Generates axial tracks from hit using the special leaf processing inspired by the legendre algorithm. More...

Inheritance diagram for AxialTrackCreatorHitHough:

[legend]

Collaboration diagram for AxialTrackCreatorHitHough:

[legend]

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.

using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
std::string	getDescription () final
	Short description of the findlet.

void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) final
	Expose the parameters to a module.

void	initialize () final
	Initialize the findlet before event processing.

void	apply (const std::vector< const CDCWireHit * > &axialWireHits, std::vector< CDCTrack > &tracks) final
	Generates the tracks from the given segments into the output argument.

void	terminate () final
	Cleanup the findlet after event processing.

virtual void	exposeParameters (ModuleParamList *moduleParamList __attribute__((unused)), const std::string &prefix __attribute__((unused)))
	Forward prefixed parameters of this findlet to the module parameter list.

virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.

void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.

void	beginEvent () override
	Receive and dispatch signal for the start of a new event.

void	endRun () override
	Receive and dispatch signal for the end of the run.

Static Public Member Functions
static std::vector< float >	getDefaultCurvBounds (std::array< float, 2 > curvSpan, int granularityLevel)
	Get a series of parameters to be set for each pass over the rough hough space.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.

int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = Findlet< const CDCWireHit *const, CDCTrack >
	Type of the base class.

using	SimpleRLTaggedWireHitPhi0CurvHough = SimpleRLTaggedWireHitHoughTree< InPhi0CurvBox, c_phi0Divisions, c_curvDivisions >
	Type of the hough space tree search.

Private Attributes
const double	m_curlCurv = 0.018
	Curvature below which particles from IP do not leave the CDC.

int	m_param_granularityLevel = 12
	Parameter: Level of divisions in the hough space.

int	m_param_sectorLevelSkip = 2
	Parameter: Number of levels to be skipped in the hough space on the first level to form sectors.

std::vector< float >	m_param_curvBounds {{ -0.02, 0.14}}
	Parameter: hough bounds.

int	m_param_discretePhi0Width = 19
	Parameter: Width of the phi0 bins at the highest level of the hough space.

int	m_param_discretePhi0Overlap = 5
	Parameter: Overlap of the phi0 bins at the highest level of the hough space.

int	m_param_discreteCurvWidth = 1
	Parameter: Width of the curvature bins at the highest level of the hough space.

int	m_param_discreteCurvOverlap = -1
	Parameter: Overlap of the curvature bins at the highest level of the hough space.

std::vector< ParameterVariantMap >	m_param_relaxationSchedule
	Parameter: Relaxation schedule for the leaf processor in the hough tree.

std::unique_ptr< SimpleRLTaggedWireHitPhi0CurvHough >	m_houghTree
	The hough space tree search.

std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.

bool	m_initialized = false
	Flag to keep track whether initialization happend before.

bool	m_terminated = false
	Flag to keep track whether termination happend before.

std::string	m_initializedAs
	Name of the type during initialisation.

Static Private Attributes
static const int	c_phi0Divisions = 2
	Fixed parameter: Number of divisions in the phi0 direction.

static const int	c_curvDivisions = 2
	Fixed parameter: Number of divisions in the curv direction.

Detailed Description

Generates axial tracks from hit using the special leaf processing inspired by the legendre algorithm.

The documentation for this class was generated from the following files:
