Configure TOP geometry for reconstruction: provides interface to fortran code. More...

#include <TOPconfigure.h>

Collaboration diagram for TOPconfigure:

[legend]

Public Types
enum	{ c_None = 0, c_PMT, c_PlaneM, c_CylindricM, c_SphericM }
	Exit window types.

enum	{ c_Left = 0, c_Right = 1 }
	Argument LR.

enum	{ c_NoRefl = 0, c_Box, c_Prism }
	Expansion volume shapes.

Public Member Functions
	TOPconfigure ()
	Constructor (which does the stuff if reconstruction geometry not configured yet)

void	setTOPvolume (double R1, double R2, double Z1, double Z2)
	Defines TOP counter volume (must be called first) More...

void	setBfield (double B)
	Sets magnetic field (use negative value to reverse polarity) More...

void	setEdgeRoughness (double R)
	Sets bar edge roughness (radius) More...

void	setPMT (double A, double B, double Asens, double Bsens, int Nx, int Ny, double TTS=50.e-3)
	Defines PMT dimensions (must be called prior to setQbar) More...

void	setTTS (int ng, float Frac[], float Mean[], float Sigma[])
	Defines TTS with multi-gaussian PDF. More...

void	setPMTDependentTTSes ()
	Sets PMT dependent TTS-es.

void	setQE (float Wavelength[], float QE[], int Size, double CE)
	Sets quantum efficiency. More...

int	setQbar (double A, double B, double Z1, double Z2, double R, double Dx, double Phi, int Lside, int Rside)
	Defines module geometry; returns module ID. More...

void	setBBoxWindow (int moduleID, double thickness)
	Adds QBB exit window. More...

void	addExpansionVolume (int moduleID, int LR, int Shape, double Dz, double Yup, double Ydown, double YupIn=0, double YdownIn=0, double Width=0, double DzRefl=0, double Refl=0)
	Adds expansion volume (wedge) More...

void	arrangePMT (int moduleID, double sizX, double sizY, double Dx=0, double Dy=0)
	Re-arranges PMT's at (both) exit window(s) More...

void	arrangePMT (int moduleID, int LR, double sizX, double sizY, double Dx=0, double Dy=0)
	Re-arranges PMT's at exit window LR. More...

void	setMirrorRadius (int moduleID, double R)
	Sets mirror radius. More...

void	setMirrorCenter (int moduleID, double Xc, double Yc)
	Sets mirror center. More...

void	setMirrorReflectivity (int moduleID, double reflectivity)
	Sets mirror reflectivity. More...

void	setSurfaceReflectivity (int moduleID, double reflectivity)
	Sets surface reflectivity. More...

void	setTDC (int NBIT, double ChWid, double Offset=0)
	Defines TDC. More...

void	setCFD (double delTpileup, double delTdoubleHit)
	Defines CFD. More...

bool	TOPfinalize (int Dump=1)
	Finalizes TOP configuration (must be called last) More...

void	print () const
	Prints configuration to std output (using fortran print)

bool	isConfigured () const
	Returns configuration status. More...

double	getR1 () const
	Returns inner radius of space for TOP modules. More...

double	getR2 () const
	Returns outer radius of space for TOP modules. More...

double	getZ1 () const
	Returns minimal z of space for TOP modules. More...

double	getZ2 () const
	Returns maximal z of space for TOP modules. More...

double	getTDCTimeRange () const
	Returns time range of TDC. More...

void	getQbar (int moduleID, double &A, double &B, double &C, int &Lside, int &Rside, int &LexpvID, int &RexpvID)
	Returns module specs. More...

void	getExpansionVolume (int expvID, double &Dz, double &Yup, double &Ydown, double &YupIn, double &YdownIn, double &Width, int &Shape, int &LR)
	Returns expansion volume (wedge) specs. More...

void	getMirror (int moduleID, double &R, double &Xc, double &Yc, double &Zc, double &F)
	Returns mirror specs. More...

double	getBBoxWindow (int moduleID)
	Returns thickness of the bar box window. More...

Static Public Member Functions
static void	setAlignmentConstants ()
	Passes alignment constants to FORTRAN code function is used in call-back.

static void	setPMTTypes ()
	Sets PMT types pixel table.

Private Attributes
double	m_R1 = 0
	inner radius

double	m_R2 = 0
	outer radius

double	m_Z1 = 0
	backward z

double	m_Z2 = 0
	forward z

double	m_timeRange = 0
	time range of TDC

Static Private Attributes
static bool	m_configured
	set to true when done

static DBObjPtr< TOPCalModuleAlignment >	m_alignment
	alignment constants

static OptionalDBArray< TOPPmtInstallation >	m_pmtInstalled
	PMT installation data.

Detailed Description

Configure TOP geometry for reconstruction: provides interface to fortran code.

Definition at line 36 of file TOPconfigure.h.

Member Function Documentation

◆ addExpansionVolume()

void addExpansionVolume	(	int	moduleID,
		int	LR,
		int	Shape,
		double	Dz,
		double	Yup,
		double	Ydown,
		double	YupIn = `0`,
		double	YdownIn = `0`,
		double	Width = `0`,
		double	DzRefl = `0`,
		double	Refl = `0`
	)

Adds expansion volume (wedge)

Parameters

moduleID	module ID (0 based, e.g. slot-1)
LR	Left or Right
Shape	shape (c_Box, c_Prism, etc.)
Dz	length
Yup	uppermost y
Ydown	lowermost y
YupIn	uppermost y at bar
YdownIn	lowermost y at bar
Width	width (0 means same width as bar)
DzRefl	length of the reflective part at exit
Refl	reflectivity of that part

Definition at line 293 of file TOPconfigure.cc.

     {
       float dz = Dz; float yup = Yup; float ydn = Ydown; float a = Width;
       float yupi = YupIn; float ydni = YdownIn;
       float dzrefl = DzRefl; float refl = Refl;
       set_extvol_(&moduleID, &LR, &Shape, &dz, &yup, &ydn, &a, &yupi, &ydni,
                   &dzrefl, &refl);
     }

◆ arrangePMT() [1/2]

void arrangePMT	(	int	moduleID,
		double	sizX,
		double	sizY,
		double	Dx = `0`,
		double	Dy = `0`
	)

Re-arranges PMT's at (both) exit window(s)

Parameters

moduleID	module ID (0 based, e.g. slot-1)
sizX	box size in x
sizY	box size in y
Dx	box offset in x
Dy	box offset in y

Definition at line 305 of file TOPconfigure.cc.

◆ arrangePMT() [2/2]

void arrangePMT	(	int	moduleID,
		int	LR,
		double	sizX,
		double	sizY,
		double	Dx = `0`,
		double	Dy = `0`
	)

Re-arranges PMT's at exit window LR.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
LR	Left or Right
sizX	box size in x
sizY	box size in y
Dx	box offset in x
Dy	box offset in y

Definition at line 316 of file TOPconfigure.cc.

◆ getBBoxWindow()

double getBBoxWindow ( int moduleID )

Returns thickness of the bar box window.

Parameters

moduleID module ID (slot number, 1 based)

Returns: thickness

Definition at line 405 of file TOPconfigure.cc.

◆ getExpansionVolume()

void getExpansionVolume	(	int	expvID,
		double &	Dz,
		double &	Yup,
		double &	Ydown,
		double &	YupIn,
		double &	YdownIn,
		double &	Width,
		int &	Shape,
		int &	LR
	)

Returns expansion volume (wedge) specs.

Parameters

expvID	expansion volume ID
Dz	length
Yup	uppermost y
Ydown	lowermost y
YupIn	uppermost y at bar
YdownIn	lowermost y at bar
Width	width
Shape	shape
LR	Left or Right

Definition at line 387 of file TOPconfigure.cc.

◆ getMirror()

void getMirror	(	int	moduleID,
		double &	R,
		double &	Xc,
		double &	Yc,
		double &	Zc,
		double &	F
	)

Returns mirror specs.

Parameters

moduleID	module ID (slot number, 1 based)
R	radius
Xc	center of curvature in x (local frame)
Yc	center of curvature in y (local frame)
Zc	center of curvature in z (local frame)
F	effective focal length

Definition at line 396 of file TOPconfigure.cc.

◆ getQbar()

void getQbar	(	int	moduleID,
		double &	A,
		double &	B,
		double &	C,
		int &	Lside,
		int &	Rside,
		int &	LexpvID,
		int &	RexpvID
	)

Returns module specs.

Parameters

moduleID	module ID (slot number, 1 based)
A	width
B	thickness
C	length
Lside	left-side window type
Rside	right-side window type
LexpvID	left-side expansion volume ID or 0
RexpvID	right-side expansion volume ID or 0

Definition at line 378 of file TOPconfigure.cc.

◆ getR1()

double getR1 ( ) const

inline

Returns inner radius of space for TOP modules.

Returns: inner radius

Definition at line 258 of file TOPconfigure.h.

262 {return m_Z1;}

◆ getR2()

double getR2 ( ) const

inline

Returns outer radius of space for TOP modules.

Returns: outer radius

Definition at line 264 of file TOPconfigure.h.

◆ getTDCTimeRange()

double getTDCTimeRange ( ) const

inline

Returns time range of TDC.

Returns: time range

Definition at line 282 of file TOPconfigure.h.

◆ getZ1()

double getZ1 ( ) const

inline

Returns minimal z of space for TOP modules.

Returns: minimal z

Definition at line 270 of file TOPconfigure.h.

◆ getZ2()

double getZ2 ( ) const

inline

Returns maximal z of space for TOP modules.

Returns: maximal z

Definition at line 276 of file TOPconfigure.h.

◆ isConfigured()

bool isConfigured ( ) const

inline

Returns configuration status.

Returns: status

Definition at line 252 of file TOPconfigure.h.

◆ setBBoxWindow()

void setBBoxWindow	(	int	moduleID,
		double	thickness
	)

Adds QBB exit window.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
thickness	window thickness

Definition at line 287 of file TOPconfigure.cc.

◆ setBfield()

void setBfield ( double B )

Sets magnetic field (use negative value to reverse polarity)

Parameters

B	magnetic field

Definition at line 245 of file TOPconfigure.cc.

◆ setCFD()

void setCFD	(	double	delTpileup,
		double	delTdoubleHit
	)

Defines CFD.

Parameters

delTpileup	pileup time
delTdoubleHit	double hit resolution

Definition at line 362 of file TOPconfigure.cc.

◆ setEdgeRoughness()

void setEdgeRoughness ( double R )

Sets bar edge roughness (radius)

Parameters

R roughness

Definition at line 251 of file TOPconfigure.cc.

◆ setMirrorCenter()

void setMirrorCenter	(	int	moduleID,
		double	Xc,
		double	Yc
	)

Sets mirror center.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
Xc	center of curvature in x (local frame)
Yc	center of curvature in y (local frame)

Definition at line 330 of file TOPconfigure.cc.

◆ setMirrorRadius()

void setMirrorRadius	(	int	moduleID,
		double	R
	)

Sets mirror radius.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
R	radius

Definition at line 324 of file TOPconfigure.cc.

◆ setMirrorReflectivity()

void setMirrorReflectivity	(	int	moduleID,
		double	reflectivity
	)

Sets mirror reflectivity.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
reflectivity	reflectivity (absolute value)

Definition at line 336 of file TOPconfigure.cc.

◆ setPMT()

void setPMT	(	double	A,
		double	B,
		double	Asens,
		double	Bsens,
		int	Nx,
		int	Ny,
		double	TTS = `50.e-3`
	)

Defines PMT dimensions (must be called prior to setQbar)

Parameters

A	size in x
B	size in y
Asens	sensitive area in x
Bsens	sensitive area in y
Nx	number of pads in x
Ny	number of pads in y
TTS	time resolution (rms)

Definition at line 257 of file TOPconfigure.cc.

◆ setQbar()

int setQbar	(	double	A,
		double	B,
		double	Z1,
		double	Z2,
		double	R,
		double	Dx,
		double	Phi,
		int	Lside,
		int	Rside
	)

Defines module geometry; returns module ID.

Parameters

A	bar width
B	bar thickness
Z1	backward window position
Z2	forward window position
R	inner radius
Dx	shift along the module frame x-axis
Phi	angle in respect to Belle y-axis
Lside	type of the left side exit window
Rside	type of the right side exit window

Returns: module ID

Definition at line 277 of file TOPconfigure.cc.

◆ setQE()

void setQE	(	float	Wavelength[],
		float	QE[],
		int	Size,
		double	CE
	)

Sets quantum efficiency.

Parameters

Wavelength	wavelength values
QE	quantum efficiency values
Size	array size
CE	electron collection efficiency

Definition at line 271 of file TOPconfigure.cc.

◆ setSurfaceReflectivity()

void setSurfaceReflectivity	(	int	moduleID,
		double	reflectivity
	)

Sets surface reflectivity.

Parameters

moduleID	module ID (0 based, e.g. slot-1)
reflectivity	reflectivity (absolute value)

Definition at line 346 of file TOPconfigure.cc.

◆ setTDC()

void setTDC	(	int	NBIT,
		double	ChWid,
		double	Offset = `0`
	)

Defines TDC.

Parameters

NBIT	number of bits
ChWid	channel width
Offset	offset

Definition at line 356 of file TOPconfigure.cc.

◆ setTOPvolume()

void setTOPvolume	(	double	R1,
		double	R2,
		double	Z1,
		double	Z2
	)

Defines TOP counter volume (must be called first)

Parameters

R1	inner radius of TOP volume
R2	outer radius of TOP volume
Z1	backward border of TOP volume
Z2	forward border of TOP volume

Definition at line 238 of file TOPconfigure.cc.

◆ setTTS()

void setTTS	(	int	ng,
		float	Frac[],
		float	Mean[],
		float	Sigma[]
	)

Defines TTS with multi-gaussian PDF.

Parameters

ng	number of Gaussian terms
Frac	fractions of Gaussian terms
Mean	mean values of Gaussian terms
Sigma	sigma values of Gaussian terms

Definition at line 266 of file TOPconfigure.cc.

◆ TOPfinalize()

bool TOPfinalize ( int Dump = 1 )

Finalizes TOP configuration (must be called last)

Parameters

Dump	print configuration to std output

Returns: true if successfull

Definition at line 368 of file TOPconfigure.cc.

The documentation for this class was generated from the following files:

top/reconstruction/include/TOPconfigure.h
top/reconstruction/src/TOPconfigure.cc

Public Types

Public Member Functions

Static Public Member Functions

Private Attributes

Static Private Attributes

Detailed Description

Member Function Documentation

◆ addExpansionVolume()

◆ arrangePMT() [1/2]

◆ arrangePMT() [2/2]

◆ getBBoxWindow()

◆ getExpansionVolume()

◆ getMirror()

◆ getQbar()

◆ getR1()

◆ getR2()

◆ getTDCTimeRange()

◆ getZ1()

◆ getZ2()

◆ isConfigured()

◆ setBBoxWindow()

◆ setBfield()

◆ setCFD()

◆ setEdgeRoughness()

◆ setMirrorCenter()

◆ setMirrorRadius()

◆ setMirrorReflectivity()

◆ setPMT()

◆ setQbar()

◆ setQE()

◆ setSurfaceReflectivity()

◆ setTDC()

◆ setTOPvolume()

◆ setTTS()

◆ TOPfinalize()
