The Class for BeamBackground Sensitive Detector. More...

#include <BkgSensitiveDetector.h>

Inheritance diagram for BkgSensitiveDetector:

Collaboration diagram for BkgSensitiveDetector:

[legend]

Public Member Functions
	BkgSensitiveDetector (const char *subDet, int iden=0)
	Constructor. More...

bool	step (G4Step aStep, G4TouchableHistory ) override
	Process each step and calculate variables defined in PXDSimHit. More...

Static Public Member Functions
static const std::map< std::string, RelationArray::EConsolidationAction > &	getMCParticleRelations ()
	Return a list of all registered Relations with MCParticles.

static void	setActive (bool activeStatus)
	Enable/Disable all Sensitive Detectors. More...

static void	registerMCParticleRelation (const std::string &name, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Register an relation involving MCParticles. More...

static void	registerMCParticleRelation (const RelationArray &relation, RelationArray::EConsolidationAction ignoreAction=RelationArray::c_negativeWeight)
	Overload to make it easer to register MCParticle relations. More...

Private Member Functions
virtual bool	ProcessHits (G4Step aStep, G4TouchableHistory aROhist)
	Check if recording hits is enabled and if so call step() and set the correct MCParticle flag. More...

Private Attributes
int	m_subDet
	subdetector id number

int	m_identifier
	identifier of subdetector component

int	m_trackID
	track id

TVector3	m_startPos
	particle position at the entrance in volume

TVector3	m_startMom
	particle momentum at the entrance in volume

double	m_startTime
	global time

double	m_startEnergy
	particle energy at the entrance in volume

double	m_energyDeposit
	energy deposited in volume

double	m_trackLength
	length of the track in the volume

int	m_eclrepscale
	replica (=sector) scale in ECL

Const::EDetector	m_subdetector
	Subdetector the class belongs to.

Static Private Attributes
static std::map< std::string, RelationArray::EConsolidationAction >	s_mcRelations
	Static set holding all relations which have to be updated at the end of the Event.

static bool	s_active
	Static bool which indicates wether recording of hits is enabled.

Detailed Description

The Class for BeamBackground Sensitive Detector.

In this class, every variable defined in BeamBackHit will be calculated, and stored in datastore.

Definition at line 24 of file BkgSensitiveDetector.h.

Member Function Documentation

◆ ProcessHits()

bool ProcessHits	(	G4Step *	aStep,
		G4TouchableHistory *	aROhist
	)

inlineprivatevirtualinherited

Check if recording hits is enabled and if so call step() and set the correct MCParticle flag.

Called by Geant4 for each step inside the sensitive volumes attached

Definition at line 96 of file SensitiveDetectorBase.h.

     {
       if (!s_active) return false;
       bool result = step(aStep, aROhist);
       // Do not include hits from invalid detector (beast,teastbeam, etc.)
       if (result && (m_subdetector != Const::invalidDetector)) TrackInfo::getInfo(*aStep->GetTrack()).addSeenInDetector(m_subdetector);
       return result;
     }

◆ registerMCParticleRelation() [1/2]

static void registerMCParticleRelation	(	const RelationArray &	relation,
		RelationArray::EConsolidationAction	ignoreAction = `RelationArray::c_negativeWeight`
	)

inlinestaticinherited

Overload to make it easer to register MCParticle relations.

Parameters

relation	RelationArray to register
ignoreAction

Definition at line 68 of file SensitiveDetectorBase.h.

◆ registerMCParticleRelation() [2/2]

void registerMCParticleRelation	(	const std::string &	name,
		RelationArray::EConsolidationAction	ignoreAction = `RelationArray::c_negativeWeight`
	)

staticinherited

Register an relation involving MCParticles.

All Relations which point from an MCParticle to something have to be registered with addMCParticleRelation() because the index of the MCParticles might change at the end of the event. During simulation, the TrackID should be used as index of the MCParticle

Parameters

name	Name of the relation to register
ignoreAction

Definition at line 22 of file SensitiveDetectorBase.cc.

     {
       std::pair<std::map<std::string, RelationArray::EConsolidationAction>::iterator, bool> insert = s_mcRelations.insert(std::make_pair(
             name, ignoreAction));
       //If the relation already exists and the ignoreAction is different we do have a problem
       if (!insert.second && insert.first->second != ignoreAction) {
         B2FATAL("MCParticle Relation " << name << " already registered with different ignore action.");
       }
     }

◆ setActive()

static void setActive ( bool activeStatus )

inlinestaticinherited

Enable/Disable all Sensitive Detectors.

By default, all sensitive detectors won't create hits to make it possible to use the Geant4 Navigator for non-simulation purposes. Only during simulation the sensitive detectors will be enabled to record hits

Parameters

activeStatus bool to indicate wether hits should be recorded

Definition at line 52 of file SensitiveDetectorBase.h.

The documentation for this class was generated from the following files:

simulation/background/include/BkgSensitiveDetector.h
simulation/background/src/BkgSensitiveDetector.cc
