ConditionCheckerBase Class Reference

Inheritance diagram for ConditionCheckerBase:

Collaboration diagram for ConditionCheckerBase:

Public Member Functions
def	__init__ (self, name, objType, tfile, rundir="", use_hist=False)
def	objType (self)
def	run (self)
def	exp (self)
def	beginRun (self)
def	define_graphs (self, ytitle="")
def	define_hists (self, name=None, title=None, ztitle=None, **kwargs)
def	get_db_content (self)
def	get_graph_value (self, sensor_db_content)
def	get_graph_value_from_hist (self, h2=None)
def	set_hist_content (self, h2, sensor_db_content)
def	fill_plots (self)
def	draw_plots (self, canvas=None, cname="", ymin=0., ymax=None, logy=False)
def	save_canvas (self, canvas, cname, logy=False)

Public Attributes
	name
	DBObj name.
	dbObj
	DBObjPtr for the condition.
	eventMetaData
	pointer to the event metadata
	tfile
	TFile for saving plots.
	rundir
	Directory for writing histograms of each run.
	graphs
	Dictionary of plots (TGraph) summarizing variables vs run.
	hists
	Dictionary of plots (TH1) to be saved for each run.
	hist_title_suffix
	Hist title suffix.
	runstart
	The 1st run.
	runend
	The last run.
	expstart
	The 1st exp.
	use_hist
	Flag to get TGraph values from a histogram (TH2F)

Private Attributes
	_objType
	DBObj type.

Detailed Description

Abstract base class describing interfaces to make plots from condition db.

Definition at line 50 of file condition_checker.py.

Constructor & Destructor Documentation

__init__()

def __init__	(		self,
			name,
			objType,
			tfile,
			rundir = "",
			use_hist = False
	)

Definition at line 53 of file condition_checker.py.

    def __init__(self, name, objType, tfile, rundir="", use_hist=False):
        """
        """
        super().__init__()

        self.name = name

        self._objType = objType

        self.dbObj = Belle2.PyDBObj(self.name, self.objType.Class())

        self.eventMetaData = Belle2.PyStoreObj("EventMetaData")

        self.tfile = tfile

        self.rundir = rundir  # empty means skipping self.hists
        if self.rundir != "":
            self.tfile.cd()
            self.tfile.mkdir(self.rundir)

        self.graphs = {}

        self.hists = {}

        self.hist_title_suffix = ""

        self.runstart = 999999  # a big number that will never be used

        self.runend = -1

        self.expstart = 999999

        self.use_hist = use_hist

        self.define_graphs()


Member Function Documentation

beginRun()

def beginRun

(

self

)

Call functions at beginning of a run

Definition at line 110 of file condition_checker.py.

define_graphs()

def define_graphs	(		self,
			ytitle = ""
	)

Method to define TGraph
Parameters:
  ytitle (str): Label for TGraph y-axis

Definition at line 117 of file condition_checker.py.

define_hists()

def define_hists	(		self,
			name = None,
			title = None,
			ztitle = None,
		**	kwargs
	)

Method to define TH2
Parameters:
  name (str): name for TH2, to which sensor name will be attached
  title (str): title for TH2
  ztitle (str): title for z-axis (color bar)
  kwargs: additional arguments

Definition at line 126 of file condition_checker.py.

draw_plots()

def draw_plots	(		self,
			canvas = None,
			cname = "",
			ymin = 0.,
			ymax = None,
			logy = False
	)

Method to draw plots on a TCanvas
Parameters:
  canvas (TCanvas): ROOT TCanvas for plotting
  canme (str): Name of the canvas
  ymin (float): Minimum value of y-axis for plotting
  ymax (float): Maximum of y-axis for plotting
  logy (bool): Flag to use log scale for y-axis

Definition at line 213 of file condition_checker.py.

exp()

def exp

(

self

)

Experiment number

Definition at line 104 of file condition_checker.py.

fill_plots()

def fill_plots

(

self

)

Method to fill plot objects

Definition at line 171 of file condition_checker.py.

get_db_content()

def get_db_content

(

self

)

Abstract method to get content of a payload
Should return a Dictionary with sensorID.getID() as key and relaated calibration results as value

Reimplemented in PXDGainMapChecker, PXDDeadPixelsChecker, PXDMaskedPixelsChecker, and PXDOccupancyInfoChecker.

Definition at line 140 of file condition_checker.py.

get_graph_value()

def get_graph_value	(		self,
			sensor_db_content
	)

Abstract method to get a value for each TGraph
Parameters:
  sensor_db_content (Any): Calibration results of a module

Reimplemented in PXDGainMapChecker, PXDDeadPixelsChecker, PXDMaskedPixelsChecker, and PXDOccupancyInfoChecker.

Definition at line 147 of file condition_checker.py.

get_graph_value_from_hist()

def get_graph_value_from_hist	(		self,
			h2 = None
	)

Method to get a value for each TGraph
Parameters:
  h2 (TH2): If not none, get value from h2

Reimplemented in PXDDeadPixelsChecker.

Definition at line 154 of file condition_checker.py.

objType()

def objType

(

self

)

DBObj type (read only)

Definition at line 90 of file condition_checker.py.

run()

def run

(

self

)

Run number

Definition at line 97 of file condition_checker.py.

save_canvas()

def save_canvas	(		self,
			canvas,
			cname,
			logy = False
	)

Save TCanvas to png/pdf format and do not write it to the ROOT file by default
Parameters:
  canvas (TCanvas): ROOT TCanvas for plotting
  canme (str): Name of the canvas
  logy (bool): Flag to use log scale for y-axis

Definition at line 247 of file condition_checker.py.

set_hist_content()

def set_hist_content	(		self,
			h2,
			sensor_db_content
	)

Method to set TH2 bins
Parameters:
  h2 (TH2): TH2F object for handling values of a pixel matrix
  sensor_db_content (Any): Calibration results of a module

Reimplemented in PXDGainMapChecker, PXDDeadPixelsChecker, and PXDMaskedPixelsChecker.

Definition at line 162 of file condition_checker.py.

---

The documentation for this class was generated from the following file:

• pxd/scripts/pxd/calibration/condition_checker.py
