Belle II Software  release-05-02-19
TrackBuilder Class Reference

TrackBuilder class to create the Track/TrackFitResult mdst output from the RecoTrack. More...

#include <TrackBuilder.h>

Collaboration diagram for TrackBuilder:

Public Member Functions

 TrackBuilder (const std::string &trackColName, const std::string &trackFitResultColName, const std::string &mcParticleColName, const TVector3 &beamSpot=TVector3(0., 0., 0.), const TVector3 &beamAxis=TVector3(0., 0., 1.))
 Constructor of the class. More...

bool storeTrackFromRecoTrack (RecoTrack &recoTrack, const bool useClosestHitToIP=false, const bool useBFieldAtHit=false)
 Stores a Belle2 Track from a Reco Track. More...


Static Public Member Functions

static uint32_t getHitPatternVXDInitializer (const RecoTrack &recoTrack)
 Get the HitPattern in the VXD.

static uint64_t getHitPatternCDCInitializer (const RecoTrack &recoTrack)
 Get the HitPattern in the CDC.


Private Attributes

std::string m_trackColName
 TrackColName (output).

std::string m_trackFitResultColName
 TrackFitResultColName (output).

std::string m_mcParticleColName
 MCParticleColName (input, optional).

TVector3 m_beamSpot
 Extrapolation target, origin.

TVector3 m_beamAxis
 Extrapolation target, positive z direction.


Detailed Description

TrackBuilder class to create the Track/TrackFitResult mdst output from the RecoTrack.

To use this class, iterate over all Reco tracks and call trackBuilder.storeTrackFromRecoTrack. All fitted hypotheses will be stored into one Track with the TrackFitResult array indices stored in the Track. for (auto& recoTrack : recoTracks) { trackBuilder.storeTrackFromRecoTrack(recoTrack); }

If you want to make sure that all hypotheses are fitted and stored, call the fitter again. If the tracks are fitted already, this produces no overhead. TrackFitter trackFitter; TrackBuilder trackBuilder; for (auto& recoTrack : recoTracks) { for (const auto& pdg : m_pdgCodes) { trackFitter.fit(recoTrack, Const::ParticleType(abs(pdg))); } trackBuilder.storeTrackFromRecoTrack(recoTrack); }

Definition at line 50 of file TrackBuilder.h.

Constructor & Destructor Documentation

◆ TrackBuilder()

TrackBuilder ( const std::string &  trackColName,
const std::string &  trackFitResultColName,
const std::string &  mcParticleColName,
const TVector3 &  beamSpot = TVector3(0., 0., 0.),
const TVector3 &  beamAxis = TVector3(0., 0., 1.)
)
inline

Constructor of the class.

Parameters
trackColNameName of the store array for tracks (output).
trackFitResultColNameName of the store array for track fit results (output).
mcParticleColNameName of the store array for MC particles (input, optional). If given, the tracks are matched to MCParticles.
beamSpotOrigin.
beamAxisPositive z-direction.

Definition at line 61 of file TrackBuilder.h.

65  {};
66

Member Function Documentation

◆ storeTrackFromRecoTrack()

bool storeTrackFromRecoTrack ( RecoTrack recoTrack,
const bool  useClosestHitToIP = false,
const bool  useBFieldAtHit = false
)

Stores a Belle2 Track from a Reco Track.

Every fitted hypothesis will be extrapolated to the perigee and stored as a TrackFitResult when the fit and the extrapolation were successful. We will only create a Track mdst object, when we are sure that we have at least one valid hypothesis available. If we do not have this, we discard the track no matter what.

The StoreArrayIndex is stored in the Belle2 Track, no relation is set.

Parameters
recoTrackThe reco track the fit results are stored for
useClosestHitInIPFlag to turn on special handling which measurement to choose; especially useful for Cosmics
useBFiledAtHitFlag to calculate the BField at the used hit (closest to IP or first one), instead of the one at the POCA. This is also useful for cosmics only.
Returns

Definition at line 28 of file TrackBuilder.cc.

30 {
33
34  const auto& trackReps = recoTrack.getRepresentations();
35  B2DEBUG(100, trackReps.size() << " track representations available.");
36  Track newTrack(recoTrack.getQualityIndicator());
37
38  bool repAlreadySet = false;
39  unsigned int repIDPlusOne = 0;
40  for (const auto& trackRep : trackReps) {
41  repIDPlusOne++;
42
43  // Check if the fitted particle type is in our charged stable set.
44  const Const::ParticleType particleType(std::abs(trackRep->getPDG()));
45  if (not Const::chargedStableSet.contains(particleType)) {
46  B2DEBUG(100, "Track fitted with hypothesis that is not a ChargedStable (PDG code = " << particleType.getPDGCode() << ")");
47  continue;
48  }
49
50  // Check if the fit worked.
51  if (not recoTrack.wasFitSuccessful(trackRep)) {
52  B2DEBUG(100, "The fit with the given track representation (" << std::abs(trackRep->getPDG()) <<
53  ") was not successful. Skipping ...");
54  continue;
55  }
56
57  if (not repAlreadySet) {
58  RecoTrackGenfitAccess::getGenfitTrack(recoTrack).setCardinalRep(repIDPlusOne - 1);
59  repAlreadySet = true;
60  }
61
62  // Extrapolate the tracks to the perigee.
64  try {
65  if (useClosestHitToIP) {
66  msop = recoTrack.getMeasuredStateOnPlaneClosestTo(TVector3(0, 0, 0), trackRep);
67  } else {
68  msop = recoTrack.getMeasuredStateOnPlaneFromFirstHit(trackRep);
69  }
70  } catch (genfit::Exception& exception) {
71  B2WARNING(exception.what());
72  continue;
73  }
74
75  genfit::MeasuredStateOnPlane extrapolatedMSoP = msop;
76  try {
77  extrapolatedMSoP.extrapolateToLine(m_beamSpot, m_beamAxis);
78  } catch (...) {
79  B2WARNING("Could not extrapolate the fit result for pdg " << particleType.getPDGCode() <<
80  " to the perigee point. Why, I don't know.");
81  continue;
82  }
83
84  // Build track fit result.
85
86  TVector3 poca(0., 0., 0.);
87  TVector3 dirInPoca(0., 0., 0.);
88  TMatrixDSym cov(6);
89  extrapolatedMSoP.getPosMomCov(poca, dirInPoca, cov);
90  B2DEBUG(149, "Point of closest approach: " << poca.x() << " " << poca.y() << " " << poca.z());
91  B2DEBUG(149, "Track direction in POCA: " << dirInPoca.x() << " " << dirInPoca.y() << " " << dirInPoca.z());
92
93  const int charge = recoTrack.getTrackFitStatus(trackRep)->getCharge();
94  const double pValue = recoTrack.getTrackFitStatus(trackRep)->getPVal();
95  const int nDF = recoTrack.getTrackFitStatus(trackRep)->getNdf();
96
97  double Bx, By, Bz; // In cgs units
98  if (useBFieldAtHit) {
99  const TVector3& hitPosition = msop.getPos();
100  genfit::FieldManager::getInstance()->getFieldVal(hitPosition.X(), hitPosition.Y(), hitPosition.Z(), Bx, By, Bz);
101  } else {
102  genfit::FieldManager::getInstance()->getFieldVal(poca.X(), poca.Y(), poca.Z(), Bx, By, Bz);
103  }
104  Bz = Bz / 10.; // In SI-Units
105
106  const uint64_t hitPatternCDCInitializer = getHitPatternCDCInitializer(recoTrack);
107  const uint32_t hitPatternVXDInitializer = getHitPatternVXDInitializer(recoTrack);
108
109  const auto newTrackFitResult = trackFitResults.appendNew(
110  poca, dirInPoca, cov, charge, particleType, pValue, Bz,
111  hitPatternCDCInitializer, hitPatternVXDInitializer, nDF
112  );
113
114  const int newTrackFitResultArrayIndex = newTrackFitResult->getArrayIndex();
115  newTrack.setTrackFitResultIndex(particleType, newTrackFitResultArrayIndex);
116  }
117
118  B2DEBUG(100, "Number of fitted hypothesis = " << newTrack.getNumberOfFittedHypotheses());
119  if (newTrack.getNumberOfFittedHypotheses() > 0) {
120  Track* addedTrack = tracks.appendNew(newTrack);
121  addedTrack->addRelationTo(&recoTrack);
122  const auto& mcParticleWithWeight = recoTrack.getRelatedToWithWeight<MCParticle>(m_mcParticleColName);
123  const MCParticle* mcParticle = mcParticleWithWeight.first;
124  if (mcParticle) {
125  B2DEBUG(200, "Relation to MCParticle set.");
126  addedTrack->addRelationTo(mcParticle, mcParticleWithWeight.second);
127  } else {
128  B2DEBUG(200, "Relation to MCParticle not set. No related MCParticle to RecoTrack.");
129  }
130  return true;
131  } else {
132  B2DEBUG(200, "Relation to MCParticle not set. No related MCParticle to RecoTrack.");
133  }
134  return true;
135 }
