PlotsFromHarvestingValidationBaseTask Class Reference

Inheritance diagram for PlotsFromHarvestingValidationBaseTask:

Collaboration diagram for PlotsFromHarvestingValidationBaseTask:

Public Member Functions
HarvestingValidationBaseTask	harvesting_validation_task_instance (self)
def	output_pdf_file_basename (self)
def	requires (self)
def	output (self)
def	process (self)

Static Public Attributes
	n_events_testing = b2luigi.IntParameter()
	Number of events to generate for the test data set.
	n_events_training = b2luigi.IntParameter()
	Number of events to generate for the training data set.
	experiment_number = b2luigi.IntParameter()
	Experiment number of the conditions database, e.g. More...
	process_type = b2luigi.Parameter(default="BBBAR")
	Define which kind of process shall be used. More...
	exclude_variables = b2luigi.ListParameter(hashed=True)
	List of collected variables to not use in the training of the QE MVA classifier. More...
	fast_bdt_option = b2luigi.ListParameter(hashed=True, default=[200, 8, 3, 0.1])
	Hyperparameter option of the FastBDT algorithm. More...
	primaries_only = b2luigi.BoolParameter(default=True)
	Whether to normalize the track finding efficiencies to primary particles only.

Detailed Description

Create a PDF file with validation plots for a quality estimator produced
from the ROOT ntuples produced by a harvesting validation task

Definition at line 1815 of file combined_quality_estimator_teacher.py.

Member Function Documentation

harvesting_validation_task_instance()

HarvestingValidationBaseTask harvesting_validation_task_instance

(

self

)

Specifies related harvesting validation task which produces the ROOT
files with the data that is plotted by this task.

Reimplemented in RecoTrackQEValidationPlotsTask, CDCQEValidationPlotsTask, and VXDQEValidationPlotsTask.

Definition at line 1839 of file combined_quality_estimator_teacher.py.

output()

def output

(

self

)

Generate list of output files that the task should produce.
The task is considered finished if and only if the outputs all exist.

Definition at line 1860 of file combined_quality_estimator_teacher.py.

output_pdf_file_basename()

def output_pdf_file_basename

(

self

)

Name of the output PDF file containing the validation plots

Definition at line 1847 of file combined_quality_estimator_teacher.py.

process()

def process

(

self

)

Use basf2_mva teacher to create MVA weightfile from collected training
data variables.

Main process that is dispatched by the ``run`` method that is inherited
from ``Basf2Task``.

Definition at line 1868 of file combined_quality_estimator_teacher.py.

requires()

def requires

(

self

)

Generate list of luigi Tasks that this Task depends on.

Definition at line 1854 of file combined_quality_estimator_teacher.py.

Member Data Documentation

exclude_variables

exclude_variables = b2luigi.ListParameter(hashed=True)

static

List of collected variables to not use in the training of the QE MVA classifier.

In addition to variables containing the "truth" substring, which are excluded by default.

Definition at line 1832 of file combined_quality_estimator_teacher.py.

experiment_number

experiment_number = b2luigi.IntParameter()

static

Experiment number of the conditions database, e.g.

defines simulation geometry

Definition at line 1825 of file combined_quality_estimator_teacher.py.

fast_bdt_option

fast_bdt_option = b2luigi.ListParameter(hashed=True, default=[200, 8, 3, 0.1])

static

Hyperparameter option of the FastBDT algorithm.

default are the FastBDT default values.

Definition at line 1834 of file combined_quality_estimator_teacher.py.

process_type

process_type = b2luigi.Parameter(default="BBBAR")

static

Define which kind of process shall be used.

Decide between simulating BBBAR or BHABHA, MUMU, YY, DDBAR, UUBAR, SSBAR, CCBAR, reconstructing DATA or already simulated files (USESIMBB/EE) or running on existing reconstructed files (USERECBB/EE)

Definition at line 1829 of file combined_quality_estimator_teacher.py.

---

The documentation for this class was generated from the following file:

• tracking/scripts/tracking/train/combined_quality_estimator_teacher.py
