SpacePointLoaderAndPreparer Class Reference

Findlet for loading SVDClusters that were created by the DATCONSVDSimpleClusterizerModule and prepare them for usage in the FastInterceptFinder2D by calculating the conformal transformed x,y coordinates and the creating pairs of coordinates for finding track candidates in r-phi and r-z. More...

#include <SpacePointLoaderAndPreparer.h>

Inheritance diagram for SpacePointLoaderAndPreparer:

Collaboration diagram for SpacePointLoaderAndPreparer:

Public Types
using	IOTypes = std::tuple< AIOTypes... >
	Types that should be served to apply on invokation.
using	IOVectors = std::tuple< std::vector< AIOTypes >... >
	Vector types that should be served to apply on invokation.

Public Member Functions
	SpacePointLoaderAndPreparer ()
	Load clusters and prepare them for intercept finding.
void	exposeParameters (ModuleParamList *moduleParamList, const std::string &prefix) override
	Expose the parameters of the sub findlets.
void	initialize () override
	Create the store arrays.
void	beginRun () override
	Retrieve the BeamSpot from DB.
void	apply (std::vector< const SpacePoint * > &spacePoints, std::vector< VXDHoughState > &hits) override
	Load the SVD SpacePoints and create a VXDHoughState object for each hit.
virtual std::string	getDescription ()
	Brief description of the purpose of the concret findlet.
virtual void	apply (ToVector< AIOTypes > &... ioVectors)=0
	Main function executing the algorithm.
void	beginEvent () override
	Receive and dispatch signal for the start of a new event.
void	endRun () override
	Receive and dispatch signal for the end of the run.
void	terminate () override
	Receive and dispatch Signal for termination of the event processing.

Protected Types
using	ToVector = typename ToVectorImpl< T >::Type
	Short hand for ToRangeImpl.

Protected Member Functions
void	addProcessingSignalListener (ProcessingSignalListener *psl)
	Register a processing signal listener to be notified.
int	getNProcessingSignalListener ()
	Get the number of currently registered listeners.

Private Types
using	Super = TrackFindingCDC::Findlet< const SpacePoint *, VXDHoughState >
	Parent class.

Private Attributes
std::string	m_param_SVDSpacePointStoreArrayName = "SVDSpacePoints"
	StoreArray name of the input Track Store Array.
double	m_param_minimumUClusterTime = -25
	Minimum u cluster time.
double	m_param_minimumVClusterTime = -25
	Minimum v cluster time.
double	m_param_maximumUClusterTime = 40
	Maximum u cluster time.
double	m_param_maximumVClusterTime = 40
	Maximum v cluster time.
StoreArray< SpacePoint >	m_storeSpacePoints
	Input SpacePoints Store Array.
DBObjPtr< BeamSpot >	m_BeamSpotDB
	BeamSpot from DB.
BeamSpot	m_BeamSpot
	Actual BeamSpot.
B2Vector3D	m_BeamSpotPosition
	B2Vector3D actually contining the BeamSpot position. This will be passed on to the VXDHoughState for the conformal transformation.
std::vector< ProcessingSignalListener * >	m_subordinaryProcessingSignalListeners
	References to subordinary signal processing listener contained in this findlet.
bool	m_initialized = false
	Flag to keep track whether initialization happend before.
bool	m_terminated = false
	Flag to keep track whether termination happend before.
std::string	m_initializedAs
	Name of the type during initialisation.

Detailed Description

Findlet for loading SVDClusters that were created by the DATCONSVDSimpleClusterizerModule and prepare them for usage in the FastInterceptFinder2D by calculating the conformal transformed x,y coordinates and the creating pairs of coordinates for finding track candidates in r-phi and r-z.

Definition at line 35 of file SpacePointLoaderAndPreparer.h.

---

The documentation for this class was generated from the following file:

• tracking/vxdHoughTracking/findlets/include/SpacePointLoaderAndPreparer.h
