneClust"] = 0;
  // Passed on L1 information
  if (m_l1Trigger.isValid()) {
    calculationResult["l1_trigger_random"] = m_l1Trigger->getTimType() == TRGSummary::ETimingType::TTYP_RAND;
    calculationResult["l1_trigger_delayed_bhabha"] = m_l1Trigger->getTimType() == TRGSummary::ETimingType::TTYP_DPHY;
    calculationResult["l1_trigger_poisson"] = m_l1Trigger->getTimType() == TRGSummary::ETimingType::TTYP_POIS;

    calculationResult["bha3d"] = m_l1Trigger->testPsnm("bha3d");
    calculationResult["bhapur"] = m_l1Trigger->testPsnm("bhapur");
    calculationResult["bhapur_lml1"] = m_l1Trigger->testPsnm("lml1") and m_l1Trigger->testFtdl("bhapur");
  } else {
    calculationResult["l1_trigger_random"] = 1; // save every event if no L1 trigger info
    calculationResult["l1_trigger_delayed_bhabha"] = 0;
    calculationResult["l1_trigger_poisson"] = 0;
    calculationResult["bha3d"] = 0;
    calculationResult["bhapur"] = 0;
    calculationResult["bhapur_lml1"] = 0;
  }

  // Every 256th event has CDC NN trigger information
  calculationResult["l1_trg_NN_info"] = 0;
  if (m_bitsNN.isValid() and m_bitsNN.getEntries() > 0) {calculationResult["l1_trg_NN_info"] = 1;}

  calculationResult["true"] = 1;
  calculationResult["false"] = 0;

  // Some utilities
  // TODO: into constructor
  ClusterUtils cUtil;
  const TVector3 clustervertex = cUtil.GetIPPosition();
  PCmsLabTransform boostrotate;
  TLorentzVector p4ofCOM;
  p4ofCOM.SetPxPyPzE(0, 0, 0, boostrotate.getCMSEnergy());

  // Pointers to the two tracks with the maximum pt
  std::map<short, std::optional<MaximumPtTrack>> maximumPtTracks = {
    { -1, {}}, {1,  {}}
  };

  // Pointer to the two tracks with maximum pt without a cut applied on z0 (used for cosmic trigger)
  std::map<short, std::optional<MaximumPtTrack>> maximumPtTracksWithoutZCut = {
    { -1, {}}, {1, {}}
  };

  // --- Track variables -- //
  for (const Track& track : m_tracks) {
    const TrackFitResult* trackFitResult = track.getTrackFitResultWithClosestMass(Const::pion);
    if (not trackFitResult) {
      // Hu? No track fit result for pion? Ok, lets skip this track
      continue;
    }

    // TODO: Temporary cut on number of CDC hits
    if (trackFitResult->getHitPatternCDC().getNHits() == 0) {
      continue;
    }

    // Count loose and tight tracks
    const double z0 = trackFitResult->getZ0();
    if (std::abs(z0) < m_tightTrkZ0) {
      calculationResult["nTrkTight"] += 1;
    }

    // From here on use only tracks with defined charge
    const short charge = trackFitResult->getChargeSign();
    if (charge == 0) {
      continue;
    }

    const TLorentzVector& momentumLab = trackFitResult->get4Momentum();
    const TLorentzVector momentumCMS = boostrotate.rotateLabToCms() * momentumLab;
    double pCMS = momentumCMS.Rho();

    // Find the maximum pt negative [0] and positive [1] tracks without z0 cut
    const double pT = trackFitResult->getTransverseMomentum();
    const auto& currentMaximum = maximumPtTracksWithoutZCut.at(charge);
    if (not currentMaximum or pT > currentMaximum->pT) {
      MaximumPtTrack newMaximum;
      newMaximum.pT = pT;
      newMaximum.track = &track;
      newMaximum.pCMS = pCMS;
      newMaximum.pLab = momentumLab.Rho();
      newMaximum.p4CMS = momentumCMS;
      newMaximum.p4Lab = momentumLab;
      maximumPtTracksWithoutZCut[charge] = newMaximum;
    }

    // Loose tracks
    if (std::abs(z0) < m_looseTrkZ0) {
      calculationResult["nTrkLoose"] += 1;
      calculationResult["netChargeLoose"] += charge;

      if (std::isnan(calculationResult["maximumPCMS"]) or pCMS > calculationResult["maximumPCMS"]) {
        calculationResult["maximumPCMS"] = pCMS;
      }

      // Find the maximum pt negative [0] and positive [1] tracks
      const double pTLoose = trackFitResult->getTransverseMomentum();
      const auto& currentMaximumLoose = maximumPtTracks.at(charge);
      if (not currentMaximumLoose or pTLoose > currentMaximumLoose->pT) {
        MaximumPtTrack newMaximum;
        newMaximum.pT = pTLoose;
        newMaximum.track = &track;
        newMaximum.pCMS = pCMS;
        newMaximum.pLab = momentumLab.Rho();
        newMaximum.p4CMS = momentumCMS;
        newMaximum.p4Lab = momentumLab;
        maximumPtTracks[charge] = newMaximum;
      }
    }
  }

  // -- Cluster variables -- //
  std::vector<SelectedECLCluster> selectedClusters;
  for (const ECLCluster& cluster : m_eclClusters) {
    // Use the photon hypothesis, and only look at clusters with times < 200 ns
    const double time = cluster.getTime();
    if (not cluster.hasHypothesis(Belle2::ECLCluster::EHypothesisBit::c_nPhotons) or
        std::abs(time) > 200 or
        cluster.getEnergy(Belle2::ECLCluster::EHypothesisBit::c_nPhotons) < 0.1) {
      continue;
    }

    const double dt99 = cluster.getDeltaTime99();

    // Store infos if above the single photon threshold
    SelectedECLCluster selectedCluster;
    selectedCluster.p4Lab = cUtil.Get4MomentumFromCluster(&cluster, clustervertex,
                                                          Belle2::ECLCluster::EHypothesisBit::c_nPhotons);
    selectedCluster.p4CMS = boostrotate.rotateLabToCms() * selectedCluster.p4Lab; // was clustp4COM
    selectedCluster.cluster = &cluster;
    selectedCluster.clusterTime = time / dt99; // was clustT
    selectedCluster.energyLab = selectedCluster.p4Lab.E();
    selectedCluster.energyCMS = selectedCluster.p4CMS.E(); // was first of ECOMPair
    selectedCluster.isTrack = cluster.isTrack(); // was tempCharge

    selectedClusters.push_back(selectedCluster);

    if (selectedCluster.energyCMS > m_E2min) {
      calculationResult["nElow"] += 1;
    }
    if (selectedCluster.energyCMS > m_E0min) {
      calculationResult["nEmedium"] += 1;
    }
    if (selectedCluster.energyCMS > m_Ehigh) {
      calculationResult["nEhigh"] += 1;
    }

    if (selectedCluster.energyCMS > m_E0min and std::abs(selectedCluster.clusterTime) < 10) {
      calculationResult["nVetoClust"] += 1;
    }


    //..Single cluster trigger objects use charge, Zernike moment, and thetaLab
    const double thetaLab = selectedCluster.p4Lab.Theta() * TMath::RadToDeg();
    const double zmva = cluster.getZernikeMVA();
    const bool photon = zmva > 0.5 and not selectedCluster.isTrack;
    const bool electron = zmva > 0.5 and selectedCluster.isTrack;

    //..For 1 track radiative Bhabha control sample
    if (selectedCluster.energyCMS > 2. and selectedCluster.isTrack) {
      calculationResult["chrgClust2GeV"] += 1;
    }
    if (selectedCluster.energyCMS > 0.45 and not selectedCluster.isTrack) {
      const bool isInAcceptance = 17. < thetaLab and thetaLab < 150.;
      if (isInAcceptance) {calculationResult["neutClust045GeVAcc"] += 1;}
      const bool isInBarrel = 30. < thetaLab and thetaLab < 130.;
      if (isInBarrel) {calculationResult["neutClust045GeVBarrel"] += 1;}
    }


    // improved 3 cluster (4 cluster) trigger
    const bool notInHighBackgroundEndcapRegion = 18.5 < thetaLab and thetaLab < 139.3;
    if (selectedCluster.energyLab > m_EminLab and notInHighBackgroundEndcapRegion) {
      calculationResult["nE180Lab"] += 1;
    }

    if (selectedCluster.energyLab > m_EminLab4Cluster and notInHighBackgroundEndcapRegion) {
      calculationResult["nE300Lab"] += 1;
    }

    if (selectedCluster.energyLab > m_EminLab3Cluster and notInHighBackgroundEndcapRegion) {
      calculationResult["nE500Lab"] += 1;
    }

    if (selectedCluster.energyCMS > m_Ehigh and notInHighBackgroundEndcapRegion) {
      calculationResult["nE2000CMS"] += 1;
    }

    //..For two-photon fusion ALP trigger
    if (selectedCluster.energyLab > 0.25) {
      calculationResult["nE250Lab"] += 1;
    }
    if (selectedCluster.energyCMS > 4.) {
      calculationResult["nE4000CMS"] += 1;
    }

    //..Single cluster triggers
    if (selectedCluster.energyCMS > m_EsinglePhoton) {
      calculationResult["nEsingleClust"] += 1;

      const bool barrelRegion = thetaLab > 45 and thetaLab < 115;
      const bool extendedBarrelRegion = thetaLab > 30 and thetaLab < 130;
      const bool endcapRegion = (thetaLab > 22 and thetaLab < 45) or (thetaLab > 115 and thetaLab < 145);

      if (photon and barrelRegion) {
        calculationResult["nEsinglePhotonBarrel"] += 1;
      }

      if (photon and extendedBarrelRegion) {
        calculationResult["nEsinglePhotonExtendedBarrel"] += 1;
      }

      if (electron and barrelRegion) {
        calculationResult["nEsingleElectronBarrel"] += 1;
      }

      if (electron and extendedBarrelRegion) {
        calculationResult["nEsingleElectronExtendedBarrel"] += 1;
      }

      if (photon and endcapRegion) {
        calculationResult["nEsinglePhotonEndcap"] += 1;
      }
    }

    if (selectedCluster.energyCMS > m_reducedEsinglePhoton) {
      const bool reducedBarrelRegion = thetaLab > 44 and thetaLab < 98;

      if (photon and reducedBarrelRegion) {
        calculationResult["nReducedEsinglePhotonReducedBarrel"] += 1;
      }
    }

    if (selectedCluster.energyCMS > m_Ehigh) {
      // TODO: different definition!
      const bool barrelRegion = thetaLab > 32 and thetaLab < 130;
      const bool endcapRegion = (thetaLab > 22 and thetaLab < 32) or (thetaLab > 130 and thetaLab < 145);
      const bool lowAngleRegion = thetaLab < 22 or thetaLab > 145;

      if (not selectedCluster.isTrack and barrelRegion) {
        calculationResult["n2GeVNeutBarrel"] += 1;
      }
      if (not selectedCluster.isTrack and endcapRegion) {
        calculationResult["n2GeVNeutEndcap"] += 1;
      }
      if (selectedCluster.isTrack and not lowAngleRegion) {
        calculationResult["n2GeVChrg"] += 1;
      }
      if (lowAngleRegion) {
        calculationResult["nEhighLowAng"] += 1;
      }
      if (photon and barrelRegion) {
        calculationResult["n2GeVPhotonBarrel"] += 1;
      }
      if (photon and endcapRegion) {
        calculationResult["n2GeVPhotonEndcap"] += 1;
      }
    }
  }
  std::sort(selectedClusters.begin(), selectedClusters.end(), [](const auto & lhs, const auto & rhs) {
    return lhs.energyCMS > rhs.energyCMS;
  });

  // -- Bhabha and two-photon lepton preparation -- //
  for (short charge : { -1, 1}) {
    auto& maximumPtTrack = maximumPtTracks.at(charge);
    if (not maximumPtTrack) {
      continue;
    }

    // Prep max two tracks for Bhabha and two-photon lepton selections
    // Track / cluster matching
    for (auto& cluster : maximumPtTrack->track->getRelationsTo<ECLCluster>()) {
      if (cluster.hasHypothesis(Belle2::ECLCluster::EHypothesisBit::c_nPhotons)) {
        maximumPtTrack->clusterEnergySumLab += cluster.getEnergy(Belle2::ECLCluster::EHypothesisBit::c_nPhotons);
      }
    }
    maximumPtTrack->clusterEnergySumCMS =
      maximumPtTrack->clusterEnergySumLab * maximumPtTrack->pCMS / maximumPtTrack->pLab;

    // Single leg Bhabha selections
    if (maximumPtTrack->clusterEnergySumCMS > 4.5) {
      calculationResult["ee1leg"] = 1;
    }

    // single muon
    if (maximumPtTrack->pCMS > 3 and maximumPtTrack->clusterEnergySumLab > 0. and maximumPtTrack->clusterEnergySumLab < 1.) {
      calculationResult["singleMuon"] = 1;
    }
  }

  // Bhabha selections using two tracks
  if (maximumPtTracks.at(-1) and maximumPtTracks.at(1)) {
    const MaximumPtTrack& negativeTrack = *maximumPtTracks.at(-1);
    const MaximumPtTrack& positiveTrack = *maximumPtTracks.at(1);

    double dphi = std::abs(negativeTrack.p4CMS.Phi() - positiveTrack.p4CMS.Phi()) * TMath::RadToDeg();
    if (dphi > 180) {
      dphi = 360 - dphi;
    }

    const double negativeClusterSum = negativeTrack.clusterEnergySumCMS;
    const double negativeClusterSumLab = negativeTrack.clusterEnergySumLab;
    const double negativeP = negativeTrack.pCMS;
    const double positiveClusterSum = positiveTrack.clusterEnergySumCMS;
    const double positiveClusterSumLab = positiveTrack.clusterEnergySumLab;
    const double positiveP = positiveTrack.pCMS;

    // two leg Bhabha
    const double thetaSum = (negativeTrack.p4CMS.Theta() + positiveTrack.p4CMS.Theta()) * TMath::RadToDeg();
    const double dthetaSum = std::abs(thetaSum - 180);
    const auto back2back = dphi > 175 and dthetaSum < 15;
    if (back2back and negativeClusterSum > 3 and positiveClusterSum > 3 and
        (negativeClusterSum > 4.5 or positiveClusterSum > 4.5)) {
      calculationResult["ee2leg"] = 1;
    }

    // one leg one track Bhabha
    if (back2back and ((negativeClusterSum > 4.5 and positiveP > 3) or (positiveClusterSum > 4.5 and negativeP > 3))) {
      calculationResult["ee1leg1trk"] = 1;
    }


    // one leg plus one electron
    if ((negativeClusterSum > 4.5 and positiveClusterSum > 0.8 * positiveP) or
        (positiveClusterSum > 4.5 and negativeClusterSum > 0.8 * negativeP)) {
      calculationResult["ee1leg1e"] = 1;
    }

    // eeee, eemm, mu mu, and radiative Bhabha selection
    const TLorentzVector p4Miss = p4ofCOM - negativeTrack.p4CMS - positiveTrack.p4CMS;
    const double pmissTheta = p4Miss.Theta() * TMath::RadToDeg();
    const double pmissp = p4Miss.Rho();
    const double relMissAngle0 = negativeTrack.p4CMS.Angle(p4Miss.Vect()) * TMath::RadToDeg();
    const double relMissAngle1 = positiveTrack.p4CMS.Angle(p4Miss.Vect()) * TMath::RadToDeg();

    const bool electronEP = positiveClusterSum > 0.8 * positiveP or negativeClusterSum > 0.8 * negativeP;
    const bool notMuonPair = negativeClusterSumLab > 1 or positiveClusterSumLab > 1;
    const double highp = std::max(negativeP, positiveP);
    const double lowp = std::min(negativeP, positiveP);
    const bool lowEdep = negativeClusterSumLab < 0.5 and positiveClusterSumLab < 0.5;


    if (calculationResult["maximumPCMS"] < 2 and dphi > 160 and (pmissTheta < 25. or pmissTheta > 155.)) {
      calculationResult["eexxSelect"] = 1;
      if (electronEP) {
        calculationResult["eeee"] = 1;
      } else {
        calculationResult["eemm"] = 1;
      }
    }
    if (1. < negativeP and 1. < positiveP and 2 == calculationResult["nTrkLoose"] and
        calculationResult["nTrkTight"] >= 1 and dphi < 170. and
        10. < pmissTheta and pmissTheta < 170. and 1. < pmissp and electronEP) {
      calculationResult["radBhabha"] = 1;
    }

    if (2. < negativeP and 2. < positiveP and 2 == calculationResult["nTrkLoose"] and
        calculationResult["nTrkTight"] >= 1 and 175. < dphi and
        (pmissTheta < 5. or pmissTheta > 175.) and electronEP) {
      calculationResult["isrRadBhabha"] = 1;
    }
    if ((pmissTheta < 20. or pmissTheta > 160.) and
        ((calculationResult["maximumPCMS"] < 1.2 and dphi > 150.) or
         (calculationResult["maximumPCMS"] < 2. and 175. < dphi))) {
      calculationResult["eexx"] = 1;
    }
    if (calculationResult["nTrkLoose"] == 2 and highp > 4.5 and notMuonPair and pmissp > 1. and
        (relMissAngle0 < 5. or relMissAngle1 < 5.)) {
      calculationResult["eeBrem"] = 1;
    }

    if (calculationResult["nTrkLoose"] == 2 and highp > 4.5 and lowEdep and dphi > 175. and 175. < thetaSum and
        thetaSum < 185.) {
      calculationResult["muonPairV"] = 1;
    }
    if (3. < highp and 2.5 < lowp and 165. < dphi and
        ((negativeClusterSumLab > 0. and negativeClusterSumLab < 1.) or
         (positiveClusterSumLab > 0. and positiveClusterSumLab < 1.))) {
      calculationResult["selectmumu"] = 1;
    }
  }

  if (selectedClusters.size() >= 2) {
    const SelectedECLCluster& firstCluster = selectedClusters[0];
    const SelectedECLCluster& secondCluster = selectedClusters[1];

    // Bhabha / gg vetoes using max two clusters
    double dphi = std::abs(firstCluster.p4CMS.Phi() - secondCluster.p4CMS.Phi()) * TMath::RadToDeg();
    if (dphi > 180) {
      dphi = 360 - dphi;
    }
    double thetaSum = (firstCluster.p4CMS.Theta() + secondCluster.p4CMS.Theta()) * TMath::RadToDeg();
    double dthetaSum = std::abs(thetaSum - 180);

    //..Quantities for two-photon fusion triggers
    calculationResult["dphiCmsClust"] = dphi;
    for (int ic = 0; ic < 2; ic++) {
      const double thetaLab = selectedClusters[ic].p4Lab.Theta() * TMath::RadToDeg();
      const bool isInAcceptance = 17. < thetaLab and thetaLab < 150.;
      const ECLCluster* cluster = selectedClusters[ic].cluster;
      const double zmva = cluster->getZernikeMVA();
      const bool photon = zmva > 0.5 and not selectedClusters[ic].isTrack;
      if (isInAcceptance and photon) {calculationResult["nMaxEPhotonAcc"] += 1;}
    }

    const double firstEnergy = firstCluster.p4CMS.E();
    const double secondEnergy = secondCluster.p4CMS.E();

    const bool highEnergetic = firstEnergy > 3 and secondEnergy > 3 and (firstEnergy > 4.5 or secondEnergy > 4.5);

    if (dphi > 160 and dphi < 178 and dthetaSum < 15 and highEnergetic) {
      calculationResult["ee2clst"] = 1;
    }

    if (dphi > 178 and dthetaSum < 15 and highEnergetic) {
      calculationResult["gg2clst"] = 1;
    }

    if ((calculationResult["ee2clst"] == 1 or calculationResult["gg2clst"] == 1) and
        calculationResult["ee1leg"] == 1) {
      calculationResult["ee1leg1clst"] = 1;
    }

    const double Elab0 = firstCluster.p4Lab.E();
    const double Elab1 = secondCluster.p4Lab.E();

    // gg and mumu accept triggers using ECL
    if (firstEnergy > 2 and secondEnergy > 2) {
      const double thetaLab0 = firstCluster.p4Lab.Theta() * TMath::RadToDeg();
      const double thetaLab1 = secondCluster.p4Lab.Theta() * TMath::RadToDeg();

      const bool barrel0 = 32. < thetaLab0 and thetaLab0 < 130.;
      const bool barrel1 = 32. < thetaLab1 and thetaLab1 < 130.;
      const bool oneClustersAbove4 = firstEnergy > 4 or secondEnergy > 4;
      const bool oneIsNeutral = not firstCluster.isTrack or not secondCluster.isTrack;
      const bool bothAreNeutral = not firstCluster.isTrack and not secondCluster.isTrack;
      const bool oneIsBarrel = barrel0 or barrel1;
      const bool dphiCutExtraLoose = dphi > 175;
      const bool dphiCutLoose = dphi > 177;
      const bool dphiCutTight = dphi > 177.5;

      if (dphiCutExtraLoose and oneIsNeutral and oneIsBarrel) {
        calculationResult["ggBarrelVL"] = 1;
      }
      if (oneClustersAbove4 and dphiCutLoose and oneIsNeutral and oneIsBarrel) {
        calculationResult["ggBarrelLoose"] = 1;
      }
      if (oneClustersAbove4 and dphiCutTight and bothAreNeutral and oneIsBarrel) {
        calculationResult["ggBarrelTight"] = 1;
      }
      if (dphiCutExtraLoose and oneIsNeutral and not oneIsBarrel) {
        calculationResult["ggEndcapVL"] = 1;
      }
      if (oneClustersAbove4 and dphiCutLoose and oneIsNeutral and not oneIsBarrel) {
        calculationResult["ggEndcapLoose"] = 1;
      }
      if (oneClustersAbove4 and dphiCutTight and bothAreNeutral and not oneIsBarrel) {
        calculationResult["ggEndcapTight"] = 1;
      }
    }

    const double minEnergy = std::min(Elab0, Elab1);
    const double maxEnergy = std::max(Elab0, Elab1);
    if (dphi > 155 and thetaSum > 165 and thetaSum < 195 and minEnergy > 0.15 and minEnergy < 0.5 and
        maxEnergy > 0.15 and maxEnergy < 0.5) {
      calculationResult["muonPairECL"] = 1;
    }

  }

  // Bhabha accept triggers.
  // Use theta_lab of negative track if available; otherwise cluster.
  double thetaFlatten = 0;

  // One leg, one cluster.
  for (short charge : { -1, 1}) {
    const auto& maximumPtTrack = maximumPtTracks.at(charge);
    if (not maximumPtTrack) {
      continue;
    }

    if (maximumPtTrack->clusterEnergySumCMS > 1.5) {
      double invMass = 0.;
      double tempFlatten = 0.;
      for (const SelectedECLCluster& cluster : selectedClusters) {
        double tempInvMass = (maximumPtTrack->p4Lab + cluster.p4Lab).M();
        if (tempInvMass > invMass) {
          invMass = tempInvMass;
          if (charge == 1) {
            tempFlatten = cluster.p4Lab.Theta() * TMath::RadToDeg();
          }
        }
      }
      if (charge == -1) {
        tempFlatten = maximumPtTrack->p4Lab.Theta() * TMath::RadToDeg();
      }
      if (invMass > 5.29) {
        calculationResult["selectee1leg1clst"] = 1;
        thetaFlatten = tempFlatten;
      }
    }
  }

  // Two legs
  if (maximumPtTracks.at(-1) and maximumPtTracks.at(1)) {
    const MaximumPtTrack& negativeTrack = *maximumPtTracks.at(-1);
    const MaximumPtTrack& positiveTrack = *maximumPtTracks.at(1);
    const double invMass = (negativeTrack.p4Lab + positiveTrack.p4Lab).M();
    if (invMass > 5.29 and (negativeTrack.clusterEnergySumCMS > 1.5 or positiveTrack.clusterEnergySumCMS > 1.5)) {
      calculationResult["selectee1leg1trk"] = 1;
    }

    thetaFlatten = negativeTrack.p4Lab.Theta() * TMath::RadToDeg();

    // Two tracks but (exactly) 1 high energy cluster
    const bool missNegClust = positiveTrack.clusterEnergySumCMS > 4.5 and negativeTrack.clusterEnergySumCMS < 1.;
    const bool missPosClust = negativeTrack.clusterEnergySumCMS > 4.5 and positiveTrack.clusterEnergySumCMS < 1.;
    if ((invMass > 9.) and (missNegClust or missPosClust)) {
      calculationResult["eeOneClust"] = 1;
    }
  }

  if (calculationResult["selectee1leg1trk"] == 1 or calculationResult["selectee1leg1clst"] == 1) {
    for (int iflat = 0; iflat < 9; iflat++) {
      const std::string& eeFlatName = "eeFlat" + std::to_string(iflat);
      calculationResult[eeFlatName] =
        thetaFlatten > flatBoundaries[iflat] and thetaFlatten < flatBoundaries[iflat + 1];
      if (calculationResult[eeFlatName]) {
        calculationResult["selectee"] = 1;
      }
    }
  }

  // Single tag pi0 / eta dedicated lines
  if (calculationResult["nTrkLoose"] == 1 and calculationResult["maximumPCMS"] > 0.8 and selectedClusters.size() >= 2) {

    decltype(selectedClusters) selectedSingleTagClusters(selectedClusters.size());
    auto lastItem = std::copy_if(selectedClusters.begin(), selectedClusters.end(), selectedSingleTagClusters.begin(),
    [](auto & cluster) {
      const bool isNeutralCluster = not cluster.isTrack;
      const bool hasEnoughEnergy = cluster.energyLab > 0.1;
      const double clusterThetaLab = cluster.p4Lab.Theta() * TMath::RadToDeg();
      const bool isInAcceptance = 17 < clusterThetaLab and clusterThetaLab < 150.;
      return isNeutralCluster and hasEnoughEnergy and isInAcceptance;
    });
    selectedSingleTagClusters.resize(std::distance(selectedSingleTagClusters.begin(), lastItem));

    if (selectedSingleTagClusters.size() >= 2) {  // One track and at least two clusters are found

      const auto& track = maximumPtTracks.at(-1) ? *maximumPtTracks.at(-1) : *maximumPtTracks.at(1);
      // in real signal, the pi0 decay daughters are always the two most-energetic neutral clusters.
      const auto& firstCluster = selectedSingleTagClusters[0];
      const auto& secondCluster = selectedSingleTagClusters[1];

      const TLorentzVector trackP4CMS = track.p4CMS;
      const TLorentzVector pi0P4CMS = firstCluster.p4CMS + secondCluster.p4CMS;

      const bool passPi0ECMS = pi0P4CMS.E() > 1. and pi0P4CMS.E() < 0.525 * p4ofCOM.M();
      const double thetaSumCMS = (pi0P4CMS.Theta() + trackP4CMS.Theta()) * TMath::RadToDeg();
      const bool passThetaSum = thetaSumCMS < 170. or thetaSumCMS > 190.;

      double dphiCMS = std::abs(trackP4CMS.Phi() - pi0P4CMS.Phi()) * TMath::RadToDeg();
      if (dphiCMS > 180) {
        dphiCMS = 360 - dphiCMS;
      }
      const bool passdPhi = dphiCMS > 160.;

      if (passPi0ECMS and passThetaSum and passdPhi and pi0P4CMS.M() < 0.7) {
        calculationResult["singleTagLowMass"] = 1;
      } else if (passPi0ECMS and passThetaSum and passdPhi and pi0P4CMS.M() > 0.7) {
        calculationResult["singleTagHighMass"] = 1;
      }
    }
  }

  //..Cosmic selection. Need exactly two tracks.
  if (m_tracks.getEntries() == 2) {

    const auto negTrack = maximumPtTracksWithoutZCut.at(-1);
    const auto posTrack = maximumPtTracksWithoutZCut.at(1);

    if (negTrack and posTrack) {

      const double maxNegpT = negTrack->pT;
      const double maxPospT = posTrack->pT;

      auto accumulatePhotonEnergy = [](double result, const auto & cluster) {
        return result + (cluster.hasHypothesis(Belle2::ECLCluster::EHypothesisBit::c_nPhotons) ? cluster.getEnergy(
                           Belle2::ECLCluster::EHypothesisBit::c_nPhotons) : 0);
      };

      const auto& clustersOfNegTrack = negTrack->track->getRelationsTo<ECLCluster>();
      const auto& clustersOfPosTrack = posTrack->track->getRelationsTo<ECLCluster>();

      const double maxClusterENeg = std::accumulate(clustersOfNegTrack.begin(), clustersOfNegTrack.end(), 0.0, accumulatePhotonEnergy);
      const double maxClusterEPos = std::accumulate(clustersOfPosTrack.begin(), clustersOfPosTrack.end(), 0.0, accumulatePhotonEnergy);

      const TLorentzVector& momentumLabNeg(negTrack->p4Lab);
      const TLorentzVector& momentumLabPos(posTrack->p4Lab);

      const double& z0Neg = negTrack->track->getTrackFitResultWithClosestMass(Const::pion)->getZ0();
      const double& d0Neg = negTrack->track->getTrackFitResultWithClosestMass(Const::pion)->getD0();
      const double& z0Pos = posTrack->track->getTrackFitResultWithClosestMass(Const::pion)->getZ0();
      const double& d0Pos = posTrack->track->getTrackFitResultWithClosestMass(Const::pion)->getD0();

      // Select cosmic using these tracks
      const bool goodMagneticRegion = (z0Neg<m_goodMagneticRegionZ0 or abs(d0Neg)>m_goodMagneticRegionD0)
                                      and (z0Pos<m_goodMagneticRegionZ0 or abs(d0Pos)>m_goodMagneticRegionD0);
      if (maxNegpT > m_cosmicMinPt and maxPospT > m_cosmicMinPt and maxClusterENeg < m_cosmicMaxClusterEnergy
          and maxClusterEPos < m_cosmicMaxClusterEnergy and goodMagneticRegion) {
        double dphiLab = std::abs(momentumLabNeg.Phi() - momentumLabPos.Phi()) * TMath::RadToDeg();
        if (dphiLab > 180) {
          dphiLab = 360 - dphiLab;
        }

        const double thetaSumLab = (momentumLabNeg.Theta() + momentumLabPos.Theta()) * TMath::RadToDeg();

        constexpr double phiBackToBackTolerance = 2.;
        constexpr double thetaBackToBackTolerance = 2.;
        if ((180 - dphiLab) < phiBackToBackTolerance and std::abs(180 - thetaSumLab) < thetaBackToBackTolerance) {
          calculationResult["cosmic"] = 1;
        }
      }
    }
  }

}

fillInCalculations()

const SoftwareTriggerObject & fillInCalculations ( )

inherited

Main function of this class: calculate the needed variables using the overwritten doCalculation function and write out the values into the results object (with their names).

Please make sure to override (or clear) the variables! Otherwise it can happen that their old values are still in the object.

What variables exactly are added to the result depends on the implementation details of the class.

Definition at line 54 of file SoftwareTriggerCalculation.cc.

writeDebugOutput()

void writeDebugOutput ( const std::unique_ptr< TTree > &  debugOutputTTree )

inherited

Function to write out debug output into the given TTree.

Needs an already prefilled calculationResult for this (probably using the fillInCalculations function).

Definition at line 29 of file SoftwareTriggerCalculation.cc.

---

The documentation for this class was generated from the following files:

• hlt/softwaretrigger/calculations/include/FilterCalculator.h
• hlt/softwaretrigger/calculations/src/FilterCalculator.cc
