TrgEclMaster Class Reference
Packages » trg

ETM class. More...

#include <TrgEclMaster.h>

Collaboration diagram for TrgEclMaster:
Collaboration graph
[legend]

Public Member Functions

 TrgEclMaster (void)
 TrgEclMaster Constructor.

virtual ~TrgEclMaster ()
 TrgEclMaster Destructor.

 TrgEclMaster (TrgEclMaster &)=delete
 Copy constructor, deleted.

TrgEclMaster & operator= (TrgEclMaster &)=delete
 Assignment operator, deleted.

void initialize (int)
 initialize

void simulate01 (int)
 simulates ECL trigger for Global Cosmic data


void simulate02 (int)
 simulates ECL trigger for Data Analysis

std::string name (void) const
 returns name.

std::string version (void) const
 returns version.

void setRS (std::vector< int >, std::vector< double >, std::vector< double > &, std::vector< std::vector< double >> &)
 ECL bit information for GDL. More...

void setClusterMethod (int cluster)
 Get Event timing. More...

void setClusterLimit (int limit)
 Set the limit # of Cluster.

void setBhabhaMethod (int bhabha)
 Set Bhabha.

void setEventTimingMethod (int EventTiming)
 Set Cluster.

void setTimeWindow (int timewindow)
 Set Trigger Decision window size.

void setOverlapWindow (int overlapwindow)
 Set Trigger Decision overlap window size.

void setNofTopTC (int noftoptc)
 set # of considered TC in energy weighted Timing method

void makeLowMultiTriggerBit (std::vector< int >, std::vector< double >)
 make LowMultiTriggerBit

void makeTriggerBit (int, int, int, int, double, int, int, std::vector< int >, int, int, int, int, int, int, int, int, int, int, int, int, int, int)
 make Trigger bit except for Low Multiplicity related bit

double setTotalEnergy (std::vector< double >)
 Set Total Energy.

int getTriggerbit (int i)
 Get ECL Trigger bit.

int getLowmultibit ()
 Get Low Multiplicity Trigger Bit.

void set2DBhabhaThreshold (const std::vector< double > &i2DBhabhaThresholdFWD, const std::vector< double > &i2DBhabhaThresholdBWD)
 set 2D Bhabha Energy Threshold

void set3DBhabhaSelectionThreshold (const std::vector< double > &i3DBhabhaSelectionThreshold)
 set 3D selection Bhabha Energy Threshold

void set3DBhabhaVetoThreshold (const std::vector< double > &i3DBhabhaVetoThreshold)
 set 3D veto Bhabha Energy Threshold

void set3DBhabhaSelectionAngle (const std::vector< double > &i3DBhabhaSelectionAngle)
 set 3D selection Bhabha Energy Angle

void set3DBhabhaVetoAngle (const std::vector< double > &i3DBhabhaVetoAngle)
 set 3D veto Bhabha Energy Angle

void setmumuThreshold (int mumuThreshold)
 set mumu bit Threshold

void setmumuAngle (const std::vector< double > &imumuAngle)
 set mumu bit Angle selection

void set3DBhabhaAddAngleCut (const std::vector< double > &i3DBhabhaAddAngleCut)
 set 3D Bhabha addtion Angle selection

void setTaub2bAngleCut (const std::vector< int > &itaub2bAngleCut)
 set tau b2b 2 cluster angle cut

void setTaub2bEtotCut (double itaub2bEtotCut)
 set tau b2b total energy cut

void setTaub2bClusterECut (double itaub2bClusterECut1, double itaub2bClusterECut2)
 set tau b2b 1Cluster energy cut

void setn300MeVClusterThreshold (int n300MeVCluster)
 set the number of cluster exceeding 300 MeV

void setECLBurstThreshold (int ECLBurstThreshold)
 set mumu bit Threshold

void setTotalEnergyThreshold (const std::vector< double > &iTotalEnergy)
 set Total Energy Theshold (low, high, lum)

void setLowMultiplicityThreshold (const std::vector< double > &iLowMultiThreshold)
 set Low Multiplicity Threshold

void set3DBhabhaVetoInTrackThetaRegion (const std::vector< int > &i3DBhabhaVetoInTrackThetaRegion)

void setEventTimingQualityThresholds (const std::vector< double > &iEventTimingQualityThresholds)


Static Public Member Functions

static TrgEclMaster * getTrgEclMaster (void)
 get pointer of TrgEclMaster object


Private Attributes

std::vector< std::vector< double > > TCEnergy
 Hit TC Energy.

std::vector< std::vector< double > > TCTiming
 Hit TC Timing.

std::vector< std::vector< int > > TCBeamBkgTag
 Hit TC Beam Background tag.

std::vector< int > HitTCId
 Hit TC Energy in time window.

std::vector< double > TCHitEnergy
 Hit TC Energy in time window.

std::vector< double > TCHitTiming
 Hit TC Timing in time window.

std::vector< int > TCHitBeamBkgTag
 Hit TC Beam Background tag in time window.

std::vector< std::vector< double > > PhiRingSum
 Phi ring sum.

std::vector< std::vector< std::vector< double > > > ThetaRingSum
 Theta ring sum.

double TimeWindow
 Hit TC Energy in time window. More...

double OverlapWindow
 TRG Decision overlap window.

int _Clustering
 clutering option

int _Bhabha
 Bhabha option.

int _EventTiming
 EventTiming option.

int _NofTopTC

int _ClusterLimit
 The limit number of Cluster.

int _Triggerbit [4]
 ECL Trigger bit.

int _Lowmultibit
 Low Multiplicity bit.

int _PrescaleFactor
 Bhabha Prescale Factor.

int _PrescaleCounter
 Bhabha Prescale Countor.

std::vector< double > _2DBhabhaThresholdFWD
 2D Bhabha Energy Threshold

std::vector< double > _2DBhabhaThresholdBWD
 2D Bhabha Energy Threshold

std::vector< double > _3DBhabhaSelectionThreshold
 3D Selection Bhabha Energy Threshold

std::vector< double > _3DBhabhaVetoThreshold
 3D Veto Bhabha Energy Threshold

std::vector< double > _3DBhabhaSelectionAngle
 3D Selection Bhabha Energy Angle

std::vector< double > _3DBhabhaVetoAngle
 3D Veto Bhabha Energy Angle

double _mumuThreshold
 mumu bit Energy Threshold

std::vector< double > _mumuAngle
 mumu bit Angle

std::vector< double > m_3DBhabhaAddAngleCut

std::vector< int > m_taub2bAngleCut
 tau b2b 2 cluster angle cut (degree)

double m_taub2bEtotCut
 tau b2b total energy (TC theta ID =1-17) (GeV)

double m_taub2bClusterECut1
 tau b2b 1 Cluster energy selection (GeV)

double m_taub2bClusterECut2

int _n300MeVCluster
 The number of Cluster exceeding 300 MeV.

double _ECLBurstThreshold
 ECL Burst Bit Threshold.

std::vector< double > _TotalEnergy
 Total Energy Theshold (low, high, lum)

std::vector< double > _LowMultiThreshold
 Low Multiplicity Threshold.

std::vector< int > m_3DBhabhaVetoInTrackThetaRegion

std::vector< double > m_EventTimingQualityThresholds

TrgEclMapping * obj_map
 Mapping object.

TrgEclCluster * obj_cluster
 Cluster object.

TrgEclTiming * obj_timing
 EventTiming object.

TrgEclBhabha * obj_bhabha
 Bhabha object.

TrgEclBeamBKG * obj_beambkg
 Beam Backgroud veto object.

TrgEclDataBase * obj_database
 Beam Backgroud veto object.


Static Private Attributes

static TrgEclMaster * _ecl = 0
 ecl object


Detailed Description

ETM class.

Definition at line 33 of file TrgEclMaster.h.

Member Function Documentation

◆ setClusterMethod()

void setClusterMethod ( int  cluster)
inline

Get Event timing.

Set Cluster

Definition at line 78 of file TrgEclMaster.h.

78 {_Clustering = cluster;}
Belle2::TrgEclMaster::_Clustering
int _Clustering
clutering option
Definition: TrgEclMaster.h:225

◆ setRS()

void setRS ( std::vector< int >  TCId,
std::vector< double >  TCHit,
std::vector< double > &  phiringsum,
std::vector< std::vector< double >> &  thetaringsum
)

ECL bit information for GDL.

ECL bit information for GDL Set Phi Ring Sum

Definition at line 1043 of file TrgEclMaster.cc.

1047 {
1048  //
1049  //
1050  // TC Phi & Theta ring sum
1051  //
1052  //----------------------------------------
1053  // FW BR BW total
1054  //----------------------------------------
1055  //TC phi ring 3 12 2 17
1056  //ID 1-3 4-15 16-17
1057  //TC Theta ring 32 36 32
1058  //ID 1-32 1-36 1-32
1059
1060  //----------------------------------------
1061  //
1062  thetaringsum.resize(3, std::vector<double>(36, 0.));
1063  phiringsum.resize(17);
1064  const int size_hit = TCHit.size();
1065  for (int iHit = 0; iHit < size_hit; iHit++) {
1066  int iTCId = TCId[iHit] - 1;
1067  if (TCHit[iHit] > 0) {
1068  int iTCThetaId = obj_map->getTCThetaIdFromTCId(iTCId + 1) - 1 ;
1069  int iTCPhiId = obj_map->getTCPhiIdFromTCId(iTCId + 1) - 1 ;
1070  phiringsum[iTCThetaId] += TCHit[iHit];
1071  if (iTCThetaId < 3) {
1072  //fwd
1073  if (iTCThetaId != 0) {
1074  thetaringsum[0][iTCPhiId] += TCHit[iHit];
1075  }
1076  } else if (iTCThetaId < 15) {
1077  //barrel
1078  thetaringsum[1][iTCPhiId] += TCHit[iHit];
1079  } else {
1080  //bwd
1081  thetaringsum[2][iTCPhiId] += TCHit[iHit];
1082  }
1083
1084  }
1085
1086  }
1087
1088 }
Belle2::TrgEclMapping::getTCThetaIdFromTCId
int getTCThetaIdFromTCId(int)
get [TC Theta ID] from [TC ID]
Definition: TrgEclMapping.cc:195
Belle2::TrgEclMapping::getTCPhiIdFromTCId
int getTCPhiIdFromTCId(int)
get [TC Phi ID] from [TC ID]
Definition: TrgEclMapping.cc:222
Belle2::TrgEclMaster::obj_map
TrgEclMapping * obj_map
Mapping object.
Definition: TrgEclMaster.h:285

Member Data Documentation

◆ _NofTopTC

int _NofTopTC
private

of considered TC in energy weighted Timing method

Definition at line 231 of file TrgEclMaster.h.

◆ TimeWindow

double TimeWindow
private

Hit TC Energy in time window.

Hit TC Timing in time window TRG Decision Time window

Definition at line 220 of file TrgEclMaster.h.
