Belle II Software  release-05-02-19
XHitFilterFactory< PointType > Class Template Reference

The factory serves as an interface between all x-hit-filters and a user only knowing their name (in string), but not their type. More...

#include <XHitFilterFactory.h>

Collaboration diagram for XHitFilterFactory< PointType >:

Public Types

typedef FilterID::filterTypes XHitFilterType
 constructor where nothing has been passed More...

using TwoHitFunction = typename std::function< double(const PointType &, const PointType &)>
 typedef for more readable function-type - to be used for 2-hit-selectionVariables.

using ThreeHitFunction = typename std::function< double(const PointType &, const PointType &, const PointType &)>
 typedef for more readable function-type - to be used for 3-hit-selectionVariables.

using FourHitFunction = typename std::function< double(const PointType &, const PointType &, const PointType &, const PointType &)>
 typedef for more readable function-type - to be used for 4-hit-selectionVariables.


Public Member Functions

 XHitFilterFactory (double x=0, double y=0, double z=0, double mField=1.5)
 constructor where virtual IP has been passed

TwoHitFunction get2HitInterface (std::string variableName)
 For given name of a variableType a function for the corresponding Filter is returned.

TwoHitFunction get2HitInterface (XHitFilterType variableType)
 For given name of a variableType a function for the corresponding Filter is returned. More...

ThreeHitFunction get3HitInterface (std::string variableName)
 For given name of a variableType a function for the corresponding Filter is returned.

ThreeHitFunction get3HitInterface (XHitFilterType variableType)
 For given name of a variableType a function for the corresponding Filter is returned. More...

FourHitFunction get4HitInterface (std::string variableName)
 For given name of a variableType a function for the corresponding Filter is returned.

FourHitFunction get4HitInterface (XHitFilterType variableType)
 For given name of a variableType a function for the corresponding Filter is returned. More...


Protected Attributes

TwoHitFilters m_twoHit
 contains all 2-hit-filters.

ThreeHitFilters m_threeHit
 contains all 3-hit-filters.

FourHitFilters m_fourHit
 contains all 4-hit-filters.

TVector3 m_virtualIP
 contains global coordinates of virtual interaction point.


Detailed Description

template<class PointType>
class Belle2::XHitFilterFactory< PointType >

The factory serves as an interface between all x-hit-filters and a user only knowing their name (in string), but not their type.

Definition at line 46 of file XHitFilterFactory.h.

Member Typedef Documentation

◆ XHitFilterType

constructor where nothing has been passed

shortCut for better readability.

Definition at line 65 of file XHitFilterFactory.h.

Member Function Documentation

◆ get2HitInterface()

TwoHitFunction get2HitInterface ( XHitFilterType  variableType)
inline

For given name of a variableType a function for the corresponding Filter is returned.

2-hit:

2+1-hit:

Definition at line 88 of file XHitFilterFactory.h.

90  {
91  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
92  prepareStuff(outerHit, innerHit);
93  return m_twoHit.calcDist3D();
94  };
95  }
96
97  if (variableType == FilterID::distanceXY) {
98  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
99  prepareStuff(outerHit, innerHit);
100  return m_twoHit.calcDistXY();
101  };
102  }
103
104  if (variableType == FilterID::distanceZ) {
105  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
106  prepareStuff(outerHit, innerHit);
107  return m_twoHit.calcDistZ();
108  };
109  }
110
111  if (variableType == FilterID::slopeRZ) {
112  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
113  prepareStuff(outerHit, innerHit);
114  return m_twoHit.calcSlopeRZ();
115  };
116  }
117
118  if (variableType == FilterID::normedDistance3D) {
119  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
120  prepareStuff(outerHit, innerHit);
121  return m_twoHit.calcNormedDist3D();
122  };
123  }
124
125  // prepare stuff for 2+1-hit-filters
126  auto prepareStuffHiOc = [ = ](const PointType & outerHit, const PointType & innerHit) -> void {
127  TVector3 tOuterHit(outerHit.X(), outerHit.Y(), outerHit.Z());
128  TVector3 tInnerHit(innerHit.X(), innerHit.Y(), innerHit.Z());
129  m_threeHit.resetValues(tOuterHit, tInnerHit, m_virtualIP);
130  };
131
132
134  if (variableType == FilterID::anglesHighOccupancy3D) {
135  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
136  prepareStuffHiOc(outerHit, innerHit);
137  return m_threeHit.calcAngle3D();
138  };
139  }
140
141  if (variableType == FilterID::anglesHighOccupancyXY) {
142  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
143  prepareStuffHiOc(outerHit, innerHit);
144  return m_threeHit.calcAngleXY();
145  };
146  }
147
148  if (variableType == FilterID::anglesHighOccupancyRZ) {
149  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
150  prepareStuffHiOc(outerHit, innerHit);
151  return m_threeHit.calcAngleRZ();
152  };
153  }
154
155  if (variableType == FilterID::distanceHighOccupancy2IP) {
156  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
157  prepareStuffHiOc(outerHit, innerHit);
158  return m_threeHit.calcCircleDist2IP();
159  };
160  }
161
162  if (variableType == FilterID::deltaSlopeHighOccupancyRZ) {
163  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
164  prepareStuffHiOc(outerHit, innerHit);
165  return m_threeHit.calcDeltaSlopeRZ();
166  };
167  }
168
169  if (variableType == FilterID::pTHighOccupancy) {
170  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
171  prepareStuffHiOc(outerHit, innerHit);
172  return m_threeHit.calcPt();
173  };
174  }
175
176  if (variableType == FilterID::helixParameterHighOccupancyFit) {
177  return [ = ](const PointType & outerHit, const PointType & innerHit) -> double {
178  prepareStuffHiOc(outerHit, innerHit);
180  };
181  }
182
183
184
185  B2ERROR(" XHitFilterAdapter-2Hit: given name (raw/full): " << variableType <<
186  "/" << FilterID::getTypeName(variableType) <<
187  " is not known, returning dummy function with 0.0 as a result instead!");
188
189  return [&](const PointType&, const PointType&) -> double { return 0.0; };
190  }
191
192
193
195  ThreeHitFunction get3HitInterface(std::string variableName)
196  {
197  XHitFilterType varType = FilterID::getTypeEnum(variableName);
198  return get3HitInterface(varType);

◆ get3HitInterface()

ThreeHitFunction get3HitInterface ( XHitFilterType  variableType)
inline

For given name of a variableType a function for the corresponding Filter is returned.

3-hit:

3+1hit:

Definition at line 212 of file XHitFilterFactory.h.

◆ get4HitInterface()

FourHitFunction get4HitInterface ( XHitFilterType  variableType)
inline

For given name of a variableType a function for the corresponding Filter is returned.

4-hit:

Definition at line 331 of file XHitFilterFactory.h.


The documentation for this class was generated from the following file:
