Inheritance diagram for SystematicsEELL:

Collaboration diagram for SystematicsEELL:

[legend]

Public Member Functions
def	load_standard_lists (self, path)

def	build_lists (self, path)

def	__description__ (self)

def	__category__ (self)

def	__authors__ (self)

def	__contact__ (self)

def	code (self)

def	additional_setup (self, path)

def	validation_histograms (self, path)

def	__call__ (self, path)

def	postskim_path (self)

def	skim_event_cuts (self, cut, *path)

def	TestFiles (self)

def	flag (self)

def	initialise_skim_flag (self, path)

def	update_skim_flag (self, path)

def	__str__ (self)

def	__name__ (self)

def	set_skim_logging (self)

def	output_udst (self, path)

def	apply_hlt_hadron_cut_if_required (self, path)

Public Attributes
	mc

	SkimLists

	name

	OutputFileName

	additionalDataDescription

Static Public Attributes
	NoisyModules = None

string	TestSampleProcess = "mixed"

dictionary	MergeDataStructures = {}

bool	ApplyHLTHadronCut = False

bool	produce_on_tau_samples = True

bool	produces_mdst_by_default = False

	validation_sample = None

bool	mc = True

	analysisGlobaltag = None

list	SkimLists = []

Private Member Functions
def	_method_unchanged (self, method)

Private Attributes
	_udstOutput

	_validation

Static Private Attributes
list	__authors__ = ["Ilya Komarov"]

string	__description__ = "Systematics skim of :math:`ee\\to ee\\ell\\ell`"

	__contact__ = __liaison__

string	__category__ = "systematics, lepton ID"

	_MainPath = None

	_ConditionalPath = None

Detailed Description

Definition at line 377 of file systematics.py.

Member Function Documentation

◆ call()

def __call__	(	self,
		path
	)

inherited

Produce the skim particle lists and write uDST file.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented in CombinedSkim.

Definition at line 214 of file core.py.

◆ _method_unchanged()

def _method_unchanged	(	self,
		method
	)

privateinherited

Check if the method of the class is the same as in its parent class, or if it has
been overridden.

Useful for determining if *e.g.* `validation_histograms` has been defined for a
particular skim.

Definition at line 375 of file core.py.

◆ additional_setup()

def additional_setup	(	self,
		path
	)

inherited

Perform any setup steps necessary before running the skim.

Warning:
    Standard particle lists should *not* be loaded in here. This should be done
    by overriding the method `BaseSkim.load_standard_lists`. This is crucial for
    avoiding loading lists twice when combining skims for production.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented in TDCPV_ccs, TDCPV_qqs, TauThrust, TauGeneric, Random, BaseFEISkim, ALP3Gamma, and CombinedSkim.

Definition at line 176 of file core.py.

◆ apply_hlt_hadron_cut_if_required()

def apply_hlt_hadron_cut_if_required	(	self,
		path
	)

inherited

Apply the ``hlt_hadron`` selection if the property ``ApplyHLTHadronCut`` is True.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented in CombinedSkim.

Definition at line 452 of file core.py.

◆ build_lists()

def build_lists	(	self,
		path
	)

Create the skim lists to be saved in the output uDST. This function is where
the main skim cuts should be applied. This function should return a list of
particle list names.

Parameters:
    path (basf2.Path): Skim path to be processed.

.. versionchanged:: release-06-00-00

   Previously, this function was expected to set the attribute
   `BaseSkim.SkimLists`. Now this is handled by `BaseSkim`, and this function is
   expected to return the list of particle list names.

Reimplemented from BaseSkim.

Definition at line 386 of file systematics.py.

◆ code()

def code ( self )

inherited

Eight-digit code assigned to this skim in the registry.

Definition at line 126 of file core.py.

◆ flag()

def flag ( self )

inherited

Event-level variable indicating whether an event passes the skim or not. To use
the skim flag without writing uDST output, use the argument ``udstOutput=False``
when instantiating the skim class.

Reimplemented in CombinedSkim.

Definition at line 347 of file core.py.

◆ initialise_skim_flag()

def initialise_skim_flag	(	self,
		path
	)

inherited

Add the module `skim.utils.flags.InitialiseSkimFlag` to the path, which
initialises flag for this skim to zero.

Reimplemented in CombinedSkim.

Definition at line 355 of file core.py.

◆ load_standard_lists()

def load_standard_lists	(	self,
		path
	)

Load any standard lists. This code will be run before any
`BaseSkim.additional_setup` and `BaseSkim.build_lists`.

Note:
    This is separated into its own function so that when skims are combined, any
    standard lists used by two skims can be loaded just once.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented from BaseSkim.

Definition at line 383 of file systematics.py.

◆ output_udst()

def output_udst	(	self,
		path
	)

inherited

Write the skim particle lists to an output uDST and print a summary of the
skim list statistics.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented in CombinedSkim.

Definition at line 425 of file core.py.

◆ postskim_path()

def postskim_path ( self )

inherited

Return the skim path.

* If `BaseSkim.skim_event_cuts` has been run, then the skim lists will only be
  created on a conditional path, so subsequent modules should be added to the
  conditional path.

* If `BaseSkim.skim_event_cuts` has not been run, then the main analysis path is
  returned.

Definition at line 244 of file core.py.

◆ set_skim_logging()

def set_skim_logging ( self )

inherited

Turns the log level to ERROR for selected modules to decrease the total size
of the skim log files. Additional modules can be silenced by setting the attribute
`NoisyModules` for an individual skim.

Parameters:
    path (basf2.Path): Skim path to be processed.

.. warning::

    This method works by inspecting the modules added to the path, and setting
    the log level to ERROR. This method should be called *after* all
    skim-related modules are added to the path.

Reimplemented in CombinedSkim.

Definition at line 399 of file core.py.

◆ skim_event_cuts()

def skim_event_cuts	(		self,
			cut,
		*	path
	)

inherited

Apply event-level cuts in a skim-safe way.

Parameters:
    cut (str): Event-level cut to be applied.
    path (basf2.Path): Skim path to be processed.

Returns:
    Path on which the rest of this skim should be processed.
    On this path, only events which passed the event-level cut will
    be processed further.

.. Tip::
    If running this function in `BaseSkim.additional_setup` or
    `BaseSkim.build_lists`, redefine the ``path`` to the path returned by
    `BaseSkim.skim_event_cuts`, *e.g.*

    .. code-block:: python

        def build_lists(self, path):
            path = self.skim_event_cuts("nTracks>4", path=path)
            # rest of skim list building...

.. Note::
    The motivation for using this function over `applyEventCuts` is that
    `applyEventCuts` completely removes events from processing. If we combine
    multiple skims in a single steering file (which is done in production), and
    the first has a set of event-level cuts, then all the remaining skims will
    never even see those events.

    Internally, this function creates a new path, which is only processed for
    events passing the event-level cut. To avoid issues around particles not
    being available on the main path (leading to noisy error logs), we need to
    add the rest of the skim to this path. So this new path is assigned to the
    attribute ``BaseSkim._ConditionalPath``, and ``BaseSkim.__call__`` will run
    all remaining methods on this path.

Definition at line 272 of file core.py.

◆ TestFiles()

def TestFiles ( self )

inherited

Location of test MDST sample. To modify this, set the property
`BaseSkim.TestSampleProcess`, and this function will find an appropriate test
sample from the list in
``/group/belle2/dataprod/MC/SkimTraining/SampleLists/TestFiles.yaml``

If no sample can be found, an empty list is returned.

Reimplemented in CombinedSkim.

Definition at line 324 of file core.py.

◆ update_skim_flag()

def update_skim_flag	(	self,
		path
	)

inherited

Add the module `skim.utils.flags.UpdateSkimFlag` to the path, which
updates flag for this skim.

.. Warning::

    If a conditional path has been created before this, then this function
    *must* run on the conditional path, since the skim lists are not guaranteed
    to exist for all events on the main path.

Reimplemented in CombinedSkim.

Definition at line 362 of file core.py.

◆ validation_histograms()

def validation_histograms	(	self,
		path
	)

inherited

Create validation histograms for the skim.

Parameters:
    path (basf2.Path): Skim path to be processed.

Reimplemented in TDCPV_ccs, TDCPV_qqs, TauThrust, TauGeneric, TauLFV, SystematicsPhiGamma, SLUntagged, PRsemileptonicUntagged, CharmoniumPsi, LowMassTwoTrack, LeptonicUntagged, feiSLBplus, feiSLB0, feiHadronicBplus, feiHadronicB0, inclusiveBplusToKplusNuNu, BtoXll, BtoXgamma, BtoD0h_Kshh, BtoD0h_hh, BtoD0h_Kspipipi0, and BtoD0h_Kspi0.

Definition at line 206 of file core.py.

The documentation for this class was generated from the following file:

skim/scripts/skim/WGs/systematics.py
