GeoFarBeamLineCreator Class Reference

The creator for the FarBeamLine geometry of the Belle II detector. More...

#include <GeoFarBeamLineCreator.h>

Inheritance diagram for GeoFarBeamLineCreator:
Inheritance graph
[legend]
Collaboration diagram for GeoFarBeamLineCreator:
Collaboration graph
[legend]

Public Member Functions

 GeoFarBeamLineCreator ()
 Constructor of the GeoFarBeamLineCreator class.

virtual ~GeoFarBeamLineCreator ()
 The destructor of the GeoFarBeamLineCreator class.

 GeoFarBeamLineCreator (const GeoFarBeamLineCreator &)=delete
 Do not want a copy constructor.

GeoFarBeamLineCreator & operator= (const GeoFarBeamLineCreator &)=delete
 Do not want an assignment operator.

virtual void create (const GearDir &content, G4LogicalVolume &topVolume, geometry::GeometryTypes type) override
 Creates the ROOT Objects for the FarBeamLine geometry. More...

virtual void createPayloads (const GearDir &content, const IntervalOfValidity &iov) override
 creates DB payload for FarBeamLineGeo class

virtual void createFromDB (const std::string &name, G4LogicalVolume &topVolume, geometry::GeometryTypes type) override
 Create the geometry from the Database.

 BELLE2_DEFINE_EXCEPTION (DBNotImplemented, "Cannot create geometry from Database.")
 Exception that will be thrown in createFromDB if member is not yet implemented by creator.


Protected Attributes

SensitiveDetector * m_sensitive
 Sensitive detector.

FarBeamLineGeo m_config
 geometry parameters object


Private Member Functions

FarBeamLineGeo createConfiguration (const GearDir &param)
 Reads IR geometry parameters from the xml files and createst DB class FarBeamLineGeo.

void createGeometry (G4LogicalVolume &topVolume, geometry::GeometryTypes type)
 Create detector geometry. More...


Detailed Description

The creator for the FarBeamLine geometry of the Belle II detector.


Definition at line 43 of file GeoFarBeamLineCreator.h.

Member Function Documentation

◆ create()

virtual void create ( const GearDir &  content,
G4LogicalVolume &  topVolume,
geometry::GeometryTypes  type
)
inlineoverridevirtual

Creates the ROOT Objects for the FarBeamLine geometry.

Parameters
contentA reference to the content part of the parameter description, which should to be used to create the ROOT objects.
topVolumeGeant4 logical top volume.
typeGeometry type.

Implements CreatorBase.

Definition at line 84 of file GeoFarBeamLineCreator.h.

85  {
86  m_config = createConfiguration(content);
87
88  // override geometry configuration from the DB
89  DBStore::Instance().addConstantOverride("FarBeamLineGeo", new FarBeamLineGeo(m_config));
90
91  createGeometry(topVolume, type);
92  }
Belle2::ir::GeoFarBeamLineCreator::m_config
FarBeamLineGeo m_config
geometry parameters object
Definition: GeoFarBeamLineCreator.h:118
Belle2::ir::GeoFarBeamLineCreator::createConfiguration
FarBeamLineGeo createConfiguration(const GearDir &param)
Reads IR geometry parameters from the xml files and createst DB class FarBeamLineGeo.
Definition: GeoFarBeamLineCreator.h:47
Belle2::ir::GeoFarBeamLineCreator::createGeometry
void createGeometry(G4LogicalVolume &topVolume, geometry::GeometryTypes type)
Create detector geometry.
Definition: GeoFarBeamLineCreator.cc:70
Belle2::DBStore::Instance
static DBStore & Instance()
Instance of a singleton DBStore.
Definition: DBStore.cc:26
Belle2::DBStore::addConstantOverride
void addConstantOverride(const std::string &name, TObject *obj, bool oneRun=false)
Add constant override payload.
Definition: DBStore.cc:194

◆ createGeometry()

void createGeometry ( G4LogicalVolume &  topVolume,
geometry::GeometryTypes  type
)
private

Create detector geometry.

Parameters
topVolumeGeant4 logical top volume.
typeGeometry type.

Definition at line 70 of file GeoFarBeamLineCreator.cc.

71  {
72
73  const int N = 2;
74
75  double stepMax = 5.0 * Unit::mm;
76  int flag_limitStep = int(m_config.getParameter("LimitStepLength"));
77
78
79  //double unitFactor = 10.0;
80  const double unitFactor = Unit::cm / Unit::mm;
81
82  map<string, FarBeamLineElement> elements;
83
84
85  //--------------
86  //- limits
87
88  //--------------
89  //- TubeR
90
91  FarBeamLineElement tubeR;
92
93  //get parameters from .xml file
94  std::string prep = "TubeR.";
95
96  int TubeR_N = int(m_config.getParameter(prep + "N"));
97
98  std::vector<double> TubeR_Z(TubeR_N);
99  std::vector<double> TubeR_R(TubeR_N);
100  std::vector<double> TubeR_r(TubeR_N);
101
102  for (int i = 0; i < TubeR_N; ++i) {
103  ostringstream ossZID;
104  ossZID << "Z" << i;
105
106  ostringstream ossRID;
107  ossRID << "R" << i;
108
109  ostringstream ossrID;
110  ossrID << "r" << i;
111
112  TubeR_Z[i] = m_config.getParameter(prep + ossZID.str()) * unitFactor;
113  TubeR_R[i] = m_config.getParameter(prep + ossRID.str()) * unitFactor;
114  TubeR_r[i] = m_config.getParameter(prep + ossrID.str(), 0.0) * unitFactor;
115  }
116
117  tubeR.transform = G4Translate3D(0.0, 0.0, 0.0);
118
119  //define geometry
120  tubeR.geo = new G4Polycone("geo_TubeR_name", 0.0, 2 * M_PI, TubeR_N, &(TubeR_Z[0]), &(TubeR_r[0]), &(TubeR_R[0]));
121
122  tubeR.logi = NULL;
123
124  elements["TubeR"] = tubeR;
125
126  //--------------
127  //- TubeL
128
129  FarBeamLineElement tubeL;
130
131  //get parameters from .xml file
132  prep = "TubeL.";
133
134  int TubeL_N = int(m_config.getParameter(prep + "N"));
135
136  std::vector<double> TubeL_Z(TubeL_N);
137  std::vector<double> TubeL_R(TubeL_N);
138  std::vector<double> TubeL_r(TubeL_N);
139
140  for (int i = 0; i < TubeL_N; ++i) {
141  ostringstream ossZID;
142  ossZID << "Z" << i;
143
144  ostringstream ossRID;
145  ossRID << "R" << i;
146
147  ostringstream ossrID;
148  ossrID << "r" << i;
149
150  TubeL_Z[i] = m_config.getParameter(prep + ossZID.str()) * unitFactor;
151  TubeL_R[i] = m_config.getParameter(prep + ossRID.str()) * unitFactor;
152  TubeL_r[i] = m_config.getParameter(prep + ossrID.str(), 0.0) * unitFactor;
153  }
154
155  tubeL.transform = G4Translate3D(0.0, 0.0, 0.0);
156
157  //define geometry
158  tubeL.geo = new G4Polycone("geo_TubeL_name", 0.0, 2 * M_PI, TubeL_N, &(TubeL_Z[0]), &(TubeL_r[0]), &(TubeL_R[0]));
159
160  tubeL.logi = NULL;
161
162  elements["TubeL"] = tubeL;
163
164  std::vector<double> zero_r(N, 0.);
165
166  std::vector<std::string> straightSections;
167  boost::split(straightSections, m_config.getParameterStr("Straight"), boost::is_any_of(" "));
168  for (const auto& name : straightSections) {
169  //--------------
170  //- Create straight element
171
172  prep = name + ".";
173  string type = m_config.getParameterStr(prep + "type");
174
175
176  FarBeamLineElement polycone;
177
178  std::vector<double> Polycone_Z(N);
179  std::vector<double> Polycone_R(N);
180  std::vector<double> Polycone_r(N);
181  Polycone_Z[0] = 0;
182  Polycone_Z[1] = m_config.getParameter(prep + "L") * unitFactor;
183  Polycone_R[0] = m_config.getParameter(prep + "R") * unitFactor;
184  Polycone_R[1] = m_config.getParameter(prep + "R") * unitFactor;
185  Polycone_r[0] = m_config.getParameter(prep + "r") * unitFactor;
186  Polycone_r[1] = m_config.getParameter(prep + "r") * unitFactor;
187
188  double Polycone_X0 = m_config.getParameter(prep + "X0") * unitFactor;
189  double Polycone_Z0 = m_config.getParameter(prep + "Z0") * unitFactor;
190  double Polycone_PHI = m_config.getParameter(prep + "PHI");
191
192  polycone.transform = G4Translate3D(Polycone_X0, 0.0, Polycone_Z0);
193  polycone.transform = polycone.transform * G4RotateY3D(Polycone_PHI / Unit::rad);
194
195  //define geometry
196  string subtract = m_config.getParameterStr(prep + "Subtract", "");
197  string intersect = m_config.getParameterStr(prep + "Intersect", "");
198
199  string geo_polyconexx_name = "geo_" + name + "xx_name";
200  string geo_polyconex_name = "geo_" + name + "x_name";
201  string geo_polycone_name = "geo_" + name + "_name";
202
203  G4VSolid* geo_polyconexx(NULL), *geo_polycone(NULL);
204
205  if (subtract != "" || intersect != "")
206  if (type == "pipe") // for pipes inner space will be created as vacuum
207  geo_polyconexx = new G4Polycone(geo_polyconexx_name, 0.0, 2 * M_PI, N, &(Polycone_Z[0]), &(zero_r[0]), &(Polycone_R[0]));
208  else
209  geo_polyconexx = new G4Polycone(geo_polyconexx_name, 0.0, 2 * M_PI, N, &(Polycone_Z[0]), &(Polycone_r[0]), &(Polycone_R[0]));
210  else if (type == "pipe") // for pipes inner space will be created as vacuum
211  geo_polycone = new G4Polycone(geo_polycone_name, 0.0, 2 * M_PI, N, &(Polycone_Z[0]), &(zero_r[0]), &(Polycone_R[0]));
212  else
213  geo_polycone = new G4Polycone(geo_polycone_name, 0.0, 2 * M_PI, N, &(Polycone_Z[0]), &(Polycone_r[0]), &(Polycone_R[0]));
214
215
216  if (subtract != "" && intersect != "") {
217  G4VSolid* geo_polyconex = new G4SubtractionSolid(geo_polyconex_name, geo_polyconexx, elements[subtract].geo,
218  polycone.transform.inverse()*elements[subtract].transform);
219  geo_polycone = new G4IntersectionSolid(geo_polycone_name, geo_polyconex, elements[intersect].geo,
220  polycone.transform.inverse()*elements[intersect].transform);
221  } else if (subtract != "")
222  geo_polycone = new G4SubtractionSolid(geo_polycone_name, geo_polyconexx, elements[subtract].geo,
223  polycone.transform.inverse()*elements[subtract].transform);
224  else if (intersect != "")
225  geo_polycone = new G4IntersectionSolid(geo_polycone_name, geo_polyconexx, elements[intersect].geo,
226  polycone.transform.inverse()*elements[intersect].transform);
227
228  polycone.geo = geo_polycone;
229
230  // define logical volume
231  string strMat_polycone = m_config.getParameterStr(prep + "Material");
232  G4Material* mat_polycone = Materials::get(strMat_polycone);
233  string logi_polycone_name = "logi_" + name + "_name";
234  G4LogicalVolume* logi_polycone = new G4LogicalVolume(polycone.geo, mat_polycone, logi_polycone_name);
235  setColor(*logi_polycone, "#CC0000");
236  setVisibility(*logi_polycone, false);
237
238  polycone.logi = logi_polycone;
239
240  //put volume
241  string phys_polycone_name = "phys_" + name + "_name";
242  new G4PVPlacement(polycone.transform, logi_polycone, phys_polycone_name, &topVolume, false, 0);
243
244  elements[name] = polycone;
245
246  double sum = 0.0;
247  for (int i = 0; i < N; ++i)
248  sum += Polycone_r[i]; // check that there is a space inside a pipe
249  if (type == "pipe" && sum != 0) { // add vacuum inside a pipe
250
251  FarBeamLineElement vacuum;
252
253  string nameVac = name + "Vac";
254
255  //define geometry
256  string geo_vacuumxx_name = "geo_" + nameVac + "xx_name";
257  string geo_vacuum_name = "geo_" + nameVac + "_name";
258
259  G4VSolid* geo_vacuumxx, *geo_vacuum;
260
261  geo_vacuumxx = new G4Polycone(geo_vacuumxx_name, 0.0, 2 * M_PI, N, &(Polycone_Z[0]), &(zero_r[0]), &(Polycone_r[0]));
262  geo_vacuum = new G4IntersectionSolid(geo_vacuumxx_name, geo_vacuumxx, geo_polycone);
263
264  vacuum.geo = geo_vacuum;
265  vacuum.transform = polycone.transform;
266
267  // define logical volume
268  G4Material* mat_vacuum = Materials::get("Vacuum");
269  string logi_vacuum_name = "logi_" + nameVac + "_name";
270  G4LogicalVolume* logi_vacuum = new G4LogicalVolume(vacuum.geo, mat_vacuum, logi_vacuum_name);
271  if (flag_limitStep) logi_vacuum->SetUserLimits(new G4UserLimits(stepMax));
272  setColor(*logi_vacuum, "#000000");
273  setVisibility(*logi_vacuum, false);
274
275  vacuum.logi = logi_vacuum;
276
277  //put volume
278  string phys_vacuum_name = "phys_" + nameVac + "_name";
279  //new G4PVPlacement(vacuum.transform, logi_vacuum, phys_vacuum_name, &topVolume, false, 0);
280  new G4PVPlacement(0, G4ThreeVector(0, 0, 0), logi_vacuum, phys_vacuum_name, logi_polycone, false, 0);
281
282  elements[nameVac] = vacuum;
283  }
284  }
285
286
287  std::vector<std::string> bendingSections;
288  boost::split(bendingSections, m_config.getParameterStr("Bending"), boost::is_any_of(" "));
289  for (const auto& name : bendingSections) {
290  //--------------
291  //- Create torus element
292
293  prep = name + ".";
294  string type = m_config.getParameterStr(prep + "type");
295
296  FarBeamLineElement torus;
297
298  double torus_r = m_config.getParameter(prep + "r") * unitFactor;
299  double torus_R = m_config.getParameter(prep + "R") * unitFactor;
300  double torus_RT = m_config.getParameter(prep + "RT") * unitFactor;
301  double torus_X0 = m_config.getParameter(prep + "X0") * unitFactor;
302  double torus_Z0 = m_config.getParameter(prep + "Z0") * unitFactor;
303  double torus_SPHI = m_config.getParameter(prep + "SPHI");
304  double torus_DPHI = m_config.getParameter(prep + "DPHI");
305
306  torus.transform = G4Translate3D(torus_X0, 0.0, torus_Z0);
307  torus.transform = torus.transform * G4RotateX3D(M_PI / 2 / Unit::rad);
308
309  //define geometry
310  string subtract = m_config.getParameterStr(prep + "Subtract", "");
311  string intersect = m_config.getParameterStr(prep + "Intersect", "");
312
313  string geo_torusxx_name = "geo_" + name + "xx_name";
314  string geo_torusx_name = "geo_" + name + "x_name";
315  string geo_torus_name = "geo_" + name + "_name";
316
317  G4VSolid* geo_torusxx(NULL), *geo_torus(NULL);
318
319  if (subtract != "" || intersect != "")
320  if (type == "pipe") // for pipes inner space will be created as vacuum
321  geo_torusxx = new G4Torus(geo_torusxx_name, 0, torus_R, torus_RT, torus_SPHI, torus_DPHI);
322  else
323  geo_torusxx = new G4Torus(geo_torusxx_name, torus_r, torus_R, torus_RT, torus_SPHI, torus_DPHI);
324  else if (type == "pipe") // for pipes inner space will be created as vacuum
325  geo_torus = new G4Torus(geo_torus_name, 0, torus_R, torus_RT, torus_SPHI, torus_DPHI);
326  else
327  geo_torus = new G4Torus(geo_torus_name, torus_r, torus_R, torus_RT, torus_SPHI, torus_DPHI);
328
329  if (subtract != "" && intersect != "") {
330  G4VSolid* geo_torusx = new G4SubtractionSolid(geo_torusx_name, geo_torusxx, elements[subtract].geo,
331  torus.transform.inverse()*elements[subtract].transform);
332  geo_torus = new G4IntersectionSolid(geo_torus_name, geo_torusx, elements[intersect].geo,
333  torus.transform.inverse()*elements[intersect].transform);
334  } else if (subtract != "")
335  geo_torus = new G4SubtractionSolid(geo_torus_name, geo_torusxx, elements[subtract].geo,
336  torus.transform.inverse()*elements[subtract].transform);
337  else if (intersect != "")
338  geo_torus = new G4IntersectionSolid(geo_torus_name, geo_torusxx, elements[intersect].geo,
339  torus.transform.inverse()*elements[intersect].transform);
340
341  torus.geo = geo_torus;
342
343  // define logical volume
344  string strMat_torus = m_config.getParameterStr(prep + "Material");
345  G4Material* mat_torus = Materials::get(strMat_torus);
346  string logi_torus_name = "logi_" + name + "_name";
347  G4LogicalVolume* logi_torus = new G4LogicalVolume(torus.geo, mat_torus, logi_torus_name);
348  setColor(*logi_torus, "#CC0000");
349  setVisibility(*logi_torus, false);
350
351  torus.logi = logi_torus;
352
353  //put volume
354  string phys_torus_name = "phys_" + name + "_name";
355  new G4PVPlacement(torus.transform, logi_torus, phys_torus_name, &topVolume, false, 0);
356
357  elements[name] = torus;
358
359  if (type == "pipe" && torus_r != 0) { // add vacuum inside a pipe
360
361  FarBeamLineElement vacuum;
362
363  string nameVac = name + "Vac";
364
365  //define geometry
366  string geo_vacuumxx_name = "geo_" + nameVac + "xx_name";
367  string geo_vacuum_name = "geo_" + nameVac + "_name";
368
369  G4VSolid* geo_vacuumxx, *geo_vacuum;
370
371  geo_vacuumxx = new G4Torus(geo_vacuumxx_name, 0.0, torus_r, torus_RT, torus_SPHI, torus_DPHI);
372  geo_vacuum = new G4IntersectionSolid(geo_vacuum_name, geo_vacuumxx, geo_torus);
373
374  vacuum.geo = geo_vacuum;
375  vacuum.transform = torus.transform;
376
377  // define logical volume
378  G4Material* mat_vacuum = Materials::get("Vacuum");
379  string logi_vacuum_name = "logi_" + nameVac + "_name";
380  G4LogicalVolume* logi_vacuum = new G4LogicalVolume(vacuum.geo, mat_vacuum, logi_vacuum_name);
381  if (flag_limitStep) logi_vacuum->SetUserLimits(new G4UserLimits(stepMax));
382  setColor(*logi_vacuum, "#000000");
383  setVisibility(*logi_vacuum, false);
384
385  vacuum.logi = logi_vacuum;
386
387  //put volume
388  string phys_vacuum_name = "phys_" + nameVac + "_name";
389  //new G4PVPlacement(vacuum.transform, logi_vacuum, phys_vacuum_name, &topVolume, false, 0);
390  new G4PVPlacement(0, G4ThreeVector(0, 0, 0), logi_vacuum, phys_vacuum_name, logi_torus, false, 0);
391
392  elements[nameVac] = vacuum;
393  }
394  }
395
396
397  //--------------
398  //- concrete wall
399
400  //--------------
401  //- GateShield (gate shield)
402
403  //get parameters from .xml file
404  prep = "GateShield.";
405
406  double GateShield_X = m_config.getParameter(prep + "X") * unitFactor;
407  double GateShield_Y = m_config.getParameter(prep + "Y") * unitFactor;
408  double GateShield_Z = m_config.getParameter(prep + "Z") * unitFactor;
409  double TUN_X = m_config.getParameter(prep + "TUNX") * unitFactor;
410  double TUN_Y = m_config.getParameter(prep + "TUNY") * unitFactor;
411  double DET_Z = m_config.getParameter(prep + "DETZ") * unitFactor;
412  double DET_DZ = m_config.getParameter(prep + "DETDZ") * unitFactor;
413  double ROT = m_config.getParameter(prep + "ROT");
414
415  G4Transform3D transform_DET = G4Translate3D(0.0, 0.0, DET_DZ);
416  G4Transform3D transform_ROT = G4Translate3D(0.0, 0.0, 0.0);
417  transform_ROT = transform_ROT * G4RotateY3D(ROT / Unit::rad);
418
419  //define geometry
420  // wall is made from the box by excluding spaces for detector and tunnel
421  G4Box* geo_GateShieldxx = new G4Box("geo_GateShieldxx_name", GateShield_X, GateShield_Y, GateShield_Z);
422  G4Box* geo_TUN = new G4Box("geo_TUN_name", TUN_X, TUN_Y, GateShield_Z);
423  G4SubtractionSolid* geo_GateShieldx = new G4SubtractionSolid("geo_GateShieldx_name", geo_GateShieldxx, geo_TUN);
424  G4Box* geo_DET = new G4Box("geo_DET_name", GateShield_X, GateShield_Y, DET_Z);
425  G4SubtractionSolid* geo_GateShield = new G4SubtractionSolid("geo_GateShield_name", geo_GateShieldx, geo_DET, transform_DET);
426
427  string strMat_GateShield = m_config.getParameterStr(prep + "Material");
428  G4Material* mat_GateShield = Materials::get(strMat_GateShield);
429  G4LogicalVolume* logi_GateShield = new G4LogicalVolume(geo_GateShield, mat_GateShield, "logi_GateShield_name");
430
431  //put volume
432  setColor(*logi_GateShield, "#CC0000");
433  //setVisibility(*logi_GateShield, false);
434  new G4PVPlacement(transform_ROT, logi_GateShield, "phys_GateShield_name", &topVolume, false, 0);
435
436
437
438  //--------------
439  //- Tube (virtual tube for radiation level study)
440
441  //define geometry
442  G4Tubs* geo_Tube = new G4Tubs("geo_Tube_name", 3995 * CLHEP::mm, 4000 * CLHEP::mm, 29 * CLHEP::m, 0. * CLHEP::deg, 360.*CLHEP::deg);
443  G4Material* mat_Tube = Materials::get("G4_Si");
444  G4LogicalVolume* logi_Tube = new G4LogicalVolume(geo_Tube, mat_Tube, "logi_Tube_name");
445
446  //put volume
447  setColor(*logi_Tube, "#CC0000");
448  //setVisibility(*logi_Tube, false);
449  bool radiation_study = false;
450  // cppcheck-suppress knownConditionTrueFalse
451  if (radiation_study) {
452  new G4PVPlacement(transform_ROT, logi_Tube, "phys_Tube_name", &topVolume, false, 0);
453  }
454
455
456  //--------------
457  //- polyethylene shields
458
459  //--------------
460  //- PolyShieldR
461
462  //get parameters from .xml file
463  prep = "PolyShieldR.";
464
465  double PolyShieldR_Xp = m_config.getParameter(prep + "Xp") * unitFactor;
466  double PolyShieldR_Xm = m_config.getParameter(prep + "Xm") * unitFactor;
467  double PolyShieldR_Y = m_config.getParameter(prep + "Y") * unitFactor;
468  double PolyShieldR_Z = m_config.getParameter(prep + "Z") * unitFactor;
469  double PolyShieldR_DZ = m_config.getParameter(prep + "DZ") * unitFactor;
470  double PolyShieldR_r = m_config.getParameter(prep + "r") * unitFactor;
471  double PolyShieldR_dx = m_config.getParameter(prep + "dx") * unitFactor;
472
473  double PolyShieldR_X = (PolyShieldR_Xp + PolyShieldR_Xm) / 2;
474  G4Transform3D transform_polyShieldR = G4Translate3D((PolyShieldR_Xp - PolyShieldR_Xm) / 2, 0.0, PolyShieldR_DZ);
475  G4Transform3D transform_polyShieldR_Hole = G4Translate3D(PolyShieldR_dx, 0.0, 0.0);
476
477  //define geometry
478  G4Box* geo_polyShieldRx = new G4Box("geo_polyShieldRx_name", PolyShieldR_X, PolyShieldR_Y, PolyShieldR_Z);
479  G4Tubs* geo_polyShieldR_Hole = new G4Tubs("geo_polyShieldRxx_name", 0 * CLHEP::mm, PolyShieldR_r, PolyShieldR_Z, 0. * CLHEP::deg,
480  360.*CLHEP::deg);
481  G4SubtractionSolid* geo_polyShieldR
482  = new G4SubtractionSolid("geo_polyShieldR_name", geo_polyShieldRx, geo_polyShieldR_Hole, transform_polyShieldR_Hole);
483
484  string strMat_polyShieldR = m_config.getParameterStr(prep + "Material");
485  G4Material* mat_polyShieldR = Materials::get(strMat_polyShieldR);
486  G4LogicalVolume* logi_polyShieldR = new G4LogicalVolume(geo_polyShieldR, mat_polyShieldR, "logi_polyShieldR_name");
487
488  //put volume
489  setColor(*logi_polyShieldR, "#0000CC");
490  //setVisibility(*logi_polyShieldL, false);
491  new G4PVPlacement(transform_polyShieldR, logi_polyShieldR, "phys_polyShieldR_name", &topVolume, false, 0);
492
493  //--------------
494  //- PolyShieldL
495
496  //get parameters from .xml file
497  prep = "PolyShieldL.";
498
499  double PolyShieldL_Xp = m_config.getParameter(prep + "Xp") * unitFactor;
500  double PolyShieldL_Xm = m_config.getParameter(prep + "Xm") * unitFactor;
501  double PolyShieldL_Y = m_config.getParameter(prep + "Y") * unitFactor;
502  double PolyShieldL_Z = m_config.getParameter(prep + "Z") * unitFactor;
503  double PolyShieldL_DZ = m_config.getParameter(prep + "DZ") * unitFactor;
504  double PolyShieldL_r = m_config.getParameter(prep + "r") * unitFactor;
505  double PolyShieldL_dx = m_config.getParameter(prep + "dx") * unitFactor;
506
507  double PolyShieldL_X = (PolyShieldL_Xp + PolyShieldL_Xm) / 2;
508  G4Transform3D transform_polyShieldL = G4Translate3D((PolyShieldL_Xp - PolyShieldL_Xm) / 2, 0.0, PolyShieldL_DZ);
509  G4Transform3D transform_polyShieldL_Hole = G4Translate3D(PolyShieldL_dx, 0.0, 0.0);
510
511  //define geometry
512  G4Box* geo_polyShieldLxx = new G4Box("geo_polyShieldLxx_name", PolyShieldL_X, PolyShieldL_Y, PolyShieldL_Z);
513  G4Tubs* geo_polyShieldL_Hole = new G4Tubs("geo_polyShieldLxxx_name", 0 * CLHEP::mm, PolyShieldL_r, PolyShieldL_Z, 0. * CLHEP::deg,
514  360.*CLHEP::deg);
515  G4SubtractionSolid* geo_polyShieldLx
516  = new G4SubtractionSolid("geo_polyShieldLx_name", geo_polyShieldLxx, geo_polyShieldL_Hole, transform_polyShieldL_Hole);
517  G4SubtractionSolid* geo_polyShieldL
518  = new G4SubtractionSolid("geo_polyShieldL_name", geo_polyShieldLx, geo_GateShield, transform_polyShieldL.inverse()*transform_ROT);
519
520  string strMat_polyShieldL = m_config.getParameterStr(prep + "Material");
521  G4Material* mat_polyShieldL = Materials::get(strMat_polyShieldL);
522  G4LogicalVolume* logi_polyShieldL = new G4LogicalVolume(geo_polyShieldL, mat_polyShieldL, "logi_polyShieldL_name");
523
524  //put volume
525  setColor(*logi_polyShieldL, "#0000CC");
526  //setVisibility(*logi_polyShieldL, false);
527  new G4PVPlacement(transform_polyShieldL, logi_polyShieldL, "phys_polyShieldL_name", &topVolume, false, 0);
528
529  //--------------
530  //- concrete tunnel-end shields
531
532  //--------------
533  //- ConcreteShieldR
534
535  //get parameters from .xml file
536  prep = "ConcreteShieldR.";
537
538  double ConcreteShieldR_X = m_config.getParameter(prep + "X") * unitFactor;
539  double ConcreteShieldR_Y = m_config.getParameter(prep + "Y") * unitFactor;
540  double ConcreteShieldR_Z = m_config.getParameter(prep + "Z") * unitFactor;
541  double ConcreteShieldR_DZ = m_config.getParameter(prep + "DZ") * unitFactor;
542  double ConcreteShieldR_x = m_config.getParameter(prep + "x") * unitFactor;
543  double ConcreteShieldR_y = m_config.getParameter(prep + "y") * unitFactor;
544  double ConcreteShieldR_dx = m_config.getParameter(prep + "dx") * unitFactor;
545  double ConcreteShieldR_dy = m_config.getParameter(prep + "dy") * unitFactor;
546
547  G4Transform3D transform_ConcreteShieldR = G4Translate3D(0.0, 0.0, ConcreteShieldR_DZ);
548  transform_ConcreteShieldR = transform_ROT * transform_ConcreteShieldR;
549  G4Transform3D transform_ConcreteShieldR_Hole = G4Translate3D(ConcreteShieldR_dx, ConcreteShieldR_dy, 0.0);
550
551
552  //define geometry
553  G4Box* geo_ConcreteShieldRx = new G4Box("geo_ConcreteShieldRx_name", ConcreteShieldR_X, ConcreteShieldR_Y, ConcreteShieldR_Z);
554  G4Box* geo_ConcreteShieldR_Hole = new G4Box("geo_ConcreteShieldRxx_name", ConcreteShieldR_x, ConcreteShieldR_y, ConcreteShieldR_Z);
555  G4SubtractionSolid* geo_ConcreteShieldR = new G4SubtractionSolid("geo_ConcreteShieldR_name", geo_ConcreteShieldRx,
556  geo_ConcreteShieldR_Hole, transform_ConcreteShieldR_Hole);
557
558  string strMat_ConcreteShieldR = m_config.getParameterStr(prep + "Material");
559  G4Material* mat_ConcreteShieldR = Materials::get(strMat_ConcreteShieldR);
560  G4LogicalVolume* logi_ConcreteShieldR = new G4LogicalVolume(geo_ConcreteShieldR, mat_ConcreteShieldR, "logi_ConcreteShieldR_name");
561
562  //put volume
563  setColor(*logi_ConcreteShieldR, "#0000CC");
564  //setVisibility(*logi_ConcreteShieldR, false);
565  new G4PVPlacement(transform_ConcreteShieldR, logi_ConcreteShieldR, "phys_ConcreteShieldR_name", &topVolume, false, 0);
566
567  //--------------
568  //- ConcreteShieldL
569
570  //get parameters from .xml file
571  prep = "ConcreteShieldL.";
572
573  double ConcreteShieldL_X = m_config.getParameter(prep + "X") * unitFactor;
574  double ConcreteShieldL_Y = m_config.getParameter(prep + "Y") * unitFactor;
575  double ConcreteShieldL_Z = m_config.getParameter(prep + "Z") * unitFactor;
576  double ConcreteShieldL_DZ = m_config.getParameter(prep + "DZ") * unitFactor;
577  double ConcreteShieldL_x = m_config.getParameter(prep + "x") * unitFactor;
578  double ConcreteShieldL_y = m_config.getParameter(prep + "y") * unitFactor;
579  double ConcreteShieldL_dx = m_config.getParameter(prep + "dx") * unitFactor;
580  double ConcreteShieldL_dy = m_config.getParameter(prep + "dy") * unitFactor;
581
582  G4Transform3D transform_ConcreteShieldL = G4Translate3D(0.0, 0.0, ConcreteShieldL_DZ);
583  transform_ConcreteShieldL = transform_ROT * transform_ConcreteShieldL;
584  G4Transform3D transform_ConcreteShieldL_Hole = G4Translate3D(ConcreteShieldL_dx, ConcreteShieldL_dy, 0.0);
585
586  //define geometry
587  G4Box* geo_ConcreteShieldLx = new G4Box("geo_ConcreteShieldLx_name", ConcreteShieldL_X, ConcreteShieldL_Y, ConcreteShieldL_Z);
588  G4Box* geo_ConcreteShieldL_Hole = new G4Box("geo_ConcreteShieldLxx_name", ConcreteShieldL_x, ConcreteShieldL_y, ConcreteShieldL_Z);
589  G4SubtractionSolid* geo_ConcreteShieldL = new G4SubtractionSolid("geo_ConcreteShieldL_name", geo_ConcreteShieldLx,
590  geo_ConcreteShieldL_Hole, transform_ConcreteShieldL_Hole);
591
592  string strMat_ConcreteShieldL = m_config.getParameterStr(prep + "Material");
593  G4Material* mat_ConcreteShieldL = Materials::get(strMat_ConcreteShieldL);
594  G4LogicalVolume* logi_ConcreteShieldL = new G4LogicalVolume(geo_ConcreteShieldL, mat_ConcreteShieldL, "logi_ConcreteShieldL_name");
595
596  //put volume
597  setColor(*logi_ConcreteShieldL, "#0000CC");
598  //setVisibility(*logi_ConcreteShieldL, false);
599  new G4PVPlacement(transform_ConcreteShieldL, logi_ConcreteShieldL, "phys_ConcreteShieldL_name", &topVolume, false, 0);
600
601
602  //---------------------------
603  // for dose simulation
604  //---------------------------
605
606  //neutron shield (poly)
607  //logi_polyShieldL->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1001));
608  //logi_polyShieldR->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1002));
609
610  //additional neutron shield (concrete)
611  //logi_ConcreteShieldL->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1003));
612  //logi_ConcreteShieldR->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1004));
613
614  //gate shield (concrete)
615  //logi_GateShield->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1005));
616
617  //virtual material outsire gate-shield
618
619  // cppcheck-suppress knownConditionTrueFalse
620  if (radiation_study) {
621  logi_Tube->SetSensitiveDetector(new BkgSensitiveDetector("IR", 1006));
622  }
623
624
625  //------------------
626  //- Collimators
627
628  std::vector<std::string> collimators;
629  boost::split(collimators, m_config.getParameterStr("Collimator"), boost::is_any_of(" "));
630  for (const auto& name : collimators) {
631  //- Collimators consist of two independent jaws (trapezoids), identical in shape, positioned opposite to each other
632  //- Each jaw consists of copper body and high Z head
633
634  prep = name + ".";
635
636  string type = m_config.getParameterStr(prep + "type");
637  string motherVolume = m_config.getParameterStr(prep + "MotherVolume");
638  string motherVolumeVacuum = motherVolume + "Vac";
639
640  // If zz < 0 (positioned at negative z) vertical collimator is flipped when rotated into Mother Volume system
641  G4Scale3D scale;
642  G4Rotate3D rotation;
643  G4Translate3D translation;
644  elements[motherVolumeVacuum].transform.getDecomposition(scale, rotation, translation);
645  double zz = rotation.zz();
646
647  // d1, d2 are collimator jaws displacements from beam center, d1<0, d2>0
648  // Z is collimator position inside its Mother Volume
649  double collimator_d1 = m_config.getParameter(prep + "d1") * unitFactor;
650  double collimator_d2 = m_config.getParameter(prep + "d2") * unitFactor;
651  double collimator_fullH = m_config.getParameter(prep + "fullH") * unitFactor;
652  double collimator_headH = m_config.getParameter(prep + "headH") * unitFactor;
653  double collimator_minW = m_config.getParameter(prep + "minW") * unitFactor;
654  double collimator_maxW = m_config.getParameter(prep + "maxW") * unitFactor;
655  double collimator_th = m_config.getParameter(prep + "th") * unitFactor;
656  double collimator_Z = m_config.getParameter(prep + "Z") * unitFactor;
657
658  B2WARNING("Collimator " << name << " displacement d1 is set to " << collimator_d1 << "mm (must be less than zero)");
659  B2WARNING("Collimator " << name << " displacement d2 is set to " << collimator_d2 << "mm (must be greater than zero)");
660
661
662  // Collimator heads
663
664  // dx1,2 dy1,2 dz are trapezoid dimensions
665  double head_dx1;
666  double head_dx2;
667  double head_dy1;
668  double head_dy2;
669  double head_dz = collimator_headH / 2.0;
670  if (type == "vertical") {
671  head_dx1 = collimator_th / 2.0;
672  head_dx2 = collimator_th / 2.0;
673  head_dy1 = ((collimator_maxW - collimator_minW) * collimator_headH / collimator_fullH + collimator_minW) / 2.0;
674  head_dy2 = collimator_minW / 2.0;
675  } else {
676  head_dx1 = ((collimator_maxW - collimator_minW) * collimator_headH / collimator_fullH + collimator_minW) / 2.0;
677  head_dx2 = collimator_minW / 2.0;
678  head_dy1 = collimator_th / 2.0;
679  head_dy2 = collimator_th / 2.0;
680  }
681
682  // storable elements
683  FarBeamLineElement collimator_head1;
684  FarBeamLineElement collimator_head2;
685
686  // move collimator to position on beam line
687  G4Transform3D transform_head1 = G4Translate3D(0.0, 0.0, collimator_Z);
688  G4Transform3D transform_head2 = G4Translate3D(0.0, 0.0, collimator_Z);
689
690  // rotate and move collimator jaws to their relative positions
691  if (type == "vertical") {
692  transform_head1 = transform_head1 * G4Translate3D(0.0, -head_dz + collimator_d1, 0.0);
693  transform_head1 = transform_head1 * G4RotateX3D(-M_PI / 2 / Unit::rad);
694
695  transform_head2 = transform_head2 * G4Translate3D(0.0, head_dz + collimator_d2, 0.0);
696  transform_head2 = transform_head2 * G4RotateX3D(M_PI / 2 / Unit::rad);
697  } else {
698  if (zz > 0) {
699  transform_head1 = transform_head1 * G4Translate3D(-head_dz + collimator_d1, 0.0, 0.0);
700  transform_head1 = transform_head1 * G4RotateY3D(M_PI / 2 / Unit::rad);
701
702  transform_head2 = transform_head2 * G4Translate3D(head_dz + collimator_d2, 0.0, 0.0);
703  transform_head2 = transform_head2 * G4RotateY3D(-M_PI / 2 / Unit::rad);
704  } else {
705  transform_head1 = transform_head1 * G4Translate3D(head_dz - collimator_d1, 0.0, 0.0);
706  transform_head1 = transform_head1 * G4RotateY3D(-M_PI / 2 / Unit::rad);
707
708  transform_head2 = transform_head2 * G4Translate3D(-head_dz - collimator_d2, 0.0, 0.0);
709  transform_head2 = transform_head2 * G4RotateY3D(M_PI / 2 / Unit::rad);
710  }
711  }
712
713  collimator_head1.transform = transform_head1;
714  collimator_head2.transform = transform_head2;
715
716  // define geometry
717  string geo_headx_name = "geo_" + name + "_headx_name";
718
719  string geo_head1_name = "geo_" + name + "_head1_name";
720  string geo_head2_name = "geo_" + name + "_head2_name";
721
722  G4VSolid* geo_headx = new G4Trd(geo_headx_name, head_dx1, head_dx2, head_dy1, head_dy2, head_dz);
723
724  G4VSolid* geo_head1 = new G4IntersectionSolid(geo_head1_name, geo_headx, elements[motherVolumeVacuum].geo,
725  collimator_head1.transform.inverse());
726  G4VSolid* geo_head2 = new G4IntersectionSolid(geo_head2_name, geo_headx, elements[motherVolumeVacuum].geo,
727  collimator_head2.transform.inverse());
728
729  collimator_head1.geo = geo_head1;
730  collimator_head2.geo = geo_head2;
731
732  // define logical volume
733  string strMat_head = m_config.getParameterStr(prep + "HeadMaterial");
734  G4Material* mat_head = Materials::get(strMat_head);
735  string logi_head1_name = "logi_" + name + "_head1_name";
736  string logi_head2_name = "logi_" + name + "_head2_name";
737  G4LogicalVolume* logi_head1 = new G4LogicalVolume(geo_head1, mat_head, logi_head1_name);
738  G4LogicalVolume* logi_head2 = new G4LogicalVolume(geo_head2, mat_head, logi_head2_name);
739  setColor(*logi_head1, "#CC0000");
740  setColor(*logi_head2, "#CC0000");
741  setVisibility(*logi_head1, false);
742  setVisibility(*logi_head2, false);
743
744  // check if collimator is inside beam pipe
745  double volume_head1 = logi_head1->GetSolid()->GetCubicVolume();
746  double volume_head2 = logi_head2->GetSolid()->GetCubicVolume();
747
748  collimator_head1.logi = logi_head1;
749  collimator_head2.logi = logi_head2;
750
751  // put volume
752  string phys_head1_name = "phys_" + name + "_head1" + "_name";
753  string phys_head2_name = "phys_" + name + "_head2" + "_name";
754  if (volume_head1 != 0)
755  new G4PVPlacement(collimator_head1.transform, logi_head1, phys_head1_name, elements[motherVolumeVacuum].logi, false, 0);
756  if (volume_head2 != 0)
757  new G4PVPlacement(collimator_head2.transform, logi_head2, phys_head2_name, elements[motherVolumeVacuum].logi, false, 0);
758
759  // to use it later in "intersect" and "subtract"
760  collimator_head1.transform = collimator_head1.transform * elements[motherVolumeVacuum].transform;
761  collimator_head2.transform = collimator_head2.transform * elements[motherVolumeVacuum].transform;
762
763  string name_head1 = name + "_head1";
764  string name_head2 = name + "_head2";
765  elements[name_head1] = collimator_head1;
766  elements[name_head2] = collimator_head2;
767
768
769  // Collimator bodies
770
771  // dx1,2 dy1,2 dz are trapezoid dimensions
772  double body_dx1;
773  double body_dx2;
774  double body_dy1;
775  double body_dy2;
776  double body_dz = (collimator_fullH - collimator_headH) / 2.0;
777  if (type == "vertical") {
778  body_dx1 = collimator_th / 2.0;
779  body_dx2 = collimator_th / 2.0;
780  body_dy1 = collimator_maxW / 2.0;
781  body_dy2 = ((collimator_maxW - collimator_minW) * collimator_headH / collimator_fullH + collimator_minW) / 2.0;
782  } else {
783  body_dx1 = collimator_maxW / 2.0;
784  body_dx2 = ((collimator_maxW - collimator_minW) * collimator_headH / collimator_fullH + collimator_minW) / 2.0;
785  body_dy1 = collimator_th / 2.0;
786  body_dy2 = collimator_th / 2.0;
787  }
788
789  // storable elements
790  FarBeamLineElement collimator_body1;
791  FarBeamLineElement collimator_body2;
792
793  // reuse head transfomation with additional shift
794  if (type == "vertical") {
795  collimator_body1.transform = G4Translate3D(0.0, -head_dz - body_dz, 0.0) * transform_head1;
796  collimator_body2.transform = G4Translate3D(0.0, head_dz + body_dz, 0.0) * transform_head2;
797  } else {
798  if (zz > 0) {
799  collimator_body1.transform = G4Translate3D(-head_dz - body_dz, 0.0, 0.0) * transform_head1;
800  collimator_body2.transform = G4Translate3D(head_dz + body_dz, 0.0, 0.0) * transform_head2;
801  } else {
802  collimator_body1.transform = G4Translate3D(head_dz + body_dz, 0.0, 0.0) * transform_head1;
803  collimator_body2.transform = G4Translate3D(-head_dz - body_dz, 0.0, 0.0) * transform_head2;
804  }
805  }
806
807  // define geometry
808  string geo_bodyx_name = "geo_" + name + "_bodyx_name";
809
810  string geo_body1_name = "geo_" + name + "_body1_name";
811  string geo_body2_name = "geo_" + name + "_body2_name";
812
813  G4VSolid* geo_bodyx = new G4Trd(geo_bodyx_name, body_dx1, body_dx2, body_dy1, body_dy2, body_dz);
814
815  G4VSolid* geo_body1 = new G4IntersectionSolid(geo_body1_name, geo_bodyx, elements[motherVolumeVacuum].geo,
816  collimator_body1.transform.inverse());
817  G4VSolid* geo_body2 = new G4IntersectionSolid(geo_body2_name, geo_bodyx, elements[motherVolumeVacuum].geo,
818  collimator_body2.transform.inverse());
819
820  collimator_body1.geo = geo_body1;
821  collimator_body2.geo = geo_body2;
822
823  // define logical volume
824  string strMat_body = m_config.getParameterStr(prep + "Material");
825  G4Material* mat_body = Materials::get(strMat_body);
826  string logi_body1_name = "logi_" + name + "_body1_name";
827  string logi_body2_name = "logi_" + name + "_body2_name";
828  G4LogicalVolume* logi_body1 = new G4LogicalVolume(geo_body1, mat_body, logi_body1_name);
829  G4LogicalVolume* logi_body2 = new G4LogicalVolume(geo_body2, mat_body, logi_body2_name);
830  setColor(*logi_body1, "#CC0000");
831  setColor(*logi_body2, "#CC0000");
832  setVisibility(*logi_body1, false);
833  setVisibility(*logi_body2, false);
834
835  // check if collimator is inside beam pipe
836  double volume_body1 = logi_body1->GetSolid()->GetCubicVolume();
837  double volume_body2 = logi_body2->GetSolid()->GetCubicVolume();
838
839  collimator_body1.logi = logi_body1;
840  collimator_body2.logi = logi_body2;
841
842  // put volume
843  string phys_body1_name = "phys_" + name + "_body1" + "_name";
844  string phys_body2_name = "phys_" + name + "_body2" + "_name";
845  if (volume_body1 != 0)
846  new G4PVPlacement(collimator_body1.transform, logi_body1, phys_body1_name, elements[motherVolumeVacuum].logi, false, 0);
847  if (volume_body2 != 0)
848  new G4PVPlacement(collimator_body2.transform, logi_body2, phys_body2_name, elements[motherVolumeVacuum].logi, false, 0);
849
850  // to use it later in "intersect" and "subtract"
851  collimator_body1.transform = collimator_body1.transform * elements[motherVolumeVacuum].transform;
852  collimator_body2.transform = collimator_body2.transform * elements[motherVolumeVacuum].transform;
853
854  string name_body1 = name + "_body1";
855  string name_body2 = name + "_body2";
856  elements[name_body1] = collimator_body1;
857  elements[name_body2] = collimator_body2;
858  }
859
860
861  //-----------------------
862  //- Collimator shields
863
864  std::vector<std::string> collimatorShields;
865  boost::split(collimatorShields, m_config.getParameterStr("CollimatorShield"), boost::is_any_of(" "));
866  for (const auto& name : collimatorShields) {
867  //- Collimator shield made as box with subtracted inner space
868
869  prep = name + ".";
870
871  double collShield_X0 = m_config.getParameter(prep + "X0") * unitFactor;
872  double collShield_Z0 = m_config.getParameter(prep + "Z0") * unitFactor;
873  double collShield_PHI = m_config.getParameter(prep + "PHI");
874  double collShield_W = m_config.getParameter(prep + "W") * unitFactor;
875  double collShield_H = m_config.getParameter(prep + "H") * unitFactor;
876  double collShield_L = m_config.getParameter(prep + "L") * unitFactor;
877  double collShield_d = m_config.getParameter(prep + "d") * unitFactor;
878
879  // storable element
880  FarBeamLineElement collShield;
881
882  // move collimator to its position on beam line
883  collShield.transform = G4Translate3D(collShield_X0, 0.0, collShield_Z0);
884  collShield.transform = collShield.transform * G4RotateY3D(collShield_PHI / Unit::rad);
885
886  G4Transform3D transform_collShieldInner = G4Translate3D(0.0, -collShield_d / 2.0, 0.0);
887
888  // define geometry
889  string geo_collShieldx_name = "geo_" + name + "x_name";
890  string geo_collShieldInner_name = "geo_" + name + "Inner" + "_name";
891  string geo_collShield_name = "geo_" + name + "_name";
892
893  G4Box* geo_collShieldx = new G4Box(geo_collShieldx_name, collShield_W / 2.0, collShield_H / 2.0, collShield_L / 2.0);
894  G4Box* geo_collShieldInner = new G4Box(geo_collShieldInner_name, collShield_W / 2.0 - collShield_d,
895  collShield_H / 2.0 - collShield_d / 2.0, collShield_L / 2.0);
896  G4SubtractionSolid* geo_collShield = new G4SubtractionSolid(geo_collShield_name, geo_collShieldx, geo_collShieldInner,
897  transform_collShieldInner);
898
899  collShield.geo = geo_collShield;
900
901  // define logical volume
902  string strMat_collShield = m_config.getParameterStr(prep + "Material");
903  G4Material* mat_collShield = Materials::get(strMat_collShield);
904  string logi_collShield_name = "logi_" + name + "_name";
905  G4LogicalVolume* logi_collShield = new G4LogicalVolume(geo_collShield, mat_collShield, logi_collShield_name);
906  setColor(*logi_collShield, "#CC0000");
907  setVisibility(*logi_collShield, false);
908
909  collShield.logi = logi_collShield;
910
911  // put volume
912  string phys_collShield_name = "phys_" + name + "_name";
913  new G4PVPlacement(collShield.transform, logi_collShield, phys_collShield_name, &topVolume, false, 0);
914
915  elements[name] = collShield;
916  }
917  }
Belle2::IRGeoBase::getParameter
double getParameter(const std::string &name) const
Get parameter value.
Definition: IRGeoBase.h:41
Belle2::IRGeoBase::getParameterStr
const std::string & getParameterStr(const std::string &name) const
Get string parameter.
Definition: IRGeoBase.h:64
Belle2::Unit::mm
static const double mm
[millimeters]
Definition: Unit.h:70
Belle2::Unit::rad
static const double rad
Standard of [angle].
Definition: Unit.h:50
Belle2::Unit::cm
static const double cm
Standard units with the value = 1.
Definition: Unit.h:47
Belle2::geometry::Materials::get
static G4Material * get(const std::string &name)
Find given material.
Definition: Materials.h:63
Belle2::intersect
int intersect(const TRGCDCLpar &lp1, const TRGCDCLpar &lp2, CLHEP::HepVector &v1, CLHEP::HepVector &v2)
intersection
Definition: Lpar.cc:249
Belle2::geometry::setVisibility
void setVisibility(G4LogicalVolume &volume, bool visible)
Helper function to quickly set the visibility of a given volume.
Definition: utilities.cc:105
Belle2::geometry::setColor
void setColor(G4LogicalVolume &volume, const std::string &color)
Set the color of a logical volume.
Definition: utilities.cc:97
The documentation for this class was generated from the following files:
