QualityEstimatorMC Class Reference

Class implementing the algorithm used for the MC based quality estimation. More...

#include <QualityEstimatorMC.h>

Inheritance diagram for QualityEstimatorMC:

Collaboration diagram for QualityEstimatorMC:

Public Types
typedef int	MCRecoTrackIndex
	typedef for MCRecoTrackIndex
typedef unsigned int	NMatches
	typedef for counter of number of matches
typedef std::pair< MCRecoTrackIndex, NMatches >	MatchInfo
	typedef for MatchInfo

Public Member Functions
	QualityEstimatorMC (const std::string &mcRecoTracksStoreArrayName="MCRecoTracks", bool strictQualityIndicator=true, bool mva_target=false)
	Constructor. More...
virtual double	estimateQuality (std::vector< SpacePoint const * > const &measurements) final
	Performing MC based quality estimation. More...
virtual QualityEstimationResults	estimateQualityAndProperties (std::vector< SpacePoint const * > const &measurements) override final
	additionally return momentum_truth if it is a perfect match to a single MCRecoTrack
void	setClustersNames (const std::string &svdClustersName, const std::string &pxdClustersName)
	Setter for StoreArray names of SVD and PXD clusters. More...
void	setMagneticFieldStrength (double magneticFieldZ=1.5)
	Setter for z component of magnetic field. More...

Protected Member Functions
MatchInfo	getBestMatchToMCClusters (std::vector< SpacePoint const * > const &measurements)
	Get MCRecoTrack index of best matching tracks and number of matched MC clusters which can be matched to the given track candidate. More...
double	calculateQualityIndicator (unsigned int nClusters, MatchInfo &match)
	Calculate MC qualityIndicator based on MatchInfo of best matched MCRecoTrack. More...
double	calcPt (double const radius) const
	Returns a value for the transverse momentum in GeV calculated from a provided radius. More...

Protected Attributes
bool	m_strictQualityIndicator
	If true only SPTCs containing SVDClusters corresponding to a single MCRecoTrack get a QI != 0. More...
bool	m_mva_target
	If true the SPTCs containing all the SVDCluster of the corresponding MCRecoTrack and no other SVDCluster receive a Quality Index larger than one. More...
std::string	m_mcRecoTracksStoreArrayName
	MCRecoTracks StoreArray name.
std::string	m_svdClustersName = ""
	SVD clusters StoreArray name.
std::string	m_pxdClustersName = ""
	PXD clusters StoreArray name.
MatchInfo	m_match
	stores the current match for optional return values
StoreArray< RecoTrack >	m_mcRecoTracks
	the storeArray for RecoTracks as member
double	m_magneticFieldZ = 1.5
	Member storing the z component of the magnetic field.
QualityEstimationResults	m_results
	Result of the quality estimation This is stored as a member variable, because some values may be calculated by 'estimateQuality' anyways. More...

Detailed Description

Class implementing the algorithm used for the MC based quality estimation.

Definition at line 22 of file QualityEstimatorMC.h.

Constructor & Destructor Documentation

QualityEstimatorMC()

QualityEstimatorMC ( const std::string &  mcRecoTracksStoreArrayName = "MCRecoTracks", bool  strictQualityIndicator = true, bool  mva_target = false  )

inline

Constructor.

Parameters

mcRecoTracksStoreArrayName	: Name of the MCRecoTracks StoreArray
strictQualityIndicator	: boolean whether to perform strict estimation
mva_target	: Boolean whether to perform quality estimation for MVA QE training. This overwrites the strictQualityIndicator option!

Definition at line 35 of file QualityEstimatorMC.h.

                                                                                   :
      QualityEstimatorBase(), m_strictQualityIndicator(strictQualityIndicator), m_mva_target(mva_target),
      m_mcRecoTracksStoreArrayName(mcRecoTracksStoreArrayName)
    {
      m_mcRecoTracks.isRequired(m_mcRecoTracksStoreArrayName);
    };

Member Function Documentation

calcPt()

double calcPt ( double const  radius ) const

inlineprotectedinherited

Returns a value for the transverse momentum in GeV calculated from a provided radius.

Utilizing m_magneticFieldZ and hard coded speed of light

Definition at line 82 of file QualityEstimatorBase.h.

calculateQualityIndicator()

double calculateQualityIndicator ( unsigned int  nClusters, MatchInfo &  match  )

protected

Calculate MC qualityIndicator based on MatchInfo of best matched MCRecoTrack.

Parameters

nClusters	: number of clusters of the track candidate
match	: MatchInfo for the best match

Returns

qualityIndicator

Definition at line 52 of file QualityEstimatorMC.cc.

{
  double qualityIndicator = 0;
  if (m_mva_target) {
    if (nClusters == m_mcRecoTracks[match.first]->getNumberOfSVDHits()) {
      qualityIndicator = 1 - (1. / nClusters);
    }
  } else if (m_strictQualityIndicator) {
    if (nClusters == match.second) {
      qualityIndicator = 1 - (1. / nClusters);
    }
  } else {
    int nRecoTrackClusters =  m_mcRecoTracks[match.first]->getNumberOfSVDHits();
    qualityIndicator = std::pow(match.second, 3) / (nRecoTrackClusters * nClusters * nClusters);
  }
  return qualityIndicator;
}

estimateQuality()

double estimateQuality ( std::vector< SpacePoint const * > const &  measurements )

finalvirtual

Performing MC based quality estimation.

Parameters

measurements

: SPs of the track candidate to be evaluate

Returns

quality indicator value

Implements QualityEstimatorBase.

Definition at line 14 of file QualityEstimatorMC.cc.

getBestMatchToMCClusters()

QualityEstimatorMC::MatchInfo getBestMatchToMCClusters ( std::vector< SpacePoint const * > const &  measurements )

protected

Get MCRecoTrack index of best matching tracks and number of matched MC clusters which can be matched to the given track candidate.

Parameters

measurements

: SPs to be evaluated

Returns

MatchInfo containing the ID of the best matching MCRecoTracks and number of matched clusters

Definition at line 24 of file QualityEstimatorMC.cc.

setClustersNames()

void setClustersNames ( const std::string &  svdClustersName, const std::string &  pxdClustersName  )

inline

Setter for StoreArray names of SVD and PXD clusters.

Parameters

svdClustersName	: SVD cluster StoreArray name
pxdClustersName	: PXD cluster StoreArray name

Definition at line 56 of file QualityEstimatorMC.h.

setMagneticFieldStrength()

void setMagneticFieldStrength ( double  magneticFieldZ = 1.5 )

inlineinherited

Setter for z component of magnetic field.

Parameters

magneticFieldZ

: value to set it to

Definition at line 55 of file QualityEstimatorBase.h.

Member Data Documentation

m_mva_target

bool m_mva_target

protected

If true the SPTCs containing all the SVDCluster of the corresponding MCRecoTrack and no other SVDCluster receive a Quality Index larger than one.

To be used for MVA QE training if both high hit purity and hit efficiency is desired.

Definition at line 84 of file QualityEstimatorMC.h.

m_results

QualityEstimationResults m_results

protectedinherited

Result of the quality estimation This is stored as a member variable, because some values may be calculated by 'estimateQuality' anyways.

Therefore they don't need to be calculated explicitly in 'estimateQualityAndProperties'.

Definition at line 92 of file QualityEstimatorBase.h.

m_strictQualityIndicator

bool m_strictQualityIndicator

protected

If true only SPTCs containing SVDClusters corresponding to a single MCRecoTrack get a QI != 0.

If a SVDCluster corresponds to several MCRecoTracks it is still valid as long as the correct MCRecoTrack is one of them.

Definition at line 78 of file QualityEstimatorMC.h.

---

The documentation for this class was generated from the following files:

• tracking/trackFindingVXD/trackQualityEstimators/include/QualityEstimatorMC.h
• tracking/trackFindingVXD/trackQualityEstimators/src/QualityEstimatorMC.cc
