TCType Class Reference

Small class for classifying types of reconstructed track candidates. More...

#include <TCType.h>

Collaboration diagram for TCType:

Public Types
enum	Type {   UnknownType,   Unclassified,   Lost,   RefOutlier,   Ghost,   SmallStump,   Clone,   Contaminated,   Clean,   Perfect,   AllTCTypes,   Reference,   NTypes }
	allows classifying TCs

Static Public Member Functions
static bool	isValidType (TCType::Type type)
	checks if a type given is a valid type for a TCType
static bool	isValidName (std::string type)
	checks if the name given is a valid name for a TCType
static std::string	getTypeName (TCType::Type type)
	for given TCType the corresponding string-name will be returned. More...
static TCType::Type	getTypeEnum (std::string type)
	for given string name of a TCType the corresponding TCType will be returned. More...
static bool	isReference (TCType::Type aType)
	returns true if given TCType is a reference-Type, false if not
static bool	isTestTC (TCType::Type aType)
	returns true if given TCType is a testTC-Type, false if not
static bool	isGoodTestTC (TCType::Type aType)
	returns true if given TCType is a testTC-Type and did successfully reconstruct a track

Static Protected Attributes
static std::map< Type, std::string >	s_fromTypeToString
	static map allowing translation from a given type to its name stored as a string More...
static std::map< std::string, Type >	s_fromStringToType
	static map allowing translation from a given name stored as a string to its type More...

Detailed Description

Small class for classifying types of reconstructed track candidates.

Contains enums and converter from and to strings

Definition at line 35 of file TCType.h.

Member Function Documentation

getTypeEnum()

static TCType::Type getTypeEnum ( std::string  type )

inlinestatic

for given string name of a TCType the corresponding TCType will be returned.

For invalid types, UnknownType will be passed

Definition at line 84 of file TCType.h.

    {
      return aType == TCType::Reference
             or aType == TCType::Lost
             or aType == TCType::RefOutlier;

getTypeName()

static std::string getTypeName ( TCType::Type  type )

inlinestatic

for given TCType the corresponding string-name will be returned.

For invalid types, UnknownType will be passed

Definition at line 72 of file TCType.h.

Member Data Documentation

s_fromStringToType

std::map< std::string, Belle2::TCType::Type > s_fromStringToType

staticprotected

Initial value:

= {
  {std::string("UnknownType"), Belle2::TCType::UnknownType},
  {std::string("Unclassified"), Belle2::TCType::Unclassified},
  {std::string("Lost"), Belle2::TCType::Lost},
  {std::string("RefOutlier"), Belle2::TCType::RefOutlier},
  {std::string("Ghost"), Belle2::TCType::Ghost},
  {std::string("SmallStump"), Belle2::TCType::SmallStump},
  {std::string("Clone"), Belle2::TCType::Clone},
  {std::string("Contaminated"), Belle2::TCType::Contaminated},
  {std::string("Clean"), Belle2::TCType::Clean},
  {std::string("Perfect"), Belle2::TCType::Perfect},
  {std::string("AllTCTypes"), Belle2::TCType::AllTCTypes},
  {std::string("Reference"), Belle2::TCType::Reference},
  {std::string("NTypes"), Belle2::TCType::NTypes}
}

static map allowing translation from a given name stored as a string to its type

setting static dictionary translating string -> type

Definition at line 125 of file TCType.h.

s_fromTypeToString

std::map< Belle2::TCType::Type, std::string > s_fromTypeToString

staticprotected

Initial value:

= {
  {Belle2::TCType::UnknownType, std::string("UnknownType")},
  {Belle2::TCType::Unclassified, std::string("Unclassified")},
  {Belle2::TCType::Lost, std::string("Lost")},
  {Belle2::TCType::RefOutlier, std::string("RefOutlier")},
  {Belle2::TCType::Ghost, std::string("Ghost")},
  {Belle2::TCType::SmallStump, std::string("SmallStump")},
  {Belle2::TCType::Clone, std::string("Clone")},
  {Belle2::TCType::Contaminated, std::string("Contaminated")},
  {Belle2::TCType::Clean, std::string("Clean")},
  {Belle2::TCType::Perfect, std::string("Perfect")},
  {Belle2::TCType::AllTCTypes, std::string("AllTCTypes")},
  {Belle2::TCType::Reference, std::string("Reference")},
  {Belle2::TCType::NTypes, std::string("NTypes")}
}

static map allowing translation from a given type to its name stored as a string

setting static dictionary translating type -> string

Definition at line 122 of file TCType.h.

---

The documentation for this class was generated from the following files:

• tracking/trackFindingVXD/analyzingTools/include/TCType.h
• tracking/trackFindingVXD/analyzingTools/src/TCType.cc
