BFieldManager Class Reference

Bfield manager to obtain the magnetic field at any point. More...

#include <BFieldManager.h>

Collaboration diagram for BFieldManager:

Static Public Member Functions
static void	getField (const double *pos, double *field)
	return the magnetic field at a given position. More...
static TVector3	getField (const TVector3 &pos)
	return the magnetic field at a given position. More...
static B2Vector3D	getField (double x, double y, double z)
	return the magnetic field at a given position. More...
static B2Vector3D	getField (const B2Vector3D &pos)
	return the magnetic field at a given position. More...
static B2Vector3D	getFieldInTesla (const B2Vector3D &pos)
	return the magnetic field at a given position in Tesla. More...
static BFieldManager &	getInstance ()
	Return the instance of the magnetic field manager.

Private Member Functions
	BFieldManager ()=default
	Singleton: private constructor.
	BFieldManager (BFieldManager &)=delete
	Singleton: no copy constructor.
BFieldManager &	operator= (const BFieldManager &)=delete
	Singleton: no assignment operator.
	~BFieldManager ()=default
	Empty destructor: this is just a wrapper to access the database object.
B2Vector3D	calculate (const B2Vector3D &pos) const
	Calculate the field value at a given position and return it. More...

Private Attributes
DBObjPtr< MagneticField >	m_magfield
	Pointer to the actual magnetic field in the database.

Detailed Description

Bfield manager to obtain the magnetic field at any point.

This class is implemented as singleton, there can only be one magnetic field. It has static members to get the field at a given point.

Note

For internal use in the simulation, there is also a BFieldMap class in the geometry package with similar behaviour. To ensure consistent output, the BFieldFrameworkInterface component provides a wrapper around BFieldMap and is used by default.

Definition at line 32 of file BFieldManager.h.

Member Function Documentation

getField() [1/3]

static B2Vector3D getField ( const B2Vector3D &  pos )

inlinestatic

return the magnetic field at a given position.

Parameters

pos	position where to evaluate the magnetic field

Returns

magnetic field value at position pos in framework units

Definition at line 62 of file BFieldManager.h.

getField() [2/3]

static TVector3 getField ( const TVector3 &  pos )

inlinestatic

return the magnetic field at a given position.

Parameters

pos	position where to evaluate the magnetic field

Returns

magnetic field value at position pos in framework units

Definition at line 43 of file BFieldManager.h.

getField() [3/3]

static B2Vector3D getField ( double  x, double  y, double  z  )

inlinestatic

return the magnetic field at a given position.

Parameters

x	x coordinate of the position where to evaluate the magnetic field
y	y coordinate of the position where to evaluate the magnetic field
z	z coordinate of the position where to evaluate the magnetic field

Returns

magnetic field value at position pos in framework units

Definition at line 54 of file BFieldManager.h.

getFieldInTesla()

static B2Vector3D getFieldInTesla ( const B2Vector3D &  pos )

inlinestatic

return the magnetic field at a given position in Tesla.

Parameters

pos	position where to evaluate the magnetic field

Returns

magnetic field value at position pos in Tesla

Definition at line 70 of file BFieldManager.h.

---

The documentation for this class was generated from the following files:

• framework/geometry/include/BFieldManager.h
• framework/geometry/src/BFieldManager.cc
