SensitiveDetector Class Reference

Sensitive Detector implementation of the PLUME detector. More...

#include <SensitiveDetector.h>

Inheritance diagram for SensitiveDetector:
Collaboration diagram for SensitiveDetector:

Public Member Functions

 SensitiveDetector ()
 Constructor.

 ~SensitiveDetector ()
 Destructor.


Static Public Member Functions

static const std::map< std::string, RelationArray::EConsolidationAction > & getMCParticleRelations ()
 Return a list of all registered Relations with MCParticles.

static void setActive (bool activeStatus)
 Enable/Disable all Sensitive Detectors. More...

static void registerMCParticleRelation (const std::string &name, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
 Register an relation involving MCParticles. More...

static void registerMCParticleRelation (const RelationArray &relation, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
 Overload to make it easer to register MCParticle relations. More...


Protected Member Functions

bool step (G4Step *step, G4TouchableHistory *) override
 Step processing method. More...


Private Member Functions

virtual bool ProcessHits (G4Step *aStep, G4TouchableHistory *aROhist)
 Check if recording hits is enabled and if so call step() and set the correct MCParticle flag. More...


Private Attributes

int current_pdgID
 particle PDG id

int current_sensorID
 sensor ID

int current_trackID
 track ID

float current_trackVertex_x
 track production vertex x coordinates in G4 ref

float current_trackVertex_y
 track production vertex y coordinates in G4 ref

float current_trackVertex_z
 track production vertex z coordinates in G4 ref

float current_energyDep
 deposited energy in MeV

float current_nielDep
 non ionizing deposited energy

float current_posIN_x
 incoming track position x in G4 ref, in mm

float current_posIN_y
 incoming track position y in G4 ref, in mm

float current_posIN_z
 incoming track position z in G4 ref, in mm

float current_posIN_u
 incoming track position u in sensor ref, in mm

float current_posIN_v
 incoming track position v in sensor ref, in mm

float current_posIN_w
 incoming track position w in sensor ref, in mm

float current_posOUT_u
 outcoming track position u in sensor ref, in mm

float current_posOUT_v
 outcoming track position v in sensor ref, in mm

float current_posOUT_w
 outcoming track position w in sensor ref, in mm

float current_posOUT_x
 outcoming track position x in sensor ref, in mm

float current_posOUT_y
 outcoming track position y in sensor ref, in mm

float current_posOUT_z
 outcoming track position z in sensor ref, in mm

float current_momentum_x
 incoming track momentum, x coordinates in G4 ref, in GeV

float current_momentum_y
 incoming track momentum, y coordinates in G4 ref, in GeV

float current_momentum_z
 incoming track momentum, z coordinates in G4 ref, in GeV

float current_thetaAngle
 local (sensor ref) theta angle, out of sensor plane, in degree

float current_phiAngle
 local (sensor ref) phi angle, in sensor plane, in degree

float current_globalTime
 global time

Const::EDetector m_subdetector
 Subdetector the class belongs to.


Static Private Attributes

static std::map< std::string, RelationArray::EConsolidationActions_mcRelations
 Static set holding all relations which have to be updated at the end of the Event.

static bool s_active
 Static bool which indicates wether recording of hits is enabled.


Detailed Description

Sensitive Detector implementation of the PLUME detector.

Definition at line 32 of file SensitiveDetector.h.

Member Function Documentation

◆ ProcessHits()

bool ProcessHits ( G4Step *  aStep,
G4TouchableHistory *  aROhist
)
inlineprivatevirtualinherited

Check if recording hits is enabled and if so call step() and set the correct MCParticle flag.

Called by Geant4 for each step inside the sensitive volumes attached

Definition at line 98 of file SensitiveDetectorBase.h.

◆ registerMCParticleRelation() [1/2]

static void registerMCParticleRelation ( const RelationArray relation,
RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight
)
inlinestaticinherited

Overload to make it easer to register MCParticle relations.

Parameters
relationRelationArray to register
ignoreAction

Definition at line 70 of file SensitiveDetectorBase.h.

◆ registerMCParticleRelation() [2/2]

void registerMCParticleRelation ( const std::string &  name,
RelationArray::EConsolidationAction  ignoreAction = RelationArray::c_negativeWeight
)
staticinherited

Register an relation involving MCParticles.

All Relations which point from an MCParticle to something have to be registered with addMCParticleRelation() because the index of the MCParticles might change at the end of the event. During simulation, the TrackID should be used as index of the MCParticle

Parameters
nameName of the relation to register
ignoreAction

Definition at line 24 of file SensitiveDetectorBase.cc.

◆ setActive()

static void setActive ( bool  activeStatus)
inlinestaticinherited

Enable/Disable all Sensitive Detectors.

By default, all sensitive detectors won't create hits to make it possible to use the Geant4 Navigator for non-simulation purposes. Only during simulation the sensitive detectors will be enabled to record hits

Parameters
activeStatusbool to indicate wether hits should be recorded

Definition at line 54 of file SensitiveDetectorBase.h.

◆ step()

bool step ( G4Step *  step,
G4TouchableHistory *
)
overrideprotectedvirtual

Step processing method.

Parameters
stepthe G4Step with the current step information
Returns
true if a Hit has been created, false if the hit was ignored

Implements SensitiveDetectorBase.

Definition at line 94 of file SensitiveDetector.cc.

95  {
96
97  //Get track information, and pre- and post-step
98  const G4Track& track = *step->GetTrack();
99  const G4StepPoint& preStepPoint = *step->GetPreStepPoint();
100  const G4StepPoint& postStepPoint = *step->GetPostStepPoint();
101
102
103  // If new track, store general information from this first step
104  if (current_trackID != track.GetTrackID()) { // if new track
105  current_trackID = track.GetTrackID();
106  current_trackVertex_x = track.GetVertexPosition().x();
107  current_trackVertex_y = track.GetVertexPosition().y();
108  current_trackVertex_z = track.GetVertexPosition().z();
109  current_pdgID = track.GetDefinition()->GetPDGEncoding();
110  current_sensorID = preStepPoint.GetTouchableHandle()->GetReplicaNumber(1);
111
112  // since this is first step in volume store track incidence and momentum and reset energy loss
113  G4ThreeVector preStepPointPosition = preStepPoint.GetPosition();
114  G4ThreeVector trackMomentum = track.GetMomentum();
115  current_energyDep = 0.;
116  current_nielDep = 0.;
117
118  current_posIN_x = preStepPointPosition.x();
119  current_posIN_y = preStepPointPosition.y();
120  current_posIN_z = preStepPointPosition.z();
121  current_momentum_x = trackMomentum.x();
122  current_momentum_y = trackMomentum.y();
123  current_momentum_z = trackMomentum.z();
124
125  // We want the track angles of incidence on the local volume and the local position
126  G4TouchableHandle theTouchable = preStepPoint.GetTouchableHandle();
127  G4ThreeVector worldDirection = preStepPoint.GetMomentumDirection();
128  G4ThreeVector localDirection = theTouchable->GetHistory()->GetTopTransform().TransformAxis(worldDirection);
129
130  if (localDirection.z() < 0.) {
131  current_thetaAngle = M_PI - acos(-1. * localDirection.z());
132  } else {
133  current_thetaAngle = acos(localDirection.z());
134  }
135
136
137  if (localDirection.x() < 0. && localDirection.y() > 0.) {
138  current_phiAngle = atan(-1. * localDirection.x() / localDirection.y());
139  } else if (localDirection.x() < 0. && localDirection.y() < 0.) {
140  current_phiAngle = M_PI - atan(localDirection.x() / localDirection.y());
141  } else if (localDirection.x() > 0. && localDirection.y() < 0.) {
142  current_phiAngle = M_PI + atan(-1. * localDirection.x() / localDirection.y());
143  } else if (localDirection.x() > 0. && localDirection.y() > 0.) {
144  current_phiAngle = 2. * M_PI - atan(localDirection.x() / localDirection.y());
145  } else if (localDirection.x() < 0. && localDirection.y() == 0.) {
146  current_phiAngle = M_PI / 2.;
147  } else if (localDirection.x() > 0. && localDirection.y() == 0.) {
148  current_phiAngle = 3.* M_PI / 2.;
149  } else if (localDirection.x() == 0. && localDirection.y() > 0.) {
150  current_phiAngle = 0.;
151  } else if (localDirection.x() == 0. && localDirection.y() < 0.) {
152  current_phiAngle = M_PI;
153  }
154
155  G4ThreeVector localINPosition = theTouchable->GetHistory()->GetTopTransform().TransformPoint(preStepPointPosition);
156  current_posIN_u = localINPosition.y();
157  current_posIN_v = - localINPosition.x();
158  current_posIN_w = localINPosition.z();
159
160  current_globalTime = step->GetPreStepPoint()->GetGlobalTime();
161
162  } // end if new track
163
164  // Update information at each step
165  current_energyDep += step->GetTotalEnergyDeposit();
166  current_nielDep += step->GetNonIonizingEnergyDeposit();
167
168  // If track leaves volume or is killed, store final step info and save simHit
169  if (track.GetNextVolume() != track.GetVolume() || track.GetTrackStatus() >= fStopAndKill) { // if last step
170
171  G4ThreeVector postStepPointPosition = postStepPoint.GetPosition();
172
173  current_posOUT_x = postStepPointPosition.x();
174  current_posOUT_y = postStepPointPosition.y();
175  current_posOUT_z = postStepPointPosition.z();
176  G4ThreeVector localOUTPosition = preStepPoint.GetTouchableHandle()->GetHistory()->GetTopTransform().TransformPoint(
177  postStepPointPosition);
178  current_posOUT_u = localOUTPosition.y();
179  current_posOUT_v = - localOUTPosition.x();
180  current_posOUT_w = localOUTPosition.z();
181
182  //Get the datastore arrays
183  StoreArray<MCParticle> mcParticles;
184  StoreArray<PlumeSimHit> simHits;
185
186  if (current_energyDep > CLHEP::eV) {
187
188  RelationArray relMCSimHit(mcParticles, simHits);
189  PlumeSimHit* hit = simHits.appendNew(
193  current_trackVertex_x / CLHEP::mm,
194  current_trackVertex_y / CLHEP::mm,
195  current_trackVertex_z / CLHEP::mm,
196  current_energyDep / CLHEP::MeV,
197  current_nielDep / CLHEP::MeV,
198  current_posIN_x / CLHEP::mm,
199  current_posIN_y / CLHEP::mm,
200  current_posIN_z / CLHEP::mm,
201  current_posIN_u / CLHEP::mm,
202  current_posIN_v / CLHEP::mm,
203  current_posIN_w / CLHEP::mm,
204  current_posOUT_u / CLHEP::mm,
205  current_posOUT_v / CLHEP::mm,
206  current_posOUT_w / CLHEP::mm,
207  current_momentum_x / CLHEP::GeV,
208  current_momentum_y / CLHEP::GeV,
209  current_momentum_z / CLHEP::GeV,
210  current_thetaAngle / CLHEP::degree,
211  current_phiAngle / CLHEP::degree,
212  current_globalTime / CLHEP::nanosecond
213  );
214
215  //Add Relation between SimHit and MCParticle with a weight of 1. Since
216  //the MCParticle index is not yet defined we use the trackID from Geant4
217  relMCSimHit.add(current_trackID, hit->getArrayIndex(), 1.0);
218  }
219
220  //Reset TrackID
221  current_trackID = 0;
222
223  } // end if last
224
225
226  //Ignore everything below 1eV
227  if (current_energyDep < CLHEP::eV) return false;
228
229
230  return true;
231  }

The documentation for this class was generated from the following files:
Belle2::plume::SensitiveDetector::current_trackID
int current_trackID
track ID
Definition: SensitiveDetector.h:52
Belle2::plume::SensitiveDetector::current_thetaAngle
float current_thetaAngle
local (sensor ref) theta angle, out of sensor plane, in degree
Definition: SensitiveDetector.h:94
Belle2::plume::SensitiveDetector::current_posOUT_x
float current_posOUT_x
outcoming track position x in sensor ref, in mm
Definition: SensitiveDetector.h:82
Belle2::plume::SensitiveDetector::current_posIN_v
float current_posIN_v
incoming track position v in sensor ref, in mm
Definition: SensitiveDetector.h:72
Belle2::plume::SensitiveDetector::current_momentum_y
float current_momentum_y
incoming track momentum, y coordinates in G4 ref, in GeV
Definition: SensitiveDetector.h:90
Belle2::plume::SensitiveDetector::current_nielDep
float current_nielDep
non ionizing deposited energy
Definition: SensitiveDetector.h:62
Belle2::plume::SensitiveDetector::current_posOUT_z
float current_posOUT_z
outcoming track position z in sensor ref, in mm
Definition: SensitiveDetector.h:86
Belle2::plume::SensitiveDetector::current_posOUT_v
float current_posOUT_v
outcoming track position v in sensor ref, in mm
Definition: SensitiveDetector.h:78
Belle2::plume::SensitiveDetector::current_posOUT_y
float current_posOUT_y
outcoming track position y in sensor ref, in mm
Definition: SensitiveDetector.h:84
Belle2::plume::SensitiveDetector::current_trackVertex_y
float current_trackVertex_y
track production vertex y coordinates in G4 ref
Definition: SensitiveDetector.h:56
Belle2::plume::SensitiveDetector::current_trackVertex_x
float current_trackVertex_x
track production vertex x coordinates in G4 ref
Definition: SensitiveDetector.h:54
Belle2::plume::SensitiveDetector::current_energyDep
float current_energyDep
deposited energy in MeV
Definition: SensitiveDetector.h:60
Belle2::plume::SensitiveDetector::current_momentum_z
float current_momentum_z
incoming track momentum, z coordinates in G4 ref, in GeV
Definition: SensitiveDetector.h:92
Belle2::plume::SensitiveDetector::current_sensorID
int current_sensorID
sensor ID
Definition: SensitiveDetector.h:50
Belle2::plume::SensitiveDetector::current_posOUT_u
float current_posOUT_u
outcoming track position u in sensor ref, in mm
Definition: SensitiveDetector.h:76
Belle2::plume::SensitiveDetector::current_pdgID
int current_pdgID
particle PDG id
Definition: SensitiveDetector.h:48
Belle2::plume::SensitiveDetector::current_momentum_x
float current_momentum_x
incoming track momentum, x coordinates in G4 ref, in GeV
Definition: SensitiveDetector.h:88
Belle2::plume::SensitiveDetector::current_trackVertex_z
float current_trackVertex_z
track production vertex z coordinates in G4 ref
Definition: SensitiveDetector.h:58
Belle2::plume::SensitiveDetector::current_posOUT_w
float current_posOUT_w
outcoming track position w in sensor ref, in mm
Definition: SensitiveDetector.h:80
Belle2::plume::SensitiveDetector::current_posIN_y
float current_posIN_y
incoming track position y in G4 ref, in mm
Definition: SensitiveDetector.h:66
Belle2::plume::SensitiveDetector::current_posIN_u
float current_posIN_u
incoming track position u in sensor ref, in mm
Definition: SensitiveDetector.h:70
Belle2::plume::SensitiveDetector::current_globalTime
float current_globalTime
global time
Definition: SensitiveDetector.h:98
Belle2::plume::SensitiveDetector::current_posIN_w
float current_posIN_w
incoming track position w in sensor ref, in mm
Definition: SensitiveDetector.h:74
Belle2::plume::SensitiveDetector::current_posIN_x
float current_posIN_x
incoming track position x in G4 ref, in mm
Definition: SensitiveDetector.h:64
Belle2::plume::SensitiveDetector::current_posIN_z
float current_posIN_z
incoming track position z in G4 ref, in mm
Definition: SensitiveDetector.h:68
Belle2::plume::SensitiveDetector::step
bool step(G4Step *step, G4TouchableHistory *) override
Step processing method.
Definition: SensitiveDetector.cc:94
Belle2::plume::SensitiveDetector::current_phiAngle
float current_phiAngle
local (sensor ref) phi angle, in sensor plane, in degree
Definition: SensitiveDetector.h:96
