SensitiveDetector Class Reference

Sensitive Detector implementation of the HE3TUBE detector. More...

#include <SensitiveDetector.h>

Inheritance diagram for SensitiveDetector:
Collaboration diagram for SensitiveDetector:

Public Member Functions

 SensitiveDetector ()
 Constructor.

int saveG4TrackInfo (int trackID, int PDG, float Mass, float Energy, float vtx[3], float mom[3])
 Save saveG4TrackInfo into datastore.


Static Public Member Functions

static const std::map< std::string, RelationArray::EConsolidationAction > & getMCParticleRelations ()
 Return a list of all registered Relations with MCParticles.

static void setActive (bool activeStatus)
 Enable/Disable all Sensitive Detectors. More...

static void registerMCParticleRelation (const std::string &name, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
 Register an relation involving MCParticles. More...

static void registerMCParticleRelation (const RelationArray &relation, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
 Overload to make it easer to register MCParticle relations. More...


Protected Member Functions

bool step (G4Step *step, G4TouchableHistory *) override
 Step processing method. More...


Protected Attributes

int m_trackID


Private Member Functions

virtual bool ProcessHits (G4Step *aStep, G4TouchableHistory *aROhist)
 Check if recording hits is enabled and if so call step() and set the correct MCParticle flag. More...


Private Attributes

Const::EDetector m_subdetector
 Subdetector the class belongs to.


Static Private Attributes

static std::map< std::string, RelationArray::EConsolidationActions_mcRelations
 Static set holding all relations which have to be updated at the end of the Event.

static bool s_active
 Static bool which indicates wether recording of hits is enabled.


Detailed Description

Sensitive Detector implementation of the HE3TUBE detector.

Definition at line 32 of file SensitiveDetector.h.

Member Function Documentation

◆ ProcessHits()

bool ProcessHits ( G4Step *  aStep,
G4TouchableHistory *  aROhist
)
inlineprivatevirtualinherited

Check if recording hits is enabled and if so call step() and set the correct MCParticle flag.

Called by Geant4 for each step inside the sensitive volumes attached

Definition at line 98 of file SensitiveDetectorBase.h.

◆ registerMCParticleRelation() [1/2]

static void registerMCParticleRelation ( const RelationArray relation,
RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight
)
inlinestaticinherited

Overload to make it easer to register MCParticle relations.

Parameters
relationRelationArray to register
ignoreAction

Definition at line 70 of file SensitiveDetectorBase.h.

◆ registerMCParticleRelation() [2/2]

void registerMCParticleRelation ( const std::string &  name,
RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight
)
staticinherited

Register an relation involving MCParticles.

All Relations which point from an MCParticle to something have to be registered with addMCParticleRelation() because the index of the MCParticles might change at the end of the event. During simulation, the TrackID should be used as index of the MCParticle

Parameters
nameName of the relation to register
ignoreAction

Definition at line 24 of file SensitiveDetectorBase.cc.

◆ setActive()

static void setActive ( bool  activeStatus)
inlinestaticinherited

Enable/Disable all Sensitive Detectors.

By default, all sensitive detectors won't create hits to make it possible to use the Geant4 Navigator for non-simulation purposes. Only during simulation the sensitive detectors will be enabled to record hits

Parameters
activeStatusbool to indicate wether hits should be recorded

Definition at line 54 of file SensitiveDetectorBase.h.

◆ step()

bool step ( G4Step *  step,
G4TouchableHistory *
)
overrideprotectedvirtual

Step processing method.

Parameters
stepthe G4Step with the current step information
Returns
true if a Hit has been created, false if the hit was ignored

Implements SensitiveDetectorBase.

Definition at line 61 of file SensitiveDetector.cc.

90  {
91  const G4VProcess* creator = step->GetTrack()->GetCreatorProcess();
92  CPName = creator->GetProcessName();
93  if (CPName.contains("Neutron")) neuProc = true;
94  }
95
96  if (m_trackID != track.GetTrackID()) {
97  //TrackID changed, store track informations
98  m_trackID = track.GetTrackID();
99  }
100  //Save Hit if track leaves volume or is killed
101  if (track.GetNextVolume() != track.GetVolume() || track.GetTrackStatus() >= fStopAndKill) {
102  auto& mcparticle = Simulation::TrackInfo::getInfo(track);
103  int PDG = mcparticle.getPDG();
104  float Mass = mcparticle.getMass();
105  float Energy = mcparticle.getEnergy();
106  float vtx[3];
107  vtx[0] = mcparticle.getProductionVertex().X();
108  vtx[1] = mcparticle.getProductionVertex().Y();
109  vtx[2] = mcparticle.getProductionVertex().Z();
110  float mom[3];
111  mom[0] = mcparticle.getMomentum().X();
112  mom[1] = mcparticle.getMomentum().Y();
113  mom[2] = mcparticle.getMomentum().Z();
114  saveG4TrackInfo(m_trackID, PDG, Mass, Energy, vtx, mom);
115  //Reset TrackID
116  m_trackID = 0;
117  }
118
119  StoreArray<He3tubeSimHit> He3tubeHits;
120  He3tubeSimHit* hit = He3tubeHits.appendNew(
121  depEnergy,
122  nielEnergy,
123  tkPDG,
124  tkKEnergy,
125  detNb,
126  GlTime,
127  tkPos,
128  tkMom,
129  tkMomDir,
130  neuProc
131  );
132
133  //Add Relation between SimHit and MCParticle with a weight of 1. Since
134  //the MCParticle index is not yet defined we use the trackID from Geant4
135  relMCSimHit.add(trackID, hit->getArrayIndex(), 1.0);
136
137  return true;
138  }
139
141  int trackID,
142  int PDG,
143  float Mass,
144  float Energy,
145  float vtx[3],
146  float mom[3]
