Implementation of a styling composed from several predefined mappings chooseable by their name. More...

#include <Styling.h>

Inheritance diagram for ChooseableStyling< AObject >:

Collaboration diagram for ChooseableStyling< AObject >:

[legend]

Public Types
using	ObjectMapping = Mapping< AObject >
	Mapping for the object type.

Public Member Functions
AttributeMap	map (int index, AObject &object) override
	Create a map of attributes from the stored attribute maps.

std::string	info () override
	Returns informal string about the currently set mappings.

virtual std::unique_ptr< ObjectMapping >	createMapping (const std::string &mappingName)
	Create a mapping for the object from a name. More...

void	set (const std::string &key, std::unique_ptr< ObjectMapping > mapping)
	Sets the given attribute to the attribute mapping.

void	set (const std::string &key, const std::string &mappingName)
	Sets the given attribute to the fixed value.

void	setStroke (const std::string &mappingName)
	Legacy method to set the mapping on how to match a object to the stroke color. More...

void	setStrokeWidth (const std::string &mappingName)
	Legacy method to set the mapping on how to match a object to the stroke width. More...

virtual AttributeMap	map (int index __attribute__((unused)), AObject &object __attribute__((unused)))
	Maps the object at the given index to attribute values.

Protected Attributes
std::map< std::string, std::unique_ptr< ObjectMapping > >	m_mappingsByKey
	Map of attribute keys to mappings to be used.

Detailed Description

Implementation of a styling composed from several predefined mappings chooseable by their name.

Definition at line 109 of file Styling.h.

Member Function Documentation

virtual std::unique_ptr<ObjectMapping> createMapping ( const std::string & mappingName )

inlinevirtual

Create a mapping for the object from a name.

Can be overriden by the subclass to introduce names with specific meanings. The default is to use the name as a fixed attribute value.

Definition at line 146 of file Styling.h.

void setStroke ( const std::string & mappingName )

inline

Legacy method to set the mapping on how to match a object to the stroke color.

Parameters

mappingName The Name of the Mapping to be used. The translation from name to Mapping class must be defined in createMapping.

Definition at line 173 of file Styling.h.

void setStrokeWidth ( const std::string & mappingName )

inline

Legacy method to set the mapping on how to match a object to the stroke width.

Parameters

mappingName The Name of the Mapping to be used. The translation from name to Mapping class must be defined in createMapping.

Definition at line 183 of file Styling.h.

The documentation for this class was generated from the following file:
