Nominal quantum efficiency of PMT. More...

#include <TOPNominalQE.h>

Inheritance diagram for TOPNominalQE:

Collaboration diagram for TOPNominalQE:

[legend]

Public Member Functions
	TOPNominalQE ()
	Default constructor.

	TOPNominalQE (float lambdaFirst, float lambdaStep, float CE, const std::vector< float > &qe, const std::string &name="TOPNominalQE")
	Full constructor. More...

void	set (float lambdaFirst, float lambdaStep, float CE, const std::vector< float > &qe, const std::string &name)
	Sets the object. More...

void	clear ()
	Clears the object.

bool	isEmpty () const
	Checks the status. More...

const std::vector< float > &	getQE () const
	Returns quantum efficiency data points. More...

double	getQE (double lambda) const
	Returns quantum efficiency at given photon wavelength using linear interpolation. More...

double	getEfficiency (double lambda) const
	Returns quantum times collection efficiency at given photon wavelength using linear interpolation. More...

double	getLambdaFirst () const
	Returns wavelenght of the first data point. More...

double	getLambdaLast () const
	Returns wavelenght of the last data point. More...

double	getLambdaStep () const
	Returns wavelenght step. More...

double	getCE () const
	Returns collection efficiency. More...

bool	isConsistent () const override
	Check for consistency of data members. More...

void	print (const std::string &title="Nominal quantum efficiency") const override
	Print the content of the class. More...

void	setName (const std::string &name)
	Sets object name. More...

const std::string &	getName () const
	Returns object name. More...

virtual void	printSurface (const GeoOpticalSurface &surface) const
	Print the content of optical surface. More...

double	getReflectivity (const GeoOpticalSurface &surface, double energy) const
	Returns reflectivity of optical surface at given photon energy. More...

Protected Member Functions
void	printUnderlined (const std::string &title) const
	Print the content of the class. More...

	ClassDef (TOPGeoBase, 1)
	ClassDef.

Protected Attributes
std::string	m_name
	geometry object name

Static Protected Attributes
static double	s_unit = Unit::cm
	conversion unit for length

static std::string	s_unitName
	conversion unit name

Private Member Functions
	ClassDefOverride (TOPNominalQE, 1)
	ClassDef.

Private Attributes
float	m_lambdaFirst = 0
	wavelength of the first data point [nm]

float	m_lambdaStep = 0
	wavelength step [nm]

float	m_CE = 0
	collection efficiency

std::vector< float >	m_QE
	QE data points.

Detailed Description

Nominal quantum efficiency of PMT.

Definition at line 33 of file TOPNominalQE.h.

Constructor & Destructor Documentation

◆ TOPNominalQE()

TOPNominalQE	(	float	lambdaFirst,
		float	lambdaStep,
		float	CE,
		const std::vector< float > &	qe,
		const std::string &	name = `"TOPNominalQE"`
	)

inline

Full constructor.

Parameters

lambdaFirst	wavelenght of the first data point [nm]
lambdaStep	wavelength step [nm]
CE	collection efficiency
qe	quantum efficiency data points
name	object name

Definition at line 50 of file TOPNominalQE.h.

Member Function Documentation

◆ getCE()

double getCE ( ) const

inline

Returns collection efficiency.

Returns: collection efficiency

Definition at line 139 of file TOPNominalQE.h.

◆ getEfficiency()

double getEfficiency ( double lambda ) const

inline

Returns quantum times collection efficiency at given photon wavelength using linear interpolation.

Parameters

lambda photon wavelength in [nm]

Returns: quantum efficiency

Definition at line 112 of file TOPNominalQE.h.

◆ getLambdaFirst()

double getLambdaFirst ( ) const

inline

Returns wavelenght of the first data point.

Returns: wavelength in [nm]

Definition at line 118 of file TOPNominalQE.h.

◆ getLambdaLast()

double getLambdaLast ( ) const

inline

Returns wavelenght of the last data point.

Returns: wavelength in [nm]

Definition at line 124 of file TOPNominalQE.h.

◆ getLambdaStep()

double getLambdaStep ( ) const

inline

Returns wavelenght step.

Returns: wavelength step in [nm]

Definition at line 133 of file TOPNominalQE.h.

◆ getName()

const std::string& getName ( ) const

inlineinherited

Returns object name.

Returns: object name

Definition at line 61 of file TOPGeoBase.h.

◆ getQE()

const std::vector<float>& getQE ( ) const

inline

Returns quantum efficiency data points.

Returns: quantum efficiency data points

Definition at line 97 of file TOPNominalQE.h.

◆ isEmpty()

bool isEmpty ( ) const

inline

Checks the status.

Returns: true if QE data points are empty

Definition at line 91 of file TOPNominalQE.h.

◆ set()

void set	(	float	lambdaFirst,
		float	lambdaStep,
		float	CE,
		const std::vector< float > &	qe,
		const std::string &	name
	)

inline

Sets the object.

Parameters

lambdaFirst	wavelenght of the first data point [nm]
lambdaStep	wavelength step [nm]
CE	collection efficiency
qe	quantum efficiency data points
name	object name

Definition at line 64 of file TOPNominalQE.h.

◆ setName()

void setName ( const std::string & name )

inlineinherited

Sets object name.

Parameters

name	object name

Definition at line 55 of file TOPGeoBase.h.

The documentation for this class was generated from the following files:

top/dbobjects/include/TOPNominalQE.h
top/dbobjects/src/TOPNominalQE.cc
