MultiHoughSpaceFastInterceptFinder Class Reference

Findlet for finding intersections of sinosoidal curves in the 2D Hough space by iteratively calling fastInterceptFinder2d. More...

#include <MultiHoughSpaceFastInterceptFinder.h>

Inheritance diagram for MultiHoughSpaceFastInterceptFinder:

Collaboration diagram for MultiHoughSpaceFastInterceptFinder:

Classes
struct	paircompare
	this sorting makes sure the clusters can be searched from bottom left of the HS to top right normally, a C++ array looks like a matrix: (0, 0 ) ... More...

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
	MultiHoughSpaceFastInterceptFinder ()
	Find intercepts in the 2D Hough space.
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) override
	Expose the parameters of the sub findlets.
void	initialize () override
	Create the store arrays.
void	apply (std::vector< VXDHoughState > &hits, std::vector< std::vector< VXDHoughState * >> &rawTrackCandidates) override
	Load in the prepared hits and create track candidates for further processing like hit filtering and fitting.
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	beginRun () override
	Receive and dispatch signal for the beginning of a new run.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = TrackFindingCDC::Findlet< VXDHoughState, std::vector< VXDHoughState * > >
	Parent class.
typedef std::map< VxdID, std::vector< VxdID > >	friendSensorMap
	Map that contains the "friend" sensors for each SVD L6 sensor.

Private Member Functions
void	initializeSectorFriendMap ()
	fill the map of friend sensors for each L6 sensor to
unsigned short	layerFilter (std::bitset< 8 > &layer)
	layer filter, checks if at least hits from 3 layers are in a set of hits More...
void	fastInterceptFinder2d (const std::vector< VXDHoughState * > &hits, uint xmin, uint xmax, uint ymin, uint ymax, uint currentRecursion)
	find intercepts in the 2D Hough Space by recursively calling itself until no hits are assinged to a given Hough Space cell, or until the maximum number of recursions (m_maxRecursionLevel) is reached More...
void	FindHoughSpaceCluster ()
	Find Hough Space clusters. More...
void	DepthFirstSearch (uint lastIndexX, uint lastIndexY)
	Perform depth first search recursive algorithm to find clusters in the Hough Space. More...

Private Attributes
HitSelector	m_HitSelector
	Use the friend map to just fill the hits in the acceptance region of the current L6 sensor into the m_currentSensorsHitList which is then used the Hough trafo track finding.
uint	m_param_maxRecursionLevel = 7
	maximum number of recursive calls of fastInterceptFinder2d
uint	m_param_nAngleSectors = 256
	number of sectors of the Hough Space on the horizontal axis
uint	m_param_nVerticalSectors = 256
	number of sectors of the Hough Space on the vertical axis
double	m_param_verticalHoughSpaceSize = 0.25
	vertical size of the Hough Space, defaults to the value for u-side
double	m_param_minimumX = -3.168
	minimum x value of the Hough Space, defaults to the value for u-side
double	m_param_maximumX = 3.168
	maximum x value of the Hough Space, defaults to the value for u-side
uint	m_param_MinimumHSClusterSize = 6
	minimum cluster size of sectors belonging to intercepts in the Hough Space
uint	m_param_MaximumHSClusterSize = 100
	maximum cluster size of sectors belonging to intercepts in the Hough Space
uint	m_param_MaximumHSClusterSizeX = 100
	maximum cluster size in x of sectors belonging to intercepts in the Hough Space
uint	m_param_MaximumHSClusterSizeY = 100
	maximum cluster size in y of sectors belonging to intercepts in the Hough Space
double	m_unitX = 0
	HS unit size in x.
double	m_unitY = 0
	HS unit size in y.
friendSensorMap	m_fullFriendMap
	friendMap for all the SVD L6 sensors
std::vector< VXDHoughState * >	m_currentSensorsHitList
	hits that are in the acceptance region (= on friend sensors) for the current L6 senosr
std::array< double, 16385 >	m_HSSinValuesLUT = {0}
	Look-Up-Tables for values as cache to speed up calculation sine values of the Hough Space sector boarder coordinates.
std::array< double, 16385 >	m_HSCosValuesLUT = {0}
	cosine values of the Hough Space sector boarder coordinates
std::array< double, 16384 >	m_HSCenterSinValuesLUT = {0}
	sine values of the Hough Space sector center coordinates
std::array< double, 16384 >	m_HSCenterCosValuesLUT = {0}
	cosine values of the Hough Space sector center coordinates
std::array< double, 16385 >	m_HSYLUT = {0}
	y values of the Hough Space sector boarders
std::array< double, 16384 >	m_HSYCenterLUT = {0}
	y values of the Hough Space sector centers
std::array< double, 16385 >	m_HSXLUT = {0}
	x values of the Hough Space sector boarders
std::array< double, 16384 >	m_HSXCenterLUT = {0}
	x values of the Hough Space sector centers
std::map< std::pair< uint, uint >, std::pair< int, std::vector< VXDHoughState * > >, paircompare >	m_activeSectors
	Map containing only active HS sectors, i.e. More...
uint	m_clusterCount = 0
	count the clusters
uint	m_clusterSize = 0
	size of the current cluster
std::pair< uint, uint >	m_clusterInitialPosition = std::make_pair(0, 0)
	start cell of the recursive cluster finding in the Hough Space
std::pair< int, int >	m_clusterCoG = std::make_pair(0, 0)
	center of gravity containing describing the current best track parameters in the Hough Space
std::vector< VXDHoughState * >	m_currentTrackCandidate
	the current track candidate
std::vector< std::vector< VXDHoughState * > >	m_trackCandidates
	vector containing track candidates, consisting of the found intersection values in the Hough Space
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

Findlet for finding intersections of sinosoidal curves in the 2D Hough space by iteratively calling fastInterceptFinder2d.

This is done 80 times for a subset of SVD sensors, one subset for each layer 6 sensor to reduce combinatorics in the Hough Space and to improve the purity of the found track candidates. The found track candidates are then clustered via a recursive search. Afterwards track candidates are formed and stored in the output vector.

Definition at line 35 of file MultiHoughSpaceFastInterceptFinder.h.

Member Function Documentation

DepthFirstSearch()

void DepthFirstSearch ( uint  lastIndexX, uint  lastIndexY  )

private

Perform depth first search recursive algorithm to find clusters in the Hough Space.

Parameters

lastIndexX	x-index of the last cell checked
lastIndexY	y-index of the last cell checked

Definition at line 330 of file MultiHoughSpaceFastInterceptFinder.cc.

{
  if (m_clusterSize >= m_param_MaximumHSClusterSize) return;

  for (uint currentIndexY = lastIndexY; currentIndexY >= lastIndexY - 1; currentIndexY--) {
    if (abs((int)m_clusterInitialPosition.second - (int)currentIndexY) >= m_param_MaximumHSClusterSizeY or
        m_clusterSize >= m_param_MaximumHSClusterSize or currentIndexY > m_param_nVerticalSectors) return;
    for (uint currentIndexX = lastIndexX; currentIndexX <= lastIndexX + 1; currentIndexX++) {
      if (abs((int)m_clusterInitialPosition.first - (int)currentIndexX) >= m_param_MaximumHSClusterSizeX or
          m_clusterSize >= m_param_MaximumHSClusterSize or currentIndexX > m_param_nAngleSectors) return;

      // The cell (currentIndexX, currentIndexY) is the current one has already been checked, so continue
      if (lastIndexX == currentIndexX && lastIndexY == currentIndexY) continue;

      // first check bounds to avoid out-of-bound array access
      // as they are uints, they are always >= 0, and in case of an overflow they would be too large
      if (currentIndexX < m_param_nAngleSectors and currentIndexY < m_param_nVerticalSectors) {

        auto activeSector = m_activeSectors.find({currentIndexX, currentIndexY});
        // Only continue searching if the current cluster is smaller than the maximum cluster size
        if (activeSector != m_activeSectors.end() and activeSector->second.first < 0 /*and m_clusterSize < m_param_MaximumHSClusterSize*/) {
          activeSector->second.first = m_clusterCount;
          m_clusterSize++;

          // No need to check whether currentIndex exists as a key in m_activeSectors as they were created at the same time
          // so it's certain the key exists.
          for (VXDHoughState* hit : activeSector->second.second) {
            if (not TrackFindingCDC::is_in(hit, m_currentTrackCandidate)) {
              m_currentTrackCandidate.emplace_back(hit);
            }
          }
          // search in the next Hough Space cells...
          DepthFirstSearch(currentIndexX, currentIndexY);
        }
      }
    }
  }
}

fastInterceptFinder2d()

void fastInterceptFinder2d ( const std::vector< VXDHoughState * > &  hits, uint  xmin, uint  xmax, uint  ymin, uint  ymax, uint  currentRecursion  )

private

find intercepts in the 2D Hough Space by recursively calling itself until no hits are assinged to a given Hough Space cell, or until the maximum number of recursions (m_maxRecursionLevel) is reached

Parameters

hits	vector containing the hits that are used for track finding
xmin	minimum x-index of the sub-Hough Space in the current recursion step
xmax	maximum x-index of the sub-Hough Space in the current recursion step
ymin	minimum y-index of the sub-Hough Space in the current recursion step
ymax	maximum y-index of the sub-Hough Space in the current recursion step
currentRecursion	current recursion step, has to be < m_maxRecursionLevel

Definition at line 211 of file MultiHoughSpaceFastInterceptFinder.cc.

FindHoughSpaceCluster()

void FindHoughSpaceCluster ( )

private

Find Hough Space clusters.

Loop over all found sectors in m_SectorArray and then calls the DepthFirstSearch function to recursively find the clusters

Definition at line 297 of file MultiHoughSpaceFastInterceptFinder.cc.

layerFilter()

unsigned short layerFilter ( std::bitset< 8 > &  layer )

inlineprivate

layer filter, checks if at least hits from 3 layers are in a set of hits

Parameters

layer

bitset containing information whether there as a hit in a layer

Definition at line 66 of file MultiHoughSpaceFastInterceptFinder.h.

      {
        uint layercount = layer.count();
        return (layercount >= 3 ? layercount : 0);
      }

Member Data Documentation

m_activeSectors

std::map<std::pair<uint, uint>, std::pair<int, std::vector<VXDHoughState*> >, paircompare> m_activeSectors

private

Map containing only active HS sectors, i.e.

those with hits from enough layers contained in them. The keys are the indices of the HS cell, and the custom sort function above is used to sort the content. The value is a pair consisting of the (negative) number of layers hit in a given cell, and a vector containing the hit information of all hits that are contained in this cell. During cluster finding the first value of the value-pair will be assigned the current cluster number.

Definition at line 173 of file MultiHoughSpaceFastInterceptFinder.h.

---

The documentation for this class was generated from the following files:

• tracking/vxdHoughTracking/findlets/include/MultiHoughSpaceFastInterceptFinder.h
• tracking/vxdHoughTracking/findlets/src/MultiHoughSpaceFastInterceptFinder.cc
