a Belle crystal in Geant4 More...
#include <BelleCrystal.h>
Public Member Functions | |
| BelleCrystal (const G4String &pName) | |
| Constructor for "nominal" BelleCrystal. | |
| BelleCrystal (const G4String &pName, int, const G4ThreeVector *) | |
| Constructor. | |
| virtual | ~BelleCrystal () |
| Destructor. | |
| Plane_t | GetSidePlane (G4int n) const |
| G4double | GetCubicVolume () |
| get the Cubic volume | |
| G4double | GetSurfaceArea () |
| get the surface area | |
| void | ComputeDimensions (G4VPVParameterisation *p, const G4int n, const G4VPhysicalVolume *pRep) |
| compute the dimensions | |
| G4bool | CalculateExtent (const EAxis pAxis, const G4VoxelLimits &pVoxelLimit, const G4AffineTransform &pTransform, G4double &pMin, G4double &pMax) const |
| calculate the extent of the volume | |
| EInside | Inside (const G4ThreeVector &p) const |
| G4ThreeVector | SurfaceNormal (const G4ThreeVector &p) const |
| G4double | DistanceToIn (const G4ThreeVector &p, const G4ThreeVector &v) const |
| G4double | DistanceToIn (const G4ThreeVector &p) const |
| G4double | DistanceToOut (const G4ThreeVector &p, const G4ThreeVector &v, const G4bool calcNorm=false, G4bool *validNorm=0, G4ThreeVector *n=0) const |
| G4double | DistanceToOut (const G4ThreeVector &p) const |
| G4GeometryType | GetEntityType () const |
| G4ThreeVector | GetPointOnSurface () const |
| G4VSolid * | Clone () const |
| std::ostream & | StreamInfo (std::ostream &os) const |
| void | DescribeYourselfTo (G4VGraphicsScene &scene) const |
| G4Polyhedron * | CreatePolyhedron () const |
| void | BoundingLimits (G4ThreeVector &pMin, G4ThreeVector &pMax) const |
| Two vectors define an axis-parallel bounding box for the shape. | |
| BelleCrystal (__void__ &) | |
| Fake default constructor for usage restricted to direct object persistency for clients requiring preallocation of memory for persistifiable objects. | |
| BelleCrystal (const BelleCrystal &rhs) | |
| copy constructor | |
| BelleCrystal & | operator= (const BelleCrystal &rhs) |
| assignment operator | |
| G4ThreeVector | vertex (unsigned int i) const |
Protected Member Functions | |
| G4bool | MakePlane (const G4ThreeVector &p1, const G4ThreeVector &p2, const G4ThreeVector &p3, const G4ThreeVector &p4, Plane_t &plane) const |
Private Member Functions | |
| G4ThreeVector | GetPointOnTriangle (int) const |
| Returns a random point on the surface of one of the faces. | |
| double | area (int, double &) const |
| triangle area | |
| double | getvolarea () const |
| const unsigned int * | ivertx (unsigned int i) const |
| get the ith vertex | |
Private Attributes | |
| unsigned int | nsides |
| the number of sides | |
| double | fDz |
| std::vector< Plane_t > | fPlanes |
| std::vector< Point_t > | fx |
| std::vector< double > | fareas |
a Belle crystal in Geant4
Definition at line 34 of file BelleCrystal.h.
