ReferenceFrame Class Referenceabstract
Packages » analysis

Abstract base class of all reference frames. More...

#include <ReferenceFrame.h>

Inheritance diagram for ReferenceFrame:
Inheritance graph
[legend]
Collaboration diagram for ReferenceFrame:
Collaboration graph
[legend]

Public Member Functions

virtual TVector3 getVertex (const TVector3 &vector) const =0
 Get vertex 3-vector in reference frame. More...

virtual TVector3 getVertex (const Particle *particle) const
 Wrapper for particles. More...

virtual TLorentzVector getMomentum (const TLorentzVector &vector) const =0
 Get momentum 4-vector in reference frame. More...

virtual TLorentzVector getMomentum (const Particle *particle) const
 Wrapper for particles. More...

virtual TMatrixFSym getMomentumErrorMatrix (const TMatrixFSym &matrix) const =0
 Get Momentum error matrix in reference frame. More...

virtual TMatrixFSym getMomentumErrorMatrix (const Particle *particle) const
 Wrapper for particles. More...

virtual TMatrixFSym getVertexErrorMatrix (const TMatrixFSym &matrix) const =0
 Get Vertex error matrix in reference frame. More...

virtual TMatrixFSym getVertexErrorMatrix (const Particle *particle) const
 Wrapper for particles. More...


Static Public Member Functions

static const ReferenceFrame & GetCurrent ()
 Get current rest frame. More...


Static Private Member Functions

static void Push (const ReferenceFrame *frame)
 Push rest frame of given particle. More...

static void Pop ()
 Pop current rest frame.


Static Private Attributes

static std::stack< const ReferenceFrame * > m_reference_frames
 Stack of current rest frames.


Friends

template<class T >
class UseReferenceFrame


Detailed Description

Abstract base class of all reference frames.

Definition at line 28 of file ReferenceFrame.h.

Member Function Documentation

◆ GetCurrent()

const ReferenceFrame & GetCurrent ( )
static

Get current rest frame.

Returns
RestFrame

Definition at line 26 of file ReferenceFrame.cc.

27 {
28  if (m_reference_frames.empty()) {
29  static LabFrame _default;
30  return _default;
31  } else {
32  return *m_reference_frames.top();
33  }
34 }
Belle2::ReferenceFrame::m_reference_frames
static std::stack< const ReferenceFrame * > m_reference_frames
Stack of current rest frames.
Definition: ReferenceFrame.h:122

◆ getMomentum() [1/2]

virtual TLorentzVector getMomentum ( const Particle *  particle) const
inlinevirtual

Wrapper for particles.

Parameters
particleparticle
Returns
momentum 4-vector in reference frame

Definition at line 59 of file ReferenceFrame.h.

60  {
61  return getMomentum(particle->get4Vector());
62  }
Belle2::ReferenceFrame::getMomentum
virtual TLorentzVector getMomentum(const TLorentzVector &vector) const =0
Get momentum 4-vector in reference frame.

◆ getMomentum() [2/2]

virtual TLorentzVector getMomentum ( const TLorentzVector &  vector) const
pure virtual

Get momentum 4-vector in reference frame.

Parameters
vector4-vector from particle
Returns
momentum 4-vector in reference frame

Implemented in CMSRotationFrame, RotationFrame, CMSFrame, LabFrame, and RestFrame.

◆ getMomentumErrorMatrix() [1/2]

virtual TMatrixFSym getMomentumErrorMatrix ( const Particle *  particle) const
inlinevirtual

Wrapper for particles.

Parameters
particleparticle
Returns
Covariance matrix in reference frame

Definition at line 76 of file ReferenceFrame.h.

◆ getMomentumErrorMatrix() [2/2]

virtual TMatrixFSym getMomentumErrorMatrix ( const TMatrixFSym &  matrix) const
pure virtual

Get Momentum error matrix in reference frame.

Parameters
matrixCovariance matrix of particle
Returns
Covariance matrix in reference frame

Implemented in CMSRotationFrame, RotationFrame, CMSFrame, LabFrame, and RestFrame.

◆ getVertex() [1/2]

virtual TVector3 getVertex ( const Particle *  particle) const
inlinevirtual

Wrapper for particles.

Parameters
particle
Returns
3-vector in reference frame

Definition at line 42 of file ReferenceFrame.h.

◆ getVertex() [2/2]

virtual TVector3 getVertex ( const TVector3 &  vector) const
pure virtual

Get vertex 3-vector in reference frame.

Parameters
vector3-vector from particle
Returns
3-vector in reference frame

Implemented in CMSRotationFrame, RotationFrame, CMSFrame, LabFrame, and RestFrame.

◆ getVertexErrorMatrix() [1/2]

virtual TMatrixFSym getVertexErrorMatrix ( const Particle *  particle) const
inlinevirtual

Wrapper for particles.

Parameters
particle
Returns
Covariance matrix in reference frame

Definition at line 93 of file ReferenceFrame.h.

◆ getVertexErrorMatrix() [2/2]

virtual TMatrixFSym getVertexErrorMatrix ( const TMatrixFSym &  matrix) const
pure virtual

Get Vertex error matrix in reference frame.

Parameters
matrixCovariance matrix of particle
Returns
Covariance matrix in reference frame

Implemented in CMSRotationFrame, RotationFrame, CMSFrame, LabFrame, and RestFrame.

◆ Push()

static void Push ( const ReferenceFrame *  frame)
inlinestaticprivate

Push rest frame of given particle.

Parameters
frameUse this reference frame

Definition at line 109 of file ReferenceFrame.h.

The documentation for this class was generated from the following files:
