ECLDatabaseImporter Class Reference

ECL database importer. More...

#include <ECLDatabaseImporter.h>

Collaboration diagram for ECLDatabaseImporter:

Public Member Functions
	ECLDatabaseImporter (std::vector< std::string > inputFileNames, const std::string &m_name)
	Constructor.
virtual	~ECLDatabaseImporter ()
	Destructor.
void	importDigitEnergyCalibration ()
	Import ECL energy calibration constants to the database.
void	importDigitTimeCalibration ()
	Import ECL time calibration constants to the database.
void	importShowerShapesSecondMomentCorrections ()
	Import ECL shower shape corrections to second moment to the database.
void	importShowerCorrectorLeakageCorrections ()
	Import ECL leakage corrections to showers.
void	importShowerEnergyCorrectionTemporary ()
	Import ECL corrections to showers energies. More...
void	importTrackClusterMatchingThresholds ()
	Import threshold values for track ECL cluster matching to the database.
void	importTrackClusterMatchingParameterizations ()
	Import parameterizations for the RMS between tracks and ECL clusters to the database.

Private Member Functions
template<class rootClass >
rootClass	getRootObjectFromFile (TFile *file, const std::string &rootObjName) const
	Extract a root object rootObjName from a root file file. More...

Private Attributes
std::vector< std::string >	m_inputFileNames
	Input file name.
std::string	m_name
	Database object (output) file name.
std::string	m_bgFractionBinNumBranchName = "bgFractionBinNum"
	Branch names for shower corrector leakage correction root file. More...
std::string	m_regNumBranchName = "regNum"
	regNum branch name
std::string	m_phiBinNumBranchName = "phiBinNum"
	phiBinNum branch name
std::string	m_thetaBinNumBranchName = "thetaBinNum"
	thetaBinNum branch name
std::string	m_energyBinNumBranchName = "energyBinNum"
	energyBinNum branch name
std::string	m_correctionFactorBranchName = "correctionFactor"
	correctionFactor branch name
const int	m_numAvgRecEnEntries = 15
	Number of entries in avgRecEn array. More...
std::string	m_avgRecEnBranchName = "avgRecEn"
	avgRecEn branch name
std::string	m_lReg1ThetaBranchName = "lReg1Theta"
	lReg1Theta branch name
std::string	m_hReg1ThetaBranchName = "hReg1Theta"
	hReg1Theta branch name
std::string	m_lReg2ThetaBranchName = "lReg2Theta"
	lReg2Theta branch name
std::string	m_hReg2ThetaBranchName = "hReg2Theta"
	hReg2Theta branch name
std::string	m_lReg3ThetaBranchName = "lReg3Theta"
	lReg3Theta branch name
std::string	m_hReg3ThetaBranchName = "hReg3Theta"
	hReg3Theta branch name
std::string	m_numOfBfBinsBranchName = "numOfBfBins"
	numOfBfBins branch name
std::string	m_numOfEnergyBinsBranchName = "numOfEnergyBins"
	numOfEnergyBins branch name
std::string	m_numOfPhiBinsBranchName = "numOfPhiBins"
	numOfPhiBins branch name
std::string	m_numOfReg1ThetaBinsBranchName = "numOfReg1ThetaBins"
	numOfReg1ThetaBins branch name
std::string	m_numOfReg2ThetaBinsBranchName = "numOfReg2ThetaBins"
	numOfReg2ThetaBins branch name
std::string	m_numOfReg3ThetaBinsBranchName = "numOfReg3ThetaBins"
	numOfReg3ThetaBins branch name
std::string	m_phiPeriodicityBranchName = "phiPeriodicity"
	phiPeriodicity branch name

Detailed Description

ECL database importer.

This module writes data from e.g. a ROOT histogram to database.

Definition at line 26 of file ECLDatabaseImporter.h.

Member Function Documentation

getRootObjectFromFile()

rootClass getRootObjectFromFile ( TFile *  file, const std::string &  rootObjName  ) const

inlineprivate

Extract a root object rootObjName from a root file file.

The file is assumed to be valid (pointer valid and not zombie). If rootObjName doesn't exist in file, do B2FATAL.

Definition at line 88 of file ECLDatabaseImporter.h.

    {
      rootClass rootObj = (rootClass)file->Get(rootObjName.data());
      if (!rootObj) {
        std::string filename = file->GetName();
        delete file;
        B2FATAL("Could not find " << rootObjName << " in " << filename);
      }
      return rootObj;
    }

importShowerEnergyCorrectionTemporary()

void importShowerEnergyCorrectionTemporary

(

)

Import ECL corrections to showers energies.

Temperary - there will be additional improvements done to these corrections in the future. Input file should be .txt file and have the format: generated-energy bkg-scale-factor theta-min theta-max corr-factor. The numbers should be seperated by spaces. For each line, the theta value used is the average of theta-min and theta-max

Definition at line 351 of file ECLDatabaseImporter.cc.

{
  if (m_inputFileNames.size() > 1)
    B2FATAL("Sorry, you must only import one file at a time for now!");

  //Expect a root file
  boost::filesystem::path path(m_inputFileNames[0]);
  if (path.extension() != ".root")
    B2FATAL("Expecting a .root file. Aborting");

  TFile* inputFile = new TFile(m_inputFileNames[0].data(), "READ");

  TGraph2D* theta_geo_graph = getRootObjectFromFile<TGraph2D*>(inputFile, "LeakageCorrections_theta_geometry");
  TGraph2D* phi_geo_graph = getRootObjectFromFile<TGraph2D*>(inputFile, "LeakageCorrections_phi_geometry");
  TGraph2D* theta_en_graph = getRootObjectFromFile<TGraph2D*>(inputFile, "LeakageCorrections_theta_energy");
  TGraph2D* phi_en_graph = getRootObjectFromFile<TGraph2D*>(inputFile, "LeakageCorrections_phi_energy");
  TH1F* bg_histo = getRootObjectFromFile<TH1F*>(inputFile, "LeakageCorrections_background_fraction");

  double bkgFactor = bg_histo->GetBinContent(1);

  double thetaMin = theta_en_graph->GetXmin();
  double thetaMax = theta_en_graph->GetXmax();
  double phiMin = phi_en_graph->GetXmin();
  double phiMax = phi_en_graph->GetXmax();

  double energyMin = theta_en_graph->GetYmin();
  double energyMax = theta_en_graph->GetYmax();


  B2DEBUG(28, "Leakage DBobjects angle boundaries: thetaMin=" << thetaMin << " thetaMax=" << thetaMax << " phiMin= " << phiMin <<
          " phiMax= " << phiMax << " enmin=" << energyMin <<
          " enmax=" << energyMax);

  //    Import to DB
  int startExp = 0;
  int startRun = 0;
  int endExp = -1;
  int endRun = -1;
  IntervalOfValidity iov(startExp, startRun, endExp, endRun);

  if (std::abs(bkgFactor - 1.0) < 1e-9) { //bkgFactor == 1 -> phase 2 backgrounds

    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_theta_geo("ECLLeakageCorrection_thetaGeometry_phase2");
    dbPtr_theta_geo.construct(*theta_geo_graph, thetaMin, thetaMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_phi_geo("ECLLeakageCorrection_phiGeometry_phase2");
    dbPtr_phi_geo.construct(*phi_geo_graph, phiMin, phiMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_theta_en("ECLLeakageCorrection_thetaEnergy_phase2");
    dbPtr_theta_en.construct(*theta_en_graph, thetaMin, thetaMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_phi_en("ECLLeakageCorrection_phiEnergy_phase2");
    dbPtr_phi_en.construct(*phi_en_graph, phiMin, phiMax, energyMin, energyMax);

    //Import into local db
    dbPtr_theta_geo.import(iov);
    dbPtr_phi_geo.import(iov);
    dbPtr_theta_en.import(iov);
    dbPtr_phi_en.import(iov);
  }
  /*else (because currently phase_2 and phase_3 are same payload*/ if (std::abs(bkgFactor - 1.0) < 1e-9) {

    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_theta_geo("ECLLeakageCorrection_thetaGeometry_phase3");
    dbPtr_theta_geo.construct(*theta_geo_graph, thetaMin, thetaMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_phi_geo("ECLLeakageCorrection_phiGeometry_phase3");
    dbPtr_phi_geo.construct(*phi_geo_graph, phiMin, phiMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_theta_en("ECLLeakageCorrection_thetaEnergy_phase3");
    dbPtr_theta_en.construct(*theta_en_graph, thetaMin, thetaMax, energyMin, energyMax);
    DBImportObjPtr<ECLShowerEnergyCorrectionTemporary> dbPtr_phi_en("ECLLeakageCorrection_phiEnergy_phase3");
    dbPtr_phi_en.construct(*phi_en_graph, phiMin, phiMax, energyMin, energyMax);

    //Import into local db
    dbPtr_theta_geo.import(iov);
    dbPtr_phi_geo.import(iov);
    dbPtr_theta_en.import(iov);
    dbPtr_phi_en.import(iov);
  }


}

Member Data Documentation

m_bgFractionBinNumBranchName

std::string m_bgFractionBinNumBranchName = "bgFractionBinNum"

private

Branch names for shower corrector leakage correction root file.

bgFractionBinNum branch name

Definition at line 104 of file ECLDatabaseImporter.h.

m_numAvgRecEnEntries

const int m_numAvgRecEnEntries = 15

private

Number of entries in avgRecEn array.

If this is wrong bad things will happen

Definition at line 112 of file ECLDatabaseImporter.h.

---

The documentation for this class was generated from the following files:

• ecl/dbobjects/include/ECLDatabaseImporter.h
• ecl/dbobjects/src/ECLDatabaseImporter.cc
