StereoHitTrackAdder Class Reference

Class to add the matched hits to the track and set the taken flag correctly. More...

#include <StereoHitTrackAdder.h>

Inheritance diagram for StereoHitTrackAdder:

Collaboration diagram for StereoHitTrackAdder:

Public Types
using	WeightedRelationItem = WeightedRelation< CDCTrack, const CDCRLWireHit >
	Shortcut class name for a weighted relation between a collector item and a collection item.
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
void	apply (std::vector< WeightedRelationItem > &weightedRelations) override
	Main function to do the adding. Override the add function below in your derived class.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	exposeParameters (ModuleParamList *moduleParamList __attribute__((unused)), const std::string &prefix __attribute__((unused)))
	Forward prefixed parameters of this findlet to the module parameter list.
void	initialize () override
	Receive and dispatch signal before the start of the event processing.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
virtual void	add (CDCTrack &collectorItem __attribute__((unused)), const CDCRLWireHit &collectionItem __attribute__((unused)), Weight weight __attribute__((unused)))
	Override this function to implement how a collection item should be matched to a collector item.
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = ProcessingSignalListener
	Type of the base class.

Private Member Functions
void	add (CDCTrack &track, const CDCRLWireHit &hit, Weight weight) override
	Add the matched hits to the track and set the taken flag correctly. More...

Private Attributes
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

Class to add the matched hits to the track and set the taken flag correctly.

Definition at line 31 of file StereoHitTrackAdder.h.

Member Function Documentation

add()

void add ( CDCTrack &  track, const CDCRLWireHit &  hit, Weight  weight  )

overrideprivate

Add the matched hits to the track and set the taken flag correctly.

We ignore the weight completely here.

Definition at line 13 of file StereoHitTrackAdder.cc.

{
  const CDCTrajectory2D& trajectory2D = track.getStartTrajectory3D().getTrajectory2D();
  const double radius = trajectory2D.getGlobalCircle().absRadius();
  const bool isCurler = trajectory2D.isCurler();

  Vector3D recoPos3D = hit.reconstruct3D(trajectory2D);
  double arcLength2D = trajectory2D.calcArcLength2D(recoPos3D.xy());
  if (isCurler and arcLength2D < 0) {
    arcLength2D += 2 * TMath::Pi() * radius;
  }

  B2ASSERT("A stereo hit should not be added twice!", not hit.getWireHit().getAutomatonCell().hasTakenFlag());
  track.emplace_back(hit, recoPos3D, arcLength2D);
  hit.getWireHit().getAutomatonCell().setTakenFlag();
}

---

The documentation for this class was generated from the following files:

• tracking/trackFindingCDC/collectors/adders/include/StereoHitTrackAdder.h
• tracking/trackFindingCDC/collectors/adders/src/StereoHitTrackAdder.cc
